Analytic Systems IPSi505MW User manual

INSTALLATION &
OPERATION MANUAL
101-8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA)
www.analyticsystems.com
An ISO9001 Registered Company Battery Chargers •Inverters •Power Supplies •Voltage Converters
IPSi505MW
INTELLIGENT
PURESINE
INVERTER

3
Copyright (2005-2022) Analytic Systems Ware (1993) Ltd.
Revised - June 13, 2022

3
MEDICAL EQUIPMENT NOTICE
Analytic Systems does not recommend the use of their products in life support
applications where failure or malfunction of this product can be reasonably expected to
cause failure of the life support device or to signicantly affect its safety or effectiveness.
Analytic Systems does not recommend the use of any of its products in direct patient
care. Examples of devices considered to be life support devices are neonatal oxygen
analyzers, nerve stimulators (whether used for anesthesia, pain relief, or other purposes),
auto-transfusion devices, blood pumps, debrillators, arrhythmia detectors and alarms,
pacemakers, hemodialysis systems, peritoneal dialysis systems, neonatal ventilator
incubators, ventilators for both adults and infants, anesthesia ventilators, and infusion
pumps as well as any other devices designated as “critical” by the U.S. FDA
DANGER: Never alter the AC power cord or plug provided. If it will not t the output, use
an approved adapter or have the proper AC power cord installed by a qualied electrician.
Improper connection can result in the risk of electric shock.
INVERTER
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS — This manual contains important safety instructions for
operating the Inverter.
INVERTER PRECAUTIONS
1. Do not expose the Inverter to rain or snow unless it is a sealed model.
2. Do not use any attachments with the Inverter unless recommended or sold by the manu-
facturer, this may result in a risk of re, electric shock, or injury to persons.
3. Do not disassemble the Inverter; if service or repair is required, return it to the manu-
facturer or an authorized service center. Incorrect reassembly may result in a risk of re,
electric shock, or injury to persons. Voltages in excess of 350 volts are present inside the
charger any time it is plugged into an AC outlet, even if switched off.
4. To reduce risk of electric shock, unplug the Inverter from the AC power before attempting
any maintenance or cleaning. Turning off controls will not reduce this risk.
5. Do not place Inverter directly above a battery; gases generated by battery will corrode
and damage Inverter.
6. Do not allow battery acid to drip on the Inverter.
GROUNDING AND AC POWER CORD CONNECTION INSTRUCTIONS
The plug must be plugged into an outlet that is properly installed and grounded in accordance
with all local codes and ordinances.

54
TABLE OF CONTENTS
• Front Cover, Product Photo and Title
• Product Warnings and Advisories
• Table of Contents
• Introduction / Box Contents
• Main Parts
• Operation
• Controls and Indicators
• Installation
• DC Connections / AC Connections
• Off-line UPS Option
• InverterWizard (Optional)
• Troubleshooting
• Specications
• Warranty
Revised - June 13, 2022
Copyright Analytic Systems Ware (1993) Ltd.

54
Introduction
The IPSi505MW series of Intelligent Pure Sinewave Inverters are designed specically for
powering computers and other sensitive AC loads in mobile, off-grid environments. They
produce pure sinewave AC power, identical to a conventional AC outlet.
Built for service in rugged, high moisture environments this unit features upgrades including
expanded operating temperature, MIL-spec connectors, water-tight seals and enhanced shock
and vibration protection.
Internally, the IPSi505MW is controlled by a sophisticated Digital Signal Processor (DSP) for
optimal control and the most efcient operation possible. The heavy-duty Toroidal Power
Transformer steps the low voltage AC produced by the Power MOSFET Transistors to 220
VAC at 50 Hz. Additional ltering on the AC output reduces or eliminates EMI noise that can
interfere with sensitive communications equipment.
Built for the safest operation possible, this unit features low voltage warning with shutdown
circuitry to protect the DC power source. While the inverter is safeguarded by high voltage
and over temperature protection both with shutdown circuitry. All the alarm conditions can
be monitored on the bright LED indicator display which can also be mirrored on the optional
remote control panel.
Using the free-to-download InverterWizard software from Analytic Systems, you can change
the output frequency, adjust the voltage shutdown thresholds and view and record operating
data from any PC with a standard USB interface.
The box you have received should contain the following:
• 1 IPSi505MW Intelligent Pure Sine Inverter
• 1 compatible USB cable
• 1 Warranty Card
• This User Guide (A PDF copy can be downloaded from www.analyticsystems.com)
Box Contents
If anything is missing or damaged please contact your dealer or Analytic Systems for a replacement.

76
1. LED Indicators
2. AC Output Connection: Amphenol
Industrial NEMA 5-15 compatible
7-8648-5 connector
(Note: This receptacle is only water-
tight with protective cap in place)
3. Remote Control Connection
4. USB Communications Port
5. Power Switch
6. DC Input Connection: Amphenol
circular MIL-Spec MS3470W14-4P
Connector
Main Parts
2
1
5
Front Panel
3
4
6
1. Chassis Grounding Stud
Back Panel (Not pictured)

76
Operation
This unit is designed for simple and intuitive operation. Before operating, the inverter must be
properly installed and connected. See Installation and AC/DC Connections for more information.
TO OPERATE THE INVERTER:
1. Move the Power Switch to ON to energize the circuitry.
2. The Invert LED and either the 50 Hz or 60 Hz LED will glow green indicating proper
operation and the presence of AC power at the outputs.
3. The inverter will automatically begin supplying the connected load with voltage and
current printed on its label.
TO END OPERATION:
1. Move the Power Switch to OFF to end operation.
2. Wait for all the LEDs to turn off.
3. The inverter can now be safely disconnected from the load and power source. It can then be
serviced or put into storage.
There are eight indicator LEDs on the inverter’s top panel which display it’s operating condition.
The table below details their meanings:
LEDs Meaning
LOW
VOLTAGE
• Blinks red when the input voltage nears the minimum limit for proper operation.
• Glows red when the input voltage is too low for proper operation. The Bypass
LED will also glow red and the Invert LED will turn off.
HIGH
VOLTAGE
• Blinks red when the input voltage nears the maximum limit for proper operation.
• Glows red when the input voltage is too high for proper operation. The Bypass
LED will also glow red and the Invert LED will turn off.
OVER TEMP • Blinks red when the unit’s internal temperature nears the safe limit. The
inverter will automatically derate its maximum power rating to try to
maintain a safe operating temperature.
• Glows red when the inverter is too hot to operate. The Bypass LED will
also glow red and the Invert LED will turn off.
OVER LOAD • Blinks red when the current being drawn reaches the unit’s continuous rating.
• Glows red when the current being drawn reaches the unit’s peak rating.
50 HZ • Glows green if the inverter’s output frequency is set to 50.00 Hz. This
setting can be changed using InverterWizard,
60 HZ • Glows green if the inverter’s output frequency is set to 60.00 Hz. This set-
ting can be changed using InverterWizard.
BYPASS • Glows green if the inverter is in Bypass mode and functioning as an Off-
line Uninterrupted Power Supply. For more information, see Off-line UPS.
• Glows red when the inverter is experiencing a malfunction.
INVERT • Glows green when the inverter operating normally.

98
MOUNTING
Mount the unit in a WELL VENTILATED area. Allow
at least one inch (2.54 cm) of clearance all around
the unit for adequate cooling.
This unit is built to meet the IP66 rating, for
protection again high-pressure water spray. Please
take this into consideration when choosing a
mounting location.
NOTE: THIS AC OUTPUT RECEPTACLE IS ONLY
WATERTIGHT WITH PROTECTIVE CAP IN PLACE
CAUTION: DO NOT MOUNT THE UNIT ANYWHERE EXPLOSIVE GASES CAN
ACCUMULATE.
A slight arc may occur when the power leads are connected, and in the unlikely event of a
failure, sparks may be generated inside the unit.
Installation
IMPORTANT: BEFORE CONNECTING OR DISCONNECTING ANYTHING TO THE
INVERTER, MAKE THE UNIT IS OFF.
GROUNDING
The unit case is connected to AC Ground and AC Neutral in order to meet regulatory
requirements and reduce the possibility of it generating any radio frequency interference.
The unit case must be bonded appropriately to the grounding system of the vehicle or marine
vessel. On a vehicle, bond the case to the vehicle’s frame. On a marine vessel, bond the case
to the vessel’s hull. A grounding stud is provided on the front panel for this purpose.
To ensure proper grounding, check the connection with an ohmmeter. The case is isolated from
the DC input, so the DC power can be connected to a different ground from the AC output.
DISCONNECTING
If you need to disconnect the Inverter for service or storage:
1. Move the power switch to OFF and disconnect the DC power source.
2. With power disconnected, move the power switch to ON.
3. Leave the switch in this position for one minute to discharge the storage capacitors.
4. Return the power switch to the OFF position. Disconnect the load(s).
5. The inverter is ready for service or storage.

98
CAUTION: DO NOT APPLY AC VOLTAGE TO THE AC OUTPUT CONNECTION!
This will damage the inverter and will not be covered under warranty.
DC Connections
AC Connections
DC INPUT CONNECTION
This unit is equipped with an Amphenol circular MIL-Spec MS3470W14-4P Connector to serve
as a DC Input Connection. Connect the DC power source here using wiring suitable for the
input amps. The maximum input amps can be found on the unit’s top panel label and also in
the Specications section.
The polarity of this connection can be found on the label on the unit’s front panel and also in
the table below.
AC OUTPUT CONNECTION
This unit is equipped with an Amphenol Industrial NEMA 5-15 compatible 7-8648-5 connector
to serve as an AC Output Connection.
Connect the AC load here using wiring suitable for the expected output. The maximum output
current can be found on the unit’s top panel label and also in the Specications section.
Pin Polarity
Pin A AC Hot/Live
Pin B AC Neutral
Pin C AC Ground (Chassis)
Pin Polarity
Pin 1 DC Input Positive
Pin 2 DC Input Negative
CAUTION: DO NOT REVERSE CONNECT THE DC INPUT POWER!
This will damage the inverter and will not be covered under warranty.
IMPORTANT: BEFORE CONNECTING OR DISCONNECTING ANYTHING TO THE
INVERTER, THE POWER SWITCH MUST BE TURNED OFF.
NOTE: THIS AC OUTPUT RECEPTACLE IS ONLY WATERTIGHT WITH PROTECTIVE CAP
IN PLACE

1110
Off-line UPS Option
The Off-line UPS (Uninterruptible Power Source) option allows the inverter to function as a
backup power source in the event of external AC power failure. Units with the ofine UPS
feature are constructed with an AC Input connection and internal off-line AC Bypass circuit.
Legend
AC Power Source
DC Power Source
Inverter Load
AC Current
DC Current
NORMAL OPERATION
• The AC power source supplies AC power
to the load (Running to AC Output through
AC input and the inverter’s off-line bypass
circuit).
• A battery is connected to the inverter’s DC
Input Connection(s) on standby. While the
inverter detects normal AC voltage, power
is not drawn from the battery.
Legend
AC Power Source
DC Power Source
Inverter Load
AC Current
DC Current
AC POWER FAILURE
• The inverter detects a drop in AC voltage on
the off-line and automatically turns on and
starts operation.
• The inverter draws DC power from the
connected battery which supplies AC power
to the load.
• The inverter continues operating until it
detects that the AC voltage is restored or
the battery is discharged.
TO SET UP THE OFF-LINE UPS:
1. Connect the AC power source to the AC Input Connection.
2. Connect the DC power source (batteries) to the DC Input Connection.
3. Connect the load to the AC Output Connection.
4. Power on the inverter. The Bypass LED will glow green indicating the load is being
supplied with AC power through the inverter’s off-line bypass circuit.
5. If the AC power fails, the Bypass LED will turn off and the Invert LED and 50/60Hz LED will
glow green indicating the Inverter is operating.
TIP: ENSURE THE BATTERIES HAVE ENOUGH CAPACITY TO POWER THE INVERTER
FOR THE EXPECTED LENGTH OF AC POWER FAILURE.
For example, a 2000-watt inverter running from 24 VDC input will draw ~100 amps. For 2 hours of
run time, the minimum required battery capacity is 280 amps-hours of capacity @ 24 VDC.

1110
InverterWizard (Optional)
InverterWizard is optional software that can be used to adjust the inverter’s operating
settings. InverterWizard is free-to-download from www.analyticsystems.com or available by
emailing [email protected]
Using InverterWizard, you can:
• Set the inverter’s output frequency to either 50.00 or 60.00 Hz.
• Adjust the inverter’s output voltage over a ±10% range in 1 VAC intervals.
• Set the voltage thresholds for the low voltage alarms.
• Set the voltage thresholds for UPS function to start and stop.This function is only available on
units with the UPS option. See Off-line UPS for more information.
• Update the inverter’s rmware.
• Monitor and record the inverter’s operating data.
ALTERNATE DC VOLTAGES AND LOW VOLTAGE SHUTDOWN
These inverters are factory-preset for the low voltage alarm/shutdown to trigger if the unit
detects an input voltage drop of:
• <12 VDC for a 12 volt model
• <24 VDC for a 20 volt model
• <48 VDC for a 40 volt model
If the inverter uses an alternate input voltage such as 32 VDC, 36 VDC, or 72 VDC (rail) battery
then the low voltage shutdown thresholds will need to be adjusted using InverterWizard.
NOTE: INVERTERWIZARD IS NOT REQUIRED TO OPERATE THE INVERTER.
The inverter can immediately be put into service if its default operating settings are suitable
for your needs. The inverter’s default settings are listed its label.

1312
Troubleshooting
This unit features eight LED indicators and an alarm buzzer to help diagnose any malfunctions
during operation. In the event of malfunction, the alarm buzzer will sound prior to the inverter
shutting down. You should immediately check which LEDs are glowing to determine the cause
of the malfunction.
TIP: FOR QUICK REFERENCE, IF THE UNIT IS EXPERIENCING A MALFUNCTION: THE INVERT
LED WILL BE OFF AND THE BYPASS LED WILL BE GLOWING RED.
LED / Issue Meaning
LOW VOLTAGE LED is ON The input voltage is too low for normal operation.
Fix: Check that the power source is appropriately rated for use with the
inverter. If using InverterWizard, check the Low Voltage Alarm thresholds
are properly set for the battery voltage you are using to power the inverter,
for example: 21V for a 24V battery and 28V for a 32V battery.
If the above are all in working order, the cause is likely an internal compo-
nent failure and the unit must be returned for repair.
HIGH VOLTAGE LED is ON The input voltage is too high for normal operation.
Fix: Check that the power source is appropriately rated for use with the in-
verter. The inverter can be damaged if the input voltage exceeds the rating
indicated on the label. Over-voltage damage is not covered under warranty.
If the above are checked and in working order, the cause is likely an inter-
nal component failure and the unit must be returned for repair.
OVER TEMP LED is ON The unit’s internal temperature is too hot for normal operation.
Fix: Check that the unit’s cooling fans are functioning. If the fans are NOT run-
ning, the unit must be returned for repair. If the fans are running, you may
need to remount the inverter for improved ventilation.
The inverter will automatically derate its maximum power rating to
maintain a safe operating temperature. If the internal temperature exceeds
the safe maximum, the unit will shut off its outputs. When the temperature
drops to safe operating range, the inverter will automatically recover.
OVER LOAD LED is ON The load is drawing too much current from the inverter.
Fix: The load has been drawing the peak current from the inverter for
longer than its intended duty cycle. Reduce the load on the inverter by
disconnecting some devices from the output.

1312
Specications
Input
Nominal Voltage 24, 28, 32, or 36 VDC 48 or 72 (Rail) VDC
Actual Voltage 20-45 VDC 40-90 BDC
Input Amps (Max.) 28 A 14 A
Under Voltage Input Alarm
Shutdown Range
19-36 VDC
(Default setting: 21 VDC)
39-70 VDC
(Default setting: 42 VDC)
Under Voltage Input Alarm
Start-up Range
20-36 VDC
(Default setting: 23 VDC)
40-70 VDC
(Default setting: 44 VDC)
Under Volt Input
Shutdown Delay 1-120 seconds (Default setting: 30 seconds)
Over Voltage
Input Shutdown 49 VDC 86 VDC
Inrush Current
(From fully discharged) 4.8 Amp Peak 8.4 Amp Peak
Output -110 -220
Nominal Voltage 110 VAC 20 VAC
Continuous Amps 4.2 A 2.2 A
Peak Amps 6 A 3 A
Output Frequency 50.00 or 60.00 Hz ± 0.01 Hz (User-selectable)
Output Distortion (THD) <2% at 500 VA into resistive load
Regulation
(Line & Load) < +/- 2.0%
Duty Cycle 100% for 24 hours per day / 1 min @ peak with 10 minute cool down
Efciency 85% @ Full load
Ground Fault Trip Current 4-6 mA

14
* Specications subjects to change without notice.
General
Length 12.7 in / 32.3 cm
Width 8.2 in / 20.8 cm (Including mounting anges)
Height 3.8 in / 9.6 cm
Clearance 1.0 in / 2.5 cm
Mounting Wall, shelf, or oor mount
Weight 16.0 lb / 7.3 kg
Material Marine-grade aluminum
Finish Black anodized
Fastenings 18-8 Stainless steel
Input Connections DC: Amphenol Circular MIL-Spec MS3470W14-4P connector
Output Connections AC: Amphenol Industrial NEMA 5-15 compatible 7-8648-5 connector
(Note: This receptacle is only watertight with protective cap in place)
Other Connections Data/Communication: MicroUSB port
Remote Control: RJ45 ‘telephone jack’ connector with proprietary pinout
Designed and manufactured by: ANALYTIC SYSTEMS WARE (1993) LTD.
101-8128 River Way
Delta, B.C. V4G 1K5 Canada
p. 604.946.9981 f. 604.946.9983
tf. 800.668.3884 US/Canada
www.analyticsystems.com [email protected]
Environmental and Safety
Operating Temperature -40°C to +55°C @ Full load
Storage Temperature -55°C to +105°C
Cooling Convection cooled
Fans One thermostatically-controlled internal stirring fan
Humidity 0 - 95% relative humidity (non-condensing) with standard conformal coating
Packaging Built to meet IP66 (Y-Option units are certied to meet IP67 rating)
Audible Noise < 0 dB @ 3 ft/ 1m with fan running
Shock and Vibration Designed to meet MIL810G
Typical Service Life > 10 Years (86,700 hours)
Isolation Input to Chassis: <1100 VDC
Input to Output and Output to Chassis: <1500 VAC
Warranty 2 Years parts and labour
Emissions Designed to meet MIL461F

14
Limited Warranty
1. The equipment manufactured by Analytic Systems Ware (1993) Ltd. (the “Warrantor”) is warranted to be free
from defects in workmanship and materials under normal use and service.
2. This warranty is in effect for:
a. 3 Years from date of purchase by the end user for standard products offered in our catalog.
b. 2 Years from date of manufacture for non-standard or OEM products
c. 1 Year from date of manufacture for encapsulated products.
3. Analytic Systems will determine eligibility for warranty from the date of purchase shown on the warranty card
when returned within 30 days, or
a. The date of shipment by Analytic Systems, or
b. The date of manufacture coded in the serial number, or
c. From a copy of the original purchase receipt showing the date of purchase by the user.
4. In case any part of the equipment proves to be defective, the Purchaser should do the following:
a. Prepare a written statement of the nature of the defect to the best of the Purchasers knowledge, and
include the date of purchase, the place of purchase, and the Purchasers name, address and telephone
number.
b. Call Analytic Systems at 800-668-3884 or 604-946-9981 and request a return material authorization
number (RMA).
c. Return the defective part or unit along with the statement at the Purchasers expense to the Warrantor;
Analytic Systems Ware (1993) Ltd., 8128 River Way, Delta, B.C., V4G 1K5, Canada.
5. If upon the Warrantor’s examination the defect proves to be the result of defective material or workmanship,
the equipment will be repaired or replaced at the Warrantor’s option without charge, and returned to the
Purchaser at the Warrantor’s expense by the most economical means. Requests for a different method of return
or special handling will incur additional charges and are the responsibility of the Purchaser.
6. Analytic Systems reserves the right to void the warranty if:
a. Labels, identication marks or serial numbers are removed or altered in any way.
b. Our invoice is unpaid.
c. The defect is the result of misuse, neglect, improper installation, environmental conditions, non-autho-
rized repair, alteration or accident.
7. No refund of the purchase price will be granted to the Purchaser, unless the Warrantor is unable to remedy the
defect after having a reasonable number of opportunities to do so.
8. Only the Warrantor shall perform warranty service. Any attempt to remedy the defect by anyone else shall
render this warranty void.
9. There shall be no warranty for defects or damages caused by faulty installation or hook-up, abuse or misuse of
the equipment including exposure to excessive heat, salt or fresh water spray, or water immersion except for
equipment specically stated to be waterproof.
10. No other express warranty is hereby given and there are no warranties that extend beyond those described
herein. This warranty is expressly in lieu of any other expressed or implied warranties, including any implied
warranty of merchantability, tness for the ordinary purposes for which such goods are used, or tness for a
particular purpose, or any other obligations on the part of the Warrantor or its employees and representatives.
11. There shall be no responsibility or liability whatsoever on the part of the Warrantor or its employees and rep-
resentatives for injury to any person or persons, or damage to property, or loss of income or prot, or any other
consequential or resulting damage which may be claimed to have been incurred through the use or sale of the
equipment, including any possible failure of malfunction of the equipment, or part thereof.
12. The Warrantor assumes no liability for incidental or consequential damages of any kind

Register Products Online | www.analyticsystems.com/support/warranty-registration
DESIGNED AND MANUFACTURED BY
800-668-3884
604-946-9983
[email protected]
www.analyticsystems.com
101-8128 River Way
Delta, BC V4G 1K5 | Canada
Battery Chargers •Inverters •Power Supplies •Voltage Converters
