DEMO MANUAL DC2328A
Description
LTM4651
EN55022B Compliant 58V, 24W
Inverting-Output DC/DC µModule Regulator
Demonstration circuit 2328A is an inverting buck-boost
converter with 12V to 34V input voltage, –24V output volt-
age and max 2A output current capability, which features
the LTM
®
4651Y. The LTM4651 is an ultralow noise, 58V,
24W inverting-topology DC/DC µModule regulator. It is
designed to meet the radiated emissions requirement of
EN55022B. A switching frequency range of 250kHz to
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Analog
Devices, Inc. All other trademarks are the property of their respective owners.
performance summary
BoarD photo
3MHz is supported and the module can synchronize to
an external clock. The LTM4651 data sheet must be read
in conjunction with this demo manual prior to working on
or modifying demo circuit DC2328A.
Design files for this circuit board are available at
http://www.linear.com/demo/DC2328A
Specifications are at TA= 25°C
DC2328A Top View
PARAMETER CONDITIONS VALUE
Input Voltage Range 12V to 34V
Output Voltage, VOUT 12VIN, 0A to 1A; 24VIN, 0A to 2A; 34VIN, 0A to 2A –24V ±2%
Maximum Output Current, IOUT Derating for Certain VIN and Thermal Conditions 2A
Default Operating Frequency 1.2MHz
Efficiency 24VIN, –24VOUT, 2A 87.5%

2
dc2328af
DEMO MANUAL DC2328A
Quick start proceDure
Demonstration circuit 2328A is easy to set up to evaluate
the performance of the LTM4651Y. Refer to Figure 1 for
the proper measurement equipment setup and follow the
procedure below:
1. With power off, connect the input power supply to VIN
(12V to 34V) and GND (input return).
2. Connect the – 24V output load between VOUT ( –) and
GND (+) (Initial load: no load).
3. Connect the DVMs to the input and output. Set the
default jumper position, JP2: ON.
4. Turn on the input power supply and check for the
proper output voltages. VOUT should be –24V ±2%.
5. Once the proper output voltages are established, adjust
the loads within the operating range and observe the
output voltage regulation, ripple voltage and other
parameters.
Note:When measuring the output or input voltage
ripple, do not use the long ground lead on the oscil-
loscope probe. See Figure 2 for the proper scope probe
technique. Short, stiff leads need to be soldered to
the (+) and (–) terminals of an output capacitor. The
probe’s ground ring needs to touch the (–) lead and
the probe tip needs to touch the (+) lead.
Figure1. Proper Measurement Equipment Setup
Figure2. Measuring Output Voltage Ripple
DC2328 F01
LOAD
VIN
12V TO 34V
+–
IOUT
SHUNT
10mΩ
IIN
SHUNT
10mΩ
+–
–
+
VIN
–
+
VOUT
–
+
+ –
VOUT GND
COUT

3
dc2328af
DEMO MANUAL DC2328A
Quick start proceDure
Figure3. Efficiency vs Load Current (VOUT = –24V) Figure4. Efficiency vs Load Current (VOUT = –12V)
LOAD CURRENT (A)
EFFICIENCY (%)
DC2328A F03
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
0.0 2.52.01.51.00.5
12VIN
24VIN
34VIN
LOAD CURRENT (A)
0
0.5
1
1.5
2
2.5
3
3.5
70
75
80
85
90
95
EFFICIENCY (%)
DC2328 F04
5VIN, 475kHz
12VIN, 825kHz
24VIN, 1.1MHz
36VIN, 1.2MHz
Optional –12VOUT
Besides the default –24V output voltage which shows the
full capacity of LTM4651, it is very easy to customize
the DC2328A demo board to make other negative output
voltages available. As an example, to implement –12VOUT
with 5V – 36V VIN,
1. Change R4 from 14k to 39k. This sets the minimum
operation input voltage, 5V for this case.
2. Change R1 and R8 from 240k to 121k. This sets the
output voltage, –12V for this case.
Check the input and output capacitor voltage rating.
And then it is done.
However, to maximize the efficiency of the regulator for
different input voltage, the switching frequency can be
adjusted by changing R13. For the recommended switch-
ing frequency for given input voltage and given output
voltage, please refer to the LTM4651 data sheet.
The results for the –12VOUT are listed below.
For 5V
IN
, change R13 from 124k to 1.3MΩ. The switching
frequency will be 475kHz. For 12VIN, change R13 from
124k to 237k. The switching frequency will be 825kHz.
For 24VIN, change R13 from 124k to 143k. The switch-
ing frequency will be 1.1MHz. For 36VIN, keep the default
R13. The switching frequency will be 1.2MHz.
The optimized efficiency for –12VOUT is as shown in
Figure4.

4
dc2328af
DEMO MANUAL DC2328A
Figure6. 0A ←→ 2A Load Transients
(VIN = 24V, VOUT = –24V)
Figure7. 0A ←→ 2A Load Transients
(VIN = 34V, VOUT = –24V)
1ms/DIV
VOUT (AC)
200mV/DIV
IOUT
1A/DIV
VIN
10V/DIV
DC2328 F06
1ms/DIV
VOUT (AC)
200mV/DIV
IOUT
1A/DIV
VIN
10V/DIV
DC2328 F07
Figure5. 0A ←→ 1A Load Transients
(VIN = 12V, VOUT = –24V)
1ms/DIV
VOUT (AC)
200mV/DIV
IOUT
1A/DIV
VIN
10V/DIV
DC2328 F05
Quick start proceDure
Figure8. Output Voltage Ripple
(VIN = 12V, VOUT = –24V, 1A Load)
Figure9. Output Voltage Ripple
(VIN = 24V, VOUT = –24V, 2A Load)
Figure10. Output Voltage Ripple
(VIN = 34V, VOUT = –24V, 2A Load)
500ns/DIV
VOUT (AC)
20mV/DIV
VSW
10V/DIV
DC2328 F08
500ns/DIV
VOUT (AC)
50mV/DIV
VSW
20V/DIV
DC2328 F09 500ns/DIV
VOUT (AC)
50mV/DIV
VSW
20V/DIV
DC2328 F10

5
dc2328af
DEMO MANUAL DC2328A
AMPLITUDE (dBµV/m)
50
60
70
40
30
20
10
–10
0
FREQUENCY (MHz)
30 830
130 230 330 430 530 630 730 930 1000
DC2328 F11
[1] HORIZONTAL
[2] VERTICAL
QPK LIMIT
FORMAL
MEAS DIST 10m
SPEC DIST 10m
+
AMPLITUDE (dBµV/m)
50
60
70
40
30
20
10
–10
0
FREQUENCY (MHz)
30 830
130 230 330 430 530 630 730 930 1000
DC2328 F12
[1] HORIZONTAL
[2] VERTICAL
QPK LIMIT
FORMAL
MEAS DIST 10m
SPEC DIST 10m
+
AMPLITUDE (dBµV/m)
50
60
70
40
30
20
10
–10
0
FREQUENCY (MHz)
30 830
130 230 330 430 530 630 730 930 1000
DC2389 F13
[1] HORIZONTAL
[2] VERTICAL
QPK LIMIT
FORMAL
MEAS DIST 10m
SPEC DIST 10m
+
Figure11. Radiated Emissions Scan of the LTM4651. Producing –24VOUT at 1A, from 12VIN.
DC2328A Hardware. fSW = 1.2MHz. Measured in a 10m Chamber. Peak Detect Method
Figure12. Radiated Emissions Scan of the LTM4651 Producing –24VOUT at 2A, from 25VIN.
DC2328 Hardware. fSW = 1.2MHz. Measured in a 10m Chamber. Peak Detect Method
Figure13. Radiated Emissions Scan of the LTM4651. Producing –24V at 2A, from 34V.
DC2328A Hardware. fSW = 1.2MHz. Measured in a 10m Chamber. Peak Detect Method

6
dc2328af
DEMO MANUAL DC2328A
parts List
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 5 C1, C3, C8, C25, C28 CAP., X7R, 4.7µF, 80V, 10%, 1210 MURATA, GRM32ER71K475KE14L
2 6 C2, C4, C5, C6, C16, C17 CAP., X7R, 10µF, 50V, 10%, 1210 MURATA, GRM32ER71H106KA12L
3 0 C19, C20, C21, C22, C23 CAP., OPT, 1210 OPT
4 1 C7 CAP., ALUM., 100µF, 40V, 10x10.5 SUN ELECTRONIC, 40HVP100M
5 1 C9 CAP., X7R, 0.1µF, 100V, 10%, 0805 MURATA, GRM21BR72A104KAC4K
6 1 C10 CAP., X7R, 1µF, 50V, 10%, 0805 MURATA, GRM21BR71H105KA12L
7 1 C11 CAP., X7R, 4.7nF, 50V, 10%, 0603 MURATA, GRM188R71H472KA01D
8 1 C12 CAP., X7R, 3.3nF, 50V, 10%, 0603 MURATA, GRM188R71H332KA01D
9 1 C13 CAP., X7R, 100nF, 50V, 10%, 0603 MURATA, GRM188R71H104KA93D
10 0 C15 CAP., OPT, 10X10.2 OPT
11 0 C18 CAP., OPT, 0805 OPT
12 0 C24 CAP., OPT, 0603 OPT
13 1 C26 CAP., OS-CON., 82µF, 35V, 8x11.9 PANASONIC, 35SVPF82M
14 1 C27 CAP., X5R, 1µF, 25V, 10%, 0603 MURATA, GRM188R61E105KA12D
15 0 D1 DIODE, OPT, SOT23 OPT
16 0 D2 DIODE, OPT, SMA OPT
17 5 E1-E5 TESTPOINT, TURRET, .061" MILL-MAX, 2308-2-00-80-00-00-07-0
18 8 E6-E13 TESTPOINT, TURRET, .094" MILL-MAX, 2501-2-00-80-00-00-07-0
19 0 JP1 HEADER, OPT OPT
20 1 JP2 HEADER, 1X3, 0.079 WURTH ELEKTRONIK, 62000311121
21 6 J1, J2, J3, J4, J5, J6 JACK, BANANA KEYSTONE, 575-4
22 0 L1 IND, OPT, 1206 OPT
23 0 L2 IND, OPT, IHLP3232CZ-01 OPT
24 2 R1, R8 RES., 240k, 0.1%, 0603 PANASONIC, ERA3AEB244V
25 1 R2 RES., 332Ω, 1%, 0603 VISHAY, CRCW0603332RFKEA
26 1 R3 RES., 102k, 1%, 0603 VISHAY, CRCW0603102KFKEA
27 1 R4 RES., 14k, 1%, 0603 VISHAY, CRCW060314K0FKEA
28 3 R5, R10, R20 Res., 10Ω, 1%, 0603 VISHAY, CRCW060310R0FKEA
29 0 R7, R9, R12, R14, R19, R22, R23, R24 RES., OPT, 0603 OPT
30 1 R13 RES., 124k, 1%, 0603 VISHAY, CRCW0603124KFKEA
31 1 R18 RES., 0Ω, 1%, 0603 VISHAY, CRCW06030000Z0EA
32 1 U1 I.C., LTM4651EY, BGA77-15X9X5.01 LINEAR TECH., LTM4651EY#PBF
33 1 XJP2 SHUNT, 0.079" CENTER WURTH ELEKTRONIK, 60800213421
34 4 (STAND-OFF) STAND-OFF, NYLON 0.50" WURTH ELEKTRONIK, 702935000
35 1 FAB, PRINTED CIRCUIT BOARD DEMO CIRCUIT, 2328A
36 2 STENCILS TOP AND BOTTOM STENCIL DC2328A

7
dc2328af
DEMO MANUAL DC2328A
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-
tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
schematic Diagram
5
5
4
4
3
3
2
2
1
1
D
D
C
C
B
B
A
A
0.1%
35V
m
NOTE: UNLESS OTHERWISE SPECIFIED 1. ALL RESISTORS AND CAPACITORS ARE 0603.
0.1%
40V
8X11.9
10X10.5
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
4
Friday, May 12, 2017
11
LOW EMI INVERTING BUCK-BOOST
LT
JEOFERRY W.
N/A
LTM4651EY
DEMO CIRCUIT 2328A
MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
4
Friday, May 12, 2017
11
LOW EMI INVERTING BUCK-BOOST
LT
JEOFERRY W.
N/A
LTM4651EY
DEMO CIRCUIT 2328A
MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
4
Friday, May 12, 2017
11
LOW EMI INVERTING BUCK-BOOST
LT
JEOFERRY W.
N/A
LTM4651EY
DEMO CIRCUIT 2328A
MODULE REGULATOR
REVISION HISTORY
DESCRIPTION DATEAPPROVEDECO REV
PRODUCTION
4 05-12-17
__
JEOFFERY W.
REVISION HISTORY
DESCRIPTION DATEAPPROVEDECO REV
PRODUCTION
4 05-12-17
__
JEOFFERY W.
REVISION HISTORY
DESCRIPTION DATEAPPROVEDECO REV
PRODUCTION
4 05-12-17
__
JEOFFERY W.
U1
LTM4651EY
SVIN C3
VD A4 VD B4
RUN
F4
VOUT-
A5
VOUT-
B5
VIN A1 VIN A2 VIN A3 VIN B3
VD C4
VOUT-
C5
VOUT-
D5
VOUT-
E5
VOUT-
F5
VOUT-
G5
VOUT-
H5
VOUT-
J5
VOUT-
K5
VOUT-
L5
VOUT-
G4
VOUT-
H3
VOUT-
J4 VOUT-
J3
VOUT-
K4
VOUT-
L4
SW H4
PGND K1 PGND K2 PGND K3 PGND L1 PGND L2 PGND L3
GNDSNS H1 GNDSNS G1
SVOUT- H2 SVOUT- G2 SVOUT- E4
PGDFB D2
PGOOD D1
GND
D4
TEMP+
J1
TEMP+
J6
TEMP-
J2
TEMP-
J7 NC A6
NC A7
NC B6
NC B7
NC C6
NC C7
NC D6
NC D7
NC E6
NC E7
NC F6
NC F7
NC G6
NC G7
NC H6
NC H7
NC K6
NC K7
NC L6
NC L7
NC B2
EXTVCC
F3
INTVCC
G3
CLKIN
B1
ISETa
F2
ISETb
F1
COMPa
E2
COMPb
E1
VINREG
D3
FSET
E3
VOUT-
C2
VOUT-
C1
C8 4.7uF 80V 1210
R8
240K
R4
14K
J4
VOUT
E6
CLKIN
C6 10uF 50V
1210
R2
332
E12
TEMP+
R9 OPT
D1 OPT
C17 10uF
50V
1210
R14 OPT
R19 OPT
E5 VEMI
JP1 OPT
1 3 2
+
C7 100uF
R1
240K
C24 OPT
R10 10
E9
SGND
E7
PGOOD
C16 10uF 50V
1210
C18
OPT
50V 0805
C25 4.7uF 80V 1210
C20 OPT
1210
E4 VOUT
C5 10uF
50V
1210
E3 GND_TEST
C2
10uF 50V
1210
C21 OPT
1210
R12 OPT
+
C15 OPT
R24 OPT
C3 4.7uF 80V 1210
R18
0
J6
GND
R22 OPT
E11
INTVCC
C13 100nF J2
GND
C23
OPT
50V 1210
J5
VEMI
R3 102K
C4
10uF 50V
1210
R5
10
E13
TEMP-
C27 1uF
C9
0.1uF
100V
0805
E10
SVIN
C19
OPT
50V 1210
J1
VIN
12V - 34V
JP2
OFF ON
RUN
1
3
2
C12 3.3nF
R23 OPT
R20
10
C10 1uF
50V 0805
C28 4.7uF 80V 1210
C11 4.7nF
E1 VIN
D2 OPT
12
E2 GND
L1
OPT 1206
L2
OPT
IHLP-3232CZ-01
J3
GND
-24V/2A MAX
+
C26
82uF
R13 124k
C1 4.7uF 80V 1210
R7 OPT
E8
RUN C22
OPT
50V 1210
CLKIN
INTVCC
VIN
VD
RUN
EXTVCC
SW
CLKIN PGOOD
RUN
SGND
VINREG
SVIN
SVIN
TEMP+
TEMP-
TEMP-
TEMP+
VD
SGND
INTVCC
SGND
PGOOD
VOUT-
SVIN
VINREG
EXTVCC
SGND
VOUT-
SVOUT-
VIN
SVOUT-
INTVCC
VOUT- VOUT-

8
dc2328af
DEMO MANUAL DC2328A
 LINEAR TECHNOLOGY CORPORATION 2017
LT 0617 • PRINTED IN USA
DEMONSTRATION BOARD IMPORTANT NOTICE
Linear Technology Corporation (LTC) provides the enclosed product(s) under the following AS IS conditions:
This demonstration board (DEMO BOARD) kit being sold or provided by Linear Technology is intended for use for ENGINEERING DEVELOPMENT
OR EVALUATION PURPOSES ONLY and is not provided by LTC for commercial use. As such, the DEMO BOARD herein may not be complete
in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including but not limited to product safety
measures typically found in finished commercial goods. As a prototype, this product does not fall within the scope of the European Union
directive on electromagnetic compatibility and therefore may or may not meet the technical requirements of the directive, or other regulations.
If this evaluation kit does not meet the specifications recited in the DEMO BOARD manual the kit may be returned within 30 days from the date
of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY THE SELLER TO BUYER AND IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE. EXCEPT TO THE EXTENT OF THIS INDEMNITY, NEITHER PARTY SHALL BE LIABLE TO THE OTHER FOR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user releases LTC from all claims
arising from the handling or use of the goods. Due to the open construction of the product, it is the user’s responsibility to take any and all
appropriate precautions with regard to electrostatic discharge. Also be aware that the products herein may not be regulatory compliant or
agency certified (FCC, UL, CE, etc.).
No License is granted under any patent right or other intellectual property whatsoever. LTC assumes no liability for applications assistance,
customer product design, software performance, or infringement of patents or any other intellectual property rights of any kind.
LTC currently services a variety of customers for products around the world, and therefore this transaction is not exclusive.
Please read the DEMO BOARD manual prior to handling the product. Persons handling this product must have electronics training and
observe good laboratory practice standards. Common sense is encouraged.
This notice contains important safety information about temperatures and voltages. For further safety concerns, please contact a LTC application
engineer.
Mailing Address:
Linear Technology
1630 McCarthy Blvd.
Milpitas, CA 95035
Copyright © 2004, Linear Technology Corporation

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Analog Devices Inc.:
DC2328A
