AMG AMG570-4G-2S Series User manual

www.amgsystems.com
AMG570
amgsystems.com
AMG Systems Ltd. 3 The Omega Centre, Stratton Business Park, Biggleswade, Bedfordshire, SG18 8QB, UK
T :: [phone] E :: [email protected]
D36187-00
AMG570-4G-2S SeriesAMG570-4G-2S Series
L2+ Industrial Managed SwitchL2+ Industrial Managed Switch
Installation Manual - HardwareInstallation Manual - Hardware
DEVICE RESET PROCEDURE
①Insert a patch cable
loop between ports
1 & 2 on the switch
②Power cycle the
switch
③After switch boot
cycle is complete
remove the patch
cable loop
Proud to be a British
Manufacturer
POE CAPABILITIES
Example part code:
AMG570-2GBT-2GAT-2S-P240
Characters PoE Standard Supported
None Non-PoE Model
AT IEEE 802.3at 30W Port
BT IEEE 802.3bt 60/90W Port
Characters PoE Budget
P120 120W Max
P240 240W Max
Check the product label to determine the PoE power supported
on each port and the units total maximum PoE budget.
IEEE 802.3at Models
Type 1 & 2 PoE support
Mode A PSE only
IEEE 802.3bt Models
Type 1, 2, 3 & 4 PoE
support. Mode A
and/or Mode B PSE
Ensure the PSU size
used is at least equal
to the maximum PoE
budget gure.
CONNECTING TO THE SWITCH
To access the full software user guide for this product
please visit the product page using the QR code
above or the direct link opposite.
Web GUI
Default IP Address: 192.168.1.101
Username: admin
Password: admin
Console CLI
USB-A to USB-C Cable 115200,8,N,1
amg-support.com/AMG570-4G-2S_Series
CONTACT INPUTS & OUTPUTS
COM
AMG570 Interface Circuit
Optical Isolation
OCOMCOM ALMI
Contact Input
Dry Contact
(No Voltage)
Alarm & Contact
Outputs
Relay Output
(400V @ 0.1A Max)

DIN RAIL MOUNT INSTALLATION
POWER
SURFACE MOUNT INSTALLATION
③Fix the unit to the surface
using two appropriate screws
(screws not provided)
LED INDICATORS
① Remove the DIN rail
clip by unscrewing the
two xing screws as
shown.
② Attach the included wall
mount brackets with the
provided 4 x M3 screws as
shown.
AMG570-4G-2S INCLUDED ACCESSORIES
Model Type Voltage
Non-PoE Models 12-56 VDC
30W PoE Models 50-56 VDC
90W PoE Models 52-56 VDC
EARTH PROTECTION
To provide correct protection from ESD
and Surge events ensure that the unit
is correctly earthed using the provided
earth connection point in accordance
with local electrical codes & standards.
(cable not provided)
AMG570 Switch
USB Console Cable
2 x Wall Mounting Brackets
DIN Rail Bracket
LED Colour Description
POWER 1 / 2 Blue DC input present on power 1
and/or power 2
ALARM Red Unit in alarm condition
SFP LINK/ACT Green SFP link present (ashes
with data trac activity)
POE 1-4 Yellow PoE is being delivered on
the port
RJ45 LINK/
ACT Green Ethernet link present (ashes with data trac activity)
+
-
Power
2
Alarm Out
+
-
Power
1
Contact In
Contact Out
Common
Warning
Check Polarity Before Powering
No Reverse Polarity Protection
Model Type Power
All Models 6W Max*
*Excludes PoE Load
