FEATURES
Complete supervisory and sequencing solution for up to
10 supplies
10 supply fault detectors enable supervision of supplies to
<0.5% accuracy at all voltages at 25°C
<1.0% accuracy across all voltages and temperatures
5 selectable input attenuators allow supervision of supplies to
14.4 V on VH
6 V on VP1 to VP4 (VPx)
5 dual-function inputs, VX1 to VX5 (VXx)
High impedance input to supply fault detector with
thresholds between 0.573 V and 1.375 V
General-purpose logic input
10 programmable driver outputs, PDO1 to PDO10 (PDOx)
Open-collector with external pull-up
Push/pull output, driven to VDDCAP or VPx
Open collector with weak pull-up to VDDCAP or VPx
Internally charge-pumped high drive for use with external
N-FET (PDO1 to PDO6 only)
Sequencing engine (SE) implements state machine control
of PDOx outputs
State changes conditional on input events
Enables complex control of boards
Power-up and power-down sequence control
Fault event handling
Interrupt generation on warnings
Watchdog function can be integrated in SE
Program software control of sequencing through SMBus
Complete voltage margining solution for 6 voltage rails
12-bit ADC for readback of all supervised voltages
1 internal and 2 external temperature sensors
Reference input (REFIN) has 2 input options
Driven directly from 2.048 V (±0.25%) REFOUT pin
More accurate external reference for improved
ADC performance
Device powered by the highest of VPx, VH for improved
redundancy
User EEPROM: 256 bytes
Industry-standard, 2-wire bus interface (SMBus)
Guaranteed PDO low with VH, VPx = 1.2 V
Available in 40-lead, 6 mm × 6 mm LFCSP and
48-lead, 7 mm × 7 mm TQFP packages
For more information about the ADM1063 register map,
refer to the AN-698 Application Note at www.analog.com.
FUNCTIONAL BLOCK DIAGRAM
04632-001
PDO7
PDO8
PDO9
PDO10
PDOGND
VDDCA P
VDD
ARBITRATOR
GNDVCCP
VX1
VX2
VX3
VX4
VX5
VP1
VP2
VP3
VP4
VH
A
GND
PROGRAMMABLE
RESET
GENERATORS
(SFDs)
DUAL-
FUNCTION
INPUTS
(LOGIC INPUTS
OR
SFDs)
SEQUENCING
ENGINE
CONFIGURABLE
OUTPUT
DRIVERS
(LV CAPABLE
OF DRIVING
LOGIC SIGNALS)
PDO1
PDO2
PDO3
PDO4
PDO5
PDO6
SD
A
SCL
A
1
A
0
SMBus
INTERFACE
REFOUTREFIN REFGND
VREF
12-BIT
SAR ADC
MUX
EEPROM
CLOSED-LOOP
MARGINING SYSTEM
ADM1063
D2ND1N D2PD1P
TEMP
SENSOR
INTERNAL
DIODE
CONFIGURABLE
OUTPUT
DRIVERS
(HV CAPABLE OF
DRIVING GATES
OF N-FET)
Figure 1.
APPLICATIONS
Central office systems
Servers/routers
Multivoltage system line cards
DSP/FPGA supply sequencing
In-circuit testing of margined supplies
GENERAL DESCRIPTION
The ADM1063 is a configurable supervisory/sequencing device
that offers a single-chip solution for supply monitoring and
sequencing in multiple supply systems. In addition to these
functions, the ADM1063 integrates a 12-bit ADC that can be
used to accurately read back up to 12 separate voltages.
The device also provides up to 10 programmable inputs for
monitoring undervoltage faults, overvoltage faults, or out-of-
window faults on up to 10 supplies. In addition, 10 programmable
outputs can be used as logic enables. Six of these programmable
outputs can provide up to a 12 V output for driving the gate of
an N-FET that can be placed in the path of a supply.

ADM1063
Rev. C | Page 2 of 32
TABLE OF CONTENTS
Features .............................................................................................. 1
Functional Block Diagram .............................................................. 1
Applications....................................................................................... 1
General Description ......................................................................... 1
Revision History ............................................................................... 2
Detailed Block Diagram .................................................................. 3
Specifications..................................................................................... 4
Pin Configurations and Function Descriptions ........................... 7
Absolute Maximum Ratings............................................................ 9
Thermal Resistance ...................................................................... 9
ESD Caution.................................................................................. 9
Typical Performance Characteristics ........................................... 10
Powering the ADM1063................................................................ 13
Inputs................................................................................................ 14
Supply Supervision..................................................................... 14
Programming the Supply Fault Detectors............................... 14
Input Comparator Hysteresis.................................................... 14
Input Glitch Filtering ................................................................. 15
Supply Supervision with VXx Inputs....................................... 15
VXx Pins as Digital Inputs ........................................................ 15
Outputs ............................................................................................ 16
Supply Sequencing Through Configurable Output Drivers. 16
Default Output Configuration.................................................. 16
Sequencing Engine ......................................................................... 17
Overview ..................................................................................... 17
Warnings...................................................................................... 17
SMBus Jump (Unconditional Jump)........................................ 17
Sequencing Engine Application Example............................... 18
Fault and Status Reporting........................................................ 19
Voltage Readback............................................................................ 20
Supply Supervision with the ADC ........................................... 20
Temperature Measurement System.............................................. 21
Remote Temperature Measurement ........................................ 21
Applications Diagram .................................................................... 23
Communicating with the ADM1063........................................... 24
Configuration Download at Power-Up................................... 24
Updating the Configuration ..................................................... 24
Updating the Sequencing Engine............................................. 25
Internal Registers........................................................................ 25
EEPROM ..................................................................................... 25
Serial Bus Interface..................................................................... 25
SMBus Protocols for RAM and EEPROM.............................. 27
Write Operations........................................................................ 27
Read Operations......................................................................... 29
Outline Dimensions....................................................................... 30
Ordering Guide .......................................................................... 31
REVISION HISTORY
7/11—Rev. B to Rev. C
Changes to Serial Bus Timing Parameter in Table 1.................... 4
Added Endnote 4 in Table 1............................................................ 4
Changes to Figure 3.......................................................................... 7
Added Exposed Pad Notation to Outline Dimensions ............. 30
Changes to Ordering Guide .......................................................... 31
5/08—Rev. A to Rev. B
Changes to Table 1............................................................................ 4
Changes to Powering the ADM1063 Section ............................. 13
Changes to Table 5.......................................................................... 14
Changes to Default Output Configuration Section ................... 16
Changes to Sequence Detector Section ....................................... 19
Changes to Temperature Measurement System Section ........... 21
Changes to Table 10........................................................................ 22
Changes to Configuration Download at Power-Up Section..... 24
Changes to Table 11........................................................................ 25
Changes to Figure 44 and Error Correction Section ................. 29
Changes to Ordering Guide .......................................................... 31
12/06—Rev. 0 to Rev. A
Updated Format..................................................................Universal
Changes to Features ..........................................................................1
Changes to Figure 2...........................................................................3
Changes to Table 1.............................................................................4
Changes to Table 2.............................................................................7
Changes to Absolute Maximum Ratings Section..........................9
Deleted Figure 17 to Figure 19...................................................... 12
Changes to Programming the Supply Fault Detectors Section... 14
Changes to Table 6.......................................................................... 14
Changes to Outputs Section.......................................................... 16
Changes to Fault Reporting Section ............................................ 20
Deleted Supply Margining Section .............................................. 21
Changes to Table 9.......................................................................... 21
Changes to Identifying the ADM1063
on the SMBus Section .................................................................... 28
Changes to Figure 34 and Figure 35............................................. 30
4/05—Revision 0: Initial Version

ADM1063
Rev. C | Page 3 of 32
Temperature measurement is possible with the ADM1063. The
device contains one internal temperature sensor and two pairs
of differential inputs for remote thermal diodes. These are
measured by the 12-bit ADC.
The logical core of the device is a sequencing engine. This state-
machine-based construction provides up to 63 different states.
This design enables very flexible sequencing of the outputs
based on the condition of the inputs.
The device is controlled via configuration data that can be
programmed into an EEPROM. The entire configuration can
be programmed using an intuitive GUI-based software package
provided by Analog Devices, Inc.
DETAILED BLOCK DIAGRAM
04632-002
GPI SIGNAL
CONDITIONING
SFD
GPI SIGNAL
CONDITIONING
SFD
SFD
SFD
SELECTABLE
ATTENUATOR
SELECTABLE
ATTENUATOR
DEVICE
CONTROLLER
OSC
EEPROM
SDA SCL A1 A0
SMBus
INTERFACE
REFOUTREFIN
REFGND
VREF
12-BIT
SAR ADC
ADM1063
CONFIGURABLE
OUTPUT DRIVER
(HV)
PDO1
PDO2
PDOGND
PDO3
VCCPGND
PDO4
PDO5
PDO8
PDO9
CONFIGURABLE
OUTPUT DRIVER
(HV)
PDO6
CONFIGURABLE
OUTPUT DRIVER
(LV)
PDO7
CONFIGURABLE
OUTPUT DRIVER
(LV)
PDO10
SEQUENCING
ENGINE
VX2
VX3
VX4
VP2
VP3
VP4
VH
VP1
VX1
AGND
VX5
VDD
ARBITRATOR
REG 5.25V
CHARGE PUMP
D2ND1N D2PD1P
TEMP
SENSOR
INTERNAL
DIODE
VDDCAP
Figure 2.

ADM1063
Rev. C | Page 4 of 32
SPECIFICATIONS
VH = 3.0 V to 14.4 V1, VPx = 3.0 V to 6.0 V1, TA= −40°C to +85°C, unless otherwise noted.
Table 1.
Parameter Min Typ Max Unit Test Conditions/Comments
POWER SUPPLY ARBITRATION
VH, VPx 3.0 V Minimum supply required on one of VH, VPx
VPx 6.0 V Maximum VDDCAP = 5.1 V, typical
VH 14.4 V VDDCAP = 4.75 V
VDDCAP 2.7 4.75 5.4 V Regulated LDO output
CVDDCAP 10 μF Minimum recommended decoupling capacitance
POWER SUPPLY
Supply Current, IVH, IVPx 4.2 6 mA VDDCAP = 4.75 V, PDO1 to PDO10 off, ADC off
Additional Currents
All PDO FET Drivers On 1 mA VDDCAP = 4.75 V, PDO1 to PDO6 loaded with 1 μA
each, PDO7 to PDO10 off
Current Available from VDDCAP 2 mA Maximum additional load that can be drawn from all
PDO pull-ups to VDDCAP
ADC Supply Current 1 mA Running round-robin loop
EEPROM Erase Current 10 mA 1 ms duration only, VDDCAP = 3 V
SUPPLY FAULT DETECTORS
VH Pin
Input Impedance 52 kΩ
Input Attenuator Error ±0.05 % Midrange and high range
Detection Ranges
High Range 6 14.4 V
Midrange 2.5 6 V
VPx Pins
Input Impedance 52 kΩ
Input Attenuator Error ±0.05 % Low range and midrange
Detection Ranges
Midrange 2.5 6 V
Low Range 1.25 3 V
Ultralow Range 0.573 1.375 V No input attenuation error
VXx Pins
Input Impedance 1 MΩ
Detection Range
Ultralow Range 0.573 1.375 V No input attenuation error
Absolute Accuracy ±1 % VREF error + DAC nonlinearity + comparator offset error
+ input attenuation error
Threshold Resolution 8 Bits
Digital Glitch Filter 0 μs Minimum programmable filter length
100 μs Maximum programmable filter length
ANALOG-TO-DIGITAL CONVERTER
Signal Range 0 VREFIN V The ADC can convert signals presented to the VH, VPx,
and VXx pins; VPx and VH input signals are attenuated
depending on the selected range; a signal at the pin
corresponding to the selected range is from 0.573 V to
1.375 V at the ADC input
Input Reference Voltage on REFIN Pin, VREFIN 2.048 V
Resolution 12 Bits
INL ±2.5 LSB Endpoint corrected, VREFIN = 2.048 V
Gain Error ±0.05 % VREFIN = 2.048 V

ADM1063
Rev. C | Page 5 of 32
Parameter Min Typ Max Unit Test Conditions/Comments
Conversion Time 0.44 ms One conversion on one channel
84 ms All 12 channels selected, 16× averaging enabled
Offset Error ±2 LSB VREFIN = 2.048 V
Input Noise 0.25 LSB rms Direct input (no attenuator)
TEMPERATURE SENSOR2
Local Sensor Accuracy ±3 °C VDDCAP = 4.75 V
Local Sensor Supply Voltage Coefficient −1.7 °C/V
Remote Sensor Accuracy ±3 °C VDDCAP = 4.75 V
Remote Sensor Supply Voltage Coefficient −3 °C
Remote Sensor Current Source 200 μA High level
12 μA Low level
Temperature for Code 0x800 0 °C VDDCAP = 4.75 V
Temperature for Code 0xC00 128 °C VDDCAP = 4.75 V
Temperature Resolution per Code 0.125 °C
REFERENCE OUTPUT
Reference Output Voltage 2.043 2.048 2.053 V No load
Load Regulation −0.25 mV Sourcing current, IDACxMAX = −100 μA
0.25 mV Sinking current, IDACxMAX = 100 μA
Minimum Load Capacitance 1 μF Capacitor required for decoupling, stability
PSRR 60 dB DC
PROGRAMMABLE DRIVER OUTPUTS
High Voltage (Charge Pump) Mode
(PDO1 to PDO6)
Output Impedance 500 kΩ
VOH 11 12.5 14 V IOH = 0 μA
10.5 12 13.5 V IOH = 1 μA
IOUTAVG 20 μA 2 V < VOH < 7 V
Standard (Digital Output) Mode
(PDO1 to PDO10)
VOH 2.4 V VPU (pull-up to VDDCAP or VPx) = 2.7 V, IOH = 0.5 mA
4.5 V VPU to VPx = 6.0 V, IOH = 0 mA
V
PU − 0.3 V VPU ≤ 2.7 V, IOH = 0.5 mA
VOL 0 0.50 V IOL = 20 mA
IOL320 mA Maximum sink current per PDOx pin
ISINK360 mA Maximum total sink for all PDOx pins
RPULL-UP 19 20 29 kΩ Internal pull-up
ISOURCE (VPx)32 mA
Current load on any VPx pull-ups, that is, total source
current available through any number of PDOx pull-
up switches configured onto any one VPx pin
Three-State Output Leakage Current 10 μA VPDO = 14.4 V
Oscillator Frequency 90 100 110 kHz All on-chip time delays derived from this clock
DIGITAL INPUTS (VXx, A0, A1)
Input High Voltage, VIH 2.0 V Maximum VIN = 5.5 V
Input Low Voltage, VIL 0.8 V Maximum VIN = 5.5 V
Input High Current, IIH −1 μA VIN = 5.5 V
Input Low Current, IIL 1 μA VIN = 0 V
Input Capacitance 5 pF
Programmable Pull-Down Current,
IPULL-DOWN
20 μA
VDDCAP = 4.75 V, TA= 25°C if known logic state is
required
SERIAL BUS DIGITAL INPUTS (SDA, SCL)
Input High Voltage, VIH 2.0 V
Input Low Voltage, VIL 0.8 V
Output Low Voltage, VOL30.4 V IOUT = −3.0 mA

ADM1063
Rev. C | Page 6 of 32
Parameter Min Typ Max Unit Test Conditions/Comments
SERIAL BUS TIMING4
Clock Frequency, fSCLK 400 kHz
Bus Free Time, tBUF 1.3 μs
Start Setup Time, tSU;STA 0.6 μs
Stop Setup Time, tSU;STO 0.6 μs
Start Hold Time, tHD;STA 0.6 μs
SCL Low Time, tLOW 1.3 μs
SCL High Time, tHIGH 0.6 μs
SCL, SDA Rise Time, tR300 ns
SCL, SDA Fall Time, tF300 ns
Data Setup Time, tSU;DAT 100 ns
Data Hold Time, tHD;DAT 5 ns
Input Low Current, IIL 1 μA VIN = 0 V
SEQUENCING ENGINE TIMING
State Change Time 10 μs
1At least one of the VH, VPx pins must be ≥3.0 V to maintain the device supply on VDDCAP.
2All temperature sensor measurements are taken with round-robin loop enabled and at least one other voltage input being measured.
3Specification is not production tested but is supported by characterization data at initial product release.
4Timing specifications are guaranteed by design and supported by characterization data.

ADM1063
Rev. C | Page 7 of 32
PIN CONFIGURATIONS AND FUNCTION DESCRIPTIONS
04632-003
ADM1063
TOP VIEW
(Not to Scale)
GND
40
VDDCAP
39
D1P
38
D1N
37
D2P
36
D2N
35
A1
34
A0
33
VCCP
32
PDOGND
31
AGND
11
REFGND
12
REFIN
13
REFOUT
14
NC
15
NC
16
SCL
17
SDA
18
NC
19
NC
20
VX1
1
VX2
2
VX3
3
VX4
4
VX5
5
VP1 6
VP2 7
VP3 8
VP4 9
VH 10
PDO1
30
PDO2
29
PDO3
28
PDO4
27
PDO5
26
PDO6 25
PDO7 24
PDO8 23
PDO9 22
PDO10 21
PIN 1
INDICATOR
NOTES
1. THE LFCSP HAS AN EXPOSED PAD ON THE BOTTOM. THIS
PAD IS A NO CONNECT (NC). IF POSSIBLE, THIS PAD
SHOULD BE SOLDERED TO THE BOARD FOR IMPROVED
MECHANICAL STABILITY.
2. NC = NO CONNECT. DO NOT CONNECT TO THIS PIN.
Figure 3. LFCSP Pin Configuration
04632-004
NC = NO CONNECT
NC
48
GND
47
VDDCAP
46
D1P
45
D1N
44
D2P
43
D2N
42
A1
41
A0
40
VCCP
39
PDOGND
38
NC
37
NC
13
AGND
14
REFGND
15
REFIN
16
REFOUT
17
NC
18
NC
19
SCL
20
SDA
21
NC
22
NC
23
NC
24
NC 1
V
X1 2
V
X2 3
V
X3 4
V
X4
5
V
X5
6
V
P1
7
V
P2
8
V
P3
9
V
P4
10
VH
11
NC 12
NC 36
PDO1 35
PDO2 34
PDO3 33
PDO4
32
PDO5
31
PDO6
30
PDO7
29
PDO8
28
PDO9
27
PDO10
26
NC 25
ADM1063
TOP VIEW
(Not to Scale)
PIN 1
INDICATOR
Figure 4. TQFP Pin Configuration
Table 2. Pin Function Descriptions
Pin No.
LFCSP1Mnemonic TQFP Description
15, 16,
19, 20
1, 12, 13, 18,
19, 22 to 25,
36, 37, 48
NC No Connection.
1 to 5 2 to 6 VX1 to VX5
(VXx)
High Impedance Inputs to Supply Fault Detectors. Fault thresholds can be set from 0.573 V to
1.375 V. Alternatively, these pins can be used as general-purpose digital inputs.
6 to 9 7 to 10 VP1 to VP4
(VPx)
Low Voltage Inputs to Supply Fault Detectors. Three input ranges can be set by altering the
input attenuation on a potential divider connected to these pins, the output of which connects
to a supply fault detector. These pins allow thresholds from 2.5 V to 6.0 V, from 1.25 V to 3.00 V,
and from 0.573 V to 1.375 V.
10 11 VH High Voltage Input to Supply Fault Detectors. Two input ranges can be set by altering the
input attenuation on a potential divider connected to this pin, the output of which connects
to a supply fault detector. This pin allows thresholds from 6.0 V to 14.4 V and from 2.5 V to 6.0 V.
11 14 AGND2Ground Return for Input Attenuators.
12 15 REFGND2Ground Return for On-Chip Reference Circuits.
13 16 REFIN Reference Input for ADC. Nominally, 2.048 V. This pin must be driven by a reference voltage.
The on-board reference can be used by connecting the REFOUT pin to the REFIN pin.
14 17 REFOUT Reference Output, 2.048 V. Typically connected to REFIN. Note that the capacitor must be
connected between this pin and REFGND. A 10 μF capacitor is recommended for this purpose.
17 20 SCL SMBus Clock Pin. Bidirectional open drain requires external resistive pull-up.
18 21 SDA SMBus Data Pin. Bidirectional open drain requires external resistive pull-up.
21 to 30 26 to 35 PDO10 to PDO1 Programmable Output Drivers.
31 38 PDOGND2Ground Return for Output Drivers.
32 39 VCCP Central Charge Pump Voltage of 5.25 V. A reservoir capacitor must be connected between this
pin and GND. A 10 μF capacitor is recommended for this purpose.
33 40 A0 Logic Input. This pin sets the seventh bit of the SMBus interface address.
34 41 A1 Logic Input. This pin sets the sixth bit of the SMBus interface address.
35 42 D2N External Temperature Sensor 2 Cathode Connection.
36 43 D2P External Temperature Sensor 2 Anode Connection.

ADM1063
Rev. C | Page 8 of 32
Pin No.
LFCSP1TQFP Mnemonic Description
37 44 D1N External Temperature Sensor 1 Cathode Connection.
38 45 D1P External Temperature Sensor 1 Anode Connection.
39 46 VDDCAP Device Supply Voltage. Linearly regulated from the highest of the VPx, VH pins to a typical of
4.75 V. Note that the capacitor must be connected between this pin and GND. A 10 μF
capacitor is recommended for this purpose.
40 47 GND2Supply Ground.
1Note that the LFCSP has an exposed pad on the bottom. This pad is a no connect (NC). If possible, this pad should be soldered to the board for improved mechanical stability.
2In a typical application, all ground pins are connected together.

ADM1063
Rev. C | Page 9 of 32
ABSOLUTE MAXIMUM RATINGS
Table 3.
Parameter Rating
Voltage on VH Pin 16 V
Voltage on VPx Pins 7 V
Voltage on VXx Pins −0.3 V to +6.5 V
Voltage on A0, A1 Pins −0.3 V to +7 V
Voltage on REFIN, REFOUT Pins 5 V
Voltage on VDDCAP, VCCP Pins 6.5 V
Voltage on PDOx Pins 16 V
Voltage on SDA, SCL Pins 7 V
Voltage on GND, AGND, PDOGND, REFGND Pins −0.3 V to +0.3 V
Voltage on DxN, DxP Pins −0.3 V to +5 V
Input Current at Any Pin ±5 mA
Package Input Current ±20 mA
Maximum Junction Temperature (TJmax) 150°C
Storage Temperature Range −65°C to +150°C
Lead Temperature,
Soldering Vapor Phase, 60 sec
215°C
ESD Rating, All Pins 2000 V
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
THERMAL RESISTANCE
θJA is specified for the worst-case conditions, that is, a device
soldered in a circuit board for surface-mount packages.
Table 4. Thermal Resistance
Package Type θJA Unit
40-Lead LFCSP 25 °C/W
48-Lead TQFP 50 °C/W
ESD CAUTION

ADM1063
Rev. C | Page 10 of 32
TYPICAL PERFORMANCE CHARACTERISTICS
6
0
1
2
3
4
5
0654321
04632-050
V
VP1
(V)
V
VDDCAP
(V)
Figure 5. VVDDCAP vs. VVP1
6
0
1
2
3
4
5
011412108642
04632-051
V
VH
(V)
V
VDDCAP
(V)
6
Figure 6. VVDDCAP vs. VVH
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
0123456
04632-052
V
VP1
(V)
I
VP1
(mA)
Figure 7. IVP1 vs. VVP1 (VP1 as Supply)
180
160
140
120
100
80
60
40
20
0
0123456
04632-053
V
VP1
(V)
I
VP1
(
μ
A)
Figure 8. IVP1 vs. VVP1 (VP1 Not as Supply)
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
011412108642
04632-054
V
VH
(V)
I
VH
(mA)
6
Figure 9. IVH vs. VVH (VH as Supply)
350
300
250
200
150
100
50
0
0654321
04632-055
V
VH
(V)
I
VH
(μA)
Figure 10. IVH vs. VVH (VH Not as Supply)

ADM1063
Rev. C | Page 11 of 32
14
12
10
8
6
4
2
0
0 15.012.510.07.55.02.5
04632-056
I
LOAD
(μA)
CHARGE-PUMPED V
PDO1
(V)
Figure 11. Charge-Pumped VPDO1 (FET Drive Mode) vs. ILOAD
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
0654321
04632-057
I
LOAD
(mA)
V
PDO1
(V)
VP1 = 5V
VP1 = 3V
Figure 12. VPDO1 (Strong Pull-Up to VPx) vs. ILOAD
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
0605040302010
04632-058
ILOAD (µA)
VPDO1 (V)
VP1 = 5V
VP1 = 3V
Figure 13. VPDO1 (Weak Pull-Up to VPx) vs. ILOAD
1.0
–1.0
–0.8
–0.6
–0.4
–0.2
0
0.2
0.4
0.6
0.8
40001000 2000 30000
04632-066
CODE
DNL (LSB)
Figure 14. DNL for ADC
1.0
–1.0
–0.8
–0.6
–0.4
–0.2
0
0.2
0.4
0.6
0.8
0 4000300020001000
04632-063
CODE
INL (LSB)
Figure 15. INL for ADC
12000
10000
8000
6000
4000
2000
0
204920482047
04632-064
CODE
HITS PER CODE
81
9894
25
Figure 16. ADC Noise, Midcode Input, 10,000 Reads

ADM1063
Rev. C | Page 12 of 32
2.058
2.038
2.043
2.048
2.053
–40 –20 0 20 40 60 10080
04632-061
TEMPERATURE (°C)
REFOUT (V)
VP1 = 3.0V
VP1 = 4.75V
Figure 17. REFOUT vs. Temperature

ADM1063
Rev. C | Page 13 of 32
POWERING THE ADM1063
The ADM1063 is powered from the highest voltage input on
either the positive-only supply inputs (VPx) or the high voltage
supply input (VH). This technique offers improved redundancy
because the device is not dependent on any particular voltage
rail to keep it operational. The same pins are used for supply
fault detection (see the Supply Supervision section). A VDD arbi-
trator on the device chooses which supply to use. The arbitrator
can be considered an OR’ing of five low dropout regulators (LDOs)
together. A supply comparator chooses the highest input to provide
the on-chip supply. There is minimal switching loss with this
architecture (~0.2 V), resulting in the ability to power the
ADM1063 from a supply as low as 3.0 V. Note that the supply
on the VXx pins cannot be used to power the device.
An external capacitor to GND is required to decouple the on-chip
supply from noise. This capacitor should be connected to the
VDDCAP pin, as shown in Figure 18. The capacitor has another
use during brownouts (momentary loss of power). Under these
conditions, when the input supply (VPx or VH) dips transiently
below VDD, the synchronous rectifier switch immediately turns
off so that it does not pull VDD down. The VDD capacitor can
then act as a reservoir to keep the device active until the next
highest supply takes over the powering of the device. A 10 μF
capacitor is recommended for this reservoir/decoupling function.
The VH input pin can accommodate supplies up to 14.4 V, which
allows the ADM1063 to be powered using a 12 V backplane supply.
In cases where this 12 V supply is hot swapped, it is recommended
that the ADM1063 not be connected directly to the supply. Suitable
precautions, such as the use of a hot swap controller, should be
taken to protect the device from transients that could cause
damage during hot swap events.
When two or more supplies are within 100 mV of each other,
the supply that first takes control of VDD keeps control. For
example, if VP1 is connected to a 3.3 V supply, VDD powers up
to approximately 3.1 V through VP1. If VP2 is then connected
to another 3.3 V supply, VP1 still powers the device, unless VP2
goes 100 mV higher than VP1.
SUPPLY
COMPARATOR
IN
EN
OUT
4.75V
LDO
IN
EN
OUT
4.75V
LDO
IN
EN
OUT
4.75V
LDO
IN
EN
OUT
4.75V
LDO
IN
EN
OUT
4.75V
LDO
VH
VP4
VP3
VP2
VP1
VDDCAP
INTERNAL
DEVICE
SUPPLY
0
4632-022
Figure 18. VDD Arbitrator Operation

ADM1063
Rev. C | Page 14 of 32
INPUTS
SUPPLY SUPERVISION
The ADM1063 has 10 programmable inputs. Five of these are
dedicated supply fault detectors (SFDs). These dedicated inputs
are called VH and VPx (VP1 to VP4) by default. The other five
inputs are labeled VXx (VX1 to VX5) and have dual functionality.
They can be used either as SFDs, with functionality similar to VH
and VPx, or as CMOS-/TTL-compatible logic inputs to the device.
Therefore, the ADM1063 can have up to 10 analog inputs,
a minimum of five analog inputs and five digital inputs, or
a combination thereof. If an input is used as an analog input,
it cannot be used as a digital input. Therefore, a configuration
requiring 10 analog inputs has no available digital inputs. Table 6
shows the details of each input.
PROGRAMMING THE SUPPLY FAULT DETECTORS
The ADM1063 can have up to 10 SFDs on its 10 input channels.
These highly programmable reset generators enable the supervision
of up to 10 supply voltages. The supplies can be as low as 0.573 V
and as high as 14.4 V. The inputs can be configured to detect
an undervoltage fault (the input voltage drops below a prepro-
grammed value), an overvoltage fault (the input voltage rises
above a preprogrammed value), or an out-of-window fault (the
input voltage is outside a preprogrammed range). The thresholds
can be programmed to an 8-bit resolution in registers provided
in the ADM1063. This translates to a voltage resolution that is
dependent on the range selected.
The resolution is given by
Step Size = Threshold Range/255
Therefore, if the high range is selected on VH, the step size can
be calculated as follows:
(14.4 V − 6.0 V)/255 = 32.9 mV
Tabl e 5 lists the upper and lower limits of each available range,
the bottom of each range (VB), and the range itself (VR).
Table 5. Voltage Range Limits
Voltage Range (V) VB(V) VR(V)
0.573 to 1.375 0.573 0.802
1.25 to 3.00 1.25 1.75
2.5 to 6.0 2.5 3.5
6.0 to 14.4 6.0 8.4
The threshold value required is given by
VT= (VR× N)/255 + VB
where:
VTis the desired threshold voltage (undervoltage or overvoltage).
VRis the voltage range.
Nis the decimal value of the 8-bit code.
VBis the bottom of the range.
Reversing the equation, the code for a desired threshold is given by
N= 255 × (VT− VB)/VR
For example, if the user wants to set a 5 V overvoltage threshold
on VP1, the code to be programmed in the PS1OVTH register
(as discussed in the AN-698 Application Note at www.analog.com)
is given by
N= 255 × (5 − 2.5)/3.5
Therefore, N= 182 (1011 0110 or 0xB6).
INPUT COMPARATOR HYSTERESIS
The UV and OV comparators shown in Figure 19 are always
monitoring VPx. To avoid chatter (multiple transitions when
the input is very close to the set threshold level), these compara
tors have digitally programmable hysteresis. The hysteresis can
be programmed up to the values shown in Table 6.
04632-023
+
–
+
–
UV
COMPARATOR
VREF
FAULT TYPE
SELECT
OV
COMPARATOR
FAULT
OUTPUT
GLITCH
FILTER
VPx
MID
LOW
RANGE
SELECT
ULTRA
LOW
Figure 19. Supply Fault Detector Block
The hysteresis is added after a supply voltage goes out of
tolerance. Therefore, the user can program the amount above
the undervoltage threshold to which the input must rise before
an undervoltage fault is deasserted. Similarly, the user can program
the amount below the overvoltage threshold to which an input
must fall before an overvoltage fault is deasserted.
Table 6. Input Functions, Thresholds, and Ranges
Input Function Voltage Range (V) Maximum Hysteresis Voltage Resolution (mV) Glitch Filter (μs)
VH High Voltage Analog Input 2.5 to 6.0 425 mV 13.7 0 to 100
6.0 to 14.4 1.02 V 32.9 0 to 100
VPx Positive Analog Input 0.573 to 1.375 97.5 mV 3.14 0 to 100
1.25 to 3.00 212 mV 6.8 0 to 100
2.5 to 6.0 425 mV 13.7 0 to 100
VXx High-Z Analog Input 0.573 to 1.375 97.5 mV 3.14 0 to 100
Digital Input 0 to 5.0 N/A N/A 0 to 100

ADM1063
Rev. C | Page 15 of 32
The hysteresis value is given by
VHYST = VR× NTHRESH/255
where:
VHYST is the desired hysteresis voltage.
NTHRESH is the decimal value of the 5-bit hysteresis code.
Note that NTHRESH has a maximum value of 31. The maximum
hysteresis for the ranges is listed in Table 6.
INPUT GLITCH FILTERING
The final stage of the SFDs is a glitch filter. This block provides
time-domain filtering on the output of the SFD comparators,
which allows the user to remove any spurious transitions, such
as supply bounce at turn-on. The glitch filter function is in addition
to the digitally programmable hysteresis of the SFD comparators.
The glitch filter timeout is programmable up to 100 μs.
For example, when the glitch filter timeout is 100 μs, any pulse
appearing on the input of the glitch filter block that is less than
100 μs in duration is prevented from appearing on the output of
the glitch filter block. Any input pulse that is longer than 100 μs
appears on the output of the glitch filter block. The output is
delayed with respect to the input by 100 μs. The filtering
process is shown in Figure 20.
04632-024
t
0
t
GF
t
0
t
GF
t
0
t
GF
t
0
t
GF
INPUT
INPUT PULSE SHORTER
THAN GLITCH FILTER TIMEOUT
INPUT PULSE LONGE
R
THAN GLITCH FILTER TIMEOUT
OUTPUT
PROGRAMMED
TIMEOUT
PROGRAMMED
TIMEOUT
INPUT
OUTPUT
Figure 20. Input Glitch Filter Function
SUPPLY SUPERVISION WITH VXx INPUTS
The VXx inputs have two functions. They can be used as either
supply fault detectors or digital logic inputs. When selected as
analog (SFD) inputs, the VXx pins have functionality that is very
similar to the VH and VPx pins. The primary difference is that
the VXx pins have only one input range: 0.573 V to 1.375 V.
Therefore, these inputs can directly supervise only the very low
supplies. However, the input impedance of the VXx pins is high,
allowing an external resistor divide network to be connected to the
pin. Thus, potentially any supply can be divided down into the
input range of the VXx pin and supervised, enabling the ADM1063
to monitor other supplies, such as +24 V, +48 V, and −5 V.
An additional supply supervision function is available when the
VXx pins are selected as digital inputs. In this case, the analog
function is available as a second detector on each of the dedi-
cated analog inputs, VPx and VH. The analog function of VX1
is mapped to VP1, VX2 is mapped to VP2, and so on; VX5 is
mapped to VH. In this case, these SFDs can be viewed as secondary
or warning SFDs.
The secondary SFDs are fixed to the same input range as the
primary SFDs. They are used to indicate warning levels rather
than failure levels. This allows faults and warnings to be gener-
ated on a single supply using only one pin. For example, if VP1
is set to output a fault when a 3.3 V supply drops to 3.0 V, VX1
can be set to output a warning at 3.1 V. Warning outputs are
available for readback from the status registers. They are also
OR’ed together and fed into the SE, allowing warnings to generate
interrupts on the PDOs. Therefore, in this example, if the
supply drops to 3.1 V, a warning is generated and remedial
action can be taken before the supply drops out of tolerance.
VXx PINS AS DIGITAL INPUTS
As discussed in the Supply Supervision with VXX Inputs section,
the VXx input pins on the ADM1063 have dual functionality.
The second function is as a digital logic input to the device.
Therefore, the ADM1063 can be configured for up to five digital
inputs. These inputs are TTL-/CMOS-compatible. Standard logic
signals can be applied to the pins: RESET from reset generators,
PWRGD signals, fault flags, manual resets, and so on. These
signals are available as inputs to the SE and, therefore, can be used
to control the status of the PDOs. The inputs can be configured
to detect either a change in level or an edge.
When configured for level detection, the output of the digital
block is a buffered version of the input. When configured for
edge detection, a pulse of programmable width is output from
the digital block once the logic transition is detected. The width
is programmable from 0 μs to 100 μs.
The digital blocks feature the same glitch filter function that is
available on the SFDs. This enables the user to ignore spurious
transitions on the inputs. For example, the filter can be used to
debounce a manual reset switch.
When configured as digital inputs, each VXx pin has a weak
(10 μA) pull-down current source available for placing the input
into a known condition, even if left floating. The current source,
if selected, weakly pulls the input to GND.
04632-027
DETECTOR
VXx
(DIGITAL INPUT)
GLITCH
FILTER
VREF = 1.4V
TO
SEQUENCING
ENGINE
+
–
Figure 21. VXx Digital Input Function

ADM1063
Rev. C | Page 16 of 32
OUTPUTS
SUPPLY SEQUENCING THROUGH
CONFIGURABLE OUTPUT DRIVERS
Supply sequencing is achieved with the ADM1063 using the
programmable driver outputs (PDOs) on the device as control
signals for supplies. The output drivers can be used as logic
enables or as FET drivers.
The sequence in which the PDOs are asserted (and, therefore,
the supplies are turned on) is controlled by the sequencing engine
(SE). The SE determines what action is taken with the PDOs,
based on the condition of the ADM1063 inputs. Therefore, the
PDOs can be set up to assert when the SFDs are in tolerance, the
correct input signals are received on the VXx digital pins, no
warnings are received from any of the inputs of the device, and
at other times. The PDOs can be used for a variety of functions.
The primary function is to provide enable signals for LDOs or
dc-to-dc converters that generate supplies locally on a board.
The PDOs can also be used to provide a PWRGD signal, when all
the SFDs are in tolerance, or a RESET output if one of the SFDs
goes out of specification (this can be used as a status signal for a
DSP, FPGA, or other microcontroller).
The PDOs can be programmed to pull up to a number of different
options. The outputs can be programmed as follows:
•Open drain (allowing the user to connect an external
pull-up resistor).
•Open drain with weak pull-up to VDD.
•Open drain with strong pull-up to VDD.
•Open drain with weak pull-up to VPx.
•Open drain with strong pull-up to VPx.
•Strong pull-down to GND.
•Internally charge-pumped high drive (12 V, PDO1 to
PDO6 only).
The last option (available only on PDO1 to PDO6) allows the
user to directly drive a voltage high enough to fully enhance an
external N-FET, which is used to isolate, for example, a card-
side voltage from a backplane supply (a PDO can sustain greater
than 10.5 V into a 1 μA load). The pull-down switches can also
be used to drive status LEDs directly.
The data driving each of the PDOs can come from one of three
sources. The source can be enabled in the PDOxCFG configuration
register (see the AN-698 Application Note at www.analog.com for
details).
The data sources are as follows:
•Output from the SE.
•Directly from the SMBus. A PDO can be configured so that
the SMBus has direct control over it. This enables software
control of the PDOs. Therefore, a microcontroller can be
used to initiate a software power-up/power-down sequence.
•On-chip clock. A 100 kHz clock is generated on the device.
This clock can be made available on any of the PDOs. It
can be used, for example, to clock an external device such
as an LED.
DEFAULT OUTPUT CONFIGURATION
All of the internal registers in an unprogrammed ADM1063 device
from the factory are set to 0. Because of this, the PDOx pins are
pulled to GND by a weak (20 kΩ) on-chip pull-down resistor.
As the input supply to the ADM1063 ramps up on VPx or VH,
all PDOx pins behave as follows:
•Input supply = 0 V to 1.2 V. The PDOs are high impedance.
•Input supply = 1.2 V to 2.7 V. The PDOs are pulled to GND
by a weak (20 kΩ) on-chip pull-down resistor.
•Supply > 2.7 V. Factory programmed devices continue to
pull all PDOs to GND by a weak (20 kΩ) on-chip pull-down
resistor. Programmed devices download current EEPROM
configuration data, and the programmed setup is latched. The
PDO then goes to the state demanded by the configuration.
This provides a known condition for the PDOs during
power-up.
The internal pull-down can be overdriven with an external pull-
up of suitable value tied from the PDOx pin to the required pull-up
voltage. The 20 kΩ resistor must be accounted for in calculating
a suitable value. For example, if PDOx must be pulled up to 3.3 V,
and 5 V is available as an external supply, the pull-up resistor
value is given by
3.3 V = 5 V × 20 kΩ/(RUP + 20 kΩ)
Therefore,
RUP = (100 kΩ − 66 kΩ)/3.3 V = 10 kΩ
04632-028
PDO
SE DATA
CFG4 CFG5 CFG6
SMBus DATA
CLK DATA
10Ω
20kΩ
10Ω
20kΩ
VP1
SEL
VP4
10Ω
20kΩ
V
DD
V
FET (PDO1 TO PDO6 ONLY
)
20kΩ
Figure 22. Programmable Driver Output

ADM1063
Rev. C | Page 17 of 32
SEQUENCING ENGINE
OVERVIEW
The ADM1063 sequencing engine (SE) provides the user with
powerful and flexible control of sequencing. The SE implements
a state machine control of the PDO outputs, with state changes
conditional on input events. SE programs can enable complex
control of boards such as power-up and power-down sequence
control, fault event handling, interrupt generation on warnings,
and so on. A watchdog function that verifies the continued
operation of a processor clock can be integrated into the SE
program. The SE can also be controlled via the SMBus, giving
software or firmware control of the board sequencing.
The SE state machine comprises 63 state cells. Each state has the
following attributes:
•Monitors signals indicating the status of the 10 input pins,
VP1 to VP4, VH, and VX1 to VX5.
•Can be entered from any other state.
•Three exit routes move the state machine onto a next state:
sequence detection, fault monitoring, and timeout.
•Delay timers for the sequence and timeout blocks can be
programmed independently and changed with each state
change. The range of timeouts is from 0 ms to 400 ms.
•Output condition of the 10 PDO pins is defined and fixed
within a state.
•Transition from one state to the next is made in less than
20 μs, which is the time needed to download a state
definition from EEPROM to the SE.
04632-029
SEQUENCE
TIMEOUT
MONITOR
FAULT STATE
Figure 23. State Cell
The ADM1063 offers up to 63 state definitions. The signals
monitored to indicate the status of the input pins are the
outputs of the SFDs.
WARNINGS
The SE also monitors warnings. These warnings can be
generated when the ADC readings violate their limit register
value or when the secondary voltage monitors on VPx and VH
are triggered. The warnings are OR’ed together and are available
as a single warning input to each of the three blocks that enable
exiting a state.
SMBus JUMP (UNCONDITIONAL JUMP)
The SE can be forced to advance to the next state uncondition-
ally. This enables the user to force the SE to advance. Examples
of the use of this feature include moving to a margining state or
debugging a sequence. The SMBus jump or go-to command can
be seen as another input to sequence and timeout blocks to
provide an exit from each state.
Table 7. Sample Sequence State Entries
State Sequence Timeout Monitor
IDLE1 If VX1 is low , go to State IDLE2.
IDLE2 If VP1 is okay, go to State EN3V3.
EN3V3 If VP2 is okay, go to State EN2V5. If VP2 is not okay after 10 ms,
go to State DIS3V3.
If VP1 is not okay, go to State IDLE1.
DIS3V3 If VX1 is high, go to State IDLE1.
EN2V5 If VP3 is okay, go to State PWRGD. If VP3 is not okay after 20 ms,
go to State DIS2V5.
If VP1 or VP2 is not okay, go to State FSEL2.
DIS2V5 If VX1 is high, go to State IDLE1.
FSEL1 If VP3 is not okay, go to State DIS2V5. If VP1 or VP2 is not okay, go to State FSEL2.
FSEL2 If VP2 is not okay, go to State DIS3V3. If VP1 is not okay, go to State IDLE1.
PWRGD If VX1 is high, go to State DIS2V5. IfVP1,VP2, or VP3 is not okay, go to State FSEL1.

ADM1063
Rev. C | Page 18 of 32
SEQUENCING ENGINE APPLICATION EXAMPLE
The application in this section demonstrates the operation of
the SE. Figure 25 shows how the simple building block of a single
SE state can be used to build a power-up sequence for a three-
supply system. Table 8 lists the PDO outputs for each state in
the same SE implementation. In this system, a good 5 V supply
on VP1 and the VX1 pin held low are the triggers required to start
a power-up sequence. The sequence next turns on the 3.3 V supply,
then the 2.5 V supply (assuming successful turn-on of the 3.3 V
supply). When all three supplies have turned on correctly, the
PWRGD state is entered, where the SE remains until a fault occurs
on one of the three supplies, or until it is instructed to go through
a power-down sequence by VX1 going high.
Faults are dealt with throughout the power-up sequence on
a case-by-case basis. The following three sections (the Sequence
Detector section, the Monitoring Fault Detector section, and
the Timeout Detector section) describe the individual blocks
and use the sample application shown in Figure 25 to
demonstrate the actions of the state machine.
Sequence Detector
The sequence detector block is used to detect when a step in
a sequence has been completed. It looks for one of the SE inputs
to change state and is most often used as the gate for successful
progress through a power-up or power-down sequence. A timer
block that is included in this detector can insert delays into a
power-up or power-down sequence, if required. Timer delays
can be set from 10 μs to 400 ms. Figure 24 is a block diagram of
the sequence detector.
04632-032
SUPPLY FAULT
DETECTION
LOGIC INPUT CHANGE
OR FAULT DETECTION
WARNINGS
FORCE FLOW
(UNCONDITIONAL JUMP)
VP1
VX5
INVERT
SEQUENCE
DETECTOR
SELECT
TIMER
Figure 24. Sequence Detector Block Diagram
If a timer delay is specified, the input to the sequence detector
must remain in the defined state for the duration of the timer
delay. If the input changes state during the delay, the timer is reset.
The sequence detector can also help to identify monitoring faults.
In the sample application shown in Figure 25, the FSEL1 and
FSEL2 states first identify which of the VP1,VP2, or VP3 pins
has faulted, and then they take appropriate action.
04632-030
IDLE1
IDLE2
EN3V3
DIS3V3
DIS2V5PWRGD
FSEL1
FSEL2
SEQUENCE
STATES
MONITOR FAULT
STATES
TIMEOUT
STATES
VX1 = 0
VP1 = 1
VP1 = 0
(VP1 + VP2) = 0
(VP1 + VP2 + VP3) = 0
(VP1 +
VP2) = 0
VP2 = 1
VP3 = 1
VP2 = 0
VX1 = 1
VP3 = 0
VP2 = 0
VP1 = 0
VX1 = 1
VX1 = 1
10ms
20ms
EN2V5
Figure 25. Sample Application Flow Diagram
Table 8. PDO Outputs for Each State
PDO Outputs IDLE1 IDLE2 EN3V3 EN2V5 DIS3V3 DIS2V5 PWRGD FSEL1 FSEL2
PDO1 = 3V3ON 0 0 1 1 0 1 1 1 1
PDO2 = 2V5ON 0 0 0 1 1 0 1 1 1
PDO3 = FAULT 0 0 0 0 1 1 0 1 1

ADM1063
Rev. C | Page 19 of 32
Monitoring Fault Detector
The monitoring fault detector block is used to detect a failure
on an input. The logical function implementing this is a wide
OR gate that can detect when an input deviates from its expected
condition. The clearest demonstration of the use of this block
is in the PWRGD state, where the monitor block indicates that
a failure on one or more of the VP1, VP2, or VP3 inputs has
occurred.
No programmable delay is available in this block because the
triggering of a fault condition is likely to be caused by a supply
falling out of tolerance. In this situation, the device needs to
react as quickly as possible. Some latency occurs when moving
out of this state because it takes a finite amount of time (~20 μs)
for the state configuration to download from EEPROM into the
SE. Figure 26 is a block diagram of the monitoring fault detector.
04632-033
SUPPLY FAULT
DETECTION
LOGIC INPUT CHANGE
OR FAULT DETECTION
V
P1
V
X5
MONITORING FAULT
DETECTOR
MASK
SENSE
1-BIT FAULT
DETECTOR
FAULT
WARNINGS
MASK
1-BIT FAULT
DETECTOR
FAULT
MASK
SENSE
1-BIT FAULT
DETECTOR
FAULT
Figure 26. Monitoring Fault Detector Block Diagram
Timeout Detector
The timeout detector allows the user to trap a failure to ensure
proper progress through a power-up or power-down sequence.
In the sample application shown in Figure 25, the timeout next-
state transition is from the EN3V3 and EN2V5 states. For the
EN3V3 state, the signal 3V3ON is asserted on the PDO1 output
pin upon entry to this state to turn on a 3.3 V supply. This supply
rail is connected to the VP2 pin, and the sequence detector looks
for the VP2 pin to go above its undervoltage threshold, which is
set in the supply fault detector (SFD) attached to that pin.
The power-up sequence progresses when this change is detected.
If, however, the supply fails (perhaps due to a short circuit over-
loading this supply), the timeout block traps the problem. In this
example, if the 3.3 V supply fails within 10 ms, the SE moves to
the DIS3V3 state and turns off this supply by bringing PDO1
low. It also indicates that a fault has occurred by taking PDO3
high. Timeout delays of 100 μs to 400 ms can be programmed.
FAULT AND STATUS REPORTING
The ADM1063 has a fault latch for recording faults. Two registers,
FSTAT1 and FSTAT2, are set aside for this purpose. A single bit
is assigned to each input of the device, and a fault on that input sets
the relevant bit. The contents of the fault register can be read
out over the SMBus to determine which input(s) faulted. The
fault register can be enabled/disabled in each state. To latch data
from one state, ensure that the fault latch is disabled in the
following state. This ensures that only real faults are captured
and not, for example, undervoltage conditions that may be
present during a power-up or power-down sequence.
The ADM1063 also has a number of status registers. These
include more detailed information, such as whether an under-
voltage or overvoltage fault is present on a particular input. The
status registers also include information on ADC limit faults.
Note that the data in the status registers is not latched in any
way and, therefore, is subject to change at any time.
See the AN-698 Application Note at www.analog.com for full
details about the ADM1063 registers.

ADM1063
Rev. C | Page 20 of 32
VOLTAGE READBACK
The ADM1063 has an on-board, 12-bit, accurate ADC for
voltage readback over the SMBus. The ADC has a 13-channel
analog mux on the front end. The 13 channels consist of the
10 SFD inputs (VH, VPx, and VXx), plus three channels for
temperature readback (see the Temperature Measurement System
section). Any or all of these inputs can be selected to be read,
in turn, by the ADC. The circuit controlling this operation is
called the round-robin circuit. This circuit can be selected to
run through its loop of conversions once or continuously.
Averaging is also provided for each channel. In this case, the
round-robin circuit runs through its loop of conversions 16 times
before returning a result for each channel. At the end of this
cycle, the results are written to the output registers.
The ADC samples single-sided inputs with respect to the AGND
pin. A 0 V input gives out Code 0, and an input equal to the
voltage on REFIN gives out full code (4095 decimal).
The inputs to the ADC come directly from the VXx pins and
from the back of the input attenuators on the VPx and VH pins,
as shown in Figure 27 and Figure 28.
04632-025
VXx
2.048V VREF
NO ATTENUATION
12-BIT
ADC
DIGITIZED
VOLTAGE
READING
Figure 27. ADC Reading on VXx Pins
04632-026
2.048V VREF
A
TTENU
A
TION NETWORK
(DEPENDS ON RANGE SELECTED)
12-BIT
ADC
DIGITIZED
VOLTAGE
READING
VPx/VH
Figure 28. ADC Reading on VPx/VH Pins
The voltage at the input pin can be derived from the
following equation:
V= 4095
CodeADC × Attenuation Factor × VREFIN
where VREFIN = 2.048 V when the internal reference is used (that is,
the REFIN pin is connected to the REFOUT pin).
The ADC input voltage ranges for the SFD input ranges are listed
in Tabl e 9.
Table 9. ADC Input Voltage Ranges
SFD Input
Range (V) Attenuation Factor
ADC Input Voltage
Range (V)
0.573 to 1.375 1 0 to 2.048
1.25 to 3.00 2.181 0 to 4.46
2.5 to 6.0 4.363 0 to 6.01
6.0 to 14.4 10.472 0 to 14.41
1The upper limit is the absolute maximum allowed voltage on the VPx and
VH pins.
The typical way to supply the reference to the ADC on the
REFIN pin is to connect the REFOUT pin to the REFIN pin.
REFOUT provides a 2.048 V reference. As such, the supervising
range covers less than half the normal ADC range. It is possible,
however, to provide the ADC with a more accurate external
reference for improved readback accuracy.
Supplies can also be connected to the input pins purely for ADC
readback, even though these pins may go above the expected
supervisory range limits (but not above the absolute maximum
ratings on these pins). For example, a 1.5 V supply connected to
the VX1 pin can be correctly read out as an ADC code of approxi-
mately 3/4 full scale, but it always sits above any supervisory limits
that can be set on that pin. The maximum setting for the REFIN
pin is 2.048 V.
SUPPLY SUPERVISION WITH THE ADC
In addition to the readback capability, another level of supervi-
sion is provided by the on-chip, 12-bit ADC. The ADM1063 has
limit registers with which the user can program a maximum or
minimum allowable threshold. Exceeding the threshold generates
a warning that can either be read back from the status registers
or input into the SE to determine what sequencing action the
ADM1063 should take. Only one register is provided for each input
channel. Therefore, either an undervoltage threshold or overvoltage
threshold (but not both) can be set for a given channel. The round-
robin circuit can be enabled via an SMBus write, or it can be
programmed to turn on in any state in the SE program. For
example, it can be set to start after a power-up sequence is
complete, and all supplies are known to be within expected
tolerance limits.
Note that a latency is built into this supervision, dictated by
the conversion time of the ADC. With all 12 channels selected,
the total time for the round-robin operation (averaging off) is
approximately 6 ms (500 μs per channel selected). Supervision
using the ADC, therefore, does not provide the same real-time
response as the SFDs.
