AMX DXLink Multi-Format SMF-D User manual

Instruction Manual
DXLink™Fiber Transmitters/Receivers, Duplex
DXLink™Fiber Transmitters and Receivers, Duplex
DXLink Multi-Format SMF-D Transmitter
DXLink Multi-Format MMF-D Transmitter
DXLink HDMI SMF-D Receiver
DXLink HDMI MMF-D Receiver
REV A: 02/28/14

AMX Domestic Channel Partner Limited
Warranty, Disclaimer and License
(Excerpt from CHANNEL PARTNER TERMS AND CONDITIONS Versions 11.17.2011 with updates for previous
version 8.25.2010 [sections 6.1 (a), (b) and (f)])
6. LIMITED WARRANTY; RETURN, REPAIR AND REPLACEMENT
6.1 AMX warrants the Products to be free of material defects in materials and workmanship under normal use
for three (3) years from the Shipping Date (or such other period as may be specified below), subject to the
following limitations and exceptions (“Limited Warranty”). For any Product, “Warranty Period” means the
period during which the Limited Warranty is in effect, as set forth herein.
(a) LCD and LED panels are warranted for three (3) years from the Shipping Date, except for the display
and touch overlay components, which are warranted for a period of one (1) year from the Shipping
Date.
(b) Disk drive mechanisms, pan/tilt heads and external power supplies are warranted for a period of one (1)
year from the Shipping Date.
(c) AMX lighting Products are warranted to switch on and off any load that is properly connected to our
lighting Products, as long as the AMX lighting Products are under warranty. AMX also warrants the
control of dimmable loads that are properly connected to our lighting Products. The dimming
performance or quality thereof is not warranted, due to the random combinations of dimmers, lamps
and ballasts or transformers.
(d) AMX software and firmware included in the Products is warranted for a period of ninety (90) days from
the Shipping Date.
(e) Batteries and incandescent lamps are not covered under the Limited Warranty.
(f) The Warranty Period for AMX AutoPatch EPICA, Enova DGX, Modula, Modula Series 4, Modula Cat Pro
Series and 8Y-3000 Product models will continue for the original installation until five (5) years after the
issuance of a PDN with respect to termination of the applicable Product model. However, if the Product is
moved from its original installation to a different installation, the Warranty Period will automatically
become three (3) years from the Shipping Date and, if more than three (3) years have elapsed since the
Shipping Date, the Warranty Period will automatically expire.
Version Date: 11-17-11
Note: The complete Warranty is at www.amx.com.

Contents
3
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Contents
ESD Warning ......................................................................................................................6
Important Safety Information and Instructions ...................................................................7
Information et directives de sécurité importantes..............................................................8
Notices ...............................................................................................................................9
Overview DXLink Fiber, Duplex........................................................................................12
Applicability Notice ................................................................................................................................. 12
Product Notes.......................................................................................................................................... 13
Product Compatibility.............................................................................................................................. 15
Features – DXLink Fiber Transmitters and Receivers, Duplex.................................................................. 16
Common Applications.............................................................................................................................. 17
DXLink Fiber Transmitters, Duplex .......................................................................................................... 17
DXLink Fiber Receivers, Duplex............................................................................................................... 20
Common Features/Functionality .............................................................................................................. 23
Quick Reference Tables for Modes.......................................................................................................... 26
DXLink Fiber Specifications ..............................................................................................28
Applicability............................................................................................................................................. 28
Specifications – DXLink Fiber Transmitters and Receivers, Duplex.......................................................... 28
Installation and Setup.......................................................................................................34
Site Recommendations ............................................................................................................................ 34
General Hazard Precautions .................................................................................................................... 34
Setup Information.................................................................................................................................... 35
DXLink Fiber TX – Attaching Signal, Transport, and Control Cables ....................................................... 43
DXLink Fiber TX – Applying Power.......................................................................................................... 44
DXLink Fiber RX – Attaching Signal, Transport, and Control Cables ....................................................... 45
DXLink Fiber RX – Applying Power.......................................................................................................... 46
Serial Data Transfer and IR Flow Control................................................................................................. 47
Optional: DXLink Fiber TX/RX – IR Control.............................................................................................. 48
Optional Accessories for USB Transport.................................................................................................. 49
ID Pushbutton Functions.......................................................................................................................... 49
DXLink Fiber RX Scaling Button and Scaling Modes................................................................................50
Detailed NetLinx (Link/Act and Status) LED Behavior.............................................................................. 52
DXLink Fiber TX – Local Out (HDMI) Port ................................................................................................ 53
DXLink Fiber TX/RX in a Multiple-Stage Switching System ..................................................................... 53
Network Configuration.....................................................................................................54
Overview ................................................................................................................................................. 54
Factory Default Parameters ..................................................................................................................... 56
Device IDs................................................................................................................................................ 57
Using the ID Pushbutton.......................................................................................................................... 57

Contents
4
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
IRL File Transfers ..............................................................................................................61
Overview ................................................................................................................................................. 61
Preparing for IRL File Transfers in an Endpoint System ........................................................................... 62
Transferring IRL Files ............................................................................................................................... 63
NetLinx Programming – DXLink Fiber TXs/RXs ................................................................66
Overview ................................................................................................................................................. 66
Device Numbering and Ports................................................................................................................... 66
CHANNELs .............................................................................................................................................. 68
DXLink Fiber Receiver Video SEND_COMMANDs................................................................................... 68
DXLink Fiber Receiver Audio SEND_COMMANDs................................................................................... 70
DXLink Fiber Transmitter Video SEND_COMMANDs .............................................................................. 71
DXLink Fiber Transmitter Audio SEND_COMMANDs.............................................................................. 75
IR SEND_COMMANDs............................................................................................................................. 76
Serial SEND_COMMANDs ....................................................................................................................... 80
DXLink Fiber Transmitter USB SEND_COMMANDs................................................................................. 82
DXLink Fiber Receiver USB SEND_COMMANDs ..................................................................................... 82
Common DXLink Fiber TX/ RX SEND_COMMANDs ................................................................................ 83
DXLink Fiber System SEND_COMMANDs ...............................................................................................84
SEND_STRING Escape Sequences ........................................................................................................... 85
Troubleshooting ...............................................................................................................86
Overview ................................................................................................................................................. 86
Basic Troubleshooting ............................................................................................................................. 86
Determining HDCP Compliance............................................................................................................... 86
Power Issues ............................................................................................................................................ 86
DXLink Fiber Troubleshooting ................................................................................................................. 87
Network Setup Issues .............................................................................................................................. 87
Technical Support .................................................................................................................................... 88
Appendix A – Upgrading the Firmware ............................................................................89
Overview ................................................................................................................................................. 89
Preparing for KIT File Transfers in an Endpoint System........................................................................... 90
Important Upgrade Information .............................................................................................................. 90
Transferring KIT Files ............................................................................................................................... 91
Firmware Versions ................................................................................................................................... 92
Appendix B – Telnet (Terminal) Commands......................................................................93
Establishing a Terminal Connection Via Telnet ........................................................................................ 93
Telnet Username and Password............................................................................................................... 94
Telnet Commands .................................................................................................................................... 95
Master Connection Modes..................................................................................................................... 108
Notes on Specific Telnet Clients ............................................................................................................ 109

Contents
5
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Appendix C – Virtual NetLinx Master .............................................................................110
Overview Virtual NetLinx Master (Masterless)....................................................................................... 110
Setting PC to Static IP Address ............................................................................................................. 110
Creating a Virtual Master....................................................................................................................... 112
Preparing a TX/RX to Work with a Virtual Master ................................................................................. 114
Appendix D – Cable Details and Pinout Info...................................................................116
Overview ............................................................................................................................................... 116
HDMI Connector Cable Pinout............................................................................................................... 116
HD-15 Connector Cable Pinout.............................................................................................................. 117
DVI Pinout for DVI-to-HDMI Cable ........................................................................................................ 118
Appendix E – Supported Input Resolutions ....................................................................119
Available Pixel Display and Refresh Rate............................................................................................... 119
Appendix F – Supported Output Resolutions.................................................................122
HDMI and DVI Supported Output Resolutions ...................................................................................... 122
Digital Video Output Resolution Support.............................................................................................. 123
Appendix G – Fiber Transceiver Replacement................................................................127
Replacing an SFP+ Fiber Optic Transceiver ........................................................................................... 128
Appendix H – EDID Management/Programming............................................................130
DXLink Fiber and EDID .......................................................................................................................... 130
DGX Configuration Software Overview ................................................................................................. 132
Software Installation on PC.................................................................................................................... 132
DXLink Fiber Connection to PC ............................................................................................................. 133
EDID Programmer View......................................................................................................................... 134

ESD Warning
6
Instruction Manual – DXLink Fiber™ Transmitters and Receivers, Duplex
ESD Warning
To avoid ESD (Electrostatic Discharge) damage to sensitive components, make sure you are properly grounded before
touching any internal materials.
When working with any equipment manufactured with electronic devices, proper ESD grounding procedures must be
followed to make sure people, products, and tools are as free of static charges as possible. Grounding straps, conductive
smocks, and conductive work mats are specifically designed for this purpose.
Anyone performing field maintenance on AMX DXLink Fiber equipment should use an appropriate ESD field service
kit complete with at least a dissipative work mat with a ground cord and a UL listed adjustable wrist strap with another
ground cord. These items should not be manufactured locally, since they are generally composed of highly resistive
conductive materials to safely drain static charges, without increasing an electrocution risk in the event of an accident.
ESD protective equipment can be obtained from 3M™, Desco®, Richmond Technology®, Plastic Systems®, and other
such vendors.

Important Safety Information and Instructions
7
Instruction Manual – DXLink Fiber™ Transmitters and Receivers, Duplex
Important Safety Information and Instructions
When using and installing your AMX product, adhere to the following basic safety precautions. For more information
about operating, installing, or servicing your AMX product, see your product documentation.
Read and understand all instructions before using and installing AMX products.
Use the correct voltage range for your AMX product.
There are no user serviceable parts inside an AMX product; service should only be done by qualified
personnel.
If you see smoke or smell a strange odor coming from your AMX product, turn it off immediately and call
technical support.
For products with multiple power supplies in each unit, make sure all power supplies are turned on
simultaneously.
Use surge protectors and/or AC line conditioners when powering AMX products.
Only use a fuse(s) with the correct fuse rating in your enclosure.
Make sure the power outlet is close to the product and easily accessible.
Make sure the product is on or attached to a stable surface.
Turn off equipment before linking pieces together, unless otherwise specified in that product’s
documentation.
For safety and signal integrity, use a grounded external power source and a grounded power connector.
To avoid shock or potential ESD (Electrostatic Discharge) damage to equipment, make sure you are properly
grounded before touching components inside an AMX product.

Information et directives de sécurité importantes
8
Instruction Manual – DXLink Fiber™ Transmitters and Receivers, Duplex
Information et directives de sécurité importantes
Veuillez vous conformer aux directives de sécurité ci-dessous lorsque vous installez et utilisez votre appareil AMX. Pour
de plus amples renseignements au sujet de l’installation, du fonctionnement ou de la réparation de votre appareil AMX,
veuillez consulter la documentation accompagnant l’appareil.
Lisez attentivement toutes les directives avant d’installer et d’utiliser les appareils AMX.
Le voltage doit être approprié à l’appareil AMX.
Les appareils AMX ne contiennent aucune pièce réparable par l’usager; la réparation ne doit être effectuée
que par du personnel qualifié.
Si de la fumée ou une odeur étrange se dégagent d’un appareil AMX, fermez-le immédiatement et appelez le
Service de soutien technique.
Veillez à ce que tous les blocs d’alimentation des appareils dotés de blocs d’alimentation multiples dans
chaque unité soient allumés simultanément.
Servez-vous de protecteurs de surtension ou de conditionneurs de lignes à courant alternatif lorsque vous
mettez les appareils AMX sous tension.
Placez uniquement des fusibles de calibre exact dans les boîtiers.
Veillez à ce que la prise de courant soit proche de l’appareil et facile d’accès.
Veillez à ce que votre appareil AMX soit installé sur une surface stable ou qu’il y soit fermement maintenu.
Fermez toutes les composantes de l’équipement avant de relier des pièces, à moins d’indication contraire
fournie dans la documentation de l’appareil.
Par mesure de sécurité et pour la qualité des signaux, servez-vous d’une source d’alimentation externe mise à
la terre et d’un connect d’alimentation mis à la terre.
Pour éviter les chocs ou les dommages éventuels causés à l’équipement par une décharge électrostatique,
veillez à ce le dispositif oit bien relié à la terre avant de toucher les composantes se trouvant à l’intérieur d’un
appareil AMX.

Notices
9
Instruction Manual – DXLink Fiber™ Transmitters and Receivers, Duplex
Notices
Copyright Notice
AMX©2014 (Rev A), all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the
prior written permission of AMX. Copyright protection claimed extends to AMX hardware and software and includes all
forms and matters copyrightable material and information now allowed by statutory or judicial law or herein after
granted, including without limitation, material generated from the software programs which are displayed on the screen
such as icons, screen display looks, etc. Reproduction or disassembly of embodied computer programs or algorithms is
expressly prohibited.
No patent liability is assumed with respect to the use of information contained herein.
Liability Notice
No patent liability is assumed with respect to the use of information contained herein.
While every precaution has been taken in the preparation of this publication, AMX assumes no responsibility for error or
omissions. No liability is assumed for damages resulting from the use of the information contained herein.
Further, this publication and features described herein are subject to change without notice.
US FCC Notice
The United States Federal Communications Commission (in 47 e-CFR 15.105) has specified that the following notice be
brought to the attention of the users of this product.
“Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.”
Lithium Batteries Notice
Switzerland requires the following notice for products equipped with lithium batteries. This notice is not applicable for
all AMX equipment.
Upon shipment of the products to Switzerland, the requirements of the most up-to-date Swiss Ordinance Annex 2.15 of
SR 814.81 will be met including provision of the necessary markings, documents, and annual reports relative to the
disposal of the batteries to the Swiss Authorities.
Trademark Notices
AMX®, Enova®, AutoPatch®, NetLinx®, SmartScale®, and InstaGate Pro®are trademarks of AMX.
Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
UL®and the UL logo are trademarks of UL LLC.
TeraTerm is a copyright product of T. Teranishi and TeraTerm Project.
PuTTY is a copyright product of Simon Tatham.
HyperTerminal is a copyright product of Hilgraeve Inc.
3M™, Desco®, Richmond Technology®, and Plastic Systems®are registered trademarks.
Ethernet®is a registered trademark of the Xerox Corporation.
ENERGY STAR® is a registered trademark of the U.S. Department of Energy and the U.S. Environmental Protection
Agency.
Apache™ is a trademark of the Apache Software Foundation. Used with permission. No endorsement by the Apache
Software Foundation is implied by the use of these marks.
Other products mentioned herein may be the trademarks of their respective owners.

Notices
10
Instruction Manual – DXLink Fiber™ Transmitters and Receivers, Duplex
Apache License, Version 2.0
Contains code Copyright 2006-2013 Giovanni Di Sirio, Licensed under the Apache License, Version 2.0.
Apache License
Version 2.0, January 2004
http://www.apache.org/licenses/
TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION
1. Definitions.
“License” shall mean the terms and conditions for use, reproduction, and distribution as defined by Sections 1 through 9
of this document.
“Licensor” shall mean the copyright owner or entity authorized by the copyright owner that is granting the License.
“Legal Entity” shall mean the union of the acting entity and all other entities that control, are controlled by, or are under
common control with that entity. For the purposes of this definition, “control” means (i) the power, direct or indirect, to
cause the direction or management of such entity, whether by contract or otherwise, or (ii) ownership of fifty percent (50%)
or more of the outstanding shares, or (iii) beneficial ownership of such entity.
“You” (or “Your”) shall mean an individual or Legal Entity exercising permissions granted by this License.
“Source” form shall mean the preferred form for making modifications, including but not limited to software source code,
documentation source, and configuration files.
“Source” form shall mean the preferred form for making modifications, including but not limited to software source code,
documentation source, and configuration files.
“Object” form shall mean any form resulting from mechanical transformation or translation of a Source form, including but
not limited to compiled object code, generated documentation, and conversions to other media types.
“Work” shall mean the work of authorship, whether in Source or Object form, made available under the License, as
indicated by a copyright notice that is included in or attached to the work (an example is provided in the Appendix below).
“Derivative Works” shall mean any work, whether in Source or Object form, that is based on (or derived from) the Work
and for which the editorial revisions, annotations, elaborations, or other modifications represent, as a whole, an original
work of authorship. For the purposes of this License, Derivative Works shall not include works that remain separable from,
or merely link (or bind by name) to the interfaces of, the Work and Derivative Works thereof.
“Contribution” shall mean any work of authorship, including the original version of the Work and any modifications or
additions to that Work or Derivative Works thereof, that is intentionally submitted to Licensor for inclusion in the Work by
the copyright owner or by an individual or Legal Entity authorized to submit on behalf of the copyright owner. For the
purposes of this definition, “submitted” means any form of electronic, verbal, or written communication sent to the Licensor
or its representatives, including but not limited to communication on electronic mailing lists, source code control systems,
and issue tracking systems that are managed by, or on behalf of, the Licensor for the purpose of discussing and improving
the Work, but excluding communication that is conspicuously marked or otherwise designated in writing by the copyright
owner as “Not a Contribution.”
“Contributor” shall mean Licensor and any individual or Legal Entity on behalf of whom a Contribution has been received
by Licensor and subsequently incorporated within the Work.
2. Grant of Copyright License. Subject to the terms and conditions of this License, each Contributor hereby grants to You
a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable copyright license to reproduce, prepare
Derivative Works of, publicly display, publicly perform, sublicense, and distribute the Work and such Derivative Works in
Source or Object form.
3. Grant of Patent License. Subject to the terms and conditions of this License, each Contributor hereby grants to You a
perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable (except as stated in this section) patent license to
make, have made, use, offer to sell, sell, import, and otherwise transfer the Work, where such license applies only to those
patent claims licensable by such Contributor that are necessarily infringed by their Contribution(s) alone or by combination
of their Contribution(s) with the Work to which such Contribution(s) was submitted. If You institute patent litigation against
any entity (including a cross-claim or counterclaim in a lawsuit) alleging that the Work or a Contribution incorporated
within the Work constitutes direct or contributory patent infringement, then any patent licenses granted to You under this
License for that Work shall terminate as of the date such litigation is filed.
4. Redistribution. You may reproduce and distribute copies of the Work or Derivative Works thereof in any medium, with
or without modifications, and in Source or Object form, provided that You meet the following conditions:
You must give any other recipients of the Work or Derivative Works a copy of this License; and
You must cause any modified files to carry prominent notices stating that You changed the files; and
You must retain, in the Source form of any Derivative Works that You distribute, all copyright, patent, trademark, and
attribution notices from the Source form of the Work, excluding those notices that do not pertain to any part of the
Derivative Works; and
If the Work includes a “NOTICE” text file as part of its distribution, then any Derivative Works that You distribute must
include a readable copy of the attribution notices contained within such NOTICE file, excluding those notices that do not

Notices
11
Instruction Manual – DXLink Fiber™ Transmitters and Receivers, Duplex
pertain to any part of the Derivative Works, in at least one of the following places: within a NOTICE text file distributed as
part of the Derivative Works; within the Source form or documentation, if provided along with the Derivative Works; or,
within a display generated by the Derivative Works, if and wherever such third-party notices normally appear. The contents
of the NOTICE file are for informational purposes only and do not modify the License. You may add Your own attribution
notices within Derivative Works that You distribute, alongside or as an addendum to the NOTICE text from the Work,
provided that such additional attribution notices cannot be construed as modifying the License.
You may add Your own copyright statement to Your modifications and may provide additional or different license terms and
conditions for use, reproduction, or distribution of Your modifications, or for any such Derivative Works as a whole,
provided Your use, reproduction, and distribution of the Work otherwise complies with the conditions stated in this License.
5. Submission of Contributions. Unless You explicitly state otherwise, any Contribution intentionally submitted for
inclusion in the Work by You to the Licensor shall be under the terms and conditions of this License, without any additional
terms or conditions. Notwithstanding the above, nothing herein shall supersede or modify the terms of any separate license
agreement you may have executed with Licensor regarding such Contributions.
6. Trademarks. This License does not grant permission to use the trade names, trademarks, service marks, or product
names of the Licensor, except as required for reasonable and customary use in describing the origin of the Work and
reproducing the content of the NOTICE file.
7. Disclaimer of Warranty. Unless required by applicable law or agreed to in writing, Licensor provides the Work (and
each Contributor provides its Contributions) on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF
ANY KIND, either express or implied, including, without limitation, any warranties or conditions of TITLE,
NON-INFRINGEMENT, MERCHANTABILITY, or FITNESS FOR A PARTICULAR PURPOSE. You are solely
responsible for determining the appropriateness of using or redistributing the Work and assume any risks associated with
Your exercise of permissions under this License.
8. Limitation of Liability. In no event and under no legal theory, whether in tort (including negligence), contract, or
otherwise, unless required by applicable law (such as deliberate and grossly negligent acts) or agreed to in writing, shall any
Contributor be liable to You for damages, including any direct, indirect, special, incidental, or consequential damages of any
character arising as a result of this License or out of the use or inability to use the Work (including but not limited to
damages for loss of goodwill, work stoppage, computer failure or malfunction, or any and all other commercial damages or
losses), even if such Contributor has been advised of the possibility of such damages.
9. Accepting Warranty or Additional Liability. While redistributing the Work or Derivative Works thereof, You may
choose to offer, and charge a fee for, acceptance of support, warranty, indemnity, or other liability obligations and/or rights
consistent with this License. However, in accepting such obligations, You may act only on Your own behalf and on Your
sole responsibility, not on behalf of any other Contributor, and only if You agree to indemnify, defend, and hold each
Contributor harmless for any liability incurred by, or claims asserted against, such Contributor by reason of your accepting
any such warranty or additional liability.
END OF TERMS AND CONDITIONS
Warnings and Cautions
This manual uses the following conventions and icons to draw attention to actions or conditions that could potentially
cause problems with equipment or lead to personal risk.
ESD Warning: The icon to the left indicates text regarding potential danger associated with the discharge of
static electricity from an outside source (such as human hands) into an integrated circuit, often resulting in
damage to the circuit.
Warning: The icon to the left indicates text that warns readers against actions or conditions that could cause
potential injury to themselves.
Caution: The icon to the left indicates text that cautions readers against actions that could cause potential
injury to the product or the possibility of serious inconvenience.

Overview DXLink Fiber, Duplex
12
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Overview DXLink Fiber, Duplex
Applicability Notice
The information in this manual applies to the AMX DXLink Fiber Transmitters and Receivers, Duplex listed in the
table below. These units handle simultaneous, bidirectional data transfer. They are available in both multimode and
single mode models (which differ only in respect to their transceivers which support different cable lengths).
Throughout this manual, the phrase “DXLink Fiber units” will be used when referring generically to all four of the
DXLink Fiber, Duplex product models.
When referring to specific Duplex models, they will be described as follows:
Multi-Format MMF-D TX*
HDMI MMF-D RX*
Multi-Format SMF-D TX**
HDMI SMF-D RX**
* MMF-D = multimode fiber - duplex
** SMF-D = single mode fiber - duplex
DXLink Fiber Transmitters and Receivers, Duplex
^ On the rear of both Transmitter units, the number will be FG1010-36X, indicating they share a common metal box design.
^^ On the rear of both Receiver units, the number will be FG1010-56X, indicating they share a common metal box design.
The multimode and single mode fiber optic transceivers allow for in-the-field replacement.
Compatibility Note: In Enova DGX systems using DXLink Fiber technology – the DXLink Fiber Input Board
and its DXLink Fiber TX, Duplex must have the same type of fiber optic transceivers: either multimode or
single mode. The same holds true for DXLink Fiber Output Boards and the DXLink Fiber RX, Duplex units.
Important: Use of a DXLink Fiber Transmitter and Receiver as a standalone pair
will be supported in a future firmware upgrade.
Part # Model Name Model Number, Description
FG1010-362^ DXLink Multi-Format Multimode Fiber Transmitter, Duplex DXLF-MFTX-MM-D,
DXLINK MULTI-FORMAT MM FIBER TX,
DUPLEX
FG1010-360^ DXLink Multi-Format Single Mode Fiber Transmitter, Duplex DXLF-MFTX-SM-D,
DXLINK MULTI-FORMAT SM FIBER TX,
DUPLEX
FG1010-562^^ DXLink HDMI Multimode Fiber Receiver, Duplex DXLF-HDMIRX-MM-D
DXLINK HDMI MM FIBER RX, DUPLEX
FG1010-560^^ DXLink HDMI Single Mode Fiber Receiver, Duplex DXLF-HDMIRX-SM-D,
DXLINK HDMI SM FIBER RX, DUPLEX

Overview DXLink Fiber, Duplex
13
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Product Notes
Fiber Optic Transceivers
The DXLink Fiber units use SFP+ fiber optic transceivers.* Fiber optic transceivers are self-contained modules that send
and receive optical signals over fiber cable. These fiber optic transceivers are either multimode or single mode and must
be wired with the corresponding cable type.
* SFP+ = enhanced small form-factor pluggable fiber optic transceiver rated at 10 Gbps transmission data rate.
Note: The types of fiber optic transceivers used in DXLink Fiber units are referred to as “multimode” and
“single mode,” which indicate the maximum length of the fiber optic cable that can be used. In addition, the
Transmitters and Receivers support modes that can be determined during setup to handle the system
architecture, accommodate networking needs, and process video signals (see page 26).
Transceiver Types / Cable Types / Cable Runs
The type of SFP+ fiber optic transceiver helps determine the maximum length of cable runs possible. Cable quality is
also a determining factor.
All DXLink Fiber units are designed for transmission of an HDMI signal over fiber optic cable.
Both multimode and single mode transceivers on DXLink Fiber units support bidirectional communication
(Bidirectional Mode).
Bidirectional communication over DXLink Fiber includes transmission of the following:
Digital video and audio
Native NetLinx control
IR
RS-232
USB keyboard and mouse
Ethernet (100 Mbps)
OSHA Directive
The OSHA Technical Manual (at https://www.osha.gov/dts/osta/otm/otm_iii/otm_iii_6.html) under “VI. Control
Measures and Safety Programs” states: “Direct exposure on the eye by a beam of laser light should always be avoided
with any laser, no matter how low the power.”
Transceiver Disposal
Important: If disposal of transceivers is necessary, dispose of them as mandated by your area or country
guidelines.
SFP+ Fiber Optic Transceivers
Transceiver Type DXLink Fiber, Duplex Units Required Cable Type Maximum Distance
Multimode • Multi-Format MMF-D TX
• HDMI MMF-D RX
OM3 50/125 μmmultimode fiber optic 984 ft. (300 m)
Single Mode • Multi-Format SMF-D TX
• HDMI SMF-D RX
9/125 μmsingle mode fiber optic 6.21 miles (10 km)
Warning: DXLink Fiber units use laser transceivers, which are Class 1 Eye Safe per IEC 60825-1/CDRH
requirements. While the Class 1 category indicates that the invisible laser used is safe, we recommend
avoiding direct eye exposure when using any optical fiber products (see the OSHA directive below).
OSHA
Directive

Overview DXLink Fiber, Duplex
14
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Multimode SFP+ Fiber Optic Transceiver
A multimode SFP+ fiber optic transceiver is used for the Multi-Format MMF-D TX and the HDMI MMF-D RX.
Depending on the transceiver model, it will have a latch that is black or a black label on the latch top with white triangles
showing data flow direction.
The multimode SFP+ fiber optic transceiver requires multimode fiber optic cable, which allows numerous optical waves
to traverse the optic core. Multimode fiber optic cable has a significantly larger optical core (which results in a higher
dispersion rate) and results in comparative shorter distance optical runs than the single mode cable.
Single Mode SFP+ Fiber Optic Transceiver
A single mode SFP+ fiber optic transceiver is used for the Multi-Format SMF-D TX and the HDMI SMF-D RX.
Depending on the transceiver model, it will have a bright blue latch or a blue label on the latch top with white triangles
showing data flow direction.
The single mode SFP+ fiber optic transceiver requires single mode fiber optic cable, which allows a single optical wave
to traverse through the optic core. Single mode fiber optic cable has a significantly smaller diameter optical core than
multimode fiber optic cable and is generally associated with longer distance transport capabilities.
FIG. 1 Multimode SFP+ fiber optic transceiver (model with black label on latch top shown)
FIG. 2 Single mode SFP+ fiber optic transceiver (model with blue latch shown)
Latch color black or black on top Dust plug
Latch color blue or blue on top Dust plug

Overview DXLink Fiber, Duplex
15
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Multi-Format MMF-D TX and Multi-Format SMF-D TX
The DXLink Fiber Transmitters, Duplex receive an HDMI signal or analog video signal (composite, Y/C, Y/Pb/Pr,
RGB, RGBS, or RGBHV) and an audio signal from a source device. The audio can be either digital audio embedded
with the HDMI or analog stereo audio.
Either analog or digital video is transmitted out of the fiber optic transceiver. The active video selection is made using
one of two methods:
Automatic – selects digital video as the priority video input or analog video when digital video is not present.
Can be set to treat either the digital or analog video as the priority, which then defaults to the opposite if the
primary is not present.
Active SEND_COMMAND video input selection from a bound NetLinx Central Controller (usually the
integrated Central Controller on the Enova DGX).
Both the video and audio are transported over fiber optic cable to an Enova DGX Digital Media Switcher. The unit also
has a local HDMI output connector on the front for sending the video signal from the source directly to a local
destination device. This local HDMI output connection supports the same input resolutions contained in the first table in
“Appendix E - Supported Input Resolutions” (see page 119).
The 232 port (RS-232) on the Transmitters supports bidirectional serial data via the fiber optic cable to/from the
232 port. In addition, the Transmitters have IR ports, which also send data via the fiber optic cable.
HDMI MMF-D RX and HDMI SMF-D RX
The DXLink Fiber Receivers, Duplex feature SmartScale®Technology (integrated EDID output scaling) to ensure an
appropriate output resolution, plus they support a Manual (override) option for setting up custom resolutions and a
Bypass option (see page 50).
The DXLink Fiber Receivers receive an HDMI signal and an audio signal over fiber optic cable from a DXLink Fiber,
Duplex Output Board on an Enova DGX Switcher. They then send the signal on to the destination. The audio output can
be either digital audio embedded with the HDMI signal or analog stereo audio (if the signal originated as a 2 channel
audio format).
The 232 ports (RS-232) support bidirectional serial data via the fiber optic cable, which connects the DXLink Fiber
TX/RX units and the Enova DGX Switcher.
Note: If a DVI-D signal is used (via a DVI-to-HDMI cable), the advanced audio support from HDMI will not be
available out the Receiver.
Note: DXLink Fiber units support several different modes which are available for system setup and use. Brief
explanations of the modes are provided in the section “Quick Reference Tables for Modes” on page 26 along
with page references to detailed information.
Product Compatibility
DXLink Fiber Transmitters and Receivers, Duplex work in conjunction with Enova DGX DXLink Fiber Duplex Boards
as specified in the following table.
DXLink Fiber TX/RX, Duplex and Enova DGX DXLink Fiber, Duplex Board Compatibility
DXLink Fiber, Duplex Unit Enova DGX DXLink Fiber, Duplex Board
Multi-Format MMF-D Transmitter (FG1010-362) MMF-D Input Board (FG1058-622)
HDMI MMF-D Receiver (FG1010-562) MMF-D Output Board (FG1058-632)
Multi-Format SMF-D Transmitter (FG1010-360) SMF-D Input Board (FG1058-620)
HDMI SMF-D Receiver (FG1010-560) SMF-D Output Board (FG1058-630)

Overview DXLink Fiber, Duplex
16
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Features – DXLink Fiber Transmitters and Receivers, Duplex
Optical transport rate of 10 Gbps.
Incorporates HDMI®technology.
HDCP 1.3 compatible.
Supports computer video up to 1920x1200, HDTV up to 1080p, as well as 3D support (3D and Deep Color).
Supports HDMI pass through with embedded digital audio and single link DVI (via DVI-to-HDMI cable).
A local HDMI output connector on the front of the Transmitters for sending the video signal from the source
directly to a local destination device.
DXLink Fiber TX, Duplex units support analog video: composite, Y/C, Y/Pb/Pr, RGB, RGBS, or RGBHV.
DXLink MMF-D units transport video signals over distances up to 984 feet (300 m).
DXLink SMF-D units transport video signals over distances up to 6.21 miles (10 km).
Interruption free content when used in conjunction with a switcher; AMX’s exclusive InstaGate Pro®
Technology allows audio and video to be switched quickly and easily to every connected display without the
difficulties typically associated with HDCP.
AutoDetect on the Transmitters and SmartScale®on the Receivers work to automatically recognize any
device’s supported resolutions and signal type parameters, allowing switching out source and destination
devices without manual setup. Also included is the ability to control detailed timing parameters for
customized video output formats. (SmartScale is the ability to configure the scaling output by automatically
selecting destination defined resolutions.)
Supports HDMI embedded digital audio and analog stereo audio.
Fiber optic cable (for fiber cable specifications, see page 28).
Field serviceable SFP+ fiber optic transceivers, easier to remove and replace an individual transceiver rather
than a TX or RX unit or an Enova DGX DXLink Fiber Board.
The USB port on the Receivers passes keyboard and mouse USB signals to control a remote computer. The
Transmitter’s USB port connects to a Host PC and will forward HID keyboard and mouse data received from
a Receiver’s USB port (for USB information, see page 23).
The 232 port (RS-232 serial) supports bidirectional transfer of serial data between TX/Master/RX (Endpoint
Mode).
The IR port supports bidirectional transfer of IR data between TX/Master/RX (Endpoint Mode).
A desktop power supply (ENERGY STAR®qualified) is provided per DXLink Fiber unit.
The Transmitters and Receivers are compatible with all V Style, versatile mounting options including rack,
surface, and pole.
Backed by AMX’s 3 year warranty (see www.amx.com).
24-hour technical support.
Note: Features and specifications described in this document are subject to change without notice.

Overview DXLink Fiber, Duplex
17
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Common Applications
DXLink Fiber Transmitters and Receivers, Duplex are ideal for any sources and destinations designed into Enova DGX
integrated systems that require the distance capabilities and/or inherent security of fiber with bidirectional data transfer.
These transmitters and receivers easily handle campus-wide distribution of sources that are shared between classrooms,
in secure military applications, medical facilities, casinos, arenas, museums, and large corporate installations. Connect
HDMI or video sources (such as PCs) directly using the HDMI or HD-15 multi-format input connection and easily
include audio on the same fiber optic cable by using the stereo or digital audio connection.
DXLink Fiber Transmitters, Duplex
The MMF-D TX and SMF-D TX are identical except for the type of fiber optic transceiver. The MMF-D TX has a
multimode transceiver (the latch is black or has a black label), and the SMF-D TX has a single mode fiber optic
transceiver (the latch is blue or has a blue label).
Note: A DVI-D signal can be used (via a DVI-to-HDMI cable) into the Transmitter.
DXLink Fiber Transmitters, Duplex – Front View
(TX-MULTI-DXLINK-MMF-D and TX-MULTI-DXLINK-SMF-D)
Components located on the front of the DXLink Fiber Transmitters, Duplex (left to right):
Power LED –Indicates when the unit is powered on.
Digital Video and Audio LEDs – Indicate the presence of digital video and digital audio signals, including an
embedded audio signal on the HDMI path.
Analog Video LEDs – Indicate the type of analog video present through the unit: composite or Y/C; Y/Pb/Pr
or RGB; RGBHV or RGBS.
Program port – This port (USB mini-B connector) supports DGX Configuration Software for programming a
custom VGA or HDMI EDID.
IR LEDs – TX and RX LEDs indicate active IR communication.
232 LEDs (RS-232 serial) – TX and RX LEDs indicate active serial communication (for details, see page 47).
NetLinx LEDs – Link/Act LED indicates network communication activity. The Status LED indicates that the
LAN connection is active.
CEC LED – CEC is not currently supported.
USB LED – When illuminated, the LED indicates that the USB port is connected and enabled (for details, see
page 23).
ID Pushbutton – Places the unit in ID Mode for setting the NetLinx ID (device only) and provides additional
functionality, such as placing the unit in Static IP Mode or DHCP Mode (for details, see page 57).
Local Out (video) – This HDMI connector can be used to send the source signal to a local monitor.
FIG. 3 DXLink Fiber Transmitter, Duplex - front view
Digital Video and Audio LEDs
Power LED USB LED
IR LEDs
232 (serial) LEDs
NetLinx LEDs CEC LED
ID Pushbutton
Program port
Analog Video LEDs Local Out (HDMI)

Overview DXLink Fiber, Duplex
18
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
LEDs – DXLink Fiber Transmitters, Duplex
Note: For detailed behavior of the NetLinx Link/Act and Status LEDs on the unit’s front, see page 52.
For detailed behavior of the ICS LAN 10/100 (RJ-45) connector LEDs on the unit’s rear, see page 42.
Note: When an analog video source cable is plugged into the TX, one of the Analog Video LEDs on the front
of the TX and the Video LED on the RX (connected via the switcher) turn green to show the type of video that
is present through the system.
DXLink Fiber Transmitters, Duplex – Rear View
Components located on the rear of the DXLink Fiber Transmitters, Duplex (from left to right):
Power Jack
The power receptacle is a 2.1 mm DC jack for connecting power. Power comes from the locally connected DC supply
of 12 V. The automatically adjusting universal 110/220 IEC power supply is provided. The power supply is ENERGY
STAR®qualified to ensure maximum efficiency and savings.
Video In Connector
The Video In connector on the TX is an HD-15 connector for analog video (composite, Y/C, Y/Pb/Pr, RGB, RGBHV,
or RGBS). Pinouts for analog video are on page 117.
DXLink Fiber Transmitters, Duplex – Indicator LEDs on the Front
LED Normal Display Indicates
Power Green Power is applied to the unit
Digital Video Green A digital video signal is present through the unit
Audio (Digital) Green Embedded audio signal is present through the unit
Analog Video One of the 3 LEDs
will be Green
The type of analog video present through the unit:
• C (composite) or Y/C (two component)
• Y/PB/PR or RGB (three component)
• RGBHV (five component) or RGBS (four component)
IR TX Red IR TX active communication
IR RX Yellow IR RX active communication
232 (Serial) TX Red Serial TX active communication
232 (Serial) RX Yellow Serial RX active communication
NetLinx Link/Act Green Active LAN connection to an AMX Network (blinking = #3 Toggle OFF)
NetLinx Status Green LAN connection is active
CEC OFF CEC is not currently supported
USB Yellow USB is connected and enabled (for details, see page 23)
FIG. 4 DXLink Fiber Transmitter, Duplex - rear view
IR ports
RS-232 port
HDMI In connector Stereo Audio In jack USB port
ICS LAN 10/100 connector Fiber optic transceiver
Digital Audio In jack
Power jack
Video In connector
Caution: The provided desktop power supply must be used to power the Transmitter, and it must not be
altered in any way.

Overview DXLink Fiber, Duplex
19
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Note: When an analog video source cable is plugged into the TX, one of the Analog Video LEDs on the front
of the TX and the Video LED on the RX (connected via the switcher) turn green to show the type of video that
is present through the system.
HDMI In Connector
The HDMI In connector is for digital video and embedded digital audio. When more than one audio signal is present and
the default “auto” mode is enabled, HDMI embedded audio takes precedence over S/PDIF and analog audio.
When a NetLinx Central Controller is connected, an audio format SEND_COMMAND is available (the TX must be set
for network connectivity via the #3 Toggle) to select the desired audio source (see page 75).
The HDMI connector has a center screw for locking capability. The HDMI connector also supports a DVI-D signal with
the use of a DVI-to-HDMI cable.
Note: When a digital video source cable is plugged into the HDMI connector, the Digital Video LED on the
front of the TX and the Video LED on the Receiver (connected via the switcher) turn green to show that video
is present through the system.
Stereo Audio In Jack
The Stereo Audio In jack is a 3.5 mm stereo jack. By default, the stereo audio jack will be third in priority behind the
embedded audio on the HDMI input and digital audio on the RCA connector.
When a NetLinx Central Controller is connected, an audio format SEND_COMMAND is available (the TX must be set
for network connectivity via the #3 Toggle) to select the desired audio source (see page 75).
Digital Audio In Jack
The Digital Audio In jack is an RCA jack for an S/PDIF audio signal. When more than one audio signal is present and
the default “auto” mode is enabled, HDMI embedded audio takes precedence over S/PDIF, which takes precedence over
analog audio.
When a NetLinx Central Controller is connected, an audio format SEND_COMMAND is available (the TX must be set
for network connectivity via the #3 Toggle) to select the desired audio source (see page 75).
ICS LAN10/100 Connector
The ICS LAN 10/100 (RJ-45) connector provides for Ethernet 10/100 connectivity (e.g., receiving
SEND_COMMANDs and downloading firmware update files). For pinout and LED information, see page 42.
Note: The #1 Toggle on the DIP switch must be set to ON to enable activity over this port.
RS-232 (Serial) Port
The RS-232 serial data interface port is a 3-position screw terminal block which accepts data from the source device and
transfers it via the fiber optic cable to the RX, which in turn transfers the data to the destination device. The transfer of
data can also be made from the destination to the source. In addition to being directly connected to a device, this port can
be connected as an independent native NetLinx control port from a networked NetLinx Central Controller.
IR RX Port
The IR RX port is used for IR control (see page 25). This port is a 3.5 mm stereo jack. In addition to being directly
connected to a device, this port can be connected as an independent native NetLinx control port from a networked
NetLinx Central Controller.
IR TX Port
The IR TX port is used for IR control (see page 25). This port is a 2-way mini-Phoenix connector. In addition to being
directly connected to a device, this port can be connected as an independent native NetLinx control port from a
networked NetLinx Central Controller.
USB Port
The USB-mini A/B “Host” port on the rear of the TX connects to a PC. The Host port forwards HID keyboard and
mouse data received from a directed DXLink Receiver’s USB port (the Receiver can be either Fiber or Twisted Pair).
For USB port information, see page 23.

Overview DXLink Fiber, Duplex
20
Instruction Manual – DXLink™ Fiber Transmitters and Receivers, Duplex
Fiber Optic Transceiver
The fiber optic transceiver transports digital video, embedded audio, Ethernet, and bidirectional control over fiber optic
cable to a DXLink Fiber Input Board, including digitally transcoded analog video signals. The DXLink Fiber path
supports HDCP. If the latch is black or has a black label, the SFP+ fiber optic transceiver accepts multimode cable; if the
latch is blue or has a blue label, the SFP+ fiber optic transceiver accepts single mode cable.
DXLink Fiber Receivers, Duplex
The MMF-D RX and SMF-D RX are identical except for the type of fiber optic transceiver. The MMF-D RX has a
multimode transceiver (the latch is black or has a black label), and the SMF-D RX has a single mode transceiver
(the latch is blue or has a blue label).
Note: If a DVI-D signal is used (via a DVI-to-HDMI cable), the advanced audio support from HDMI will not be
available out the Receiver.
DXLink Fiber Receivers, Duplex – Front View
(RX-DXLINK-HDMI-MMF-D and RX-DXLINK-HDMI-SMF-D)
Components located on the front of the DXLink Fiber Receivers, Duplex (left to right):
Power LED – Indicates when the unit is powered on.
Video and Audio LEDs – Indicate the presence of video and embedded audio signals through the unit.
Scaling button and LEDs – Use the Scaling button to select one of the 3 scaling options: Bypass, Auto
(default), or Manual. For information on using the Scaling button and options for persisting the Scaling
Mode, see page 50.
Program port – This port will be supported in a future firmware upgrade.
IR LEDs – TX and RX LEDs indicate active IR communication.
232 (RS-232) LEDs – TX and RX LEDs indicate active serial communication (for details, see page 47).
NetLinx LEDs – Link/Act LED indicates network communication activity. The Status LED indicates that the
LAN connection is active.
CEC LED – CEC is not currently supported.
USB LED – When illuminated, the LED indicates that the USB port connection has been established (for
details, see page 23).
ID Pushbutton – Places the unit in ID Mode for setting the NetLinx ID (device only) and provides additional
functionality, such as placing the unit in Static IP Mode or DHCP Mode (for details see page 57).
Warning: DXLink Fiber units use laser transceivers, which are Class 1 Eye Safe per IEC 60825-1/CDRH
requirements. While the Class 1 category indicates that the invisible laser used is safe, we recommend
avoiding direct eye exposure when using any optical fiber products (see the OSHA directive on page 13).
FIG. 5 DXLink Fiber Receiver, Duplex - front view
Video and Audio LEDs
Power LED
USB LED
IR LEDs
232 (serial) LEDs
NetLinx LEDs
ID Pushbutton
Scaling LEDs
Program port
CEC LED
Scaling button
