AMG AMG350-4G-1C-1S Series User manual

AMG350-4G-1C-1S
Industrial 6 Port Unmanaged Switch 4 × 10/100/1000Base-T(x) RJ45
Ports, 1 × 10/100/1000Base-T(x) RJ45 or 100/1000Base-Fx SFP
Combo Port, 1 × 100/1000Base-Fx SFP Port, DIN Rail / Wall Mount,
-40°C to +75°C, 12-56VDC Power Input
AMG350-4GAT-1C-1S-P120
Industrial 6 Port Unmanaged PoE Switch 4 × 10/100/1000Base-T(x)
RJ45 Ports with 802.3at 30W PoE, 1 × 10/100/1000Base-T(x) RJ45 or
100/1000Base-Fx SFP Combo Port, 1 × 100/1000Base-Fx SFP Port,
DIN Rail / Wall Mount, -40°C to +75°C, 48-56VDC Power Input
AMG350
AMG350-4G-1C-1S Series
Industrial Unmanaged Switch
Installation Manual - Hardware
www.amgsystems.com
AMG Systems Ltd. 3 The Omega Centre, Stratton Business Park, Biggleswade, SG18 8QB, UK
T :: [phone] E :: [e-mail]
www.amgsystems.com
D33426-00
Proud to be a British
Manufacturer
AMG350-4G-1C-1S SERIES MODELS DIN RAIL MOUNT INSTALLATION
SURFACE MOUNT INSTALLATION
AMG350-4GAT-1C-1S-P120
① Remove
the DIN
rail clip by
unscrewing
the two xing
screws as
shown.
③ Fix the unit to the surface
using two appropriate screws
(not provided)
AMG350-4G-1C-1S
② Attach the
wall brackets
using the
M3×4 xing
screws
(included) as
shown.

LED INDICATORS
LED Colour Description
POWER 1 Blue DC input present on power 1
POWER 2 Blue DC input present on power 2
ALARM O Both power inputs active
Yellow Power failure on power 1 or 2
LINK/ACT
O No Ethernet / SFP link connection
Green Ethernet / SFP link present
(ashes with data trac activity)
POE*
*PoE Model Only
O No PoE being supplied
Yellow PoE is being delivered on the port
POWER
INTERFACE CONNECTIONS
Note
On the PoE model only ports 1-4
support PoE output.
Maximum PoE budget 120W total.
Warning
Do not exceed the rated voltage
Refer to product label
+-
Power 2
Model Type Voltage
Non-PoE Models 12-56 VDC
PoE Models 48-56 VDC
Model Type Power
6 Port Models 6W Max*
*Excludes PoE Load
DIP SWITCH SETTINGS
*Non-PoE Model Only
*PoE Model Only
Fault relay is normally closed and
will open on either power failure.
If used with a single PSU, the PSU
should be wired to both power inputs.
Fault Relay
24V @ 1A Max
+-
Power 1
①Remove the dust caps from
the RJ45 and SFP ports of the
channel that is to be connected.
②Insert the SFP module
into the SFP slot.
③Insert the Cat5/6 cable
into the RJ45 port.
④Insert the bre patch
cable into the SFP module.
Switch Position Description
DIP Switch 1 P5 TX Port 5 operates as an RJ45 port
P5 SFP Port 5 operates as an SFP port
DIP Switch 2
SFP 100M SFP ports 5 & 6 forced to 100Mb
speed*
SFP 1G SFP ports 5 & 6 forced to 1Gb
speed*
*Both SFP ports must operate at the same speed. It is not possible to mix 100Mb & 1Gb SFP
modules. Please ensure that the SFP port speed is set to the correct speed of your installed SFP’s.
Note
When a DIP switch setting is changed
the unit must be power cycled for the
changes to be applied.
