AMP Mitre-Mite VN4 MemoryProgram User manual

2
Index
1. GENERAL INFORMATION 4
1.1 PRODUCER 4
1.2 ASSISTANCE CENTERS 4
1.3 CERTIFICATION 4
1.4 WARRANTY 4
1.5 PRE-ARRANGEMENTS CHARGED TO
THE CUSTOMER 4
1.6 HANDBOOK STRUCTURE 4
1.6.1 Object and contents 4
1.6.2 Utilizers 4
1.6.3 Preservation 4
1.6.4 Symbols utilized 5
2. MACHINE DESCRIPTION 6
2.1 WORKING PRINCIPLE 6
2.2 MAIN COMPONENTS 6
2.3 MACHINE STRUCTURE 6
2.4 DIMENSIONS 6
2.5 SURROUNDING CONDITIONS 6
2.6 LIGHTING 6
2.7 VIBRATIONS 6
2.8 NOISE EMISSIONS 6
2.9 TECHNICAL DATA 7
2.10 STANDARD EQUIPMENT 7
2.10.1 Standard accessories 7
2.10.2 Upgrading and implementing of mechanical
parts 7
2.10.3.Customized optional accessories 7
2.11 ELECTROMAGNETIC AMBIENT 7
3. SAFETY 8
3.1 GENERAL WARNINGS 8
3.2 SCHEDULED USE 8
3.3 INADVISABLE USE 8
3.4 DANGEROUS AREAS 8
3.5 PROTECTION DEVICES 8
3.6 STOP FUNCTIONS 8
3.7 SAFE WORKING PROCEDURES 8
3.8 RESIDUAL RISKS 9
3.9 PLATES 9
4. INSTALLATION 9
4.1 SHIPPING AND HANDLING 9
4.2 STORAGE 9
4.3 PRELIMINARY ARRANGEMENTS 10
4.4 UNPACKING 10
4.5 MACHINE POSITIONING 10
4.6 CONNECTIONS 10
4.6.1 Pneumatic connection 10
4.6.2 Electric connection 10
4.6.3 Collegamento elettrico della tastiera di
controllo 11
4.7 PRELIMINARY CONTROLS 12
4.8 MACHINE ARRANGEMENT 12
4.8.1 V-Nails magazine loadiing 12
4.8.2. V-nail guide head replacement to change V-nails
size 12
4.9 ADJUSTMENTS 13
4.9.1 Adjustments for v-nails positioning 13
4.9.2 VERTICAL CLAMP ADJUSTMENT 13
4.9.2.A Vertical clamp position adjustment 13
4.9.2.B Vertical clamp height adjustment 13
4.9.3 Frontal clamp adjustment 14
4.9.4 FENCE ADJUSTMENT 14
4.9.5 Working pressure adjustment 14
4.9.6. Protective shield adjustment 15
4.10 CHECKING OPERATIONS TO BE EF-
FECTED BEFORE WORKING START 15
5 FUNCTIONING 16
5.1 OPERATORS 16
5.2 CONTROL PANEL 16
5.3 KEYBOARD CODE/COLORS OF ELEC-
TRONIC CONTROL DEVICE 17
5.4 Mode of operation 18
5.4.1 Manual functions menu 18
5.4.2 Jog menu 18
5.4.3 Input test menu 18
5.4.4 Output test menu 18
5.4.5 Machine zero point (homing) 19
5.4.6 Editing menu 19
5.4.7 Rename 19
5.4.8 Copy 19
5.4.9 Delete 19
5.4.10 Search 19
5.4.11 Creation of new programs 19
5.4.12 Execution menu 21
5.4.13 Working speed modification 22
5.4.14 Enabling access code protected services 22
5.5 FRAMES PRODUCTION AND V-NAILS
CONSUMPTION 23
5.6 TIPS FOR PERFECT JUNCTIONS 23
5.7 MACHINE STOP 24
5.8 PUTTING OUT OF SERVICE 24
6. PROGRAMMING 25
6.1 CREATION OF A PROGRAM 25
6.1.A. Auto-learning mode 25
6.1.B Inputting mode 25
7. EXECUTION OF THE PROGRAM 26
7.1 EXECUTION OF JUST DIGITED
PROGRAM 26
7.2 EXECUTION OF A PROGRAM PREVI-
OUSLY MEMORIZED 26
7.3 MACHINE ADJUSTMENT 26
8. MAINTENANCE 27
8.1 STATE OF MAINTENANCE 27
8.2 MACHINE ISOLATION 27
8.3 SPECIAL CAUTIONS 27
8.4 CLEANING 27
8.5 LUBRICATION 27
8.6 ORDINARY MAINTENANCE 27
8.7 EXTRAORDINARY MAINTENANCE 28

3
9. DIAGNOSTIC 29
9.1 SAFETY WARNINGS 29
9.2 BREAKDOWN SEARCH 29
9.3 REQUEST OF ASSISTANCE 30
10. SPARE PARTS 31
10.1 SPARE PARTS LIST 31
10.2 SPARE PARTS ORDERING 31
11. DEMOLITION 31
11.1 DEMOLITION 31
12. ATTACHMENTS 31
12.1 DECLARATIONS 31
12.2 SCHEMES 31

4
1. GENERAL INFORMATION
1.1 PRODUCER
The rm Alfamacchine-AMP can boast more than 10
years of expe rience in t he con struction of Wood working
Machines. It is the acquired technological know-how,
developed during years of research in strict touch with
manufacturing departments and international
commercialization.We o er the best warranty that anyone
can grant to its customers.
TEL [phone] FAX [phone]
1.2 ASSISTANCE CENTERS
AMP is represented throughout North America.
Contact us directly to nd your nearest distributor.
For every need regarding Use, Maintenance or
Request of Spare Parts, the Customer is requested to
call the authorized service centers or directly to
AMP, specifying the machine’s identi cation data
impressed on the plate.
1.3 CERTIFICATION
The machine is produced in conformity to the pertinent
European Community Norms in force at the moment of its
introduction on the market.
1.5 PRE-ARRANGEMENTS CHARGED TO
THE CUSTOMER
It is the customer’sduty,ontimesagreedwith
the producer, to execute what is indicated in
our documentation (see the attachment 10.3-B).
Things normally charged to the customer:
tPremises predisposition, included building
works
tMachine power supply, observing the current
norms of Country where the machine is
installed (see at the paragraph 4.6.2)
tPneumatic supply of compressed air (see at
the paragraph 4.6.1)
1.4 WARRANTY
AMP’s products are built to have a long
life and are tested one b y one .
If, in spite of this,if any damages would occur
or malfunctioning, the replacement of defective
parts is warranted (counting from the date
written on the delivery bill) for a period of:
*24 months for mechanical components
*12 months for pneumatic part
The driver blade is tested for about 1.000.000
working cycles.
The Warranty does not include the sending of
technical sta .
The repair will be performed at AMP and the
freight of shipment will be entirely charged to
the Customer.
The warranty does not cover the damages caused
by an inappropriate use of the machine or not
corresponding to the instructions described in
this handbook.
The warranty decays in case of unauthorized
modi cations or because of accidental damages
or tampering performed by unquali ed personnel.
The warranty also decays if you use V-nails
di erent from the original AMP’sones.
To take advantage of warranty services it is
necessary, at the moment you receive your machine
to com ple tely ll out th e warranty card and
send back as soon as possible to AMP.
The warranty will be valid after it is received
& recorded at AMP.
1.6 HANDBOOK STRUCTURE
The customer must pay extreme attention to the
indications reported in this handbook, because
the proper Pre-Arrangement, Installation and
Use of the Machine, constitute the basis of a
correct customer-distributor relationship.
1.6.1 Object and contents
The handbook goal is to provide to the customer
all necessary information so that, besides the
proper use of the machine, He would be able to
run it in complete autonomy and safety. The
handbook contains information concerning the
technical aspects, machine working and
standstill, maintenance, spare parts and safety.
Before making any operation on the machine, the
quali ed technicians and operators must
carefully read this handbook. In case of doubt
about correct interpretation of the
instructions, ask yur local distributor or
AMP to e xp lain it to you.
1.6.2 Utilizers
This handbook is made both for operators and technicians
authorized to the machine maintenance.
The operators cannot execute operations reserved to the
maintainers or to the quali ed technicians.
The producer doesnot answer ofdamagesderived from not-
ob servance of th is p rohib ition
1.6.3 Preservation
The instruction handbook must be kept very closed to the
machin e, int o a sp ecial contain er p rote cted from liq uid s and
whatever could compromise its legibility

5
1.6.4 Symbols utilized
P...
A...
O...
I...
C...
R...
WARNING
OBSERVATION
INQUIRY
EXAMINATION
ADJUSTMENT
It indicates a danger with a mortal risk for
the operator
It indicates a warning or a note about key
functions or useful information. Pay the maximum
attention to the paragraph marked with this
symbol.
It is requested to take a measurement data, to
check a signal,....
The user is requested to check the proper
positioning of any element of the machine,
before operating a certain command
It’s necessary to consult the handbook before
effecting a certain operation
In case of strange working and/or anomalies,
can be requested a certain mechanical adjustment
and/or electrical setting
DANGER

6
2. MACHINE DESCRIPTION
2.1 WORKING PRINCIPLE
The frame assembling machine Mitre-Mite VN 4
Memory Program has been realized for the mass
production of medium or large sized frames.
The machine is controlled by an electronic
system able to execute very quickly the different
working cycles.
You can store in the machine’s memory 1.400
different programs corresponding to several
types and sizes of frames.
The machine can work only semi-automatically
controlled by a program input by the operator.
The frame assembling machine Mitre-Mite VN 4
Memory Program can use special V-nails with
“pulling power”to pull the joints tightly
together.
2.2 MAIN COMPONENTS
The main components constituting the machine
are:
•Frontal clamping device to have a perfect
joint.
•Floor stand with Filter/regulator/lubricator
•Double Hydralic hold down
•Double & triple mechanical hold downs
•Pneumatic opening of V-nails magazine for a
very quick reloading
•Nail heads sizes 7, 10 and 15 mm.
2.3 MACHINE STRUCTURE
The movement directions during the machine
working are the followings:
- X AXIS
Movement of horizontal clamp
- Y AXIS
Movement of vertical clamp
2.4 DIMENSIONS
The overall dimensions are reported on complete drawing
of table 2.9-A
2.5 SURROUNDING CONDITIONS
The machine does not need special surrounding conditions.
It has to be installed inside an industrial building, lit, aired
and with a compact and flat floor. The admitted temperatures
go from 40°to 104°F, with an humidity not higher than
50% at 104°F or 90% at 68°F.
2.6 LIGHTING
Premises lighting must be conformed to the
norms in force in that Country where the machine
is installed and has to guarantee a clear
visibility and can not create dangerous
reflections.
2.7 VIBRATIONS
In standard conditions conformed to the
indication of machine proper utilization the
vibrations do not create dangerous conditions.
The average quadratic weighed level, according
to the acceleration frequency to which arms
are exposed does not exceed 2,5 m/s2.
The indicated noise levels are
emission ones measured in standard
conditions of use. In case of any
machine modification, the above
mentioned levels could be changed
and should be tested on the same
machine.
2.8 NOISE EMISSIONS
The machine is designed and projected for
reducing the noise emission level to its source.
In standard working conditions the Machine noise
power level is:
•Acoustic Continuous Equivalent weighed pression A
<70dB
•Acoustic Istantaneous weighed pression
<130dB
The noise levels indicated are emission levels
and are not representative of operating levels.
In spite of an existing relationship between
emission levels and exposure ones, this can not
be used in a reliable way to define if further
precautions are necessary. The factors
determining the exposure level to which the
working force is subjected, include exposure
length, working premises characteristics and
other noise sources (number of machines, closed
bldg., etc...). Furthermore, also the allowed
exposure levels could change according to
several Countries. At any rate, the information
provided, will allow the Machine Operator to
achieve a better evaluation of the danger and
risks he is submitted to.

7
2.10 STANDARD EQUIPMENT
The equipment listed below are the standard
ones:
2.10.1 Standard accessories
Once you have removed the packing, please check
the presence of following accessories:
- N.1 nail head mm. 7
- N.1 nail head mm.10
- N.1 nail head mm.15
- N.1 L shaped pressure pad
- N.1 Allen Wrench 5 mm. for V-nails head replacement
- N. 4 adjustable feet.
- N.1 pressure gauge
- N.1 fast clutch fitting
- N.1 Brass rod magnet to remove V-nails
- N.1 double hydraulic hold down
- N.1 double & triple mechanical hold down
2.10.3.Customized optional accessories
Thanks to its versatility this machine can be
‘custom-made’to meet our users’requirements,
by using additional accessories that can make
frame assembling easier: e.g. special fences
for peculiar moulding shapes, special clamps
to ensure the mouldings are locked properly
during V-nail firing, and so on. You can have
your local machine shop make these for you.
2.10.2 Upgrading and implementing mechanical
parts
The machine has been designed and developed
based on modular standards, therefore the
existing equipment can be further upgraded with
additional accessories that will not alter its
basic structure.
Technical upgrades on the machine model, if
any, will be such that they can be installed at
any time without requiring any substantial
modifications to the machine structure.
2.9 TECHNICAL DATA
We have listed below the Machine data and
technical characteristics to which you can make
reference for any eventual contact with Producer
for Technical Assistance.
- Frames thickness min-max .197”- 3.15”
- Frames width min-max .39”- 3.94”
- Max distance between V- nails 4.72”
- V-nail magazine capacity n. 220
- V-nails size 7, 10, 15 mm.
- V-nails size on request 3, 5, 12 mm.
- Pneumatic supplying Psi 80-110
- Power supplying 120 V
- Weight about 254 LB
- Height of working bench 37.8”
- Overall dimensions 30.3”x30.3”x5.9”
- Max programming capacity n. 1400
- Max V-nails inserting position n. 10
- Max V-nails stacking per position n. 9
- Serial linking support type RS 232
- Air consumption per cycle 4 NI/5 Bar
2.11 ELECTROMAGNETIC AMBIENT
The Machine is designed to operate properly in
an industrial electromagnetic ambient, being
included in the following Norms about Emission
and Immunity:
EN 50081-2 Electromagnetic compatibility-
Generic Norm on Emissions-2nd part-Industrial
Environment-(1993)
EN 50082-2 Electromagnetic compatibility-
Generic Norm on Immunity-2nd part-Industrial
Environment-(1995)

8
3.SAFETY
3.1 GENERAL WARNINGS
The operator must read paying the maximum
attention to the information written in this
Handbook, expressively about proper precautions
for Safety listed in this chapter.
It is indispensable for the operator to follow
the warnings list here below:
•Keep the machine & it’s working area clean
& ordered
•Provide appropriate containers to stock
moulding to be used.
•Use the Machine only in perfect psycho
physical condition
•Wear an adequate clothing to avoid obstacles
and/or dangerous entangles to/from the
machine
•Wear the individual protection gears
prescribed by this instructions handbook
•Do not remove or alter the warning plates
and adhesive signs
•Do not remove or elude the Machine Safety
Systems
•Keep the fingers away from the working area
•Disconnect the air pressure and power supply
during any maintenance intervention
•Keep the feet separated from the pedal during
Machine repair
3.3 INADVISABLE USE
The machine can not be used for:
•For uses different from those listed in 3.2
paragraph
•In an explosive or aggressive atmosphere,
where there is a high density of dust or
oily substances suspended in the air
•In flammable atmosphere
•Outside in all weather severity
•With disconnected electromagnetic
interblocks
•With electric bridges and/or mechanical
instruments leaving out machine parts or
functions
•For working materials not suitable with
machine characteristics
3.2 SCHEDULED USE
The Machine is designed and built to execute
junctions of frames.
The machine is projected for semi-automatic
operation (under operator control).
3.4 DANGEROUS AREAS
The area of frames assembly is defined as the
“working area”
The dangerous areas of machine, include the
movable parts and surrounding zones
3.5 PROTECTION DEVICES
The machine is equipped with adequate protections
for persons exposed to the risks due to the
transmission mobile elements, or movable organs
taking part in working (driver blade, horizontal
clamp, vertical clamp).
3.7 SAFE WORKING PROCEDURES
The other risks related with working are:
•Finger crushing in the vertical clamp working
area
•Finger crushing in the frontal clamp working
area
It is necessary to carefully adhere to the
following instructions:
1 Keep the fingers away from frontal and vertical
clamp working areas
2 Disconnect the air pressure and the power
supply during any maintenance interventions
3 Keep the foot away from the pedal during
machine maintenance.
3.6 STOP FUNCTIONS
The machine stop functions are the following:
- Stop Category 0.
- Stop Category 1.
STOP CATEGORY 0
It is obtained by disconnecting the fast clutch
fitting from the feed system (uncontrolled
stop).It is obtained by flipping the main switch
located on the floor stand.
STOP CATEGORY 1
Controlled stop obtained by lifting the foot
from the pedal which will not allow the v-nails
firing.
The machine is projected and
realized to eliminate any risk
connected with its use.
The user is requested to achieve
an adequate training to be
instructed by their distributor.
Dangerous area
Figure 3.4.A- Working area and dangerous zones

9
3.8 RESIDUAL RISKS
During the normal working cycle and while
performing maintenance, the operators are
exposed to several residual risks that, because
of operations own nature, can not be totally
eliminated.
•Risk of finger crushing due to the presence
of vertical and frontal clamping
•Risk due the presence of electricity in the
machine
3.9 PLATES
The warning plates carrying out safety functions
can not be removed, covered or damaged.
To view the plates or adhesive signs location,
consult the Fig.10.2-D
Table 3.9 A- Types of plates
Plate concerning machine characteristics
Adhesive sign concerning the finger danger
zone
Adhesive sign concerning the finger danger
zone
Adhesive sign concerning the behaviour to be
kept in the working area
4. INSTALLATION
4.1 SHIPPING AND HANDLING
The shipment must be performed by qualified
technical staff. The machine has to be shipped
in a safe way to avoid any damage to its parts.
•All the protections & guard devices must be
properly closed and clamped.
•The machine has to be shipped like positioned
for installation.
•Before shipment, it is necessary to lubricate
the parts which are not painted to avoid
rusting them.
•According to the type of shipment, it is
necessary to protect the machine from any
jarring impact or stress
Figure 4.1A - machine handling indications
Machine’s total weight: about 380 Kilos
Any damage of the machine caused during its
shipment or handling is not covered under
warranty.
Repairs or replacements of damaged parts are
charged to the customer.
4.2 STORAGE
In case of long inactivity, the machine must be
stored with cautions concerning storage place
and times.
•Store the machine indoors
•Protect the machine from jarring impacts
and stresses
•Protect the machine from humidity and high
temperatures
•Avoid corrosive materials that could touch
the machine
•Lubricate parts which are not painted

10
4.6 CONNECTIONS
To avoid any problems while starting up the
machin e, it is suggested to follow what is
described below.
4.6.1 Pneumatic connection
Unscrew the lubricator bowl out from the air
lter lu bricato r.”C”
Fill the bowl with lubricating oil up to the
level mark.
Scre w t h e “A”pressure gauge on the air lter
Scre w t h e “B”fast clutch tting normally
supplied or another suitable with the erising
system. (See picture 3)
Connect the feed line to the tting. (See
picture 4)
In the lubricator it is
advisable to use lubricant type
CASTROL MAGNA GC 3 2 o r a n
eq uivale nt lub ricant. Don’tuse
generic lubricants !
The use of non-suitable lubricants
might damage the valves.
4.6.2 Electric connection
Check the network Voltage: it must be the same
of what indicated on machine cable (120 V).
Connect the power supplying cable to the plug
positioned on the machines rear side.
Avoid the use of long extension cables.
Pu t th e switch ( E) on “1”which is located on the oorstand
to switch on the machine.
Check that the green light next to the switch
is lit (if not, check the electric connections).
Rotate clockwise the emergency mushroom headed
button located on the keyboard.
Press the green button of the keyboard to
activate the keyboard controls.
4.3 PRELIMINARY ARRANGEMENTS
To install the machine it is necessary to prepare
a working area adequate to the machines
dimensions, lifting devices chosen and length
of mouldings to be worked.
4.4 UNPACKING
The machine is shipped on a wooden pallet,
packed into an appropriate carton and protected
with foam and polyurethane parts.
Remove the external packing and save it for
future use.
Check for any casual shipping damage and report
it immediately. Shipping damages or any other
defects must be reported to AMP within and
not later than 3 days from receipt of the
machine.
4.5 MACHINE POSITIONING
Position the machine in its working area.
Screw in the provided levelors to the oor
stand and level the machine by releasing or
tightening the levelors.
A
B
C
Picture 3
D
Picture 4
In order to eliminate the
condensation in the lter press
upwards on the “D”valve (see
picture 4).
D
E

11
4.6.3Electric connection of the control keyboard
Proceed as follows, in order to perform the connection of the control keyboard:
- Connect the “A”terminal of picture 4.6.3 together with the “a”terminal of picture 4.6.4
- Connect the “B”terminal of picture 4.6.3 together with the “b”terminal of picture 4.6.4
- Connect the “C”terminal of picture 4.6.3 together with the “c”terminal of picture 4.6.4
Picture 4.6.3
Picture 4.6.4
c
b
a
A
B
C

12
4.8.2. V-nail guide head replacement to
change V-nails size
The V-nail guide head must be changed each time
you use V-nails of different sizes.
Proceed as follows to change it:
•Move the claw pusher backwards by flipping
the special lever located on the right side
of the machine working bench, this will
permit access to the nail magazine (see
fig. 6).
•Remove all the V-nails that are still in the
magazine (using the proper brass magnet, if
necessary) (see fig.10).
•Insert the new V-nail stick(of desired
height) into the magazine
•Move forward the claw pusher by flipping
the control lever (see figure 6).
•Insert the new size V-nail guide head to
match the V-nails to be used (see fig. 11).
•Tighten the locking screw of the V-nail
guide head (see fig.8).
4.8. MACHINE ARRANGEMENT
4.8.1 V-Nails magazine loadiing
To load the V-nail magazine proceed as follows:
•Move the claw pusher backwards by flipping
the special lever located on the right side
of the machine working bench. This will
make the V-nail magazine accessible (see
fig. 6).
•Insert one or more V-nails strips, taking
care that the sharpened edge of the V-nails
(glue side) faces up and that they are
loaded with the V of the V-nails pointing in
the direction indicated in the figure 7.
You also need to check that the v-nail size
is the same as the type of claw head mounted.
•Move the claw pusher forward by flipping
the control lever (see figure 6).
TAKE CARE: When the magazine runs short of
V-nails, or when it contains an amount of V-nails
that is not sufficient to complete a working cycle,
the machine will stop at the next foot-pedal
pressure and warn the operator with three beeps
and a message on the display- informing the
operator that magazine is running short of V-
nails.
Figure 8
Figure 7
Figure 6
4.7 PRELIMINARY CONTROLS
The Machines preliminary operations before you
1st start the machine, must be executed by a
technician appointed by the customer. Before
machine commissioning, it is necessary to execute
certain verifications and checks to prevent
mistakes or accidents during the setup.
The verifications to execute are the followings:
•Verify that machine has not been damaged
during assembly steps.
•Verify with extreme care, the integrity of
electric boards, control panels, electric
cables, wires and pipes
•Check the proper connection of external
power sources

13
Figure 9
Figure 10
Figure 11
4 . 9 ADJUSTMENTS
Seeing as the machine was tested before shipping,
the operator has only to execute the following
adjustments:
4.9.1 Adjustments for v-nails positioning
The Mitre-Mite VN 4 Memory Program is equipped
with a V-nail driver mounted on a movable
carriage. This is controlled by an electric
motor able to fix with extreme precision each
V-nail inserting position.
The maximum carriage stroke is 5.7”. Within this stroke you
can define several inserting positions. These different points
are settled on the program that the operator must input for
each working cycle.
For further information regarding the programs
creation and V-nails inserting positions see
chapter 6.
4.9.2 VERTICAL CLAMP ADJUSTMENT
To guarantee perfect clamping of the mouldings
throughout the several working cycles the machine
is equipped with a double hydraulic clamp.
It allows the adjustment of both position and
height.
4.9.2.A Vertical clamp position adjustment
•Position on the working bench the moulding
to be assembled
•Loosen the (B) handles (see fig 12)
•Shift the cylinders, by sliding them along
the cross-bar.
•Position the cylinders directly over the
moulding to be assembled.
•Tighten the “B”handles (see fig. 12)
•Loosen the “A”handles (see fig. 12)
•From the execution menùpress key F5
•Tighten the “A”handles (see fig. 12)
Picture 12
A
B
A
B
4.9.2.B Vertical clamp height adjustment
Procced as follows, in order to adjust the
vertical clamp height:
•unscrew by using a 6mm allen wrench the “C”
screw of picture 4.9.2.B
•lift or lower the vertical clamp
•tighten the “C”screw of picture 4.9.2.B
Picture 4.9.2.B

14
4.9.3 Frontal clamp adjustment
The Front Clamp bar has a series of holes in
it. By lifting the bar you can move it from its
initial position and reposition it forward or
backward.
To lock the bar it is sufficient to insert it
into the proper peg in the center of the guide
channel.
To properly position the Horizontal Clamp,
operate as follows:
1. lift the bar from its peg about 10 - 15 mm
and move it forward until reaching the
moulding to be assembled;
2. lower the bar & allow it to drop over the
peg to lock it in the new position.
4.9.4 Fence adjustment
The machine is equipped with a special fence
composed of 2 different parts.
Each fence side is equipped with a knob that
allows it to tilt the moulding supports.
This fence use is recommended to assemble highly
profiled mouldings.
Furthermore, if the moulding rolls forward or
backwards as the front clamps engages, you can
adjust the tilting fence to compensate the
effect.
In addition to 90 degrees junctions , the Mitre-
Mite VN 4 Memory Program can be used also for
6-sided (120 degrees) or 8-sided frames (135
degrees), by properly positioning the back fence
supports.
Proceed as follows to modify the position of
back fence supports:
•use a 5 mm Allen wrench and remove the
outside screw on the fence parts
•loosen the inside screw slightly and position
the fence in the corresponding tapped holes
located on the working area.
The proper positioning of the back supports can
be obtained by using a special template, which
is included with the machine.
Care must be taken to ensure that the 120°or
135°angle is perfectly centered on the internal
vertex of the V-nail head.Use the center line
of the template to do this.
4.9.5Working pressure adjustment
The working pressure must be adjusted to the
hardness of the mouldings to be assembled.
The pressure regulation permits you to change
the clamping pressure of mouldings to be
assembled.
Too high of a working pressure can cause a poor
junction and (especially on small-size frames)
the mouldings can be crushed.
Too low of a working pressure can cause an
incomplete insertion of the V-nails into the
frame.
The working pressure is adjusted by means of
the regulator on the panel near the pressure
gauge (see fig. 13).
Proceed as follows to adjust the working
pressure:
1. Pull up the regulator cap about 3÷4 mm to
unlock it
2. Turn it clockwise to increase the pressure
and counter-clockwise to decrease it.
3. Push the regulator cap back down, to lock it
into position
The suggested pressures are:
Soft woods (samba,........) 30- 40 PSI
Medium (ramin,........) 40 - 60 PSI
Very hard woods (oak) 60 - 80 PSI
The above listed values apply to 7 and 10 mm high V-nails.
Increase the pressure by 10 % for 15 mm high V-
nails.
When stacking 2 or more V-nails, increase the
working pressure by 10/15 %.
Figure 13
In case of continued use without
removing the bar from its position,
it is possible to fix it to the peg
using the proper screws. In case of
shipment, we suggest to clamp the
bar by using the supplied screw knob.
DO NOT ADJUST the pressure
if the machine is not
connected to the air supply
line.

15
4.9.6. Protective shield adjustment
The machine can be ordered with a protective
shield made of transparent plastic material.
Proceed as follows to adjust the protection
shield:
1. loosen the screw knobs fixing the protection
and lift or lower it at an height of about
6-8 mm from the mouldings to be assembled;
2. tighten knobs to lock the protection shield.
Even if the protective shield is properly
adjusted, it is necessary to respect the
following instructions:
•keep the fingers away from the frontal and
vertical clamp working area
•disconnect the pressure supply during any
maintenance intervention
•keep the foot separated from the pedal during
the machines adjustments
4.10 OPERATIONSTOBECHECKED
BEFORE STARTING YOUR WORK
Once the machine has been properly installed
(like previously described), check that:
•The mouldings to be assembled are properly
positioned on the working bench
•The magazine is loaded with the type of
nails suitable with the mouldings to be
assembled
•The adjustment of vertical and horizontal
clamping is correct (chapter 4.9.2 and 4.9.3)
•The machine is connected to the electric
network,air and the switches are activated
•The working pressure is adequate to the
wood hardness (see chapter 4.9.5)
•The protective shield is properly positioned
(see chapter 4.9.6)
•Press the pedal full down to activate the
machines cycle
Opening the shield causes the control
pedal deactivation.

16
5 FUNCTIONING
5.1 OPERATORS
The machine has been projected to be used by only one operator.
The staff assigned to operate with the machine, must be in possession (or acquire through an
adequate training) the requirements indicated here below, and, in addition, to have the knowledge
of this handbook and of every information concerning safety:
•General and technical culture sufficient to comprehend this handbook contents and understand
properly the drawings and schemes
•Knowledge of sanitary conditions, technological and anti-accidental norms
•Overall knowledge of line and plant where the machine is inserted
•Specific experience frames assembly & working technologies
•To know how operate in case of emergency, where to find the individual protection means and how
to use them properly.
The Maintenance person, in addition to the above mentioned characteristics, must be in possession
of an adequate technical education.
5.2 CONTROL PANEL
F1 - F6 FUNCTION KEYS
MENU GO BACK TO THE PREVIOUS MENU
RESET RE-INITIALIZE THE BOARD
1 - 9 TO INPUT NUMERIC DATA
A - Z TO INPUT ALPHABETICAL DATA
TC V-NAILS COUNTER
T ADJUSTMENT SET
YELLOW KEYS NAVIGATION KEYS
S1 S4 SPEED SHIFTING TYPE 1 IN EXECUTION
(shift) S1 S4 SPEED SHIFTING TYPE 2 IN EXECUTION
S5 FUTURE APPLICATIONS
SPACE INSERTION OF EDITING SPACES
SHIFT ACTIVATION ALPHABETICAL KEYS
DEL EDITING CHARACTER DELETION
ENTER DATA CONFIRMATION OR CHOICE
M- M+ DELETE/INSERT POSITIONS
EXE PROGRAM EXECUTION
STOP STOP THE MOVEMENTS

17
On the keyboard there are 2 diodes:
tOne of them is green, labeled POWER ON: when it is turned on it indicates that the machine is
electrically supplied
tThe other diode, the red one labeled CPU ERROR: when it is turned on it indicates an error of
CPU control board. In case it should turn on, try to press on RESET and, if the situation does
not improve, contact AMP or your local distributor for assistance.
5.3 KEYBOARD CODE/COLORS OF ELECTRONIC CONTROL DEVICE
BLUEkeys f unctions/alphabetical keys
GREENkeys alpha/numerical keys
RED keys RESET (re-initialization) keys ; STOP (motor stop)
ORANGEkeys EDITING ke ys (fu t u re a p p lica t io n s )

18
5.4 MODE OF OPERATION
The Mitre-Mite VN 4 Memory Program allows the
operator to create customized working cycles
according to size and profile of mouldings to
be assembled.
The machine has only one operating mode:
•Semi-automatic operating mode using programs
created by the operator
Switching the machine on: the following is
displayed on the screen:
5.4.1 Manual functions menu
Pressing F1 from the main menu allows you access
to the Manual Functions sub-menu.
The following functions are available:
F1 Jog motor it allows you to shift the
V-nail driver to the
(positive and/or negative
side)
F2 Test Ingressi It allows you to check the
proper functioning of
the control board inputs
F3 Output Test It allows you to check the
proper functioning of
the control board outputs
F4 Machine zero It takes the V-nail driver
back to the homing point
(position 0)in the middle
of the fences vertex
5.4.2 Jog menu
Entering into the Jog menu (manual movement of
V-nail driver) the following picture is
displayed:
5.4.3Input test menu
Opening the Input Test Menu (checking of inputs
proper functioning) the following is displayed
on the screen:
Input status is displayed here: only pedal
status (enabled / disabled) can be displayed by
the operator when the pedal is pressed and
released, the other values are only set by
authorised technicians.
5.4.4 Output test menu
Opening the Output Test Menu (outputs are tested)
the following is displayed on the screen:
To return to this display always press
the MENU key from any sub-menu.
Use the yellow arrows to position the cursor on
the desired option, then press ENTER to activate
it and check if it is working properly.
The outputs test works only if the machine has
performed the homing cycle at least once before
entering into the test.
The icons corresponding to the function keys
(F1..F6) have the following meanings:
F1 Manual Functions ( chapter 5.4.1)
F2 Programming/Executing Functions
F4 Transfering programs (see page 42)
F5 Access Enabled
F6 Parameter Functions
Press the yellow arrows to move the carriage:
<== (toward zero) ==> (toward operator)
The position of the V-nail driver is
simultaneously adjusted and displayed on the
screen.
This option can be useful to verify visually
the V-nails insertion points and record their
relevant positions.
Select F1 to confirm or F2 to delete.
Input Test
Pedal :off
V-Nails inserting :on
Pressoswitch :on
Home or min. switch :off
Sensore di massima :off
Emergency :on
Change speed :off
Output Test
Horizontal Block :off
Vertical Block :off
Hammer :off
Buzzer :on
Free :off
Free :off
Free :off
Figure 5.4

19
5.4.6 Editing menu
Pressing F2 then F4 from the main menu allows you to access
to the Editing submenu.
The following functions are available:
F1 Rename It permits the replacement
of the name of a program
previously filed
F2 Copy It allows you to duplicate
a program previously filed
F3 Delete It allows you to delete a
program previously filed
F4 Search It permits a quick search
of a code number or name
of a program previously
memorized
When you are in this menu, you can also create
new programs.
To prevent accidental variations or deletions
of the existing programs, the editing service
is protected by an access key (password).
To enter into the Editing sub-menu you must type the access
code which can be input:
- Before entering into the Editing menu by pressing F5
- After entering into the Editing menu by pressing F5 or F6
On the display you will see the request for the access code :
5678
To return to the previous selection
always press the MENU key from the
sub-menu.
5.4.5 Machine zero point (homing)
The V-nail driver can be positioned on zero (0)
by pressing F4 on the manual functions menu.
To disable this option press SHIFT again: the diode goes
off.
To delete a wrong entry shift back the <== arrow then press
DEL as many times as the number of characters you wish to
delete. To add a space press on SPACE.
5.4.10Search
Pressing the F4 key, appears 3 searching sub-groups
represented by F1 , F2 , & F3 keys.
F1 Allows you to search the name of the program.
F2 Allows you to search the code (step) of the program.
F3 Permits the access tothe first free programming step.
5.4.11 Creation of new programs
To create a new frame program, perform the following steps:
From the main menu press F2, then press F4.
Press F5 or F6 & type in the editing password 5678.
Position the cursor on a free program code line.
Type in the new program name & press ENTER
At this point the following screen is displayed:
5.4.7 Rename
Position the cursor on the line corresponding to the program
you wish to rename using the yellow arrows, then press F1:
type in the new name and confirm it by pressing on ENTER.
If you wish to use the letters
corresponding to the keys, press SHIFT:
the diode inserted in the button is
lit.
To return to the previous selection
always press MENU, from the sub-
menu.
5.4.8 Copy
Position the cursor on the line corresponding
to the program you wish to copy by using the
yellow arrows.
Press F2: use the yellow arrows to move the cursor on a new
field, press F1 and digit the new program name (use DEL to
delete exceeding characters)
5.4.9 Delete
Position the cursor on the line corresponding to the program
you wish to delete by using the yellow arrows , then press
F3. You will see a box that says:
Cancella da: 1 = delete from code # 1
fino a: 1 = delete to code # 1
The first code number Cancella da:..? will be the one that
you positioned the cursor on.You must type in the fino a: or
delete to code number. This will be the code number you
want to set as the final one to delete. Then confirm it by
pressing ENTER.
If you wish to use the letters instead of numbers,
press SHIFT & the letters to be inserted.
The icon indicates that the editing
access is enabled
The icon indicates that the editing
access is not enabled.

20
Once the above mentioned data are all entered,
the program needs to know the values
corresponding to the inserting positions and
the number of V-nails that have to be driven
for each position (max.9).
Two possibilities are available:
1. self-learning mode (F5) see chapt. 5.4.11.a
2. insertion mode. see chapt.5.4.11.b
5.4.11.a F5 Self-learning
Pressing F5 , the following picture is displayed
on the screen:
use the yellow arrows <== ==>to move the V-nail
driver to the desired point, and check the
value on the bottom of the screen;
press ENTER when you reach the desired position;
on the table below in the frame picture the
chosen value is shown and the user is prompted
to digit the number of V-nails he wants to
insert in that point:
press F5 again to program possible new positions,
then repeat the above mentioned procedure, or
press the MENU key to exit and save.
NOTE: When the V-nail driver is positioning, F1
can be used instead of ENTER to confirm, otherwise
press F2 to cancel.
5.4.11.b Insertion
Use the yellow arrows to move to the position 1 of the
inserting point management:
Type the value in mm of the distance from the
external vertex of the mouldings to be assembled
- then press ENTER;
the cursor shifts on the V-nail number programming side:
type the amount of V-nails you wish to insert in the just
defined position (max. nine V-nails per position) then
press ENTER;
The cursor will position automatically on the next value:
repeat the above mentioned steps to add further insertion
points.
To switch back to the program list press the
MENU key. Press MENU again to return to the
main menu.
If one of the critical data to run the cycle is
missing a message appears on the screen asking
the user to either enter the missing data or
terminate the program definition, in which case
the program will be considered as incomplete.
The F1 ÷F6 keys are enabled to perform the
following functions:
F1 Specifies the height of V-nails to be used
in the program
F2 Specifies the sharpening of V-nails to be
used in the program
F3 Specifies the hardness of material to be
used in the program
F4 Specifies the width of the moulding, (not including
the rabbit) in mm .
F5 Position self-learning
F6 Definition of running speed to be used in
the program
•Press F1, the cursor blinks on the V-nail height field:
Type the height of the v-nails in mm;
•Press F2, the cursor blinks on the V-nail sharpening field:
type the sharpening to be used (SW, MW etc.);
•Press F3: the screen is updated and the following table
is displayed:
Use the yellow arrows to move along the table and, once the
type of material is selected, press ENTER.
•Press F4, the cursor blinks on the frame profile width:
type in the size in mm then press ENTER.
* Press F6, the following table is displayed on the screen:
Use the arrows to move along the table and , once the running
speed is selected, press ENTER or F1 to confirm it or F2 to
delete it & use the default value.
Codice Materiali
> 1 > Very Soft
2 Soft
3 Medium
4 Hard
5 Very Hard
6 Plastic
Codice Speed
> 1 > Speed slow 001
2 Speed slow 002
3 Speed normal 001
4 Speed normal 002
5 Speed fast 001
6 Speed fast 002
7 Speed extra fast 001
8 Speed extra fast 002
The working speed value will go to the default if
you decide not to change it. See default parameters
in chapt. 5.4.15.a
