AMF TILT Bowl Mixer (TBM) User manual

• Mostrobustframeandbowldesignintheindustry
• Easyaccessdesignand6"(152mm)oorclearancefacilitatecleaningandmaintenance
• Newbowldesignformaximumglycolcoolingefciencyandoptimaldoughtemperature
control
• Heavydutystainlesssteeltriplerolleragitatorandshafts
• Longlastingsanitarystyleshaftsealsaredesignedforeasyremovalwhenreplacementis
needed
• Singleendbeltdrivesystemforminimalmaintenance
FEATURES AND BENEFITS
• HeavyDutyHorizontalTiltBowlDoughMixer
• DesignedforMixingBreads,Rolls,Buns,FlourTortillas,
Croissants,Bagels,Pizza,SpecialtyDoughsandEnglishMufns
TILT BOWL MIXER (TBM)

TILT BOWL MIXER
MECHANICAL SPECIFICATIONS
FrameAssembly
• Theexteriorofthemixerisentirelycoveredwithpolishedstainlesssteeland
mountedonarigidsteelframetreatedwithastainlesssteelepoxypaint
• Rigidstainlesssteelbumperguards
• Liftlugs
• Anti-vibrationpads
BowlandCoolingJacket
• Thebowlistiltedto120degreestowardsthefront
• Stainlesssteelbowlandjackettotallyredesignedforhighefciency(Glycol
cooling)
• Bowlinsulatedwithurethanefoamcoveredwithaweldedstainlesssteelsheet
• BowlrestsonNylatronbushings
• Bowltestedat150PSI
• Glycolmanualhandvalvesareincluded
• Refrigerationhosesareincluded
AgitatorandDriveAssembly
• SolidstainlesssteelYtypespiderssplitatmainshaftandagitatorbars
• Stainlesssteelprimaryandsecondaryagitatorbarsmountedonlubricationfree
UHMWbushings
• Mainshaftsealsareeasilyremovableandfabricatedofpolyethylenefor
exceptionaldurability.Thisnewtypeofsealallowseasycleaning.
• Solidstainlesssteelbreakerbar(adjustablefourpositions)
• Heavydutystainlesssteelmainshaft
• Singleendbeltdrivewithintegralgearheadmotormountedonadjustablebase
eliminatesbinder
• Mainmotorcanbereplacedfromthebackorthedriveside(dependingonoption)
• StandardagitatorRPM:35/70(otherRPM'sareavailableasoptions)
• Manualcentrallubricationsystem
TopAssembly
• 12"(305mm)O.D.butteryorslidingourgate
• Twostainlesssteelliquidinlets
• Canopyscraper
• Flourvent
TiltingAssemblies
• Hydraulictiltonallmodelsinclude:
- Hydraulicunitwithmanualback-uppump
- Hydrauliccylinder
AgitatorDriveSide
MechanicalOvertiltOptions
SanitaryMainShaftSeal
MixerTopCanopyWithMultiple
FlourInletsandSpongeDoor
HydraulicTiltMechanismSide

ELECTRICAL SPECIFICATIONS
OperatorpanelisNEMA4ratedandcontainsthefollowing:
• AllenBradleyPanelView550operatorinterfacewhichdisplays:
- Mixingandrefrigerationtime
- Doughtemperature
- Statusandalarmmessages
- Editableproductcodesandrecipes
- Totaloperationtimeclock
• AllenBradleypush-buttonsforthefollowingfunctions:
- Mixing(slow,fast,stop)
- Tilting(lower,raise,stop)
- Alarm(acknowledge/reset)
- Safety
- Emergencystop
NEMA12remoteenclosure(paintedsteel)including:
- Mainbreaker
- FullvoltagemagneticNEMAratedconsequentpolestarter
- AllenBradleySLC5/03processor
• WashdowndutyWegdrivemotor(aluminumorcopperrotor)integralmountwithNORDgearreducer
• Motoroverheatprotectioninstalledinthestatorwinding
• High/lowspeedjogoperationwithspecialanti-jogfunction
• Mixerandrefrigerationmodeselectionfromoperatorinterface
• Timerandsetpointbasedtemperaturecontrolmodesincluded
• Safety:Latchingsafetydevicesoningredientandaccessdoorsinterlockedwithagitatormotionmonitor.
• Standardvoltage460and600volts/3Phase/60Hz(othervoltagesavailable)
• Controlpower:24VDCinputs,120VACoutputs
MECHANICAL OPTIONS
• Bowldrainvalve
• Lipextension
• Bowlendcooling
• PolarBarrefrigeratedbreakerbar(includesbowlendcoolingoption)
• ArcticAgitatorcoolingpackage(providesbowlend,breakerbarand
standardagitatorcooling)
• Doubleextraheavydutystainlesssteelprimaryagitatorbars(included
inmodels2000lb.andabove)
• Y-Tasymmetricalfullsplitstainlesssteelagitator
• Extraliquidinlet
• Additionalourinlet(availableonlywithbutteryvalve)
• Rearspongedoor,airoperatedhingetype
• Rearingredientdoorwithsafetybarsandagitatormotioninterlock
• Solid,fulllengthlegswithhighperformancestainlesssteelpigmented
grayepoxypaintupto24”(610mm)
• Mechanicalovertiltto140degreeson1600lb.to3200lb.modelsinclude:
-Integralgearheadbrakemotorwithchainandsprockets
-Caliperanddiskbowllockmechanism
-Airdrivenhydraulicpumpforcalipers
• Mechanicalreversetilt25degreeswithsealcleaningsystem
• Automaticcentrallubricationsystem
• Troughholddownmechanism,manualorairoperated OptionalY-TAgitator
ArcticCooling
Package

09/2008
TILT BOWL MIXER
Europe Ofce:
West Park Ring Road
Leeds LS16 6QQ
England
Tel: [phone]
Fax: [phone]
[e-mail]
1-800-BAKERS-1
www.amfbakery.com
FOR MORE INFORMATION PLEASE CALL YOUR ACCOUNT MANAGER OR
AMF’s focus on continuous improvement may result
in changes to machinery specications without notice.
Asia Ofce:
Room 801 A-Building
Thunis Dev. Building
No. 11 Hui Xin East St.
Chaoyang District
Beijing, China 100029
Tel: [phone]
Fax: [phone]
[e-mail]
Headquarters:
2115 W. Laburnum Ave.
Richmond, Virginia 23227
Tel: [phone]
or 1-804-355-7961
Fax: [phone]
[e-mail]
ELECTRICAL OPTIONS
ModelName TBM
800
TBM
1000
TBM
1300
TBM
1600
TBM
2000
TBM
2400
TBM
2800
TBM
3200
Mixing
Capacity12
lb.
kg
800
363
1000
454
1300
590
1600
726
2000
907
2400
1089
2800
1270
3200
1452
Working
Capacity
ft3
liters
22.9
649
28.9
817
37.6
1064
46.6
1319
58.2
1649
63.7
1804
71.3
2019
76.3
2161
BowlVolume ft3
liters
30
850
37.5
1062
45.3
1283
61.8
1750
77.2
2186
81.8
2316
91.4
2588
98.2
2781
BaseMotor HP 20/40 25/50 30/60 37.5/75 50/100 62.5/125 75/150 87.5/175
MainPower
Requirement KVA 45 55 65 80 105 130 155 180
Approximate
FloorLoad
lb./ft2
kg/m2
1790
8739
1900
9275
2090
10203
1200
5859
1350
6591
1400
6835
1450
7080
1525
7446
Approximate
ShippingWeight
lb.
kg
17500
7938
18500
8391
20000
9072
21000
9525
24000
10886
24500
11113
25000
11340
26000
11793
1: Estimated for dough densities of 60 lb./ft3
2: Minimum mixing capacity should not be lower than 50% of Mixing capacity
• SinglespeedmaindrivemotorwithACinverterspeedcontrol
• Ampmeterorwattmetertodisplaymotorload
• Doughqualitymonitortotrendagitatormotorenergyandreferenceto
pre-recordedcurves
• Remotepedestalmountstainlesssteeloperatorconsole
• Stainlesssteelmainelectricalenclosure
• Fullautomode(automaticdischargesequenceprogrammingwithstatus
messagesandinterfacing)
• Processorandoperatorinterfaceupgrades OptionalRemotePedestalOperatorConsole
withDoughQualityMonitoringSystem
AMF is Your Industry Leading
Source for Complete Integrated
Dough Systems from Design to
Professional Project Management
and Implementation
SPECIFICATIONS
