ADSP-BF707 EZ-KIT Lite®
Evaluation System Manual
Revision 1.0, May 2014
Part Number
82-000707-01
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106
This datasheet has been downloaded fromhttp://www.digchip.com at this page

Copyright Information
©2014 Analog Devices, Inc., ALL RIGHTS RESERVED. This document
may not be reproduced in any form without prior, express written consent
from Analog Devices, Inc.
Printed in the USA.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices logo, Blackfin, CrossCore, EngineerZone, EZ-Board,
and EZ-KIT Lite are registered trademarks of Analog Devices, Inc.
Blackfin+ is a trademark of Analog Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.

Regulatory Compliance
The ADSP-BF707 EZ-KIT Lite is designed to be used solely in a labora-
tory environment. The board is not intended for use as a consumer end
product or as a portion of a consumer end product. The board is an open
system design which does not include a shielded enclosure and therefore
may cause interference to other electrical devices in close proximity. This
board should not be used in or near any medical equipment or RF devices.
The ADSP-BF707 EZ-KIT Lite is in the process of being certified to com-
ply with the essential requirements of the European EMC directive
2004/108/EC and therefore carries the “CE” mark.
The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent dam-
age may occur on devices subjected to high-energy discharges. Proper ESD
precautions are recommended to avoid performance degradation or loss of
functionality. Store unused EZ-KIT Lite boards in the protective shipping
package.

ADSP-BF707 EZ-KIT Lite Evaluation System Manual v
CONTENTS
PREFACE
Product Overview ............................................................................ x
Purpose of This Manual ................................................................ xiii
Intended Audience ........................................................................ xiii
Manual Contents ........................................................................... xiv
What’s New in This Manual ........................................................... xiv
Technical Support ........................................................................... xv
Supported Processors ....................................................................... xv
Supported Tools ............................................................................. xvi
Product Information ...................................................................... xvi
Analog Devices Web Site .......................................................... xvi
EngineerZone .......................................................................... xvii
Notation Conventions ................................................................... xvii

Contents
vi ADSP-BF707 EZ-KIT Lite Evaluation System Manual
USING ADSP-BF707 EZ-KIT LITE
Package Contents ......................................................................... 1-2
ADSP-BF707 EZ-Board ............................................................... 1-3
Default Configuration .................................................................. 1-3
EZ-KIT Lite Installation ............................................................... 1-5
EZ-KIT Lite Session Startup ......................................................... 1-6
Evaluation License ........................................................................ 1-8
DDR2 Memory ............................................................................ 1-8
SPI Flash ...................................................................................... 1-9
Housekeeping ADC .................................................................... 1-10
UART0 Interface ........................................................................ 1-10
CAN0 Interface .......................................................................... 1-10
CAN1 Interface .......................................................................... 1-11
USB Interface ............................................................................. 1-11
SD Interface ............................................................................... 1-12
Debug Interface .......................................................................... 1-12
Power-On-Self Test ..................................................................... 1-12
Expansion Interface .................................................................... 1-13
Power Architecture ..................................................................... 1-13
Power Measurements .................................................................. 1-14
Example Programs ...................................................................... 1-14
Reference Design Information ..................................................... 1-15

ADSP-BF707 EZ-KIT Lite Evaluation System Manual vii
Contents
ADSP-BF707 EZ-KIT LITE HARDWARE REFERENCE
System Architecture ...................................................................... 2-2
Software-Controlled Switches (SoftConfig) .................................... 2-3
Overview of SoftConfig ........................................................... 2-3
SoftConfig on the ADSP-BF707 EZ-KIT LITE ...................... 2-7
Programming SoftConfig Switches ........................................... 2-8
Push Buttons and Switches .......................................................... 2-16
Boot Mode Select Switch (SW1) ............................................ 2-17
Reset Push Button (SW2) ...................................................... 2-17
GPIO Push Buttons (SW3-4) ................................................ 2-17
Jumpers ...................................................................................... 2-18
Power Jumpers (P8-12, P14-18) ............................................. 2-18
LEDs .......................................................................................... 2-19
GPIO LEDs (LED3–5) ......................................................... 2-20
Reset LED (LED6) ................................................................ 2-20
Power LED (LED2) ............................................................... 2-20
SYS_FAULT LED (LED1) ..................................................... 2-20
Connectors ................................................................................. 2-21
Expansion Interface III Connectors (P1A-C) .......................... 2-22
Power Connector (P13) ......................................................... 2-22
USB to UART Connector (P6) .............................................. 2-22
USB Connector (P5) ............................................................. 2-23
RF Wireless Connector (J3) ................................................... 2-23
HADC SMC Connectors (J7, J8, J9) ..................................... 2-23

Contents
viii ADSP-BF707 EZ-KIT Lite Evaluation System Manual
HADC Connector (JP1) ....................................................... 2-24
SD Connector (J6) ................................................................ 2-24
CAN0 Connector (J4) ........................................................... 2-24
CAN1 Connector (J5) ........................................................... 2-25
JTAG/SWD/SWO Connector (P3) ....................................... 2-25
TRACE and JTAG/SWD/SWO Connector (P2) .................... 2-25
ADSP-BF707 EZ-KIT LITE BILL OF MATERIALS
ADSP-BF707 EZ-KIT LITE SCHEMATIC
INDEX

ADSP-BF707 EZ-KIT Lite Evaluation System Manual ix
PREFACE
Thank you for purchasing the ADSP-BF707 EZ-KIT Lite®, Analog
Devices, Inc. low-cost evaluation system for the ADSP-BF70x Blackfin®
processors.
The ADSP-BF707 processor is a member of the Blackfin family of prod-
ucts. Blackfin processors combine a dual-MAC state-of-the-art signal
processing engine, the advantages of a clean, orthogonal RISC-like micro-
processor instruction set, and single-instruction, multiple-data (SIMD)
multimedia capabilities into a single instruction-set architecture. New
enhancements to the Blackfin+™ core add 32-bit MAC and 16-bit com-
plex MAC support, cache enhancements, branch prediction and other
instruction set improvements—all while maintaining instruction set com-
patibility to previous Blackfin products.
The EZ-KIT Lite is shipped with all of the necessary hardware—you can
start the evaluation immediately. The package contains the standalone
evaluation board, CE-approved power supply, and USB cable. The
EZ-KIT Lite version ships with an ICE-1000 emulator, while the
EZ-Board® version is supported by the ICE-1000 or ICE-2000 emulator.
Expansion Interface III is provided for connecting a camera or audio
extender board.
Traditional mechanical switches for changing the board’s factory setup
have been removed in favor of I2C controlled software switches. The only
remaining mechanical switches are the boot mode switch and push
buttons.

Product Overview
x ADSP-BF707 EZ-KIT Lite Evaluation System Manual
The evaluation board is designed to be used in conjunction with the
CrossCore® Embedded Studio (CCES) development tools to test capabil-
ities of the ADSP-BF707 Blackfin processors. The CCES development
environment aids advanced application code development and debug,
such as:
• Create, compile, assemble, and link application programs written
in C++, C, and assembly
• Load, run, step, halt, and set breakpoints in application programs
• Read and write data and program memory
• Read and write core and peripheral registers
Product Overview
The board features:
• Analog Devices ADSP-BF707 processor
• 184-ball BGA package
• 25 MHz CLKIN core oscillator
• DDR2 memory (DMC0) chip
• 128M x 16-bit (2G bit)
• Micron MT47H128M16
• Quad SPI Flash (SPI2)
• 32M bit serial flash memory
• Winbond W25Q32

ADSP-BF707 EZ-KIT Lite Evaluation System Manual xi
Preface
• RF Wireless
• 4 x 2 connector
• 0.05” socket
• Universal Asynchronous Receiver/Transmitter (UART0)
• FTDI FT232RQ USB to UART converter
• USB Mini B connector
• Controller Area Network (CAN) interfaces
• CAN0—NXP TJA1041 transceiver and RJ11 connector
• CAN1—NXP TJA1041 transceiver and RJ11 connector
• USB0 interface
• Micro AB connector
•HADC
• VIN0 RTC battery through jumper
• VIN1 timer through RC
• VIN2 0.1” header
• VIN3 0.1” header
• RTC
• 16MM coin connector
• 3V 125 mAh Li-ion
• CR1632

Product Overview
xii ADSP-BF707 EZ-KIT Lite Evaluation System Manual
• RESET controller
• Analog Devices ADM6315 microprocessor supervisory
circuits
• Debug (JTAG/SWD/TRACE) interface
• JTAG/SWD/SWO 10-pin 0.05” header for use with ADI
emulators
• TRACE/JTAG/SWD 38-pin Mictor header
• Power measurement
• INA3221 to measure 3V, VDD_INT and VDD_EXT
• INA230 to measure VDD_DMC0
•LEDs
• Six LEDs: one power (green), one board reset (red), one
SYS_FAULT (red), and three general-purpose (amber)
• Push buttons
• Three push buttons: one reset and two IRQ/Flag
• Expansion Interface III connectors (EI3)
•SMC0
•PPI
• SPORT
•SPI
•UART
• TWI
•TMR

ADSP-BF707 EZ-KIT Lite Evaluation System Manual xiii
Preface
•GPIOs
• PWR_IN
• GND/3.3V output
• External power supply
• CE compliant
• 5V @ 3.6 Amps
• Other features
• SD/MMC memory connector
• Boot mode switch
• 0.05-ohm resistors for processor current measurement
For information about the hardware components of the EZ-KIT Lite,
refer to ADSP-BF707 EZ-KIT Lite Bill Of Materials.
Purpose of This Manual
The ADSP-BF707 EZ-KIT Lite Evaluation System Manual provides
instructions for installing the product hardware (board). The text
describes operation and configuration of the board components and pro-
vides guidelines for running your own code on the ADSP-BF707 EZ-KIT
Lite. Finally, a schematic and a bill of materials are provided for reference.
Intended Audience
The primary audience for this manual is a programmer who is familiar
with Analog Devices processors. This manual assumes that the audience
has a working knowledge of the appropriate processor architecture,
instruction set, and C/C++ programming languages.

Manual Contents
xiv ADSP-BF707 EZ-KIT Lite Evaluation System Manual
Programmers who are unfamiliar with Analog Devices processors can use
this manual, but should supplement it with other texts (such as the
ADSP-BF70x Blackfin+ Processor Hardware Reference and the
ADSP-BF70x Blackfin+ Processor Programming Reference) that describe
your target architecture.
Programmers who are unfamiliar with CrossCore Embedded Studio
should refer to the CCES online help.
Manual Contents
The manual consists of:
• Chapter 1, Using ADSP-BF707 EZ-KIT Lite
Describes EZ-KIT Lite functionality from a programmer’s perspec-
tive and provides a simplified memory map of the processor.
• Chapter 2, ADSP-BF707 EZ-KIT Lite Hardware Reference
Provides information about the EZ-KIT Lite hardware
components.
• Appendix A, ADSP-BF707 EZ-KIT Lite Bill Of Materials
Provides a list of hardware components used to manufacture the
EZ-KIT Lite board.
• Appendix B, ADSP-BF707 EZ-KIT Lite Schematic
Lists the resources for board-level debugging.
What’s New in This Manual
This is the first revision (Revision 1.0) of the ADSP-BF707 EZ-KIT Lite
Evaluation System Manual.

ADSP-BF707 EZ-KIT Lite Evaluation System Manual xv
Preface
Technical Support
You can reach Analog Devices processors and DSP technical support in
the following ways:
• Post your questions in the processors and DSP support community
at EngineerZone®:
http://ez.analog.com/community/dsp
• Submit your questions to technical support directly at:
http://www.analog.com/support
• E-mail your questions about processors and processor applications
to:
[email protected] or
[email protected] (Greater China support)
• Contact your Analog Devices sales office or authorized distributor.
Locate one at:
www.analog.com/adi-sales
• Send questions by mail to:
Processors and DSP Technical Support
Analog Devices, Inc.
Three Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
USA
Supported Processors
This evaluation system supports Analog Devices ADSP-BF707 Blackfin
processors.

Supported Tools
xvi ADSP-BF707 EZ-KIT Lite Evaluation System Manual
Supported Tools
Information on supported tools for the ADSP-BF707 EZ-KIT Lite and
the ADSP-BF70x family of Blackfin processors is available at:
http://www.analog.com/BF707EZKit
Product Information
Product information can be obtained from the Analog Devices Web site
and the online help system.
Analog Devices Web Site
The Analog Devices Web site, www.analog.com, provides information
about a broad range of products—analog integrated circuits, amplifiers,
converters, and digital signal processors.
To access a complete technical library for each processor family, go to
http://www.analog.com/processors/technical_library. The manuals
selection opens a list of current manuals related to the product as well as a
link to the previous revisions of the manuals. When locating your manual
title, note a possible errata check mark next to the title that leads to the
current correction report against the manual.
Also note, myAnalog.com is a free feature of the Analog Devices Web site
that allows customization of a Web page to display only the latest
information about products you are interested in. You can choose to
receive weekly e-mail notifications containing updates to the Web pages
that meet your interests, including documentation errata against all manu-
als. myAnalog.com provides access to books, application notes, data sheets,
code examples, and more.

ADSP-BF707 EZ-KIT Lite Evaluation System Manual xvii
Preface
Visit myAnalog.com (found on the Analog Devices home page) to sign up.
If you are a registered user, just log on. Your user name is your e-mail
address.
EngineerZone
EngineerZone is a technical support forum from Analog Devices. It allows
you direct access to ADI technical support engineers. You can search
FAQs and technical information to get quick answers to your embedded
processing and DSP design questions.
Use EngineerZone to connect with other DSP developers who face similar
design challenges. You can also use this open forum to share knowledge
and collaborate with the ADI support team and your peers. Visit
http://ez.analog.com to sign up.
Notation Conventions
Text conventions used in this manual are identified and described as
follows.
Example Description
File > Close Titles in reference sections indicate the location of an item within the
CCES environment’s menu system (for example, the Close command
appears on the File menu).
{this | that} Alternative required items in syntax descriptions appear within curly
brackets and separated by vertical bars; read the example as this or
that. One or the other is required.
[this | that] Optional items in syntax descriptions appear within brackets and sepa-
rated by vertical bars; read the example as an optional this or that.
[this,…] Optional item lists in syntax descriptions appear within brackets delim-
ited by commas and terminated with an ellipse; read the example as an
optional comma-separated list of this.

Notation Conventions
xviii ADSP-BF707 EZ-KIT Lite Evaluation System Manual
.SECTION Commands, directives, keywords, and feature names are in text with
letter gothic font.
filename Non-keyword placeholders appear in text with italic style format.
Note: For correct operation, ...
A Note provides supplementary information on a related topic. In the
online version of this book, the word Note appears instead of this
symbol.
Caution: Incorrect device operation may result if ...
Caution: Device damage may result if ...
A Caution identifies conditions or inappropriate usage of the product
that could lead to undesirable results or product damage. In the online
version of this book, the word Caution appears instead of this symbol.
Warning: Injury to device users may result if ...
A Warning identifies conditions or inappropriate usage of the product
that could lead to conditions that are potentially hazardous for the
devices users. In the online version of this book, the word Warning
appears instead of this symbol.
Example Description




ADSP-BF707 EZ-KIT Lite Evaluation System Manual 1-1
1 USING ADSP-BF707 EZ-KIT
LITE
This chapter provides information to assist you with development of pro-
grams for the ADSP-BF707 EZ-KIT Lite evaluation system.
The following topics are covered.
•Package Contents
•ADSP-BF707 EZ-Board
•Default Configuration
•EZ-KIT Lite Installation
•EZ-KIT Lite Session Startup
•Evaluation License
•DDR2 Memory
•SPI Flash
•Housekeeping ADC
•UART0 Interface
•CAN0 Interface
•CAN1 Interface
•USB Interface
•SD Interface

Package Contents
1-2 ADSP-BF707 EZ-KIT Lite Evaluation System Manual
•Debug Interface
•Power-On-Self Test
•Expansion Interface
•Power Architecture
•Power Measurements
•Example Programs
•Reference Design Information
Package Contents
Your ADSP-BF707 EZ-KIT Lite package contains the following items.
• ADSP-BF707 EZ-Board
• Universal 5V DC power
• USB A to micro B cable
• USB micro A to A receptacle cable
• ICE-1000 (only in the EZ-LIT Lite version)
• Standoffs and screws in a bag
• Release note
• 2GB SD card
Contact the vendor where you purchased your EZ-KIT Lite or contact
Analog Devices, Inc. if any item is missing.
