Andersen LuminAire User manual

1
Emco Enterprises, Inc., is a wholly owned subsidiary of Andersen Corporation. Emco Enterprises, Inc.
manufactures and supports the limited warranties for Andersen®and EMCO®doors. “Andersen”,
“EMCO” and all other marks where denoted are trademarks of Andersen Corporation. ©2019
Andersen Corporation. All rights reserved.
Installation Guide
Please Do Not Return Product to Store!
with any questions regarding installation, lost part replacement, or anything else related to your retractable
insect screen purchase. Replacement parts can also be found at: parts.andersenstormdoors.com
Read this entire guide before you begin your installation. If your abilities do not
match the requirements of this installation, contact an experienced contractor.
PLEASE call the Storm Door Solution Center at 844-813-6664,
For installation help please visit www.AndersenLuminAire.com/install
Designed for 68”– 72”wide by 80”tall double hinged doors with suitable mounting surface.
2
4
5
9
1
1
2
5
3
3
4
4
66
66
7
7
4
4
6
10
3
8
7
11
Your installation kit should contain the following parts.
Andersen SDD, PO Box 853
Des Moines, IA 50306-0853
Rev 02-2019 r2 Print in Color
p/n 900900
for Andersen®LuminAire®Retractable Insect Screen Double Door
with SlideAway® Insect Screen System
Active Housing (gray fastener clips on end caps)
Passive Housing (labeled passive on end caps)
Screen Tracks (top and bottom)
End Caps (attached to ends of housings)
Sill Adapter
Orange Installation Clips
Shipping Plastic Wrap
In the Parts Bag:
Track Extenders (qty 2)
Track Stops (qty 2)
Slot Covers (qty 2)
Not Shown: Screw Pack containing:
• 1 inch #8 screws (qty 6)
• ½ inch #8 self-tapping screws (qty 6)
• #2 Phillips Bit
• ⁄ inch Drill Bit
• ⁄ inch Hex Wrench
• Corner Pile (qty 2)
NOTE: The orange installation clips attached to the Housings provide
product protection during shipping and installation. DO NOT extend the
screens from the housings or remove installation clips until instructed.
To avoid product damage, be sure to place all parts of your retractable
insect screen on a soft non-abrasive surface such as carpet, drop cloth
placed on your lawn or cardboard.
NOTICE
A
A
Items in the Parts Bag:
8
10
9
DOUBLE DOOR PARTS OVERVIEW

2
SAFETY FIRST: Please read and follow all Cautions and Warnings in this guide.
RECOMMENDED TOOLS
Drill
Safety Glasses
Sealant
#2 Phillips Bit
(provided)
1/8 Drill Bit
(provided)
3/32 Hex Wrench
(provided)
Work Gloves
The retractable insect screen is intended for reasonable
insect control and not the retention of objects, persons,
or pets within the interior. The retractable insect screen
will not stop a person from falling through the door.
Follow manufacturers' instructions for hand and power
tools. Always wear safety glasses. Failure to do so could
result in injury, product or property damage.
Windows and doors can be heavy. Use safe lifting techniques and a reasonable number of people with enough
strength to lift, carry, and install window and door products. Heavier windows and doors will require mechanical
assistance. Failure to do so could result in injury, product or property damage.
Metal fasteners and components could corrode when exposed to preservative-treated or re-retardent treated
lumber. Use approved fasteners and components to fasten window or door. Failure to do so could cause a failure
resulting in injury, product or property damage.
Fastener must attach to a structural framing member with a 1" minimum fastener embedment. Failure to do so
could result in injury, product or property damage.
DO NOT remove screws that attached installation clips or gusset plates to window or door frames. Doing so could
result in injury, product or property damage.
Metal components of the retractable insect screen may
become hot when exposed to sunlight.
IMPORTANT
WARNING WARNING
WARNINGCAUTION
Major Injury /
Death
Product or
Property Damage
Minor
Injury
Procedure and
Product Information
This is the Safety Alert Symbol used to alert you to potential injury hazards.Obey all safety messages that follow this symbol to avoid possilbe injury or death.
WARNING NOTICE CAUTION IMPORTANT
Signal Word and Consequence
COULD
Result in:
COULD
Result in:
COULD
Result in:
Tape Measure
Screwdriver
Hacksaw
Metal
File
For installs less than 68"wide
Scissors Soft Cloth
Pencil

3
To install the retractable insect screen door, you must verify that the opening width, height and mounting surface are suitable size to
properly install into the opening.
1. Measure the width at the top (W1), middle (W2), and bottom (W3) of the opening (see Figure 1). Measure from the inside of the exterior trim.
Utilizing the narrowest width, reference chart below.
2. Measure the height at the center of the opening, from the bottom of the exterior trim at the top of opening down to the sill at the bottom of
opening. Reference chart for height compliance.
Configuration Widths
(Adjustable Width - Use for Step 1b)
Opening Widths
(Configuration Ranges) Opening Heights
72 Configuration 70" – 72" 80" (80" – 80 ⁄")
68 Configuration 68" – 69 ⁄" Also Available in
See Appendix A (Pg. 10) Less than 68" 78" (78"–78 ⁄") or 84" (84"– 84 ⁄")
3. Make sure that the exterior trim meets the mounting surface requirements to accommodate the retractable insect screen assembly (see Figure 2).
The assembly needs 3/4" at surface on exterior trim face and 3/4" minimum depth of mounting surface.
MEASURE - VERIFY MOUNTING SURFACE REQUIREMENTS AND MEASURE DOOR OPENING
Verify that the exterior brickmould, trim board or casing (exterior trim) is rmly attached to the opening structure and is a material that is suitable
to suciently fasten the retractable insect screen to the door opening. The performance of the retractable insect screen could be eected over
time if it is not suciently fastened to the opening.
Figure 1
W3
H
W2
W1
Figure 2
3/4"MIN
DEPTH
3/4"MIN FLAT
SURFACE ON FACE
Figure 3a
Figure 3b
No Modication Required
See Appendix B
MOUNTING
SURFACE
MOUNTING
SURFACE
DOOR
SILL
DOOR
SILL
If the Door Sill doesn’t extend past the Mounting Surface
or does not have sucient support, product damage, injury
or both may occur.
•If the Door Sill extends past your exterior trim Mounting Surface
and is supported, no modication is required (see Figure 3a).
•If the Door Sill is extended without support or not extended
(see Figure 3b), you will need to add support blocking.
See Appendix B (on page 10).
CAUTION
Track Extenders A and C
Not all openings require the use of Track Extenders.They are
for reinforcing the screen assembly at the wider ranges of the
conguration.The track extenders can not be used at narrower
ranges of the congurations as screen interference will occur.
Reference the chart below detailing when to use the screen
extenders and when not to use them.
Opening Width Configuration Track Extender
71" – 72" 72" Config. Yes - Needed
70" – 70 ⁄" 72" Config. Not needed
69" – 69 ⁄" 68" Config. Yes - Needed
Less than 69" 68" Config. Not needed
IMPORTANT
A
A
C
C
Track Extender A
Track Extender C

4
A
A
(Passive Screen)
Passive
Screen
ASSEMBLE
SCREEN
TRACKS &
HOUSINGS
1
a1 Unpack both housings and screen tracks onto a non-abrasive surface, with the housing's side labeled Interior facing up. Leaving the screens in the retracted
position, arrange the components so the letters marked on the Screen Tracks and the letters marked on the Housing Endcaps align (A to A, C to C, Passive A
to Passive Screen A and Passive C to Passive Screen C). Screen Tracks should be orientated with Long End up, and labeled side facing out from the assembly.
Note: Active Housing has fastener clips and 68 & 72 inch markings. The Passive Housing is labeled PASSIVE on the end caps.
INTERIOR
LABEL
INTERIOR
LABEL
PASSIVE
HOUSING
ACTIVE
HOUSING SCREEN TRACK
A PASSIVE SCREEN
SCREW
FLANGE
LONG
END
PASSIVE HOUSING
ENDCAP A
A C C
C A A
Screen Track Screen Track
ALL ITEMS DURING THE ASSEMBLY STEPS SHOULD BE ARRANGED
LAYING FLAT ON THE GROUND ON A SOFT NON ABRASIVE SURFACE.
a
A
Passive
Screen
A
(Passive Screen)
A
A
b1 At the end of the Screen Track labeled (Passive Screen) A, rotate the
Screen Track so labeled side is down and the Screen Channel is up.
b2 Insert Hex Wrench into the Set Screw in the Track Stop.
b3 Insert Track Stop into the Screen Track with the Hex Wrech so the Set Screw
slides into Screen Channel rst followed by Locking Pin Receiver end.
b4 Slide the Track Stop to approximately the middle of the Screen Track.
Tighten the Set Screw enough to prevent the Track Stop from moving.
b5 Repeat for Screen Track end labeled (Passive Screen) C. Rotate both screen
tracks back to original position, so the long ends of Screen Tracks are up.
c1 If your opening width is between 69" and 70" or 71" and 72" you will
need to insert the Track Extenders into the Passive Housing End Caps.
If your opening does not fall into these ranges, skip to Step d.
c2 Position the thicker end of the Track Extender A toward Passive
Housing End Cap A with the Locking Tab toward the Screen Track.
c3 Slide the Track Extender all the way into the Passive Housing
End Cap A, and repeat these steps for side C.
bc
SET SCREW
TRACK STOP LOCKING PIN
RECEIVER END
TRACK STOP PASSIVE HOUSING
END CAP A
LOCKING TAB
TRACK
EXTENDER A
HEX
WRENCH
HEX
WRENCH
LONG
END
PASSIVE
SCREEN LABEL
SCREEN
CHANNEL
SCREEN
TRACK
SCREEN
TRACK
SCREEN TRACKSIDE A PASSIVE
Tools
Recommended:
Track Stops (Qty 2)
Track Extenders
if required (Qty 2)
PARTS BAG
A
A
Use Track Extender Only:
If your opening width is between 69" & 70" or 71" & 72", see Page 3 for details.
A PASSIVE SCREEN
C PASSIVE SCREEN
Opening Width Configuration Track Extender
71" – 72" 72" Config. Yes - Needed
70" – 70 ⁄" 72" Config. Not needed
69" – 69 ⁄" 68" Config. Yes - Needed
Less than 69" 68" Config. Not needed
3/32 Hex Wrench
(provided)

5
A
72
68
A
ASSEMBLE
SCREEN
TRACKS &
HOUSINGS
Continued
1
A
C
Passive
Screen
d1 Conrm the Fastener Clips on Active Housing endcaps, A and C are in the open position. Starting at corner A on the Active Housing, slide the Receiving Tab
on Endcap A inside the Screen Track. Ensure the Receiving Tab ts inside the Screen Track, and the Screen Track slides into the Channel. (see“correct” above).
(Visit AndersenLuminAire.com/Install to view a video of this step.)
d2 Repeat for endcap C on the Active Housing and endcaps A and C on the Passive Housing. Be sure the screen tracks are all the way into the passive housing.
(Note: The passive housing endcaps do not have Fasterner Clips, this allows the screen tracks to slide for adjustment to t the door opening.)
d3 Use the“72 Conguration” for openings 70 - 72"wide or “68 Conguration” for openings less than 70"wide in step b.
(If the opening is narrower than 68"wide, See Appendix A on page 10.)
e1 If the opening is between 70" and 72", adjust Screen Track A
until 72"line aligns with edge of Active Housing Endcap A.
e2 Rotate the Fastener Clip up until it snaps into the closed position.
e3 Repeat steps for side C.
e1 If the opening is less than 70", adjust Screen Track A until 68"line
aligns with edge of Active Housing Endcap A.
e2 Rotate the Fastener Clip up until it snaps into the closed position.
e3 Repeat steps for side C.
A
A
A
68
RECEIVING TAB
SLIDES INSIDE SCREEN TR ACKTUBING!
A
A
A
72 Configuration
(use for opening widths between 70" to 72")
68 Configuration
(use for opening widths less than 70")
A
A
A
72
68
FASTENER CLIP
IN OPEN POSITION
PASSIVE
HOUSING
ACTIVE
HOUSING
SCREEN
TRACK A
SCREEN
TRACK A
CHANNEL
FOR SCREEN TRACK
CHANNEL
FOR SCREEN TRACK
ENDCAP A
ENDCAP A ENDCAP A
C
A
FASTENER CLIPFASTENER CLIP 72"LINE 68"LINE
SCREEN TRACK A SCREEN TRACK A
e
Active Housing Passive Housing Screen Track Screen Track
KEY REFERENCES
A
A
A
72
68
CORRECT INCORRECT
RECEIVING TAB
FITS INSIDE SCREEN TRACK
RECEIVING TAB
FITS INSIDE SCREEN TRACK
RECEIVING TAB SHOULD NOT
BE OUTSIDE SCREEN TRACK
Visit AndersenLuminAire.com/install
to view a video of this step.
Screw Flanges
Receiving Tabs
Letter Labels
Fastener Clips
Passive Label
OR
1
2
3
4
5
1 1
4 5
333
3
2 2
dReceiving Tabs on the Endcaps must
slide inside the Screen Track. Product
damage may occur if ReceivingTab is
forced outside the screen track.
NOTICE
A PASSIVE SCREEN
C PASSIVE SCREEN

6
PLACE, FASTEN
ASSEMBLY
INTO OPENING
2
Tools Recommended:
c1 Slide the screen assembly in the door opening until the Active Housing
side Screw Flange is on the Mounting Surface.
c2 Verify the screen assembly is plum, level and square in the door opening
and the Screen Housing side Screw Flange is tight to Mounting Surface.
b1 The screen assembly will be narrower than your opening until fully
expanded in the following steps.
b2 Start by placing the Screen Assembly onto the exterior Trim Surface,
with the Screw Flanges extending into the Door Opening. Rest the
bottom of the screen assembly onto your sill or support blocking.
SCREEN
ASSEMBLY
DOOR
OPENING
MOUNTING
SURFACE
MOUNTING
SURFACE
SCREW
FLANGE
SCREW
FLANGE
TRIM
SURFACE
b
SCREW
FLANGE
MOUNTING
SURFACE
SLIDE
SLIDE
PRIMARY
ACTIVE
DOOR
PRIMARY
ACTIVE
DOOR
ACTIVE
HOUSING
ACTIVE
HOUSING
ACTIVE
HOUSING
DOOR OPENING DOOR OPENING
PASSIVE
HOUSING
PASSIVE
HOUSING
a1 With a Scissors, cut the Plastic Wrap along inside edge of the Screw Flange from both housings.
a2 With the interior of the screen assembly facing the door opening, rotate the assembly so the
Active Housing is on the same side of the Door Opening as your Primary Active Door.
a
OR
PLASTIC WRAP
SCISSORS
SCREW FLANGE
c
To avoid product damage. It is recommended to use two (2)
people to install double door unit into the door opening.
NOTICE
Scissors

7
f1 From the interior, while holding the Passive Housing side Screw Flange
tight to the Mounting Surface, extend the screen so it is clear of your drill/
driver. Orange installation clips can come o and be properly disposed of.
f2 With ⁄"bit provided, predrill through the three holes on the Passive
Housing side Screw Flange into the Mounting Surface a maximum
depth of ¾".
f3 With the three remaining #8 - 1"screws, fasten Passive Housing
to the Mounting Surface. (Be careful not to over tighten)
PLACE, FASTEN
ASSEMBLY
INTO OPENING
Continued
2
Tools Recommended:
g1 With a pencil and tape measure nd the center of the opening and make
a Center Mark on the lower and upper Screen Tracks.
g2 Insert the Hex Wrench into the Track Stop, positioned near the center of
the Screen Track.
g3 Loosen the set screw just enough to move the Track Stop, and reposition
it to the Center Mark on the Screen Track. Tighten the set screw in place.
g4 Repeat step for other Screen Track.
e1 Expand the screen assembly in the door opening until the
Passive Housing side Screw Flange is on the Mounting Surface.
e2 Verify the screen assembly is plum, level and square in the door
opening and the Passive Housing side Screw Flange is tight to
Mounting Surface.
d1 From the interior, while holding the Active Housing side Screw Flange
tight to the Mounting Surface, extend the screen so it is clear of your drill/
driver. Orange installation clips can come o and be properly disposed of.
d2 With the ⁄"bit provided, predrill through the center hole of the Screw
Flange (large arrow) into the Mounting Surface a maximum depth of ¾".
d3 With one #8 - 1"screw, fasten Active Housing to the Mounting Surface.
(Be careful not to overtighten)
d4 Repeat steps for top and bottom holes. (Being careful not to overtighten)
#8-1"
(Qty 6)
SCREW PACK
#8
#10
#12
#6
3/4” Machine Pan Painted
1/2” SMS Pan
1/2” SMS Pan Painted
1/2” SMS Flathead
1/2” Self-Drill Pan
1/2” Self-Drill Pan Painted
3/4” Machine Flathead
7/8” Machine Pan Painted
1” SMS Pan
1” SMS Pan Painted
1” Machine Pan Painted
1-1/2” Machine Flathead
1-1/2” Machine Flathead
2” SMS Pan Painted
5/8” SMS Pan Painted
1-1/4” SMS Pan
gf
MOUNTING
SURFACE
MOUNTING
SURFACE
ACTIVE
HOUSING
CENTER
MARK
HEX
WRENCH
SCREW
FLANGE
SCREW
FLANGE #8  1"
SCREW
EXPAND
EXPAND
PASSIVE
HOUSING
#8  1"
SCREW
MOUNTING
SURFACE
MOUNTING
SURFACE
SCREW
FLANGE
SCREW
FLANGE
e
SCREEN
TRACK
SCREEN
TRACK
TRACK
STOP
HEX
WRENCH HEX
WRENCH
CENTER
MARK
Switch to Interior View
d
Drill/Driver 1/8 Drill Bit
(provided)
3/32 Hex Wrench
(provided)
Tape
Measure
Screwdriver
Pencil

8
ADJUSTMENTS,
DUST PLUGS,
PLACE &
FASTEN SILL
ADAPTER
Tools Recommended:
3
c1 Once the track stops and locking pins have been adjusted and set,
unlatch and open both screens.
c2 Insert a Slot Cover into the upper Adjustment Slot until the
Lock Legs snap into place and it is rmly seated in place.
c3 Repeat for the lower Adjustment Slot.
d1 Peel paper from back of Corner Pile and place at the top of the Passive
Housing Screen Pull against the Glide and rmly press into place.
d2 Repeat step for other end of the Passive Housing Screen Pull.
a1 Inside the Upper Adjustment Slot, keeping the Phillips Screwdriver in
contact with the screw, loosen the screw until it can be moved, approximately
2 turns; do not fully remove the screw. Use the Phillips Screwdriver to slide
the upper pin up towards the Screen Track until it stops. Tighten screw down.
a2 Inside the Lower Adjustment Slot, keeping the Phillips Screwdriver
in contact with the screw, loosen the screw until it can be moved,
approximately 2 turns; do not fully remove the screw. Use the Phillips
Screwdriver to slide the lower pin down towards the Screen Track until
it stops. Tighten screw down.
b1 From the exterior of the screen assembly, extend the Passive Housing
Screen Pull to the closed position in the center of opening. The Screen
Pull should latch at the top and bottom Screen Tracks.
b2 Verify Passive Housing Screen Pull is centered. If not centered, you can
adjust the location of Passive Housing Screen Pull by repeating step 2g
through 4g until the desired position is achieved.
b3 Once positioned, extend the Active Housing Screen Pull to the closed
position, latching it into Passive Housing Screen Pull. If not done previously,
the orange installation clips can come o and be properly disposed of.
SCREEN
TRACK
SCREEN TRACK
ACTIVE HOUSING
SCREEN PULL
GLIDE
SCREEN TRACK
CORNER
PILE
CORNER
PILE
SLOT
COVER
ADJUSTMENT
SLOT
ADJUSTMENT
SLOT
SLOT
COVER
LOCK
LEGS
PASSIVE
HOUSING
SCREEN PULL
PASSIVE
HOUSING
SCREEN PULL
PASSIVE
HOUSING
SCREEN PULL
SCREEN TRACK
PHILLIPS
SCREWDRIVER
UPPER
ADJUSTMENT SLOT
LOWER
ADJUSTMENT
SLOT
HEX
WRENCH
a
c
b
d
SCREEN
TRACK
PARTS BAG SCREW PACK
Slot Covers Corner Pile
3/32 Hex Wrench
(provided)
Screwdriver

9
ADJUSTMENTS,
DUST PLUGS,
PLACE &
FASTEN SILL
ADAPTER
Continued
Tools Recommended:
e1 Thoroughly clean the Door Sill.
e2 From the interior of screen assembly, position Sill Adapter with the textured side up
and screw holes in toward the interior of the home.
e3 Insert edge of the Sill Adapter into the Adapter Channel located on the Screen Track (see Figure 1).
e4 Rotate the Sill Adapter down to the Door Sill (see Figure 2).
e5 Center the Sill Adapter in the door opening.*
f1 With ⁄"bit provided, predrill through the six holes on the Sill Adapter into the Door Sill a maximum depth of ¼".
f2 Lift Sill Adapter and apply sealant into predrilled holes until sealant over-ows onto Door Sill surface. (see Figure 3)
f3 Rotate the Sill Adapter back down to the Door Sill and fasten using six #8 - ½"Self-Tapping Screws. Cleanup excess sealant.
(see Figure 4)
* 66.5” sill adapter is designed to avoid the need for cutting during installation. If a wider sill adapter is preferred, visit parts.andersenstormdoors.com
f
SCREW PACK
#8 - ½"
(Qty 6)
#8
#10
#12
#6
3/4” Machine Pan Painted
1/2” SMS Pan
1/2” SMS Pan Painted
1/2” SMS Flathead
1/2” Self-Drill Pan
1/2” Self-Drill Pan Painted
3/4” Machine Flathead
7/8” Machine Pan Painted
1” SMS Pan
1” SMS Pan Painted
1” Machine Pan Painted
1-1/2” Machine Flathead
1-1/2” Machine Flathead
2” SMS Pan Painted
5/8” SMS Pan Painted
1-1/4” SMS Pan
SCREEN
TRACK
SILL
ADAPTER
SILL ADAPTER
SILL
ADAPTER
DOOR
SILL
DOOR
SILL
DOOR
SILL
ADAPTER
CHANNEL
ADAPTER
CHANNEL
SILL
ADAPTER
#8  ½ "
SCREW
SILL
ADAPTER
DOOR
SILL
DOOR
SILL
3
Sill Adapter
e
Figure 1
Figure 3
Figure 2
Figure 4
MAX ¼"
DEPTH
Drill/Driver
Sealant
#2 Phillips Bit
(provided)
1/8 Drill Bit
(provided)

10
APPENDIX A
Narrow Opening
Modication for
Openings less
than 67 ⁄" wide.
A
B
Tools Recommended:
b1 Measure and mark from Passive End of the Screen Track the Calculated Length.
b2 With a Hacksaw make a clean square cut through the Screen Track at the Cut Mark.
With a metal le, le down all sharp edges. Repeat steps for the other Screen Track
at the Passive End. (see Figure 1).
b3 Measure and mark from each end of the Sill Adapter the Halved Calculated Length
so equal amounts are removed from both sides (see Figure 2).
b4 With the Hacksaw make a clean square cut through the Sill Adapter on both ends at the
Cut Marks. With a metal le, le down all sharp edges. Return to Measure on Page 2.
a1 To modify screen assembly to work in a Narrow Opening,
the Screen Tracks and Sill Adapter need to be cut down.
a2 Measure door opening width at top (W1), middle (W2), and
bottom (W3) from the inside of the exterior trim.
a3 Calculate Length of material to be cut o by taking the
narrowest width from above and subtracting it from 69.½
inches (see Example above).
A
(Passive Screen)
a b
CALCULATED
LENGTH
CUT
MARK SCREEN
TRACK
PASSIVE END
HACKSAW
APPENDIX - STEPS FOR NARROW OPENING AND SUPPORT BLOCKING FOR SILL (if required)
a1 Choose Support Blocking the width of the Door Sill with enough depth
to Extend ¾" Minimum out from the exterior trim Mounting Surface.
a2 Center the Support Blocking under the sill and make sure it is level and
parallel to the sill. Conrm it Extends ¾" Minimum from Mounting Surface.
a3 Properly secure Support Blocking below the Sill.
Return to Measure on Page 2.
a
SUPPORT
BLOCKING
DOOR SILL
APPENDIX B –Support Blocking for Door Sill
Screen Track
(A/C Passive)
Screen Track
(C/A Passive)
If opening width W1 = 65 ¾"
W2 = 65 ¾"and W3 = 65 ½"
Take narrowest width = 65 ½"
and subtract from 69½inches.
69 ½ - 65 ½ = 4 inches
The Calculated Length
of material to cut o is 4
inches in this example.
For sill adapter (step b3), use
half the Calculated Length
by dividing it by 2.
4 ÷ 2 = 2 inches
EXAMPLE
FOR STEP a3 BELOW
Sill Adapter
SILL ADAPTER
CUT MARK CUT MARK
HALF CALCULATED
LENGTH
HALF CALCULATED
LENGTH
MOUNTING
SURFACE
EXTEND
3/4"MIN
Figure 1
Figure 2
W3
W2
W1
Work Gloves
Tape Measure
Hacksaw
Metal File

11
RECEIVING TAB
SLIDES INSIDE SCREEN TRACK TUBING!
A
A
A
1. How do I open and close the insect screen?
Use the Handle to extend insect screen to the center of door frame. It will
automatically latch when fully extended. Slide the Release Lever up or down
to unlatch, the insect screen will automatically retract (see Figure 1).
2. How do I lock and unlock the insect screen?
To lock the insect screen door, move the Lock Tab toward the screen assembly.
To unlock, move the Lock Tab away from the screen assembly (see Figure 2).
3. What should I do to maintain my retractable insect screen door?
The screen tracks will need occasional vacuuming to remove dirt and debris.
This will help keep the tracks clean and free of debris that may aect operation.
4. Can the fastener clips be opened if I closed them in the wrong
position during installation?
You can open the fastener clip by applying downward pressure
with a at blade screwdriver until it releases open (see Figure 3).
5. Can replacement parts be purchased if something gets damaged on my door?
Parts can be purchased by visiting parts.andersenstormdoors.com or calling Customer
Service at 844-813-6664. It is helpful to have your serial number when ordering parts. The
serial number is located near Endcap A on your active screen housing.
6. What should I do with the unit in cold weather?
It is best for the unit to be stored in the retracted position during cold weather. We do not
recommend operating when temperatures are near or below freezing.
7. Why is the sill adapter narrower than the door opening?
The length of the sill adapter is designed to cover the door pass through space while
avoiding the need for cutting during installation. For wider door installations, a longer sill
adapter is available for a fee at parts.andersenstormdoors.com or by calling Customer
Service at 844-813-6664.
8. Is there a video available that will show me how to install and operate the door?
You can nd a video of how to install and operate the retractable insect screen door at
AndersenLuminAire.com/install
FREQUENTLY ASKED QUESTIONS – ANDERSEN®LUMINAIRE®RETRACTABLE INSECT SCREEN
For additional assistance visit ANDERSENLUMINAIRE.COM or Customer Service: 844-813-6664
Figure 1
Unlatching Locking/Unlocking
Opening Fastener Clip
Figure 2
Figure 3
INTERIOR
HANDLE
INTERIOR
HANDLE
FASTENER CLIP IN CLOSED POSITION
RELEASE
LEVER
LOCK
TAB
FLAT BLADE SCREWDRIVER

12
LIMITED WARRANTY
ANDERSEN® LUMINAIRE® RETRACTABLE SCREEN DOOR 5 YEAR LIMITED WARRANTY
LIMITED WARRANTY ON RETRACTABLE SCREEN DOOR COMPONENTS
Emco Enterprises LLC (Emco), an Andersen company, warrants the screen housing, latch housing, screen track, endcap and sill adapter
components of the Andersen® LuminAire® retractable screen door to be free from defects in manufacturing, materials, paint adhesion, and
workmanship, under normal conditions, for five (5) years from the date of purchase or as long as the original consumer purchaser owns the
home in which the door was initially installed, whichever is shorter.
In the event a screen housing, latch housing, screen track, endcap or sill adapter fails as a result of a defect in manufacturing, materials or
workmanship within the limited warranty period specified above, and upon written proof of purchase, Emco, will at its option refund or
provide a replacement screen housing, latch housing, screen track, end cap or sill adapter without charge – installation is not included.
Such replacement is warranted for the remainder of the original limited warranty period. Please locate the door serial number and written
proof of purchase then contact Emco Consumer Support at 1-844-813-6664.
NO OTHER WARRANTIES OR REPRESENTATIONS
THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. ALL WARRANTIES ARE LIMITED TO THE APPLICABLE
STATUTE OF LIMITATIONS, BUT IN NO CASE WILL EXTEND BEYOND THE LIMITED WARRANTY PERIODS SPECIFIED ABOVE. EMCO EXCLUDES
AND WILL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, WHETHER ARISING OUT OF CONTRACT, TORT OR
OTHERWISE. THE REMEDY OF REPLACEMENT OF THE PRODUCT PROVIDED BY THIS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY WITH
RESPECT TO AND ANY AND ALL LOSS OR DAMAGE.
APPLICABLE LAW
This Limited Warranty is only applicable in the U.S.A. (i.e. the fifty states and the District of Columbia). This Limited Warranty gives you
specific legal rights, and you may have other rights which vary from state to state or province. Some states do not allow the exclusion
or limitation of incidental or consequential damages or limitation of the duration of an implied warranty, so the above limitations or
exclusions may not apply to you. If any specific term of this Limited Warranty is prohibited by any applicable law, it shall be null and void,
but the remainder of this Limited Warranty shall remain in full force and effect.
WHAT IS NOT COVERED BY THIS LIMITED WARRANTY
Damage caused by:
• Improper installation (including failure to follow installation instructions), modification, maintenance, or use
• Chemicals or airborne pollutants, such as salt or acid rain
• Acts of God, including wind damage
• Accidents
• Normal wear and tear
• Products not manufactured by Emco
Emco Enterprises LLC is a wholly owned subsidiary of Andersen Corporation. Emco manufactures and supports the limited warranties
covering Andersen® and EMCO® Storm and Screen Doors. “Andersen” “EMCO” and all other marks where denoted are trademarks of
Andersen Corporation. ©2017 Andersen Corporation. All rights reserved.
Reprinted and effective as of September 12, 2017.
