Anchor AN-30 User manual

AN-30 Speaker
Portable Speaker Monitor Specifications
Advancing Technology
The AN-30 speaker is the smallest system in the Anchor Audio line of products and
offers a lot of sound in such a small cube. With 30 watts of rated power output,
the AN-30 can cover a typical sized conference room or classroom with ease. The
AN-30 is so lightweight at under two pounds that it mounts to a wall or ceiling
bracket quite effortlessly. Combine an AN-30 with a projector in a classroom for
the perfect audio visual solution.
Anchor Audio, Inc. 888/444-6077
Portable Sound Systems • Torrance, California www.anchoraudio.com
S-AN30/0708
AN-30 FEATURES
6-YEAR WARRANTY!
REACH CROWDS OF 50+
DELIVERS 109 dB OF CLEAR SOUND
BUILT IN BRACKET MOUNT
MOUNTS ON WALL OR CEILING
LIGHTWEIGHT AT UNDER 2 POUNDS
2 LINE IN JACKS: 1/4” & 3.5 MM
LINE INPUT FOR AUDIO SOURCE
LINE OUT JACK: 3.5 MM
“DAISY CHAIN“ MULTIPLE AN-30 UNITS
4.5” NEODYMIUM WOOFER & 30W AMPLIFIER
CHOICE OF COLORS: BLACK, BLUE,
YELLOW, RED OR CLEAR
MADE IN THE USA!
AN-30 ACCESSORIES
SB-30 Wall or ceiling mounting bracket
SS-300 Speaker stand
MINI-15ST Stereo mini-plug cable: 15”
AC-30 AC adapter
(FEATURES & SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)
AN-30 TECHNICAL SPECIFICATIONS
Rated Power Output 30 Watts
Max SPL @ Rated Power 109 dB @ 1 meter
Frequency Response 100Hz - 15KHz ±3dB
Speaker Type 4.5” Neodymium woofer
Line Out Jack line level, 3.5 mm – stereo
Line In Jack line level, 3.5 mm – stereo
1/4” phone – mono
DC Input Jack 12 - 24 V, 2A Min
Dimensions (HWD) 5.5 x 5.5 x 6.5” / 14 x 14 x 16.5 cm
Weight 1.5 pounds / 0.68 Kg
AN-30 MODELS
AN-30 AC powered speaker monitor
AN-30CP AN-30 powered speaker & SB-30
wall mount bracket
AN-30
www.anchoraudio.com
PATENT PENDING
POWER
LINE OUTLINE IN
2A MIN
OFF
12-24 VDC
LINE IN
(AN-30 Control Panel)
AN-30CP – Contractor Package
(AN-30 & SB-30 Wall Bracket)
