AMX MIO R-4 User manual

Instruction Manual
Remotes
MIO-R4
Mio Modero R-4 Remote Kit
Last Revised: 4/28/2014

AMX Limited Warranty and Disclaimer
This Limited Warranty and Disclaimer extends only to products purchased directly from AMX or an AMX Authorized Partner which
include AMX Dealers, Distributors, VIP’s or other AMX authorized entity.
AMX warrants its products to be free of defects in material and workmanship under normal use for three (3) years from the date of
purchase, with the following exceptions:
• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay compo-
nents are warranted for a period of one (1) year.
• Disk drive mechanisms, pan/tilt heads, power supplies, and MX Series products are warranted for a period of one (1) year.
• AMX lighting products are guaranteed to switch on and off any load that is properly connected to our lighting products, as long
as the AMX lighting products are under warranty. AMX also guarantees the control of dimmable loads that are properly con-
nected to our lighting products. The dimming performance or quality there of is not guaranteed, impart due to the random combi-
nations of dimmers, lamps and ballasts or transformers.
• AMX software is warranted for a period of ninety (90) days.
• Batteries and incandescent lamps are not covered under the warranty.
• AMX AutoPatch Epica, Modula, Modula Series4, Modula CatPro Series and 8Y-3000 product models will be free of defects in
materials and manufacture at the time of sale and will remain in good working order for a period of three (3) years following the
date of the original sales invoice from AMX. The three-year warranty period will be extended to the life of the product (Limited
Lifetime Warranty) if the warranty card is filled out by the dealer and/or end user and returned to AMX so that AMX receives it
within thirty (30) days of the installation of equipment but no later than six (6) months from original AMX sales invoice date. The
life of the product extends until five (5) years after AMX ceases manufacturing the product model. The Limited Lifetime Warranty
applies to products in their original installation only. If a product is moved to a different installation, the Limited Lifetime Warranty
will no longer apply, and the product warranty will instead be the three (3) year Limited Warranty.
All products returned to AMX require a Return Material Authorization (RMA) number. The RMA number is obtained from the AMX
RMA Department. The RMA number must be clearly marked on the outside of each box. The RMA is valid for a 30-day period. After
the 30-day period the RMA will be cancelled. Any shipments received not consistent with the RMA, or after the RMA is cancelled, will
be refused. AMX is not responsible for products returned without a valid RMA number.
AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost
savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Autho-
rized Partner for a third party.
This Limited Warranty does not apply to (a) any AMX product that has been modified, altered or repaired by an unauthorized agent or
improperly transported, stored, installed, used, or maintained; (b) damage caused by acts of nature, including flood, erosion, or earth-
quake; (c) damage caused by a sustained low or high voltage situation or by a low or high voltage disturbance, including brownouts,
sags, spikes, or power outages; or (d) damage caused by war, vandalism, theft, depletion, or obsolescence.
This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim (including
negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by
any person. This limitation of liability will be effective even if AMX or an authorized representative of AMX has been advised of the
possibility of any such damages. This limitation of liability, however, will not apply to claims for personal injury.
Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or exclusion of inci-
dental or consequential damages for consumer products. In such states, the limitation or exclusion of the Limited Warranty may not
apply. This Limited Warranty gives the owner specific legal rights. The owner may also have other rights that vary from state to state.
The owner is advised to consult applicable state laws for full determination of rights.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX
EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT
MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS LIMITED WARRANTY. EXCEPT AS OTHERWISE LIMITED
BY APPLICABLE LAW, AMX RESERVES THE RIGHT TO MODIFY OR DISCONTINUE DESIGNS, SPECIFICATIONS, WARRAN-
TIES, PRICES, AND POLICIES WITHOUT NOTICE.

Table of Contents
i
Mio Modero R-4 Remote
Table of Contents
Mio Modero® R-4 Remote .................................................................................1
Overview .................................................................................................................. 1
Touch And Tilt Sensor ..................................................................................................... 2
Specifications............................................................................................................ 2
Display Features ....................................................................................................... 3
Device Navigation..................................................................................................... 3
FCC Compliance ....................................................................................................... 3
Patents...................................................................................................................... 3
Mio R-4 Setup .....................................................................................................5
Installing or Replacing the Mio R-4 Lithium-Ion Battery............................................ 5
Battery Low Indicator ............................................................................................... 6
Customized Keypads ................................................................................................ 6
Installing Keypads ........................................................................................................... 6
Device Setup Pages ............................................................................................9
Overview .................................................................................................................. 9
Accessing the Setup Pages.............................................................................................. 9
Project Information ................................................................................................... 9
Viewing Project Information.......................................................................................... 10
Remote & Display Settings ..................................................................................... 10
Changing the Remote and Display Settings .................................................................. 11
Raising and Lowering the LCD Brightness..................................................................... 12
Raising and Lowering the Charge LED Brightness......................................................... 13
Setting the Home Hold Time......................................................................................... 13
Changing the Remote Inactivity Page Flip..................................................................... 13
Checking Remote Display Settings................................................................................ 13
Date/Time Settings ................................................................................................. 13
Getting time and date from your NetLinx Master......................................................... 14
Sound Settings........................................................................................................ 14
Setting the Volume ....................................................................................................... 14
Testing the Sound Settings ........................................................................................... 14
Battery Settings ...................................................................................................... 15
Checking Dock Status.................................................................................................... 15
Toggling Brightness Limit.............................................................................................. 15
Protected Settings Menu ..................................................................................17
Overview ................................................................................................................ 17
Password Entry ....................................................................................................... 18
Entering a Numeric Password ....................................................................................... 18

ii Mio Modero R-4 Remote
Table of Contents
Options & Recovery Page ....................................................................................... 19
Checking the Device Number........................................................................................ 19
Toggling the Function Show option .............................................................................. 19
Toggling the Page Tracking Option .............................................................................. 19
Resetting System Settings............................................................................................. 20
Removing User Pages.................................................................................................... 20
Enabling Front Button Setup Access ............................................................................. 20
Edit Passwords........................................................................................................ 21
Changing the Device Password ..................................................................................... 21
Calibrate ................................................................................................................. 22
Calibrating the Touch Screen Area................................................................................ 22
System Settings ...................................................................................................... 22
Checking Connection Status.......................................................................................... 23
Checking the Master IP Address ................................................................................... 23
Checking the Gateway IP Address ................................................................................ 23
Checking the Gateway EUI Address .............................................................................. 23
Checking the Extended PAN ID .................................................................................... 23
Changing the Device Number ....................................................................................... 23
Site Survey.............................................................................................................. 24
Joining a Wireless Network........................................................................................... 24
ZigBee Diagnostics ................................................................................................. 25
Reboot Page ........................................................................................................... 26
Rebooting the Device.................................................................................................... 26
Test Pages .............................................................................................................. 26
Programming the Mio R-4 ................................................................................27
Overview ................................................................................................................ 27
Using the Programming Jack on the Mio R-4.......................................................... 27
Downloading Configuration Files through TPDesign4................................................... 27
Updating Firmware ................................................................................................. 28
Updating Mio R-4 Firmware Through USB .................................................................... 28
USB ......................................................................................................................... 28
Prepare Your PC for USB Communication With the Mio R-4 ......................................... 28
Configure a Virtual NetLinx Master Using NetLinx Studio ............................................ 28
Programming Numbers........................................................................................... 30
Fixed Fonts and ID Numbers......................................................................................... 32
Slider/Cursor Names ..................................................................................................... 32
Border Styles by Numbers ............................................................................................ 33
Text Effects Names................................................................................................. 35
SEND_COMMANDs ................................................................................................ 36
Page Commands ........................................................................................................... 36
PAGE...................................................................................................................................... 36

Table of Contents
iii
Mio Modero R-4 Remote
@APG ..................................................................................................................................... 36
@CPG ..................................................................................................................................... 36
@DPG ..................................................................................................................................... 36
@PDR ..................................................................................................................................... 37
@PHE...................................................................................................................................... 37
@PHP...................................................................................................................................... 37
@PHT...................................................................................................................................... 37
@PPA...................................................................................................................................... 37
@PPF ...................................................................................................................................... 38
@PPG ..................................................................................................................................... 38
@PPK...................................................................................................................................... 38
@PPM ..................................................................................................................................... 38
@PPN ..................................................................................................................................... 39
@PPT ...................................................................................................................................... 39
@PPX...................................................................................................................................... 39
@PSE ...................................................................................................................................... 39
@PSP ...................................................................................................................................... 39
@PST ...................................................................................................................................... 40
PPOF ...................................................................................................................................... 40
PPOG ..................................................................................................................................... 40
PPON ..................................................................................................................................... 40
“^” Button Commands with Embedded Codes............................................................. 41
^BMF ..................................................................................................................................... 41
“^” Button Commands .................................................................................................. 42
^ANI....................................................................................................................................... 42
^BMF
(Cont.)................................................................................................................................. 42
^APF ...................................................................................................................................... 43
^BAT ...................................................................................................................................... 43
^BAU...................................................................................................................................... 43
^BCB ...................................................................................................................................... 44
^BCF ...................................................................................................................................... 44
^BCT ...................................................................................................................................... 44
^BDO ..................................................................................................................................... 45
^BFB ...................................................................................................................................... 45
^BIM ...................................................................................................................................... 45
^BMC ..................................................................................................................................... 46
^BMF ..................................................................................................................................... 46
^BMI ...................................................................................................................................... 46
^BMP ..................................................................................................................................... 47
^BOR...................................................................................................................................... 47
^BPP ...................................................................................................................................... 47
^BRD...................................................................................................................................... 47
^BSF....................................................................................................................................... 48
^BSM ..................................................................................................................................... 48
^BSP ...................................................................................................................................... 48
^BWW.................................................................................................................................... 48
^CPF ...................................................................................................................................... 48
^DPF ...................................................................................................................................... 49
^ENA ..................................................................................................................................... 49
^FON ..................................................................................................................................... 49
^GDI....................................................................................................................................... 49
^GIV....................................................................................................................................... 50

iv Mio Modero R-4 Remote
Table of Contents
^GLH...................................................................................................................................... 50
^GLL....................................................................................................................................... 50
^GRD ..................................................................................................................................... 50
^GRU ..................................................................................................................................... 50
^GSC...................................................................................................................................... 51
^GSN ..................................................................................................................................... 51
^ICO....................................................................................................................................... 51
^JSB....................................................................................................................................... 52
^JSI ........................................................................................................................................ 52
^JST ....................................................................................................................................... 52
^SHO ..................................................................................................................................... 53
^TEC ...................................................................................................................................... 53
^TEF....................................................................................................................................... 53
^TXT ...................................................................................................................................... 53
Button Query Commands.............................................................................................. 54
^UNI....................................................................................................................................... 54
?BCB ...................................................................................................................................... 55
?BCF....................................................................................................................................... 55
?BCT....................................................................................................................................... 56
?BMP...................................................................................................................................... 56
?BOP ...................................................................................................................................... 57
?BRD ...................................................................................................................................... 57
?BWW .................................................................................................................................... 58
?FON...................................................................................................................................... 58
?ICO ....................................................................................................................................... 59
?JSB ....................................................................................................................................... 59
?JSI......................................................................................................................................... 60
?JST........................................................................................................................................ 60
?TEC....................................................................................................................................... 61
?TEF ....................................................................................................................................... 61
Remote Run Time Commands ....................................................................................... 62
ABEEP .................................................................................................................................... 62
ADBEEP.................................................................................................................................. 62
AKEYR.................................................................................................................................... 62
?TXT ....................................................................................................................................... 62
@AKP ..................................................................................................................................... 63
@AKR ..................................................................................................................................... 63
BEEP....................................................................................................................................... 63
BRIT........................................................................................................................................ 63
DBEEP .................................................................................................................................... 63
@EKP...................................................................................................................................... 63
PKEYP .................................................................................................................................... 64
@PKP...................................................................................................................................... 64
SETUP .................................................................................................................................... 64
SLEEP ..................................................................................................................................... 64
@TKP...................................................................................................................................... 64
TPAGEON .............................................................................................................................. 64
Input Commands ........................................................................................................... 65
^CAL ...................................................................................................................................... 65
Remote Setup Commands ............................................................................................. 65
^MUT ..................................................................................................................................... 65
@PWD .................................................................................................................................... 65

Table of Contents
v
Mio Modero R-4 Remote
TPAGEOFF ............................................................................................................................. 65
@VKB ..................................................................................................................................... 65
WAKE..................................................................................................................................... 65
Listboxes................................................................................................................. 66
List Box Commands ....................................................................................................... 66
^LDN...................................................................................................................................... 66
^PWD..................................................................................................................................... 66
^LDA...................................................................................................................................... 67
^LDR ...................................................................................................................................... 67
^LDC ...................................................................................................................................... 67
^LDD...................................................................................................................................... 67
^LDT ...................................................................................................................................... 68
^LDL....................................................................................................................................... 68
^LVC ...................................................................................................................................... 68
^LVF....................................................................................................................................... 69
^LVL....................................................................................................................................... 69
^LVM...................................................................................................................................... 69
^LVO...................................................................................................................................... 70
^LVP....................................................................................................................................... 70
^LVS....................................................................................................................................... 70
List Box Command: My Music ...................................................................................... 71
^LVU ...................................................................................................................................... 71
List Box Command: My Music with Changes ............................................................................ 72
Getting The Most From Your Mio Modero R-4 .................................................73
Overview ................................................................................................................ 73
Getting the Most From the Mio R-4........................................................................ 73
The ZigBee Network Calculator .................................................................................... 75
The Mio Modero R-4 Return Button........................................................................ 75
Mio Remote Charging Base ..............................................................................77
Overview ................................................................................................................ 77
Specifications ......................................................................................................... 77
Charging The Mio Remote with Charging Base ...................................................... 78

vi Mio Modero R-4 Remote
Table of Contents

Mio Modero® R-4 Remote
1
Mio Modero R-4 Remote
Mio Modero®R-4 Remote
Overview
The Mio Modero®R-4 remote provides custom control features, contained in an elegant hand-held rechargeable
device(FIG. 1). The Mio R-4 communicates with a NetLinx master via a wireless ZigBee network: the device comes
with installed firmware for connecting to a ZigBee Pro 2007 network, but it can be updated with firmware to allow it to
connect to older ZigBee 2004 networks.
Selecting a source device sends a command to the master and runs predetermined events associated with that source.
Selecting a macro will run predefined events, which might not be associated with sources listed, then return the device to
its previous mode.
You will need TPDesign4 to properly program this device. Both the application and its documentation are available from
www.amx.com.
FIG. 1 The Mio R-4 (front panel)
1
23
45
6
7
89
10
11
12
13
14
15
16
17 18
Numeric Keypad
19
Touch Screen
20
1- Power
2- Guide
3- Exit
4- Menu
5- Information
6 - Move Up
7- Move Down
8- Move Left
9- Move Right
10 - Select
11 - Volume Up
12 - Volume Down
13 - Channel Up
14 - Channel Down
15 - Last Viewed
16 - Mute
17 - Input
18 - Enter
19 - Back/Home
20 - Up/Down Touch Screen Navigation

Mio Modero® R-4 Remote
2Mio Modero R-4 Remote
Touch And Tilt Sensor
The Mio R-4 wakes up upon touching the chrome side rails, touching the touch screen, or pressing a button. If the remote
should go to sleep when holding it, you can reawaken the device by tilting it. Errant jostling, such as bumping a table on
which the device rests, will not wake the device unless you are holding it.
Specifications
The Mio Modero R-4 remote specifications are as follows:
Mio Modero R-4 (FG148-04) Specifications
Dimensions (HWD) 9.50" x 2.00" x .74" (241.3 mm x 50.8 mm x 18.80 mm)
Weight • .45 lbs (20 g) without batteries
• .55 lbs (25 g) with batteries
Battery Rechargeable Lithium-Ion
Transmission
Frequencies ZigBee RF wireless network
Transmission
Range • 100 feet (30.48m).
• Refer to the The ZigBee Network Calculator section on page 75 for more information
Memory • 32 Mbytes of FLASH
• 64 Mbytes of SDRAM
Top Components • LED - blue backlit buttons indicate device is awake
• LCD - high resolution (240x320) 76800 pixels with backlight and touch overlay
• Pushbuttons - the power button is red backlit; the rest are blue backlit buttons.
• 29 buttons total
Rear Components • Programming Port
• Battery Door
• Rechargeable Battery Connection
Supported
Languages: • English
• Spanish
• French
•Italian
•German
• Portuguese
• Arabic
• Russian
• Greek
• Simplified Chinese
• Japanese
•Thai
• Hindi
• Korean
Certifications: • FCC ID: CWU-NXR-MO
• IC: 5078A-NXRMO
•CE
• IEC-60950
• Japan Approval
• Designed for ZigBee
Operating
Environment • Operating Temperature: 0° to 40° C (32° to 104° F)
• Storage Temperature: -20° to 70° C (-4° to 158° F)
Included Items • Mio-RBP Rechargeable Lithium-ion Battery (FG147-10)
Optional Keypads: • Mio-R4-KP-ITALIAN (FG148-141)
• Mio-R4-KP-FRENCH (FG148-142)
• Mio-R4-KP-ARABIC (FG148-143)
• Mio-R4-KP-CHINESE (FG148-144)
Other AMX
Equipment • CC-USB Programming cable USB to mini USB (FG10-5965)
• Mio-RCC Charging Base (FG147-02) with power supply
• NXR-ZGW NetLinx ZigBee Gateway (FG5791-01)
• NXR-ZRP NetLinx ZigBee Repeater (FG5791-02)

Mio Modero® R-4 Remote
3
Mio Modero R-4 Remote
Display Features
The Mio R-4 remote device supports the following display features:
General Buttons
Bargraphs
Multistate General Buttons
Multistate Bargraph Buttons
Joystick Buttons
Animated Icons
List Buttons
Marquee Text
These features can be implemented using TPDesign4 or higher. For details, please refer to the TPDesign4 online help or
Instruction Manual, both available from www.amx.com.
Device Navigation
The Mio R-4 allows you to scroll through pages using the up and down buttons beneath the touch screen. Pressing the
Back buttons moves the selection back by one page while holding the button down returns the device to the power up
page.
FCC Compliance
This radio module was tested and certified as a stand-alone device according to FCC Rules CFR 47, Part 15, Subpart C.
If this device is installed in a manner such that the radio module FCC ID label is not visible on the outside of the end
product, a label must be placed on the end product with the following statement:
This device complies with Part 15 of the FCC rules. Subject to the following two conditions:
1. This device must not cause harmful interference and
2. This device must accept all interference, including interference that interferes with the operation of this device. "
Modifications not expressly approved by the manufacturer will void the user’s authority to operate the equipment.
Patents
This product is covered by the following patents:
AMX
U.S. Patent No. D 602,858
U.S. Patent No. D 520,495
U.S. Patent No. 7,786,623
This product employs or practices certain features and/or methods of one or more of the following patents:
SIPCO, LLC
U.S. Patent No. 7,103,511
U.S. Patent No. 6,914,893
U.S. Patent No. 7,697,492
This device has been evaluated and found to be compliant with the FCC Rules for RF
Exposure when the device is operated at a minimum separation distance of 2 cm.
from the user and nearby persons. Operation of this device at closer distances
should be avoided.”

Mio Modero® R-4 Remote
4Mio Modero R-4 Remote

Mio R-4 Setup
5
Mio Modero R-4 Remote
Mio R-4 Setup
Installing or Replacing the Mio R-4 Lithium-Ion Battery
To install your lithium-ion battery into the Mio R-4:
1. Flip and turn the Mio R-4 so that the buttons are facing away from you and the device is upside down.
2. Holding the device in both hands, place your thumbs on the battery door and slide the battery door free. The battery
door should slide toward the bottom end of the device.
3. Connect the terminal end of the Lithium Ion battery to the port shown in FIG. 2. It may be necessary to use a thin,
blunt non-conductive object to seat the battery connector fully within its port.
4. Place the battery door back on the device, and slide the door upwards to lock it in place.
FIG. 2 Rechargeable Battery Port on The Mio Remote
Lithium-Ion Battery
Rechargeable
Battery Port
Connection
Rear view -
battery compartment
Programming Port
(USB)
Correct path for
battery wires and
connector
Make sure that the battery wires run alongside the battery in the compartment as
shown in FIG. 2. Otherwise, the wires may be damaged or the battery door may not
close properly.

Mio R-4 Setup
6Mio Modero R-4 Remote
Battery Low Indicator
When the battery charge level is too low to sustain continuous operation, the Mio R-4’s touchscreen will display a popup
window reading “Battery Low” as an initial warning, and then a popup window reading “Battery Very Low” to
encourage the user to shut it down. The device will then shut down to prevent a total discharge of the battery. To recharge
the battery, insert the Mio R-4 into the Mio Remote Charging Base (see Charging The Mio Remote with Charging Base
on page 78).
Customized Keypads
The Mio R-4 has the capacity to replace its default English keypad with an optional keypad in one of four languages for
Arabic, French, Italian, or Mandarin Chinese readers. The keypad may also be replaced with other keypads to support
other functions or arrangements of keys. The additional functions or arrangements are supported with firmware
upgrades, available for download at www.amx.com.
Installing Keypads
To install a new keypad:
1. Flip and turn the Mio R-4 so that the buttons are facing away from you and the device is upside down.
2. Holding the Mio R-4 in both hands, place your thumbs on the battery door and push up to slide the battery door
free.
3. Remove the battery.
4. Unscrew the 6 screw points indicated in FIG. 3.
5. Turn the unit over so the buttons are facing you.
6. Lift the top assembly away from the PCB.
Each of the alternate keypads requires the appropriate firmware download for proper
function; please refer to the Updating Firmware section on page 28 for more
information.
FIG. 3 Internal Mio R-4 Components
6 Screw Points
Programming Jack

Mio R-4 Setup
7
Mio Modero R-4 Remote
7. If necessary, push out the standard buttons from the front of the top assembly.
8. Place the new keypad in the top assembly and verify the alignment with the guide posts on the PCB.
9. Place the top assembly back down on the PCB and turn the unit over again, exposing the 6 screw points.
10. Tighten the 6 screw points.
11. Install the battery, replace the battery door, and slide the door to lock it in place.

Mio R-4 Setup
8Mio Modero R-4 Remote

Device Setup Pages
9
Mio Modero R-4 Remote
Device Setup Pages
Overview
The Mio R-4 features onboard Setup pages that allow you to set and check the following features:
Project Information functions (page 9)
Remote & Display Settings (page 10)
Date/Time Settings (page 13)
Sound Settings (page 14)
Protected Settings(page 17)
Battery Settings (page 15)
Accessing the Setup Pages
To enter Setup Menu:
Hold the Input and Back buttons (see FIG. 1) for 6 seconds.
Navigate the Setup pages using the onscreen menu selections and the up and down arrows.
Project Information
The Project Information page displays information specific to the TPDesign4 remote file currently located on the Mio R-
4. Use the up and down arrows to scroll from viewable page to page.
FIG. 4 Setup Page Menu
FIG. 5 Mio R-4 Project Information Pages
Project Information
File Name The name of the file as it was created in the designing application.
Designer ID The ID of the designer for the control pages.

Device Setup Pages
10 Mio Modero R-4 Remote
Viewing Project Information
1. Select Project Information from the Setup Menu.
2. Use the Up/Down touchscreen arrows to view each page.
3. When finished, select the Back button until you are out of the Setup Menu.
Remote & Display Settings
The device provides you with information concerning current displays settings and allows you to edit the timeout and
brightness. Use the up and down arrows to scroll from viewable page to page.
Project Information (Cont.)
File Revision The revision number for the control pages.
Dealer ID The ID of the dealer associated with the control pages.
Job Name A friendly name for the job associated with the control pages.
Sales Order The sales order number for the job.
Purchase Order The purchase order number for the job.
Build Number The current build version number for the device firmware.
Charger Sensor Port The port number for the charger sensor.
Charger Sensor Channel The channel number for the charger sensor.
Creation Date The date the control pages were created.
Revision Date The date of the last revision for the control pages.
Last Save Date The date of the last save for the control pages.
Job Comments Any additional comments added in the designing application.
FIG. 6 Remote & Display Settings Pages

Device Setup Pages
11
Mio Modero R-4 Remote
Changing the Remote and Display Settings
The remote has two timeout levels to increase battery life; Display Timeout and Sleep Timeout. By default, these are set
to occur together. For these to occur separately, disable Sleep on Display Timeout.
When the Mio R-4 is in Display Timeout, the device only turns off the display, while the device otherwise remains fully
functional. Its display then comes on immediately upon registering a button or screen press. Upon Display Timeout, the
device will send the sleep string, defined in the TPD4 panel page properties. to the NetLinx master. Besides turning on
from a button or screen press, the device will also turn on upon receiving a wake command from the Master.
When the unit is in Sleep Timeout, the display is off and the radio is put in low-power mode. In this mode, the device
takes slightly longer to wake up and respond to button presses or message updates from the master. When the device
enters Sleep Timeout at the time specified, it sends a standby event, which is registered on the gateway and the master.
When the device is touched, it will bring the radio out of low-power mode and send an awake event to the master. If
defined in the TPD4 project properties, a wakeup string is also sent to the master when the display comes on as the unit
comes out of Display Timeout mode.
To change the Display Timeout and Sleep Timeout settings:
1. Select Remote & Display Settings from the Setup Page.
2. Under Display Timeout, use the Up/Down arrows to adjust the timeout period in five-second increments, to a
maximum of 30 seconds.
Remote & Display Settings
Display Timeout The valid display timeout times are 0, 10, 15, 20, 25, and 30 seconds.
Sleep Timeout The valid sleep timeout times are 0, 3, 5, 10, 15, 30, 60, 120, 180, and 240
minutes.
LCD The current brightness of the touchscreen display, between 0 and 100.
Charge LED The current brightness of the LED displaying charging status, between 0 and 100.
Home Hold Time The amount of time (in seconds, 0-6) in which the selected home page will be displayed.
Inactivity The amount of time (in minutes, 0-240) spent inactive in its charging cradle before the unit
switches to its inactivity page.
Inactivity Page The selected page displayed when the inactivity timer expires.
Panel Type The type of unit connected to the ZigBee network. This is always R4.
Firmware Version The most current firmware version uploaded to the unit.
ZigBee Version The most current version of the ZigBee module firmware uploaded to the device.
S/N The device serial number
Setup Pages Version The current version of the Setup pages uploaded to the unit.
Power-up Page The page displayed when the unit powers up.
File System The total and available amounts of storage space in the unit.
RAM The total amount of available RAM in the unit.
Setup Port The port (usually 0) used to upload information to the unit.
High Port The highest port number specified in the project pages.
High Address The highest address specified in the project pages.
High Channel The highest channel specified in the project pages.
High Level The highest level specified in the project pages
Refresh Rate The refresh rate, in screen lines, of the Setup page screen display.
Screen Width The width (in pixels) of the Setup page screen display.
Screen Height The height (in pixels) of the Setup page screen display.
Blink Rate The rate (in seconds) at which features on the screen will blink.
Wake-up String The code string chosen by the NetLinx administrator for the unit wake-up.
Sleep String The code string chosen by the NetLinx administrator for the unit sleep mode.
Start-up String The code string chosen by the NetLinx administrator for the unit startup.

Device Setup Pages
12 Mio Modero R-4 Remote
3. Under Sleep Timeout, use the Up/Down arrows to adjust the timeout period in regular increments, to a maximum of
240 minutes.
4. To disable the default setting and allow separate display and sleep timeouts, press the Sleep on Display Timeout
button. When Sleep on Display Timeout is engaged, the button is green (FIG. 7), and the Sleep Timeout settings will
be disabled. Press the button again to re-enable the Sleep on Display Timeout function.
5. Select the Back button until you are out of the Setup Menu.
Raising and Lowering the LCD Brightness
1. Select Remote & Display Settings from the Setup Page.
2. Under LCD, use the Up/Down arrows to adjust the LCD brightness in one-point increments, from a minimum of 0
to a maximum of 100.
3. Select the Back button until you are out of the Setup Menu.
The Sleep Timeout period increments are 0 (sleep timeout disabled, remote will stay
active until the battery charge runs low), 3, 5, 10, 15, 30, 60, 120, 180, and 240
minutes.
FIG. 7 Sleep on Display Timeout - enabled
Make sure to adjust the Sleep Timeout period after disengaging the Sleep on Display
Timeout function. From the factory, the default sleep timeout will be set for 15
minutes, but engaging and then disengaging the Sleep on Display Timeout function
will reset the period for 0 minutes (will not sleep until the battery charge runs low)
because the previous setting will already have 0 for that setting, even though it was
not actually used.
While deactivating the Sleep on Display Timeout function will prevent the Mio R-4
from going offline when the selected Display Timeout time is reached, doing so will
decrease the effective battery life. Setting the Sleep Timeout period to 0 will keep the
device from disconnecting from the network, but even a fully charged battery will
reach a very low point within 10 to 14 hours. If the device’s battery is too depleted, it
may need to be returned to the charging cradle and recharged before it can be used
again.
Take care not to set the LCD brightness too low, as the screen may become too dark
to read. If you accidentally set the LCD brightness too low and the screen becomes
too dark, touch the center right of the touchscreen until the screen brightens again.
