PMB-IRI Mini IR Receiver
Overview
The PMB-IRI Mini IR Receiver (FIG. 1) provides a simple and cost-effective
way to add IR reception capabilities anywhere in a Landmark system.
Its small size allows mounting in discrete locations, and the PHASTLink
RJ-45 connectors on the back of the receiver allow it to be connected
directly to the PHASTLink data bus of a Landmark system without any other
intermediary devices.
An LED on the front of the Mini IR Receiver flashes when valid commands
are received.
An ID button on the front of the Mini IR Receiver provides device ID infor-
mation to the Landmark system to facilitate attaching a physical Mini IR
Receiver to the appropriate software receiver.
Safety Instructions
ATTENTION!
Read and follow all safety and operating instructions before installing or
operating this device. Adhere to all warnings listed on the device and in the
operating instructions.
• Disconnect this device from the power source before cleaning. Do not
use liquid or aerosol cleaners. Use only a clean, soft, damp cloth for
cleaning.
Operating Instructions
Note: There are no user-serviceable parts inside the Mini IR Receiver.
Opening the unit may void your warranty.
PHASTLink Ports:
There are two RJ-45 PHASTLink ports on the rear of the Mini IR Receiver.
Usually you will use only one, but the second port allows you to daisy chain
this device to other PHASTLink devices. Both PHASTLink ports are func-
tionally identical.
Number of IR Receivers:
You may install as many Mini IR Receivers as you like in a Landmark sys-
tem, but do not install more than one IR receiver in any given room. The IR
receiver may be a PMB-IRI, PLC-IRIN, or PLB-TCC.
Troubleshooting Tips
If you are having difficulty receiving commands, check the following:
• Make sure there is only one IR receiver per room, and that the IR
receiver in each room is not positioned so that it can receive signals
from a nearby room. These include the PMB-IRI, PMB-TCC, or the
PLC-IRIN and any connected IR receivers.
• Make sure none of the IR receivers are placed in locations that receive
direct or high levels of sunlight. Reposition if necessary.
• Start Landmark Designer and monitor the PMB-IRI function in the Net-
work Log. Make a number of clean button-press commands. You
should see these come in on the correct port. Watch for any interfer-
ence from other ports.
• Check the remote mode when comparing programming functions.
Make sure the mode matches the appropriate programming mode.
FCC Notice
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful inter-
ference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning
the equipment off and on, the user in encouraged to try to correct the inter-
ference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a different circuit from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FIG. 1 PMB-IRI Mini IR Receiver
Specifications
Inputs 1 IR sensor
Connection PHASTLink data bus
Wiring 2 RJ-45 PHASTLink ports
Dimensions (HWD) .93" x 1.6" x 2.97" (2.36 cm x 4.06 cm x 7.54 cm)
Weight 1.7 oz. (5.13 g)
LED
ID Button
IR Sensor
