Amino AMULET 6 User manual

AMULET 6
MEDIA RECORDER
Quick Start Guide

QUICK START GUIDEAMULET MEDIA RECORDER
1
Table of Contents
OVERVIEW
2
4
What’s Included
5
Front Panel
Rear Panel

QUICK START GUIDE
QUICK START GUIDE
AMULET MEDIA RECORDER
AMULET MEDIA RECORDER
32
What’s Included
2 Batteries for
Remote Control
Amulet Media Recorder
HDMI Cable
AC Power Adapter
IR Remote Control*

QUICK START GUIDE
QUICK START GUIDE
AMULET MEDIA RECORDER
AMULET MEDIA RECORDER
54
Amulet — Front Panel
Name Description
1Power LED Solid blue indicates the unit is on
Solid red indicates the unit is in standby mode
Flashing blue indicates the unit is starting up
2
3
Network LED Solid green indicates network is connected
4
Clock Displays current time set by your service provider. May
not display time while device is booting up.
5
Record Indicator Blue dot indicates a TV program is currently recording
HD Indicator Blue dot indicates current program is playing in HD
(720p or higher) resolution
Amulet — Rear Panel
Name Description
1
2
A/V OUT 9-Pin DIN conector for connecting to video output us-
ing DIN-to-RCA cable
3
Digital Audio S/PDIF digital optical audio TOSLINK output
4
Reset Reset the device factory settings with a thin metal
probe
5
HDMI Digital video and audio port for connecting to a high-
TV (HDTV)
6
IR Extender Jack To connect IR Extender Receiver
7
USB To connect USB 3.0 devices such as USB Flash Drive
and External Hard Drive (max 900mA load)
8
Ethernet Plug for wired network connection
Power DC power jack (100-240V, O tutpu 212V/ A)
1 2 3 4 5
246
11 3 5 7 8
