Clarke CWL435 Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS DL0621 Rev1
17” WOOD LATHE
MODEL NO: CWL435
PART NO: 6500671

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE 17” Wood Lathe.
Before attempting to operate the machine, it is essential that you read this
manual thoroughly and carefully follow all instructions given. In doing so you
will ensure the safety of yourself and that of others around you, and you can
also look forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
Weight 31 kg
Dimensions (L x W x H) 855 x 280 x 380 mm
Speed 760 - 3200 rpm (5 Speed)
Distance between centres 435 mm
Turning Capacity 254 mm
Tool Rest 150mm
Headstock Arbour Thread Size 1” 8 RH Thread
IP (Ingress protection) rating IP 40
Motor voltage/frequency 230V / 50Hz
Rated input wattage 370W
Sound Pressure Level (Lp) No load 61.3 / loaded 78.7 dB(A)
Sound Power Level Measured (Lw) No load 74.3 / loaded 91.7 dB(A)

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY WARNINGS
WORK ENVIRONMENT
1. Keep the work area clean, tidy and well lit. Cluttered and dark areas invite
accidents.
2. DO NOT operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while operating a power tool. Anyone
entering the work area must wear personal protective equipment.
Distractions can cause you to lose control and fragments of work may fly
away and cause injury.
4. Store power tools properly when not in use. Abrasive products should be
stored in a dry, secure place out of the reach of children.
5. Please read these instructions carefully and retain for future reference.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. NEVER modify the plug in any way.
DO NOT use adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce the risk of electric
shock.
2. This machine is designed for indoor environments and must not be used for
other purposes. DO NOT expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
3. DO NOT abuse the power cable. NEVER use the cable for carrying, pulling
or unplugging the power tool. Keep the cable away from heat, oil, sharp
edges or moving parts. Damaged or entangled cables increase the risk of
electric shock.
4. Position the power cable so that it cannot be inadvertently pulled or
pinched, and where it does not cause a trip hazard.
5. Before cleaning or maintenance operations, always unplug the machine
from the power supply.
CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN
PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use common sense when
operating a power tool. DO NOT use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in personal injury.
2. Use personal protective equipment. ALWAYS wear eye protection. Safety
equipment such as dust mask, non-skid safety shoes, hearing protection
and a workshop apron capable of stopping small abrasive or workpiece
fragments.
3. AV O I D accidental starting. Ensure the switch is in the off position before
plugging in. Plugging in power tools that have the switch on invites
accidents.
4. Remove any adjusting key or drift rod before turning the power tool on. A
wrench or drift rod left attached to a rotating part of the power tool may
result in personal injury.
5. DO NOT overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
6. Keep your hair and clothing away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
7. Regularly clean the power tool’s air vents. The motor fan will draw dust
inside the housing and accumulation of material could cause electrical
hazards.
8. AV O I D operator fatigue. Stop the power tool at regular intervals for a short
break to rest hands and arms.
9. Maintain your tools. Keep all handles and grips dry and clean.
10. If the machine requires repair, always contact your CLARKE dealer. Always
insist on original spare parts. Repairs carried out by unauthorized persons
may be dangerous and invalidate the guarantee.
11. This machine must only be used by adults. Children should not be allowed
to play with this appliance.
POWER TOOL USE AND CARE
1. DO NOT force the machine.Use the correct power tool for your
application. It will do a better and safer job at the rate for which it was
designed.
2. DO NOT use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. Disconnect the power tool from the power supply before making any
adjustments, changing accessories, or storing the tool. These measures will
reduce the risk of the power tool starting accidently.
4. Store power tools out of the reach of children and DO NOT allow persons
unfamiliar with the tool or these instructions to operate the power tool.
Power tools are potentially dangerous in the hands of untrained users.
5. Maintain power tools in top condition. Keep tools/ machines clean for the
best and safest performance. Check for misalignment or binding of
moving parts, broken parts, or any condition that may affect the power
tool’s operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
6. Use recommended accessories. The use of improper accessories could be
hazardous.
7. Machine cleanliness. DO NOT allow the ventilation slots in the machine to
become blocked with dust.
8. Check the power tool for damage before using the machine. Any
damaged part should be inspected to ensure that it will operate properly
and perform its intended function. Check for alignment of moving parts,
breakage of parts, mountings, and any other condition that may affect the
machine’s operation. Any damage should be properly repaired or the part
replaced. If in doubt, DO NOT use the machine. Consult your local CLARKE
dealer.
SERVICING
1. When necessary, have your power tools serviced or repaired by a qualified
person using identical replacement parts. This will ensure that the safety of
the power tool is maintained.
ADDITIONAL PRECAUTIONS FOR WOOD LATHES
1. ALWAYS familiarise yourself with wood lathes and turning techniques before
using the machine. If there is any doubt whatsoever you should consult a
qualified person.
2. ALWAYS store chisels safety when you have finished with the machine.
3. CAUTION: This machine is designed for use with woodturning chisels only.
4. NEVER attempt to turn a workpiece unless a suitable support is used.
WARNING: DUST GENERATED FROM CERTAIN MATERIALS CAN BE
HAZARDOUS TO YOUR HEALTH. ALWAYS OPERATE THE LATHE IN A WELL
VENTILATED AREA. USE A DUST COLLECTION SYSTEM WHENEVER
POSSIBLE.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. ALWAYS stop the lathe before removing workpieces, work supports or swarf
from the table.
6. ALWAYS be sure that the workpiece is securely locked in position
7. ALWAYS keep hands and fingers away from the moving workpiece.
SAFETY SYMBOLS
The following safety symbols may be found on the machine.
ENVIRONMENTAL PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All
unwanted accessories and packaging should be sorted and taken to a
recycling centre for disposal in a manner which is compatible with the
environment.
ENVIRONMENTAL RECYCLING POLICY
Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.
In effect, this means that this product must not be disposed of with general
household waste but according to the laws governing Waste Electrical and
Electronic Equipment (WEEE) at a recognised disposal facility.
Fully read this
manual and safety
instructions before
use
Eye protection
should be worn
Ear protection
should be worn
Dust mask should be
worn
Indoor Use Only

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ELECTRICAL CONNECTIONS
Before switching the product on, make sure that the voltage of your electricity
supply is the same as that indicated on the rating plate. This product is
designed to operate on 230VAC 50Hz. Connecting it to any other power
source may cause damage.
This product may be fitted with a non-rewireable plug. If it is necessary to
change the fuse in the plug, the fuse cover must be refitted. If the fuse cover
becomes lost or damaged, the plug must not be used until a suitable
replacement is obtained.
If the plug has to be changed because it is not suitable for your socket, or due
to damage, it should be cut off and a replacement fitted, following the wiring
instructions shown below. The old plug must be disposed of safely, as insertion
into a mains socket could cause an electrical hazard.
If the colours of the wires in the power cable of this product do not correspond
with the markings on the terminals of your plug, proceed as follows.
•TheBlue wire must be connected to the terminal which is marked Nor
coloured Black.
•TheBrown wire must be connected to the terminal which is marked Lor
coloured Red.
•TheYellow and Green wire must be connected to the terminal which is
marked E or or coloured Green.
We strongly recommend that this machine is connected to the mains supply
via a Residual Current Device (RCD)
If in any doubt, consult a qualified electrician. DO NOT attempt any repairs
yourself.
WARNING! Read these electrical safety instructions thoroughly
before connecting the product to the mains supply.
Plug must be BS1363/A approved.
Always fit a 13 Amp fuse.
Ensure that the outer sheath of the cable is firmly held by the clamp
Neutral
(Blue)
Live
(Brown)
Earth
(Green and Yellow)

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
OVERVIEW
Ensure the wood lathe and its components suffered no damage during transit
and that all components are present. Should any loss or damage be
apparent, please contact your CLARKE dealer immediately.
The following components are supplied with the lathe assembly.
Item Description Item Description
1 Hand Wheel 10 Tailstock
2 Headstock 11 Tail Axis Locking Handle
3 Faceplate 12 Tail Axis Adjusting Wheel
4 Headstock Centre Spur 13 Drift Rod
5 150mm Tool Rest 14 Stop/Start Switch
6 Tool Rest Locking Handle 15 Bed
7 Tool Rest Base Locking Handle 16 Motor
8 Tool Rest Base 17 3 x Hex Keys (3mm,6mm,8mm)
Not Shown
9 Tailstock Centre Cup

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLY
1. Fit the tailstock centre cup into
the tail axis.
NOTE: To detach the tailstock
centre cup, place the drift
rod into the adjusting wheel
as far as it goes and give it a
tap.
2. Fit the tool rest into the tool rest
base. Adjust to the required
height and position using the rest
locking handle and base locking
handle.
3. Install the headstock faceplate by
screwing it onto the headstock
spindle, using the drift rod as a
counter lever. Lock the faceplate
into place using the 2 x 3mm hex
grub screws.
NOTE: The faceplate has 4 screw
holes evenly spaced. these
are for securing workpieces
that do not require the
tailstock for support.

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
4. Install the headstock centre spur
by sliding it into the headstock
spindle as shown
NOTE: To detach the headstock
centre spur, place the drift
rod into the hand wheel as
far as it goes and give it a
tap.
OPERATION
1. Always rotate the workpiece by hand before switching on the motor and
check it does not strike the tool rest or bed.
2. Ensure the tool rest and tailstock are securely locked in position before
starting work.
3. Always position the tool rest just above the centre-line of the lathe.
4. Press the green push-button (I) to
start the lathe.
NOTE: Always use the lowest speed
when starting a new
workpiece, see Adjusting The
Belt Position on page 11.
5. Avoid turning timber which has
splits or substantial knots or voids
and take special care if these are discovered.
6. When turning, always roughly turn the work to a round form at slow speed.
7. Take care that the turning tools do not bite suddenly into the workpiece.

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ADJUSTING THE BELT POSITION
The lathe is fitted with a 5 step pulley set-up,
which allows for a range of speeds, as shown.
Change the pulley range as follows.
NOTE: Make sure that the lathe is unplugged
from the power supply.
1. Unscrew the retaining plate on the headstock
end of the bed for access to the motor
pulley.
2. Unscrew the rear belt door on the rear of the
headstock for access to the drive pulley.
3. Loosen the lock screw that is holding the
motor plate using the 6mm hex key, allowing the motor plate to swivel
upwards.
4. Move the belt to the required
pulleys as shown in the diagram
above.
NOTE: Always go from the large
pulley to the small pulley.
5. After moving the belt, tighten the
motor pulley by swiveling the
motor plate downwards and
tightening the locking screw.
6. Turn on the lathe to make sure the
belt is running consistently in its
parallel grooves on the pulleys. If
the belt is running smoothly, turn
power off and reattach the
retaining plate and rear belt door.

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
MAINTENANCE
For maximum performance, it is essential that the machine is properly
maintained. Always inspect before use. Any damage should be repaired and
faults rectified. The machine requires very little maintenance other than the
following guidelines.
IMPORTANT: Disconnect from mains power before cleaning.
1. Vacuum clean any dust or shavings that accumulate in or on the motor.
2. Check all cables periodically and ensure that they are in good condition
and not cracked.
3. Check the tightness of the headstock mounting bolts.
4. Check the drive belt for wear and replace if it is frayed or otherwise
damaged.
5. Periodically lubricate the tail-stock, screw threads with engine oil such as
SAE20 or SAE30 grade if they become stiff to use.
6. Lightly lubricate the tail-stock and tool-post locking handles with oil if they
become difficult to use.
• The ball bearings in the headstock and tail-stock spindles are greased and
permanently sealed at the factory and require no further lubrication.
REPLACING THE BELT, SPINDLE OR BEARINGS
NOTE: Numbers in brackets refer to the Parts Diagram on pages 14-15.
1. To change the Drive Belt (53), Headstock Spindle (14) or Bearings (4) you
must first loosen the Motor Plate and Belt, as mentioned in section Adjusting
Belt Position on page 11.
2. Remove the rear belt door (7) and knob (8).
3. Loosen the two 3mm hex screws
(2) and unscrew the hand wheel
(1).

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
4. Loosen the 3mm hex screw (54)
on the drive pulley (52).
5. Tap out the spindle (14) using a
mallet.
NOTE: If you don’t have a mallet,
place a block of wood
against the spindle and tap
with a hammer.
6. To get the spindle completely out,
use a flat head screwdriver to tap
it the rest of the way if needed.
NOTE: Be careful not to damage the bearings or the threads.
7. Replace the bearings, spindle or belt as required.
BELT: You need only to move the spindle enough to slide a new belt on.
SPINDLE: You must knock the spindle completely out through both bearings.
BEARINGS: After removal of the spindle, completely knock out the bearings
from the inside of the headstock. This is best accomplished by inserting a
long rod or screwdriver through one bearing inside the headstock toward
the opposite bearing. tap firmly to remove the bearing from the casting. Do
the same for the second bearing. Please be aware not to damage the
circlip (13) when tapping out the bearing. Reassemble the new bearings by
tapping them into place from the outside and replace spindle.
NOTE: You may have to loosen the motor plate screws (44, 45 & 46) to
reinstall the spindle pulley (52), spindle collar (3) and belt (53).
8. Reinstall the hand wheel (1) and set screws (2).
NOTE: DO NOT tighten the hand wheel against the bearings
9. Tighten the pulley taper screw (69) and close the rear belt door (7)
Please refer to TROUBLESHOOTING on page 14. If you are unable to rectify any
faults, please contact your local dealer or CLARKE International Service
Department on 0208 988 7400 for assistance.

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
TROUBLESHOOTING
Problem Check Solution
Motor stops and
will not run.
1. Defective/broken switch.
2. Damaged power cable.
3. Open circuit, loose
connections or burned out
motor.
4. Blown fuse or circuit breaker.
5. Low voltage.
Send to your CLARKE dealer
for repair.
Send to your CLARKE dealer
for replacement.
Send to your CLARKE dealer
for replacement.
Replace fuse or re-set circuit
breaker. Turn off other
machines on same circuit.
Check the power supply for
correct voltage. Use
another circuit or have a
qualified electrician
upgrade the power supply.
Motor will not start
and fuses or
circuit breaker trip
out.
1. Short circuit in motor or
power cable.
2. Incorrect fuses or circuit
breakers.
Send to your CLARKE dealer
for repair.
Replace with correct fuse or
circuit breaker for the circuit.
Motor fails to
reach full power.
1. Overloaded circuit.
2. Unsuitable extension cable
Turn off other machines &
retry.
Replace with correct size
extension cable.
Noisy operation 1. Incorrect belt tension.
2. Dry spindle.
3. Loose drive pulley.
Adjust belt tension. See
Replacing the Belt on page
12.Lubricate the spindle.
Tighten the retaining set-
screw on the pulley.

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSOCIATED PRODUCTS
Wood Turning Chisel Set
- CHT874
4 Sided Diamond
Sharpener - CHT593
SAE30 Motor Oil - 1 litre
•8 piece wood turning
chisel set
•Part No. 1801874
•Multi-purpose
sharpener with four
different grits
•Part No. 1801593
•For lubricating
tailstock & screw
threads
•Part No. 3050852

16
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS DIAGRAM

17
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LIST
PART DESCRIPTION PART DESCRIPTION
1 Bed 32 Motor
2 Hex Socket Screw M10 x 12 33 Lock Lever
3 Retaining Plate 34 Retaining Ring
4 Quill Adjusting Wheel 35 Tool Rest
5 Tailstock 36 Tool Rest Base
6 Lock Lever Assembly 37 Bolt
7 Eccentric Axis 38 Lock Plate
8 Tail Axis 39 Hex Nut
9 Taper Rod 40 Lock Handle for Tool Rest
10 Ball Bearing 80102 41 Lock Lever Assembly
11 Cup Centre 42 Bolt
12 Headstock Spur Centre 43 Lock Plate
13 Faceplate 44 Hex Nut
14 Headstock Spindle 45 Power Cable
15 Ball Bearing 80102 46 Switch Faceplate
16 Retaining Ring 47 Washer
17 Retaining Ring 48 Screw
18 Ball Bearing 80102 49 On/Off Switch
19 Headstock 50 Washer
20 Rear Belt Door 51 Spring Washer
21 Screw 52 Rubber Foot Washer
22 Hand Wheel 53 Switch Box
23 Side Plate 54 Washer
24 Hex Screw 55 Retaining Ring 10
25 Drive Pulley 56 Tailstock Quill
26 Drive Belt 57 Bolt
27 Hex Screw M8 x 25 58 Quill Crank Handle
28 Hex Screw M6 x10 59 Moving Knob
29 Motor Pulley 60 Stationary Knob
30 Hex Screw 61 Sleeve
31 Motor Plate

18
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATION OF CONFORMITY

19
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
