AND UC-502 User manual

Classic Weight Scale
Model UC-502
Instruction Manual
Original
ENGLISH
Manuel d’instructions
Traduction
FRANÇAIS
Manual de Instrucciones
Traducción
ESPAÑOL
Manuale di Istruzioni
Traduzione
ITALIANO
使用手冊
翻譯
中文
ﺕﺎﻣﻳﻠﻌﺗﻟﺍ ﻝﻳﻟﺩ
ﺔﻣﺟﺭﺗ
ﻲﺑﺭﻋ
1WMPD4003400

English 1
ENGLISH
CONTENTS
Dear Customers........................................................................
Page 2
Precautions for Use ..................................................................
Page 2
Parts .........................................................................................
Page 4
Accessories ..............................................................................
Page 5
Safety and Usage Information ..................................................
Page 5
Operating Instructions...............................................................
Page 5
Troubleshooting ........................................................................
Page 7
Specifications............................................................................
Page 7
Maintenance .............................................................................
Page 8

English 2
Dear Customers
Congratulations on purchasing a state-of-the-art A&D health scale, one of the most advanced health
scales available today. Designed for ease of use and accuracy, this device will facilitate your daily weight
management regimen. We recommend that you read through this manual carefully before using the
device for the first time.
Precautions for Use
The following items contain information to prevent the risk of harm or injury to yourself or other people.
Please read these items carefully and be sure to use this product correctly.
Danger
This symbol indicates “an immediate danger which could result in
death or serious injury”.
Warning
This symbol indicates “the possibility of death or serious injury”.
Caution
This symbol indicates “the possibility of physical injury or damage to
property”.
Warning

Do not rely on self-diagnosis when attempting weight loss or therapeutic exercise.
Follow the instructions of a physician or specialist.
 Do not step on the edges of the scale or jump on the scale.
This may result in a fall, causing injury. The impact may also cause damage to the scale.
 Do not use the scale on an uneven surface.
This may damage the scale. Also, the scale cannot measure accurately on uneven surfaces.
 Do not use the scale on a slippery surface or step on the scale with wet feet.
This may result in slipping and injury. Also, the scale cannot measure accurately in these situations.

English 3
Caution

Do not place the scale where it is exposed to excess water or humidity such as a bathroom, where it
is exposed to direct sunlight, where it is exposed directly to the air outlet of an air conditioning unit,
or near fire.
This may cause the scale to malfunction.
 This scale should only be used for weighing body weight.
 This scale is a precision measuring device. Do not drop the scale or expose it to vibration or
powerful shocks.
 Do not disassemble, repair or modify the scale.
This may cause malfunction or injury.
 Persons with disabilities should be assisted by a caregiver when using this scale.
Failure to do so may result in a fall, causing injury.
 When installing the batteries, be sure that the + (positive) and - (negative) terminals are correct.
Incorrect installation may cause overheating, battery fluid leaks or rupturing of the batteries, resulting
in damage to the scale or injury.
 This scale is designed for personal use.
 Store this scale out of the reach of small children.
 Do not store this scale vertically. If for any reason this scale is stored vertically, be sure not to let the
scale fall.
 Do not place any items on this scale during storage.
 If use of this scale is shared with a person who has an infectious disease such as a skin disease on
the feet, etc., clean the scale before use.
(For details on cleaning the scale, see “Maintenance (P.6)”.)
 To accurately measure your weight, use the scale on a flat, hard floor. Do not use on a carpet or
other soft surfaces.

English 4
Parts
Name/Function
Display Symbol
kg
Kilogram
lb
Pound
st
lb
Stone ―Fraction stroke
LCD Display
UNIT key
Battery
Compartment

English 5
Accessories
•One CR2032 Button Cell (pre-installed with insulating sheet)
•User Manual
If any of the accessories are missing or damaged, contact the product vendor or an A&D Sales
Branch.
Safety and Usage Information
Your Scale and Its Environment
•Do not use your scale on a slippery floor or on a carpet.
•Do not jump onto the platform immediately after bath or with wet hands.
•To ensure the accuracy of the measurement, when the scale is moved or not-in-use for a long time,
please place the scale on a flat surface and turn it on first. Wait until after the scale shuts off
automatically to take a measurement.
•Do not expose the scale to extreme temperatures, humidity, moisture, direct sunlight, dust or salty
air.
Battery Safety
•When installing the battery, pay attention to the polarity indication and ensure +/- terminals are
correct. Otherwise, the battery may leak, overheat or crack, and lead to injury.
•Remove the battery when the device is NOT in use for extended periods of time.
Operating Instructions
Insert the Battery
•Open the battery door in the back of the scale.
•Insert the battery (1 x CR2032 Button Cell) into
the battery compartment according to the
polarity indications marked on the side of the
compartment.
* All the digits will be shown on the LCD in full
screen.
•Close the battery door and wait until the digits
“0.0 kg” are shown on the LCD.

English 6
Select Measurement Unit
•With the battery correctly installed, press the “UNIT” button on the back of the scale to select
measurement unit. The default measurement unit is “kilogram”. You may press the “UNIT” button to
choose among kilogram, pound and stone.
kg
Measure in Kilogram / Centimeter
lb
Measure in Pound / Foot
st
lb
Measure in Stone / Foot
Start Measuring
•Place the scale flat on a hard surface.
•Step onto the platform and stand still until the numeral on the LCD stops blinking.
•The measuring result is displayed for about 6 seconds.
Unit: kilogram
Unit: Pound
Unit: Stone
•Then the scale powers off automatically.

English 7
Troubleshooting
Error
Description
Solution

The weight placed on the platform
keeps fluctuating for 25 to 35
seconds. The scale will then shut off
automatically.

Step off the platform for a while.
Then step onto the platform and
stand still until the numerals on the
LCD stops blinking.
 Low Battery. The scale will power off
in four seconds.
 Replace the battery. Please
purchase the authorized battery for
replacement.

Overload

Stop using this scale for
measurement.
Specifications
Product Name
Bathroom Scale
Dimension
Scale
300mm(L) x 300mm(w) x 23.6mm(H)
Panel
300mm(L) x 300mm(W) x 6mm(H)
Net Weight
Approximately 1.51kg (Excluding the cells)
Display
Digital LCD, V.A. = 63mm(L) x 30mm (W)
Measurement Unit
Kilogram / Pound / Stone
Measurement Range
5kg to 180kg
Division
0.1kg / 0.2lb
Accuracy
0-50.0kg: ±0.4kg
50.1-100.0kg: ±0.5kg
100.1-150kg: ±0.6kg
150.1-180kg: ±0.7kg
Working Environment
Temperature
5°C to 40°C
Humidity
≤ 90% RH
Storage Environment
Temperature
-20°C to 60°C
Power Source
3V (1 x CR2032 Button Cell)
Auto-ON
SENSE ON technology
Auto-OFF
4 to 6 seconds after last operation
Accessories
1. One CR2032 Button Cell (pre-installed)
2. User Manual
UC-502 conforms to the requirements of the council directives on …
•Electromagnetic Compatibility (EMC) 2004/108/EC
•Restriction of the use of certain Hazardous Substances (RoHS) 2011/65/EU

English 8
Maintenance
Do’s and Don’ts
When carrying out general maintenance, please practice the following Do’s and Don’ts:
•DO use a dry soft cloth to wipe off dust.
•DO use a wet soft cloth, dipped into water or neutral detergent and wrung out, to wipe the dirt. Then
use a dry soft cloth to dry up the device.
•DON’T wash the device with water or immerse it in water.
•DON’T use propellant, abrasive or other chemicals to wipe the dirt. This is to avoid discoloration or
malfunction.
•DON’T disassemble this device.
Battery Replacement
•Used batteries are hazardous waste. DON’T dispose of them together with the household garbage.
Please refer to the local ordinances and recycling instructions regarding disposal of the used
batteries.
Disposal
•This mark Indicates this device is subject to the Waste Electrical and Electronic Equipment Directive
in the European Union.
•To protect the environment, dispose of useless device at appropriate collection sites according to
national or local regulations.
