Anritsu MD1230A User manual

Document No.: M-W1927BE-1.0
Measurement Solutions
ANRITSU CORPORATION
MD1230A
Data Quality Analyzer
Service Manual
First Edition
To ensure that this equipment is used safely, impor-
tant safety items are also explained in the MD1230A
Data Quality Analyzer Operation Manual. This
manual explains important service items related to
service. Read both the operation manual and this
manual, and keep both with the equipment.

ii
iiii
ii
Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the following
safety symbols to indicate safety-related information. Insure that you clearly understand the meanings of the sym-
bols BEFORE using the equipment.
Some or all of the following five symbols may not be used on all Anritsu equipment. In addition, there may be other
labels attached to products which are not shown in the diagrams in this manual.
Symbols used in manual
This indicates a very dangerous procedure that could result in serious injury or
death if not performed properly.
This indicates a hazardous procedure that could result in serious injury or death if
not performed properly.
This indicates a hazardous procedure or danger that could result in light-to-severe
injury, or loss related to equipment malfunction, if proper precautions are not taken.
Safety Symbols Used on Equipment and in Manual
The following safety symbols are used inside or on the equipment near operation locations to provide information
about safety items and operation precautions. Insure that you clearly understand the meanings of the symbols
and take the necessary precautions BEFORE using the equipment.
This indicates a prohibited operation. The prohibited operation is indicated sym-
bolically in or near the barred circle.
This indicates an obligatory safety precaution. The obligatory operation is indicat-
ed symbolically in or near the circle.
This indicates warning or caution. The contents are indicated symbolically in or
near the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.
MD1230A
Data Quality Analyzer
Service Manual
17 October 2001 (First Edition)
Copyright © 2001, ANRITSU CORPORATION.
All rights reserved. No part of this manual may be reproduced without the prior written permission of the
publisher.
The contents of this manual may be changed without prior notice.
Printed in Japan
DANGER
WARNING
CAUTION

For Safety
iii
iiiiii
iii
WARNING
1. ALWAYS refer to the operation manual when working near locations
at which the alert mark shown on the left is attached. If the operation,
etc., is performed without heeding the advice in the operation manual,
there is a risk of personal injury. In addition, the equipment perfor-
mance may be reduced.
Moreover, this alert mark is sometimes used with other marks and de-
scriptions indicating other dangers.
2. Laser radiation warning
•NEVER look directly into the cable connector on the equipment nor
into the end of a cable connected to the equipment. If laser radia-
tion enters the eye, there is a risk of injury.
•Laser Radiation Markings on a following page show the Laser
Safety label attached to the equipment near the cable connector.
3. When supplying power to this equipment, connect the accessory 3-pin
power cord to a 3-pin grounded power outlet. If a grounded 3-pin
outlet is not available, before supplying power to the equipment, use a
conversion adapter and ground the green wire, or connect the frame
ground on the rear panel of the equipment to ground. If power is
supplied without grounding the equipment, there is a risk of receiving
a severe or fatal electric shock.
4. This equipment cannot be repaired by the user. DO NOT attempt to
open the cabinet or to disassemble internal parts. Only Anritsu-
trained service personnel or staff from your sales representative with a
knowledge of electrical fire and shock hazards should service this
equipment. There are high-voltage parts in this equipment present-
ing a risk of severe injury or fatal electric shock to untrained personnel.
In addition, there is a risk of damage to precision parts.
Anritsu Corporation will not accept liability for any injuries sustained as
a result of opening the equipment covers.
5. This equipment should be used in the correct position. If the cabinet
is turned on its side, etc., it will be unstable and may be damaged if it
falls over as a result of receiving a slight mechanical shock.
Repair
Falling Over
or

For Safety
iv
iviv
iv
WARNING
6. When replacing the battery, use the specified battery and insert it with
the correct polarity. If the wrong battery is used, or if the battery is
inserted with reversed polarity, there is a risk of explosion causing
severe injury or death.
7. DO NOT short the battery terminals and never attempt to disassemble
it or dispose of it in a fire. If the battery is damaged by any of these
actions, the battery fluid may leak.
This fluid is poisonous.
DO NOT touch it, ingest it, or get in your eyes. If it is accidentally in-
gested, spit it out immediately, rinse your mouth with water and seek
medical help. If it enters your eyes accidentally, do not rub your eyes,
irrigate them with clean running water and seek medical help. If the
liquid gets on your skin or clothes, wash it off carefully and thoroughly.
8. This instrument uses a Liquid Crystal Display (LCD); DO NOT subject
the instrument to excessive force or drop it. If the LCD is subjected
to strong mechanical shock, it may break and liquid may leak.
This liquid is very caustic and poisonous.
DO NOT touch it, ingest it, or get in your eyes. If it is ingested acci-
dentally, spit it out immediately, rinse your mouth with water and seek
medical help. If it enters your eyes accidentally, do not rub your eyes,
irrigate them with clean running water and seek medical help. If the
liquid gets on your skin or clothes, wash it off carefully and thoroughly.
Replacing Battery
Battery Fluid
ＬＣＤ
ＬＣＤＬＣＤ
ＬＣＤ

For Safety
v
vv
v
CAUTION
1. Before changing the fuses, ALWAYS remove the power cord from the
poweroutlet and replace the blown fuses. ALWAYS use new fuses of
the type and rating specified on the fuse marking on the rear panel of
the cabinet.
Fuse label :
F10A indicate a normal fusing type fuse.
There is risk of receiving a fatal electric shock if the fuses are replaced
with the power cord connected.
2. Keep the power supply and cooling fan free of dust.
•Clean the power inlet regularly. If dust accumulates around the
power pins, there is a risk of fire.
•Keep the cooling fan clean so that the ventilation holes are not ob-
structed. If the ventilation is obstructed, the cabinet may overheat
and catch fire.
3. NEVER input a signal of more than the indicated value between the
measured terminal and ground. Input of an excessive signal may
damage the equipment.
Changing Fuse
Cleaning
Check Terminal

For Safety
vi
vivi
vi
WARNING
Optical output safety is assured by the correct operation of the optical
output warning means. If the light emission from optical output warning
means cannot be confirmed at power-On or optical switch On before us-
ing the optical output, the warning means may be faulty. In this case,
don’t use the equipment and ask repair to Anritsu Corp. or the represen-
tative.
Class 1, Class 2 and Class 3 indicates the degree of danger of the laser
radiation outlined below as defined by JIS C60825-1, IEC60825-1 and
21CFR1040.10.
Class 1 Safe laser presenting no danger when used according to des-
ign specifications.
Class 2 Laser radiating in 400 to 700 nm wavelength range. In prin-
cipal, this class of laser is not safe, but the danger to the eyes
is eliminated by the eye avoidance reaction including the blink
response.
Class 3A Laser radiating in 400 to 700 nm wavelength range. The
danger to the eyes is eliminated by the eye avoidance reaction
including the blink response. For lasers radiating at other
wavelengths, the degree of danger to the naked eyes is not
greater than Class 1.
Class 3B The eyes will be damaged if direct laser radiation enters the
eyes. Normally there is no danger if the diffused beam is ob-
served.
This equipment is a Class-1 Laser Product as defined by the relevant
safety specifications (JIS C60825-1, IEC60825-1, 21CFR1040.10).
Class 1 is indicated at the rear panel of this equipment.
LASER SAFETY
Laser Radiation Markings

For Safety
vii
viivii
vii
CAUTION
This equipment uses a fluoridation graphite lithium battery to back-up the
memory. This battery must be replaced by a service engineer when it
has reached the end of its useful life; contact the Anritsu sales section or
your nearest representative.
Note: The battery used in this equipment has a maximum useful life of 7
years. It should be changed before this period has elapsed.
Floppy disk drive may be damaged by the dust and dirt. For maintaining
the correct operation, perform cleaning the magnetic head, periodically.
This instrument uses parts with operating times or power-on time life
span These parts must be replaced at the customers expense even if
within the guaranteed period described in Warranty in the beginning of
this manual.
Pay attention to the life-span of parts used in continuous long-time op-
eration.
Changing memory
back-up battery
Floppy disk drive
Life time of parts

viii
viiiviii
viii
Equipment Certificate
Anritsu Corporation certifies that this equipment was tested before ship-
ment using calibrated measuring instruments with direct traceability to
public testing organizations recognized by national research laboratories
including the Electrotechnical Laboratory, the National Research Labora-
tory of Metrology and the Communications Research Laboratory, and was
found to meet the published specifications.
Anritsu Warranty
Anritsu Corporation will repair this equipment free-of-charge if a mal-
function occurs within 1 year after shipment due to a manufacturing fault,
provided that this warranty is rendered void under any or all of the fol-
lowing conditions.
•The fault is outside the scope of the warranty conditions described in
the operation manual.
•The fault is due to mishandling, misuse, or unauthorized modification
or repair of the equipment by the customer.
•The fault is due to severe usage clearly exceeding normal usage.
•The fault is due to improper or insufficient maintenance by the cus-
tomer.
•The fault is due to natural disaster including fire, flooding, earthquake,
etc.
•The fault is due to use of non-specified peripheral equipment,
peripheral parts, consumables, etc.
•The fault is due to use of a non-specified power supply or in a non-
specified installation location.
In addition, this warranty is valid only for the original equipment pur-
chaser. It is not transferable if the equipment is resold.
Anritsu Corporation will not accept liability for equipment faults due to
unforeseen and unusual circumstances, nor for faults due to mishandling
by the customer.
Anritsu Corporation Contact
If this equipment develops a fault, contact Anritsu Corporation or its rep-
resentatives at the address at the end of paper-edition manual or the
separate file of CD-edition manual.

ix
ixix
ix
Notes On Export Management
This product and its manuals may require an Export License/Approval by
the Government of the product's country of origin for re-export from your
country.
Before re-exporting the product or manuals, please contact us to confirm
whether they are export-controlled items or not.
Trademark
Windows is a registered trademark of Microsoft Corporation US.
Disposing of Product
This equipment uses chemical compound semiconductors including
arsenide, and a lithium battery. At the end of its life, the equipment
should be recycled or disposed properly according to the local disposal
regulations.

x
xx
x
Software License Agreement
Please read this Software License Agreement before using the accom-
panying software program (hereafter this software).
You are authorized to use this software only if you agree to all the terms of
this License.
By opening the sealed package containing this software, you are agreeing
to be bound by the terms of this License.
If you do not agree to these terms, return the unopened software package
to Anritsu Corporation (hereafter Anritsu).
1. License
(1) This License gives you the right to use this software on one computer
system.
(2) To use this software on one computer system, this License allows you
to make one copy of this software on the storage device of your com-
puter system.
(3) You must obtain a site license to use this software on more than one
computer system even if such computer systems are not operating
simultaneously.
2. Copyright
(1) Although you are licensed to use this software, Anritsu retains the
copyright.
(2) Although you have purchased this software, rights other than those
specified in this License are not transferred to you.
(3) You may not print, copy, modify, create derivative works, incorporate
in other software programs, decompile or disassemble this software
in whole or in part, without obtaining prior written permission from
Anritsu.
3. Copying
Notwithstanding item (3) of section 2 above, you may make one copy of
this software for backup purposes only. In this case, you may only use
either the backup copy or the original copy of this software.
4. Termination
(1) Anritsu will deem this License to be automatically terminated if you
fail to comply with any provision of this License. Upon termination,
you will lose all rights to this software.
(2) Either party (Anritsu or yourself) to this Software License Agree-
ment may terminate this Agreement by giving 1 months notice in
writing to the other party.
(3) Upon termination of this License for any reason, you must either
immediately destroy this software and related documentation, or re-
turn it to Anritsu.

xi
xixi
xi
CE Marking
Anritsu affixes the CE Conformity Marking on the following product (s) in
accordance with the Council Directive 93/68/EEC to indicate that they
conform with the EMC directive of the European Union (EU).
CE Conformity Marking
1. Product Name/Model Name
Product Name: Data Quality Analyzer, and Modules
Model Name: MD1230A, MU120101A, MU120102A,
MU120103A, MU120104A, MU120105A and
MU120106A
2. Applied Directive
EMC: Council Directive 89/336/EEC
LVD: Council Directive 73/23/EEC
3. Applied Standards
EMC:
Emission: EN61326: 1997/A1: 1998 (Class A)
Immunity:EN61326: 1997/A1: 1998 (Annex A)
Performance Criteria*
IEC61000-4-2 (ESD) B
IEC61000-4-3 (EMF) A
IEC61000-4-4 (Burst) B
IEC61000-4-5 (Surge) B
IEC61000-4-6 (CRF) A
IEC61000-4-8 (RPFMF) A
IEC61000-4-11 (V dip/short) B
*: Performance Criteria
A: During testing normal performance within the specifi-
cation limits.
B: During testing, temporary degradation, or loss of func-
tion or which is self-recovering.
Harmonic current emissions:
EN61000-3-2: 1995/A2: 1998 (Class A equipment)
LVD: EN61010-1: 1993/A2: 1995 (Installation Category II, Pollu-
tion Degree 2)

xii
xiixii
xii
Anritsu affixes the C-tick marking on the following product (s) in accor-
dance with the regulation to indicate that they conform with the EMC
framework of Australia/New Zealand
C-tick marking
1. Product Name/Model Name
Product Name: Data Quality Analyzer, and Modules
Model Name: MD1230A, MU120101A, MU120102A,
MU120103A, MU120104A, MU120105A and
MU120106A
2. Applied Standards
EMC:
Emission:
AS/NZS 2064.1/2 (ISM, Group 1, Class A equipment)
Immunity:
AS/NZS 4252.1
*Performance Criteria
IEC61000-4-2 (ESD) B
IEC61000-4-3 (EMF) A
IEC61000-4-4 (Burst) B
IEC61000-4-5 (Surge) B
IEC61000-4-6 (CRF) A
IEC61000-4-8 (RPFMF) A
IEC61000-4-11 (V dip/short) B
*: Performance Criteria
A: During testing normal performance within the specifi-
cation limits.
B: During testing, temporary degradation, or loss of func-
tion or which is self-recovering.

xiii
xiiixiii
xiii
Power Line Fuse Protection
For safety, Anritsu products have either one or two fuses in the AC power
lines as requested by the customer when ordering.
Single fuse: A fuse is inserted in one of the AC power lines.
Double fuse: A fuse is inserted in each of the AC power lines.
Example: An example of the double fuse is shown below:
Fuse Holders

xiv
xivxiv
xiv

I
II
I
About This Manual
This is a service manual written for service personnel trained by Anritsu
Service Course, and describes how to service the Anritsu MD1230A Data
Quality Analyzer, how to install the latest software version, and how to
troubleshoot faults.
Section 1 Outline of Operation
This section describes the configuration and the block diagram of this sys-
tem.
Section 2 Upgrading Software
This section describes how to upgrade the software of this system.
Section 3 Troubleshooting
This section describes how to locate faulty modules.
Section 4 Replacing Modules
This section describes how to replace modules.
This explains repair by exchanging modules but does not describe parts-
level repair of modules.
For specifications, operating instructions and a details of panel controls of
MD1230A, refer to the separate operation manuals.

II
IIII
II.
..
.
Table of Contents
For Safety ................................................... iii
About This Manual ....................................... I
Section 1 Outline of Operation................. 1-1
1.1 Exchangeable Module Lists.......................................... 1-2
1.2 Block Diagram .............................................................. 1-3
1.3 Module Function ........................................................... 1-4
1.4 General Circuit Diagram ............................................... 1-6
Section 2 Upgrading Software ................. 2-1
2.1 Installing the Software .................................................. 2-2
Section 3 Troubleshooting ....................... 3-1
3.1 General ......................................................................... 3-2
3.2 Preparation ................................................................... 3-3
3.3 Troubleshooting............................................................ 3-4
Section 4 Replacing Modules................... 4-1
4.1 Disassembly ................................................................. 4-2
4.2 MD1230A Disassembly ................................................ 4-3

Section 1
Section 1Section 1
Section 1 Outline of Operation
Outline of OperationOutline of Operation
Outline of Operation
1-
1-1-
1-1
11
1
This section describes the module and unit configuration, the block dia-
gram, module function and general circuit diagram of the MD1230A sys-
tem.
1.1 Exchangeable Module Lists ....................................... 1-2
1.1.1 Exchangeable Module Lists of MD1230A...... 1-2
1.2 Block Diagram ............................................................ 1-3
1.2.1 Block Diagram of MD1230A........................... 1-3
1.3 Module Function......................................................... 1-4
1.3.1 MD1230A ....................................................... 1-4
1.4 General Circuit Diagram............................................. 1-6
1.4.1 MD1230A ....................................................... 1-6

Section 1
Section 1Section 1
Section 1 Outline of Operation
Outline of OperationOutline of Operation
Outline of Operation
1-
1-1-
1-2
22
2
1.1 Exchangeable Module Lists
1.1.1 Exchangeable Module Lists of MD1230A
The MD1230A is composed of the 13 exchangeable modules listed in Table
1-1. If they develop a fault, simply changing the modules can repair it.
Plug-in units that can be inserted into the MD1230A are listed in Table 1-2.
Table 1-1 Exchangeable Modules of MD1230A
Part Number Name Material
Drawing Number
MM100217A CPU 44Y109162
MM100218A MOTHER 44Y109164
MM100219A INTERFACE 44Y109166
MM100220A R-FRONT 44Y109168
MM100221A L-FRONT 44Y109170
MM100222A D-FRONT 44Y109172
MM100223A HDD 44Y109176
MM100224A 44Z109348 Power supply
unit (1 fuse)
44Z109348
MM100225A 44Z109348B Power supply
unit (2 fuses)
44Z109348B
S4Z10398 3.5FDD-1/2S-2.0/1.6/1.0 S4Z10398
44Z109930 HDD 44Z109930
LTM08C351 LCD NO. 1251
VNL08C351-INV INVERTER NO. 1251
44Z103440 KEYBOARD 44Z103440
44Z109931 MOUSE 44Z109931
MD1230A-05 GPS NO. 7320
34048-00-AD ANTENNA NO. 7320
Table 1-2 Plug-in Units of MD1230A
Part Number Name Material
Drawing Number
MU120101A 10M/100M Ethernet
Module
44Y109200
MU120102A Gigabit Ethernet Module 44Y109207
MU120103A 2.5G (1.31) module 44Y109208
MU120104A 2.5G (1.55) module 44Y109209
MU120105A 10G (1.31) module 44Y109210
MU120106A 10G (1.55) module 44Y109211

1.2
1.21.2
1.2 Block Diagram
Block DiagramBlock Diagram
Block Diagram
1-
1-1-
1-3
33
3
1.2 Block Diagram
1.2.1 Block Diagram of MD1230A
Interface
Mother
L-Front R-Front D-FrontFDD
HDD
Inverter
Slot 1
GPIB
RS-232C
USB (Back)
VGA
CPU
Main-CPU
(Card-PC)
(Windows-98)
Sub-CPU
(SH-3)
(pSOS)
GPS (Option)
HUB
Slot 5
PCI-bus
(32 bits/33 MHz)
A
ntenna
Ethernet
(10/100 M)
DCS
Keyboard
USB (Front)
to
Serial
LCD

Section 1
Section 1Section 1
Section 1 Outline of Operation
Outline of OperationOutline of Operation
Outline of Operation
1-
1-1-
1-4
44
4
1.3 Module Function
1.3.1 MD1230A
(1) CPU (MM100217A)
This module controls the MD1230A using the built-in main CPU and
sub CPU.
Main CPU has the human interface functions of LCD display and key
control. Sub CPU has the function of the hardware control for meas-
urement and collection of the measured results. Both CPUs are con-
nected with Ethernet and RS-232C interfaces, and the Ethernet can
be connected to any external device through a hub device.
(2) MOTHER (MM100218A)
This module has six slots conformed to ConpactPCI standard, and
connects the CPU port to five plug-in modules, and also connect the
signal lines from CPU to Interface module.
(3) INTERFACE (MM100219A)
This module relays the input/output signals from/to CPU in order to
deliver them to external connectors and each module of D-Front, R-
Front, and L-Front.
(4) R-FRONT (MM100220A)
This module has the panel keys and LEDs at the right side of the
front panel.
(5) L-FRONT (MM100221A)
This module has the panel keys and LEDs at the left side of the front
panel.
(6) D-FRONT (MM100222A)
This module has the connectors of keyboard and USB at the right bot-
tom of the front panel.
(7) HDD (MM100223A)
This module saves the softwares such as Windows 98 etc..
(8) 44Z109348 Power Supply unit (1 fuse) (MM100224A)
This module provides DC power to each module.
(9) 44Z109348B Power Supply unit (2 fuses) (MM100225A)
This module provides DC power to each module.
(10) 3.5FDD-1/2S-2.0/1.6/1.0 (S4Z10398)
This module saves the measurement conditions or the measured data
into the floppy disks, and loads the measurement conditions or the
measured data from these.
(11) HDD (44Z109930)
The HDD part of HDD (MM100223A).
