OPERATING AND MAINTENANCE MANUAL
FOR POWER DIVIDERS
1. INTRODUCTION
This manual describes the 11, K240 and V240 Series
Power Dividers (Figure 1). It provides specifications
and a list of precautions the user should observe
when using them.
2. DESCRIPTION
ANRITSU precision power dividers are produced in
three models:
•11 Series, DC to 3000 MHz using N connectors
•K240B, DC to 26.5 GHz using K Connectors®
K240C, DC to 40 GHz using K Connectors
•V240C, dc to 65 GHz using V Connectors®
All models are symmetrical, three-resistor tee
designs that can be used in applications where
signals must be accurately divided or combined.
K Connectors are compatible with GPC–3.5 and
SMA. V Connectors are compatible with GPC 2.4
connectors. All three models have exceptional
amplitude and tracking characteristics.
3. SPECIFICATIONS
Table 3 provides performance specifications.
4. PRECAUTIONS
ANRITSU precision power dividers are high-quality,
precision laboratory components and should receive
the same care and respect afforded other such
devices. Complying with the following precautionary
notes will guarantee longer component life and less
equipment downtime due to connector failure. Also,
such compliance will ensure that RF component
failures are not due to misuse or abuse — two failure
modes not covered under the ANRITSU warranty.
a. Beware of Destructive Pin Depth on Mating
Connectors. Measure the pin depth of the
connector that mates with the RF component,
before mating. Use an ANRITSU Pin Depth
Gauge (Figure 2, Table 1) or equivalent. Based on
RF components returned for repair, destructive
pin depth on mating connectors is the major cause
of failure in the field. When an RF component
connector is mated with a connector having a
destructive pin depth, damage will likely occur to
the RF component connector. (A destructive pin
depth has a center pin that is too long in respect
to the connector’s reference plane.)
The center pin on an RF component connector has a
precision tolerance measured in mils (1/1000 inch),
whereas connectors on test devices that mate with
RF components may not be precision types. Their
pins may not have the proper depth. They must be
measured before mating to ensure suitability. When
gauging pin depth, if the test device connector
Figure 1. Model V240 Series Power Divider
Figure 2. Pin Depth Gauge
Table 1. Available Gauging Sets
Model Connector Type Gauging Set Model Zeroing Block
11 Series N female SC6311 SC6312
K240X K female SC7738 SC7736
V240C V female SC6982 SC7736
0
1
2
3
45
1
2
3
4
2
11
2

2 PN: 10100-00027 Rev. F Power Dividers OMM
measures out of tolerance in the “+” region, the
center pin is too long. Mating under this condition
will likely damage the RF component connector. On
the other hand, if the test device connector measures
out of tolerance in the “–” region, the center pin is too
short. While this will not cause any damage, it will
result in a poor connection and a consequent
degradation in performance.
The pin depth for all power divider models shown in
Table 2.
b. Avoid Over Torquing Connectors. Over
torquing connectors is destructive; it may damage
the connector center pin. Never use pliers to
tighten connectors.
c. Avoid Mechanical Shock. RF components are
designed to withstand years of normal bench
handling. However, do not drop or otherwise treat
them roughly. They are laboratory-quality devices
and, like other such devices, require careful
handling.
d. Keep Power Divider Connectors Clean. The
precise geometry that makes the RF component’s
high performance possible can be easily disturbed
by dirt and other contamination adhering to
connector interfaces. When not in use, keep the
connectors covered. Refer to the next section for
cleaning instructions.
5. MAINTENANCE
ANRITSU recommends that no maintenance other
than cleaning be attempted by the customer. The
power divider should be returned to ANRITSU for
repair and/or service when needed.
The traditional method of cleaning K Connectors
with a cotton swab and alcohol can break the
connector pin on the precision connector. The cotton
swab has a larger diameter than the area between
the inner wall and the center pin of the power divider
connectors.
ANRITSU still recommends using a cotton swab;
however, you need to trim the swab before inserting
it into the connector.
A cotton swab must never be used to cleaning
V Connectors; use a pinch of cotton held with
fine-pointed tweezers.
Some precautions to follow when using the power
divider:
•Use either the finger saver that has been
provided with the power divider or use an
8 inch-pound torque wrench for V and
K connectors or a 12 inch-pound for
N connectors when connecting the power
divider to other devices. No other tools are
recommended.
•Always spin the coupling nut to tighten
connections. Spinning the connector body
causes premature wear to the connector
interface.
Table 2. Power Divider Pin Depth Measurements
Model Pin Depth (Inch)
11 Series 0.207 to 0.187
K240X 0.000 to –0.005
V240C 0.000 to –0.005

Power Dividers OMM PN: 10100-00027 Rev. F 3
Maximum Input Power: 1 W
Weight: 43 grams (1.5 ounces)
Table 3. Performance Specifications
Model Frequency Range (GHz) SWR Insertion Loss (dB max.) Impedance (Ohms)
Connectors
Input Output
11N50B DC to 3 < 1.25 7 50 N female N female
11N75B 75
Model Frequency Range (GHz) Impedance (Ohms)
Connectors
Input Output
K240B DC to 26.5 50 K female K female
K240C DC to 40
V240C DC to 65 V female V female
Frequency Range
(GHz)
Tracking Outputs Insertion Loss
(dB max.) SWRAmplitude Phase
DC to 6 ± 0.3 dB ± 2º 71.2
6 to 18 ± 0.3 dB ± 3º 7.5 1.4
18 to 26.5 ± 0.6 dB ± 4º 81.5
26.5 to 40 ± 0.6 dB ± 6º 8.5 1.7
40 to 65 ± 1.5 dB ± 15º 10 2.7
Figure 3. Return Loss and Insertion Loss (Typical)
Frequency (GHz)
067
0
2
4
6
8
10
12
0
5
10
15
20
25
30
Typical Return Loss (dB)
Typical Insertion Loss (dB)
Return loss
Insertion loss
Frequency (GHz)
V240C
11N50B
03
0
2
4
6
8
10
12
0
10
20
30
40
50
60
Typical Return Loss (dB)
Typical Insertion Loss (dB)
Return loss
Insertion loss

Figure 4. Outline Dimensions
WARRANTY
Anritsu power dividers are warranted against defects in materials and workmanship for one year from the date of shipment.
Anritsu’s obligation covers repairing or replacing products which prove to be defective during the warranty period. Buyers shall
prepay transportation charges for equipment returned to Anritsu for warranty repairs. Obligation is limited to the original
purchaser. Anritsu is not liable for consequential damages.
LIMITATION OF WARRANTY
The foregoing warranty does not apply to Anritsu connectors that have failed due to normal wear. Also, the warranty does not
apply to defects resulting from improper or inadequate maintenance by the Buyer, unauthorized modification or misuse, or
operation outside of the environmental specifications of the product. No other warranty is expressed or implied, and the
remedies provided herein are the Buyer’s sole and exclusive remedies.
NOTICE
Anritsu Company has prepared this manual for use by Anritsu Company personnel and customers as a guide for the proper
installation, operation and maintenance of Anritsu Company equipment and computer programs. The drawings, specifications,
and information contained herein are the property of Anritsu Company, and any unauthorized use or disclosure of these
drawings, specifications, and information is prohibited; they shall not be reproduced, copied, or used in whole or in part as the
basis for manufacture or sale of the equipment or software programs without the prior written consent of Anritsu Company.
4.6
9.1
2-56 UNC-2B, 2X
Ø 2.6 2X
11.4
6.1
10.2
14.7
10.2
14.7
10.2
14.7
DC-65 GHz
3
2
1
7.4
7.4 V CONNECTOR FEMALE
THREAD M7.0 X .75-6G,2X
V240C
POWER DIVIDER
All dimensions in mm
7.4
7.4
1
2 3
14.7 10.2
Ø 2.6 2X
2-56 UNC-2B, 2X
9.1
4.6
6.6 TYP.
7.4
K CONNECTOR FEMALE
1/4 - 36 UNS - 2A, 3X
K240C
POWER
DIVIDER
DC-40
GHz
31.75
(MAX)
31.75
(MAX)
40.64
(MAX)
17.78
(TYP.)
11 Series
K240B, K240C
V240C
Printed on Recycled Paper with Vegetable Soybean Oil Ink Anritsu Company
490 Jarvis Drive
Morgan Hill, CA 95037-2809
USA
http://www.anritsu.com
