Andonstar AD409-Max User manual

Digital Microscope AD409-Max
Users Manual
Thanky o u f o r p u r c h a s i n g o u r p r o d u c t s ! T o facilitate y o u r u s e a n d maintenance, p l e a s e
r e a d t h e u s e r s manual c a r e f u l l y beforeu s e . I f y o u have a n y questions,p l e a s e feel f r e e t o
contact u s , w e w i l l r e p l y within 24H ( t h e r e m a y bead e l a y o n holidays). W e a p p r e c i a t e
t h e opportunity t o s e r v e y o u , y o u r satisfaction i s o u r u t m o s t priority!
Customers e r v i c e ：support@andonstar

1
CONTENTS
Basic Parameters................................................................................................................................. 2
What’s in the box................................................................................................................................. 3
Installation............................................................................................................................................. 4
Button Instructions............................................................................................................................ 6
Quick Start..............................................................................................................................................7
Adjust Magnification & Focus.................................................................................................7
Save Picture and Video.............................................................................................................. 7
Review and Manage Images.................................................................................................... 8
Remote Control Instructions..........................................................................................................9
Settings.....................................................................................................................................................9
Gridline Setting...........................................................................................................................10
Save Setting..................................................................................................................................11
Three Output Modes........................................................................................................................11
①HDMI Output......................................................................................................................... 11
②USB Output.............................................................................................................................12
③WIFI Output (Test function)........................................................................................... 17
Safety and Maintenance.................................................................................................................19
FAQ.......................................................................................................................................................... 19
Warranty Card....................................................................................................................................20

2
Basic Parameters
Image sensor
4 Mega Pixels HD Sensor
Video output
UHD 2880X2160 24FPS; FHD1920X1080 60FPS/30FPS,
HD1280X720 120FPS,
Video format
MP4
Magnification ratio
Up to 300X (27 inch HDMI monitor output)
Photo resolution
Max 24M (5600*4200)
Photo format
JPG
Minimum focus distance
5cm
Frame rate
Max 120f/s (under 600 Lux Brightness& HDP120)
Storage
Micro-SD card up to 64G (not included, Class10 high-speed card is
recommended)
PC support
Yes, for Windows XP/7/8/10, PC software with Measurement
Mobile phone & tablet terminal
Support WiFi connection
HDMI Output
Support
Power source
USB 5V 2A DC
Stand size
18*20*32cm
Screen size & Resolution
10.1 inch, 1280*800
Language support
10 types, English/French/German/Italian/Portuguese/Spanish
/Russian/Simplified Chinese/Traditional Chinese/Japanese
Package contents
Microscope monitor, UV filter(assembled), Base(with light), Repair
mat, Beam, Column, Tool holder, Power cable, HDMI cable, USB cable,
Power adapter, Remote, Users Manual

3
What’s in the box
（P1:What’s in the box）

4
Installation
Step1 Step2
Step3 Step4

5
（P2:Installation complete）

6
Button Instructions
（P3: Button Instructions）
①Power on/off ②Menu/Mode(Long press Menu/press Mode)
③Up（Zoom+）④Down（Zoom-）
⑤OK/Start video record ⑥Picture capture
⑦Infrared sensor ⑧Focus controller
⑨Endoscope interface (optional) ⑩Memory card slot
⑪USB port ⑫HDMI port
⑬Reset hole

7
Quick Start
（P4: Connection）
Adjust Magnification & Focus
Lift the monitor to adjust the object distance, and turn the focus controller (P3/⑧) to focus.
Save Picture and Video
Insert the memory card in the direction shown in P4, the memory card does not support hot swap.

8
Record Videos
Video recording
Press the "OK" button to start recording. Press
the "OK" button again to stop recording.
Take photos
Press the"capture" button（ ）to take photos.
Review and Manage Images
Press the "MODE" (M) button to enter playback mode. Press the “Up” and “Down” keys to cycle through
pictures and videos. When reviewing pictures or videos, long press the "MENU" (M) button to manage files.

9
Remote Control Instructions
（P5: Remote Control Instructions）
Note: The “Switch lens image” button is only available after inserting the endoscope
Settings
①Long press the "M" button to enter the video menu of video standby mode：
(P6: Video menu)
