anko MT-600 User manual

Instruction Manual
For Household Use Only
Model No.: MT-600
Rev 2
Note: The specifications and/or components of this appliance are subject to change without prior notice.
If any Accessories should fail during use, please call 1300 105 888 (Australia) or 09 8870 447 (New Zealand)
for an immediate replacement. This will save you from returning the product to the store.
If we can assist you in any other way, please feel free to contact us.

Page 2 of 36

Page 3 of 36
1Warnings.................................................................................................................................. 4
2Safety Direction....................................................................................................................... 4
3Please observe the following points..................................................................................... 8
4Components ............................................................................................................................ 9
4.1 Robot Bottom View.......................................................................................................... 10
4.2 Robot Right Side View .................................................................................................... 11
4.3 Charging Dock ................................................................................................................. 11
4.4 Dust Canister (Opened)................................................................................................... 12
5Transporting the Robot......................................................................................................... 12
6Environment .......................................................................................................................... 13
7Before Use ............................................................................................................................. 14
7.1 Side Brush Installation..................................................................................................... 14
7.1 Charging Dock Setup....................................................................................................... 15
7.2 Charging the Robot – Charging Dock ............................................................................. 16
7.3 Charging the Robot – Direct Charging............................................................................ 17
8Controls ................................................................................................................................. 17
8.1 Robot Top Control Button ............................................................................................... 17
9Remote Control ..................................................................................................................... 18
9.1 Battery Installation / Replacement .................................................................................. 19
10 Types of Floor Surfaces........................................................................................................ 20
11 Using the Robot Cleaner....................................................................................................... 20
11.1 Start / Pause / Sleep.................................................................................................... 20
11.2 Manually Finishing a Cleaning Session .................................................................... 21
12 Advanced Cleaning ............................................................................................................... 21
13 User Maintenance.................................................................................................................. 22
13.1 Cleaning the Dust Canister ........................................................................................ 22
13.2 Cleaning / Replacing Filters....................................................................................... 23
13.3 Cleaning Robot Body and Accessories..................................................................... 25
13.4 Cleaning / Replacing the Robot Spinning Brushes. ................................................. 25
13.5 Cleaning the Roller Brush .......................................................................................... 26
13.6 Cleaning the Robot Sensors ...................................................................................... 27
13.7 Cleaning the Wheels................................................................................................... 28
13.8 Cleaning the Charging Contacts Robot / Charging Stand ....................................... 28
14 Troubleshooting.................................................................................................................... 29
14.1 Indicator Lights and Beeping..................................................................................... 29
15 Storage................................................................................................................................... 30
15.1 FAQ.............................................................................................................................. 30
15.2 Operation Troubleshooting........................................................................................ 32
16 Specifications........................................................................................................................ 34
16.1 Technical Specification for the Robot ....................................................................... 34
16.2 Technical Specification for the Charging Dock ........................................................ 34
16.3 Technical Specification for the Remote Control....................................................... 34
17 Warranty Against Defect....................................................................................................... 35

Page 4 of 36
1 Warnings
Before using this appliance, read and follow all warnings and instructions in this
manual, even if you are familiar with this product.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
2 Safety Direction
Please read this instruction manual carefully before first use. It is advisable to keep
this instruction manual for future reference.
DO NOT vacuum water, wet objects, liquids, ashes, hot coals, cigarette butts,
matches or any hot, smoking or burning objects, etc.
DO NOT pick up flammable or combustible materials (i.e., lighter fluid, petrol,
kerosene, etc.) or use in the presence of explosive liquids or vapour.
DO NOT pick up toxic material (i.e., chlorine bleach, ammonia, drain cleaner, etc.)
DO NOT vacuum Toner (for laser printer, copy machines etc.) as there is a risk of
fire and explosion.
DO NOT vacuum plaster dust, cement dust etc. as the filter will block very quick.
DO NOT use the vacuum without all filters fitted.
DO NOT store or use the appliance near high temperature areas.
DO NOT run over the charger cable with the Robot cleaner.
DO NOT use the Robot cleaner if it is blocked. Turn off and clear all blockages
before continuing.
DO NOT use the Robot cleaner with a blocked filter. Clean filter before continuing.
(refer to User Maintenance section).
DO NOT use the Robot cleaner if the appliance malfunctions, abnormal noise,
smell, smoke, is dropped or damaged in any manner or any breakage is found
during operation.

Page 5 of 36
For electrical safety, any repairs to the product must be performed by a qualified
electrical person only, or the product must be disposed of.
DO NOT misuse the Charger Cable. Never pull the appliance by the cable or pull
to disconnect it from the outlet. Instead, grasp the charger body and pull to
disconnect.
DO NOT use with damaged Charger Cable or Charger Body.
DO NOT handle Charger or Robot cleaner with wet hands.
DO NOT sit or stand on this appliance.
DO NOT place any objects on top of this appliance.
DO NOT use in wet or moist areas such as bathrooms, showers, etc.
DO NOT place the appliance on tables or chairs etc. where it may fall off.
DO empty the Dust Canister regularly for optimal operation of the Robot.
DO clean the filter regularly for optimal operation of the Robot.
DO keep hair, loose clothing, fingers, feet and body parts away from openings or
moving parts such as the wheels and spinning brushes.
DO disconnect the Charger from the power supply when not in use for extended
periods.
DO NOT use the Robot cleaner to pick up large objects, hard or sharp objects such
as glass, nails, screws, coins, etc. that are likely to cause damage.
DO NOT use Robot cleaner if it has been dropped, damaged, left outdoors, or
dropped into liquid (water etc.)
DO NOT put any objects into openings.
DO NOT use with any openings blocked and do not restrict airflow.
DO NOT use without the filter in place.
DO NOT attempt to modify this product in any way.
DO use extra care when vacuuming on stairs.
DO ensure children and babies cannot play with plastic bags or any packaging
materials

Page 6 of 36
DO use only on indoor surfaces. Not for Outdoor Use.
DO use only as described in this manual. Use only manufacturer's recommended
attachments.
DO Keep Charger Cable away from heated surfaces.
DO Keep all openings free of dust, lint. hair, and anything that may reduce airflow.
DO keep your work area well lit.
DO store your appliance indoors in a cool. dry area.
DO operate the Charger from a power source of the same voltage, frequency and
rating as indicated on the product identification plate.
DO Only use the Battery Charger which was supplied with this appliance.
DO ensure appliance is switched off before handling or picking up.
When handling the appliance, to avoid injury take care that your fingers or other
parts of your body do not touch the wheels or spinning brushes.
Take care that your clothing or other items do not touch the wheels or spinning
brushes as damage may occur.
WARNING
Only use the Battery Charger which was supplied with this appliance.
Model No. ZD12D260050AU 100–240V~ 50-60Hz 0.5A Output: 26.0V 500mA
Battery Pack Specification:
Type: Li-ion, 18650 14.8Vd.c., 2200mAh
Consumers are cautioned against using and/or purchasing counterfeit and/or
inferior quality batteries. These batteries have the potential to cause fire, personal
injury, and/or damage to property. These batteries are typically found on online-
auction websites or from other retailers and are known to pose a potential safety
risk.
Never try to recharge Non-Rechargeable batteries as they may explode, catch on
fire or cause personal injury and/or damage to property.
- May explode if disposed of in fire.
- To prevent injury or burns, do not allow metal objects to contact battery
terminals.
- Do not use or store in temperatures above 40°C

Page 7 of 36
The Battery Pack must be removed from the Robot cleaner before disposal.
Contact your local waste management authority for more information on Battery
Recycling and disposal regulations in your area.
This symbol on the product or its packaging indicates:
Do not dispose of electrical appliances or batteries as unsorted municipal waste,
use separate collection facilities. Contact your local council for information
regarding the collection systems available. If electrical appliances are disposed of
in landfills or dumps, hazardous substances can leak into the groundwater and get
into the food chain, damaging your health and well-being. Please contact your local
council or regional authority for more information on collection, reuse, and
recycling programmes.
If this appliance is used by a third party, DO supply the instruction manual with it.
No liability can be accepted for any damage caused by non-compliance with these
instructions or any other improper use or mishandling of appliance.
This product has not been designed for any uses other than those specified in this
manual.
ONLY for domestic use. Industrial or commercial use invalidates the warranty.
Only use a genuine battery and other accessories/parts from the supplier, as using
a non-genuine battery and other parts may harm the product and could be a risk
to the user and bystanders.
Read and Save These Instructions

Page 8 of 36
3 Please observe the following points
Electrical devices are not for children
Never allow children to use electrical devices unsupervised.
If used, Batteries / rechargeable batteries can be extremely dangerous if swallowed,
therefore: keep the device and batteries out of reach of small children.
If a battery is swallowed, seek medical help immediately.
Proper Recycling
Batteries and packaging material should not be disposed of in domestic waste.
Contact your local authority for instruction on proper disposal and collection points.
Batteries must be handed in to a used-battery collection point.
Remove the battery from the remote control and from the appliance prior to recycling.
Ensure the battery in the appliance is not being charged when removing.
Separated disposal of packaging materials cares for the environment.
Moisture and Cleaning
This product is not waterproof! Do not immerse the unit in water or let it come in contact
with water.
If water penetrates the unit, it can cause serious damage.
Do not use cleaning agents which contain alcohol, ammonia, benzene or abrasives, as
these can damage the unit. Use a soft, damp cloth for cleaning.
Heat
Do not expose the unit to direct sunlight.
Ensure that the device is not exposed to any direct heat sources, such as radiators or
open fires. Ensure that the unit is not covered.

Page 9 of 36
4 Components
Note: The specifications and/or components of this appliance are subject to change without prior notice
1
Bumper / Sensor Window
7
Battery Charger ZD12D260050AU
2
Start / Pause Button
8
Side Brushes x 4
3
Dust Canister release button
9
Cleaning Brush with Hair Cutter
4
Dust Canister
10
Filter
5
Instruction Manual
11
Remote Control
6
Charging Dock
3
11
10
8
6
4
9
7
1
5
2
Instruction
manual

Page 10 of 36
4.1 Robot Bottom View
12 Side Brushes 16 Front Castor Wheel
13 Charging Contacts 17 Roller Brush
14 Sensors 18 Battery Compartment
15 Left Drive Wheel 19 Right Drive Wheel
14
15
12
17
13
12
13
16
19
18
14
14
