Anritsu ShockLine MS46322A Series User manual

Maintenance Manual
ShockLine™
Vector Network Analyzer
MS46322A
1MHz to 4GHz
1MHz to 8GHz
1MHz to 14GHz
1MHz to 20GHz
1MHz to 30GHz
1MHz to 43.5GHz
MS46322B
1MHz to 8GHz
1MHz to 20GHz
1MHz to 43.5GHz
Anritsu Company
490 Jarvis Drive
Morgan Hill, CA 95037-2809
USA
Part Number: 10410-00342
Revision: J
Published: October 2022
Copyright 2018 Anritsu Company. All Rights Reserved.

NOTICE
Anritsu Company has prepared this manual for use by Anritsu Company personnel and customers as a guide for the
proper installation, operation and maintenance of Anritsu Company equipment and computer programs. The
drawings, specifications, and information contained herein are the property of Anritsu Company, and any
unauthorized use or disclosure of these drawings, specifications, and information is prohibited; they shall not be
reproduced, copied, or used in whole or in part as the basis for manufacture or sale of the equipment or software
programs without the prior written consent of Anritsu Company.
UPDATES
The latest service and sales contact information, and updated documents can be downloaded from the Anritsu
Website at: http://www.anritsu.com

MS46322A/B MM PN: 10410-00342 Rev. J Contents-1
Table of Contents
Chapter 1 — General Information
1-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1-2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Standard Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Available Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Identification Number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1-3 Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1-4 Basic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Maintain Operating System Integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Antivirus Protection – Best Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Windows OS Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Solid State Drive Data Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Performance Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Repair Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1-5 Anritsu Customer Service Centers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1-6 Recommended Test Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1-7 Replaceable Parts and Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Chapter 2 — MS46322A Performance Verification
2-1 Introduction to Performance Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-2 VNA Traceability and Uncertainty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
First Tier of Uncertainty  The VNA Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Second Tier of Uncertainty  Systematic Measurement Errors. . . . . . . . . . . . . . . . . . . . . . 2-2
Third Tier of Uncertainty  Random Measurement Error . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Standards and Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2-3 Electrostatic Discharge Prevention. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2-4 Calibration and Measurement Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2-5 System Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Verification Result Determination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2-6 System Verification Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Special Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Chapter 3 — MS46322B Performance Verification
3-1 Introduction to Performance Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3-2 VNA Traceability and Uncertainty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
First Tier of Uncertainty  The VNA Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Second Tier of Uncertainty  Systematic Measurement Errors. . . . . . . . . . . . . . . . . . . . . . 3-2
Third Tier of Uncertainty  Random Measurement Error . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Standards and Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3-3 Electrostatic Discharge Prevention. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Contents-2 PN: 10410-00342 Rev. J MS46322A/B MM
Table of Contents (Continued)
3-4 Calibration and Measurement Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3-5 Performance Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3-6 System Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Verification Result Determination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3-7 System Verification Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Special Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Verification Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3-8 Instrument Key Parameter Performance Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
PASS/FAIL Determination for Instrument Key Parameter Performance Tests . . . . . . . . . . 3-9
3-9 Frequency Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
3-10 Output Power (Operational Test) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3-11 System Dynamic Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3-12 High Level Noise (Operational Test). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Chapter 4 — Adjustment
4-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4-2 Source Level Adjustment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4-3 IF Adjustment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4-4 Time Base Adjustment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4-5 Factory RF Calibration (RF Cal) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4-6 Thru Line Length Determination Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Chapter 5 — Troubleshooting
5-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5-2 General Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

MS46322A/B MM PN: 10410-00342 Rev. J Contents-3
Table of Contents (Continued)
5-3 Troubleshooting Test – Power Supply DC Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Reference Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5-4 Troubleshooting Test – Non-Ratio Power Level Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5-5 Troubleshooting Turn-on Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Unit Cannot Boot Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Unit Cannot Boot into Windows OS environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Unit Cannot Launch ShockLine Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
5-6 Troubleshooting Operating Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Frequency Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
RF Power Related Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5-7 Troubleshooting Measurement Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
VNA Measurement Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Checking Possible Measurement Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Chapter 6 — Assembly Removal and Replacement
6-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-2 Electrostatic Discharge Prevention. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-3 Basic Assembly Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-4 Disassembly Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Common Disassembly Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6-5 VNA Module Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Reference Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Replacement Procedure (For instruments with Options 4 or 10) . . . . . . . . . . . . . . . . . . . 6-12
Replacement Procedure (For Instruments with Options 14, 20, 30, 40, or 43) . . . . . . . . . 6-13
6-6 CPU Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Replacement Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Reference Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
6-7 Solid State Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
Replacement Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
Reference Figure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
Replacement Procedure for MS46322A Revision 1 Instrument . . . . . . . . . . . . . . . . . . . . 6-19
Replacement Procedure for MS46322A Revision 2 Instrument and MS46322B . . . . . . . 6-19
6-8 Back Plane PCB Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
Replacement Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
Reference Figure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21

Contents-4 PN: 10410-00342 Rev. J MS46322A/B MM
Table of Contents (Continued)
6-9 IO Handler PCB Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
Reference Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
Replacement Procedure for IO Handler PCB Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
6-10 Fan Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-23
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-23
Reference Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-23
Replacement Procedure for Right Fan Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24
Replacement Procedure for Left Fan Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25
Replacement Procedure for Rear Fan Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25
6-11 Power Supply Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Replacement Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Reference Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28
6-12 Test Port Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-29
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-29
Reference Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-29
Replacement Procedure  N(f) Test Port Adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32
Replacement Procedure  K(m) Test Port Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32
6-13 Front Panel LED PCB Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-33
Replacement Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-33
Reference Figure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-33
Replacement Procedure  Instruments with N(f) Test Ports . . . . . . . . . . . . . . . . . . . . . . . 6-34
Replacement Procedure  Instruments with K(m) Test Ports . . . . . . . . . . . . . . . . . . . . . . 6-34
Appendix A — Test Records
A-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A-2 ShockLine MS46322A/B System Performance Test Record . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
System Performance Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A-3 ShockLine MS46322B Instrument Performance Test Record . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Frequency Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Output Power (Operational Test). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
System Dynamic Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
High Level Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8
Index

MS46322A/B MM PN: 10410-00342 Rev. J 1-1
Chapter 1 — General Information
1-1 Introduction
This manual provides service and maintenance information for the Anritsu ShockLine MS46322A/B Vector
Network Analyzer. The information includes product description, performance verification procedures, parts
removal and replacement procedures, and troubleshooting information.
1-2 Description
The ShockLine MS46322A/B Vector Network Analyzer is an instrument system that contains a built-in source,
test set, and analyzer. Designed for manufacturing applications, the ShockLine MS46322A/B supports remote
test programming through LAN communications. Test results can be displayed real time on an external video
monitor.
Standard Accessories
Each instrument includes:
•Power Cord
Available Options
The main system options of MS46322A are:
•MS46322A-001 Rack Mount
•MS46322A-002 Time Domain
•MS46322A-004 Frequency Option, 1 MHz to 4 GHz, type N(f) test ports
•MS46322A-010 Frequency Option, 1 MHz to 8 GHz, type N(f) test ports
•MS46322A-014 Frequency Option, 1 MHz to 14 GHz, type K(m) test ports
•MS46322A-020 Frequency Option, 1 MHz to 20 GHz, type K(m) test ports
•MS46322A-030 Frequency Option, 1 MHz to 30 GHz, type K(m) test ports
•MS46322A-040 Frequency Option, 1 MHz to 43.5 GHz, type K(m) test ports
The main system options of MS46322B are:
•MS46322B-001 Rack Mount
•MS46322B-002 Time Domain
•MS46322B-010 Frequency Option, 1 MHz to 8 GHz, type N(f) test ports
•MS46322B-020 Frequency Option, 1 MHz to 20 GHz, type K(m) test ports
•MS46322B-024 Universal Fixture Extraction Option
•MS46322B-040 Frequency Option, 1 MHz to 43.5 GHz, type K(m) test ports
•MS46322B-043 Frequency Option, 1 MHz to 43.5 GHz, type K(m) test ports

1-3 Related Documents General Information
1-2 PN: 10410-00342 Rev. J MS46322A/B MM
Identification Number
All Anritsu MS46322A/B instruments are assigned a seven-digit ID number (Serial Number), such as
“1334203”. This number appears on a decal affixed to the rear panel.
When corresponding with Anritsu Customer Service, please use this identification number with reference to
the specific instrument model number and installed options.
For example, a MS46322A/B, Option 2, Option 10, Serial Number 1234567.
1-3 Related Documents
Other documents are available for the MS46322A/B at the Anritsu web site at: www.anritsu.com
•ShockLine MS46322A VNA Technical Data Sheet – part number 11410-00751
•ShockLine MS46322B VNA Technical Data Sheet – part number 11410-00996
•ShockLine MS46322A/B VNA Operation Manual – part number 10410-00335
•ShockLine MS46122A/B, MS46131A, MS46322A/B VNA Calibration and Measurement Guide –
part number 10410-00336
•ShockLine MS46121A/B, MS46122A/B, MS46131A, MS46322A/B VNA User Interface Reference Manual
– part number 10410-00337
•ShockLine MS4612xA/B, MS46131A, MS46322A/B, MS4652xB VNA Programming Manual – part
number 10410-00746
•ShockLine Product Information, Compliance, and Safety – 10100-00067
1-4 Basic Maintenance
Maintain Operating System Integrity
The Microsoft Windows Embedded operation system on the ShockLine MS46322A/B is configured for optimum
performance when the instrument leaves the factory. To maintain the system’s operating integrity, follow
proper Windows shutdown procedure and DO NOT modify the operating system configuration, the firewall
settings, the system registry, the solid state drive partitions, or the Anritsu user account.
Antivirus Protection – Best Practices
If the VNA is attached to a network, best practices recommend installing antivirus software. Anritsu
recommends connecting the instrument only to a secure network.
The user assumes the responsibility to provide virus protection because this is not supplied with the
instrument. Contact your network administrator for information about your network security and antivirus
protection policies.
Windows OS Updates
Not all Microsoft updates are compatible with the ShockLine MS46322A/B VNA and, if installed, may affect
the performance of the instrument.
Note Stability of the system is not guaranteed with all antivirus software.
Caution
Changing some of the default Windows settings may cause a loss of instrument control or undesired
instrument behavior. Changing the Windows Regional and Language Options settings may cause
unstable menu operation. These settings must be maintained as English (United States) as is set at
the factory by default.

General Information 1-5 Anritsu Customer Service Centers
MS46322A/B MM PN: 10410-00342 Rev. J 1-3
Solid State Drive Data Backup
Anritsu recommends that you make a backup copy of your critical data stored on the VNA solid state drive as
often as possible.
Performance Verification
Test instruments are often put on a regular interval to re-verify their performance to ensure accuracy,
reliability, and cost of ownership. The details of the performance verification procedures are included in
Chapter 2 — MS46322A Performance Verification and Chapter 3 — MS46322B Performance Verification.
Repair Service
In the event that the MS46322A/B VNA requires repair, contact your local Anritsu Service Center. See
Section 1-5 “Anritsu Customer Service Centers” for contact information. When contacting Anritsu Service
Center, please provide the following information:
•Your company name and address
•The model number and serial number of the instrument
•A detailed description of the problem
1-5 Anritsu Customer Service Centers
For the latest service and sales information in your area, please visit the following URL:
https://www.anritsu.com/contact-us
Choose a country for regional contact information.
Note Anritsu reserves the right to reformat or replace the VNAs solid state drive as part of the repair.
In such incidence, all user data on the drive will be erased.

1-6 Recommended Test Equipment General Information
1-4 PN: 10410-00342 Rev. J MS46322A/B MM
1-6 Recommended Test Equipment
The following test equipment is recommended for use in testing and maintaining the ShockLine MS46322A
(Table 1-1) and MS46322B (Table 1-2).
Table 1-1. Recommended Test Equipment for MS46322A (1 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
Use
Codesa
Calibration Tee
(For Opt. 4 or 10)
Frequency: DC to 8 GHz
Connector: N(m)
Anritsu Model OSLN50A-8 or
TOSLN50A-8
P
Calibration Tee
(For Opt. 4 or 10)
Frequency: DC to 8 GHz
Connector: N(f)
Anritsu Model OSLN50A-8 or
TOSLN50A-8
P
Verification Kit
(For Opt. 4 or 10)
Connector: N Type Anritsu Model 3663-2
(Includes Verification Software)
P
Torque Wrench 3/4 in Open End Wrench
12 lb·in (1.35 N·m)
Anritsu Model 01-200 P, A
Adapter
(For Opt. 4 or 10)
Frequency: DC to 18 GHz
Connector: N(m) to K(m)
Anritsu Model 34NK50 P, A
Adapter
(For Opt. 4 or 10)
Frequency: DC to 18 GHz
Connector: N(m) to K(f)
Anritsu Model 34NKF50 P, A
RF Coaxial Cable
Frequency: DC to 40 GHz
Impedance: 50 ohm
Connector: K(f) to K(m)
Anritsu Model 3670K50-2 P, A
Calibration Tee
(For Opt. 14, 20, 30, or 40)
Frequency: DC to 40 GHz
Connector: K(m)
Anritsu Model TOSLK50A-40 P
Calibration Tee
(For Opt. 14, 20, 30, or 40)
Frequency: DC to 40 GHz
Connector: K(f)
Anritsu Model TOSLKF50A-40 P
Verification Kit
(For Opt. 14, 20, 30 or 40)
Connector: K Type Anritsu Model 3668-2
(Includes Verification Software)
P
Torque Wrench
(For Opt. 14, 20, 30, or 40)
5/16 in Open End Wrench
8 lb·in (0.90 N·m)
Anritsu Model 01-201 P, A
Torque Wrench
(For Opt. 14, 20, 30, or 40)
13/16 in Open End Wrench
8 lb·in (0.90 N·m)
Anritsu Model 01-203 P
Adapter
(For Opt. 14, 20, 30, or 40)
Connector: K(m) to K(f) Anritsu Model 33KKF50B P
Adapter
(For Opt. 14, 20, 30, or 40)
Connector: K(f) to K(f) Anritsu Model 33KFKF50B P, A
Interface Cable Ethernet: RJ45, cross-over, Cat.5E
Ethernet: RJ45, Cat.5E
Anritsu Part Number 3-806-152
Anritsu Part Number 2000-1371-R
P
Personal Computer
Operating System: Windows 7
Interface: Ethernet (RJ45)
Software: National Instruments
VISA version 4.4.1 or later
Any P
Calibration Kit
(For Opt. 4 or 10)
Frequency: DC to 18 GHz
Connector: N Type
Anritsu Model 3653A A
Calibration Kit
(For Opt. 14, 20, 30, or 40)
Frequency: DC to 40 GHz
Connector: K Type
Anritsu Model 3652A A
Frequency Counter Frequency: 10 MHz to 20 GHz Anritsu Model MF2412B with
Option 3 or MF2412C with Option 3
A

General Information 1-6 Recommended Test Equipment
MS46322A/B MM PN: 10410-00342 Rev. J 1-5
Power Sensor
(For Opt. 4 or10)
Frequency: 10 MHz to 18 GHz
Connector Type: N(m)
Anritsu Model MA24118A A
Power Sensor
(For Opt. 14, 20, 30, or 40)
Frequency: 10 MHz to 40 GHz
Connector Type: K(m)
Anritsu Model SC8268 A
a. P = Performance Verification; A = Adjustment
Table 1-2. Recommended Test Equipment for MS46322B (1 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
Use
Codesa
Calibration Tee
(For Opt. 10)
Frequency: DC to 8 GHz
Connector: N(m)
Anritsu Model OSLN50A-8 or
TOSLN50A-8
P
Calibration Tee
(For Opt. 10)
Frequency: DC to 8 GHz
Connector: N(f)
Anritsu Model OSLN50A-8 or
TOSLN50A-8
P
Verification Kit
(For Opt. 10)
Connector: N Type Anritsu Model 3663-3
(Includes Verification Software)
P
Torque Wrench
(For Opt. 10)
3/4 in Open End Wrench
12 lb·in (1.35 N·m)
Anritsu Model 01-200 P, A
Adapter
(For Opt.10)
Frequency: DC to 18 GHz
Connector: N(m) to K(m)
Anritsu Model 34NK50 P, A
Adapter
(For Opt.10, 40, or 43)
Frequency: DC to 18 GHz
Connector: N(m) to K(f)
Anritsu Model 34NKF50 P, A
RF Coaxial Cable
(For Opt. 10, 20 or 40)
Frequency: DC to 40 GHz
Impedance: 50 ohm
Connector: K(f) to K(m)
Anritsu Model 3670K50-2 P, A
Calibration Tee
(For Opt. 20 or 40)
Frequency: DC to 40 GHz
Connector: K(m)
Anritsu Model TOSLK50A-40 P
Calibration Tee
(For Opt. 20 or 40)
Frequency: DC to 40 GHz
Connector: K(f)
Anritsu Model TOSLKF50A-40 P
Verification Kit
(For Opt. 20 or 40)
Connector: K Type Anritsu Model 3668-3
(Includes Verification Software)
P
Calibration Tee
(For Opt. 43)
Frequency: DC to 43.5 GHz
Connector: K(m)
Anritsu Model TOSLK50A-43.5 P
Calibration Tee
(For Opt. 43)
Frequency: DC to 43.5 GHz
Connector: K(f)
Anritsu Model TOSLKF50A-43.5 P
Verification Kit
(For Opt. 43)
Connector: K type Anritsu Model 3668-4
(Includes Verification Software)
P
RF Coaxial Cable
(For Opt. 43)
Frequency: DC to 43.5 GHz
Impedance: 50 ohm
Connector: K(f) to K(m)
Anritsu Model 3670K50A-2 P, A
Torque Wrench
(For Opt. 20, 40, or 43)
5/16 in Open End Wrench
8 lb·in (0.90 N·m)
Anritsu Model 01-201 P, A
Torque Wrench
(For Opt. 20, 40, or 43)
13/16 in Open End Wrench
8 lb·in (0.90 N·m)
Anritsu Model 01-203 P
Table 1-1. Recommended Test Equipment for MS46322A (2 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
Use
Codesa

1-6 Recommended Test Equipment General Information
1-6 PN: 10410-00342 Rev. J MS46322A/B MM
Adapter
(For Opt. 20 or 40)
Connector: K(m) to K(f) Anritsu Model 33KKF50B P
Adapter
(For Opt. 20 or 40)
Connector: K(f) to K(f) Anritsu Model 33KFKF50B P, A
Adapter
(For Opt. 43)
Connector: K(m) to K(f) Anritsu Model 33KKF50C P
Adapter
(For Opt. 43)
Connector: K(f) to K(f) Anritsu Model 33KFKF50C P, A
Interface Cable Ethernet: RJ45, cross-over, Cat.5E
Ethernet: RJ45, Cat.5E
Anritsu Part Number 3-806-152
Anritsu Part Number 2000-1371-R
P
Personal Computer
Operating System: Windows 7 or
higher
Interface: Ethernet (RJ45)
Software: National Instruments
VISA version 4.4.1 or later
Any P
Calibration Kit
(For Opt. 10)
Frequency: DC to 18 GHz
Connector: N Type
Anritsu Model 3653A A
Calibration Kit
(For Opt. 20, 40, or 43)
Frequency: DC to 40 GHz
Connector: K Type
Anritsu Model 3652A A
Frequency Counter Frequency: 10 MHz to 20 GHz Anritsu Model MF2412B with
Option 3 or MF2412C with Option 3
A
Power Sensor
(For Opt. 10)
Frequency: 10 MHz to 18 GHz
Connector Type: N(m)
Anritsu Model MA24118A A
Power Sensor
(For Opt. 20, 40, or 43)
Frequency: 10 MHz to 40 GHz
Connector Type: K(m)
Anritsu Model SC8268 A
Power Meter Power Range: -70 to +20 dBm Anritsu Model ML2438A P
Power Sensor
(For Opt. 10)
Frequency: 100 kHz to 18 GHz
Connector Type: N(m)
Anritsu Model SC7400 P
Power Sensor
(For Opt. 20, 40, or 43)
Frequency: 100 kHz to 40 GHz
Connector Type: K(m)
Anritsu Model SC7413 P
Termination
(For Opt. 20 or 40)
Frequency: DC to 40 GHz
Connector Type: K(m)
Anritsu Model 28K50A P
a. P = Performance Verification; A = Adjustment
Table 1-2. Recommended Test Equipment for MS46322B (2 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
Use
Codesa

General Information 1-7 Replaceable Parts and Assemblies
MS46322A/B MM PN: 10410-00342 Rev. J 1-7
1-7 Replaceable Parts and Assemblies
To ensure that the correct options are provided on the replacement assembly when ordering a VNA Module
Assembly, all installed instrument options must be declared on the order.
The installed options are listed on a label on the rear panel of the MS46322A/B. They can also be viewed in the
ShockLine application About box display (Select 9 Help | 1.About Anritsu).
Table 1-3 and Table 1-4 below summarize the available replaceable parts and assemblies. Refer to
Chapter 6, “Assembly Removal and Replacement” for detailed procedures.
Table 1-3. MS46322A Replaceable Parts and Assemblies (1 of 2)
Part Number Description
ND81295-RFB VNA Module Assembly for MS46322A instruments with Option 4
ND81296-RFB VNA Module Assembly for MS46322A instruments with Option 10
ND81297-RFB VNA Module Assembly for MS46322A instruments with Option 14
ND81298-RFB VNA Module Assembly for MS46322A instruments with Option 20
ND81299-RFB VNA Module Assembly for MS46322A instruments with Option 30
ND81300-RFB VNA Module Assembly for MS46322A instruments with Option 40
ND80983-RFB CPU Assembly
ND80984-RFB Solid State Drive with Operating System software
ND80997-RFB Solid State Drive with Operating System software
(For Revision 2 instrument only)
ND80994-RFB Back Plane PCB Assembly
ND80995-RFB IO Handler PCB Assembly
(For Revision 2 instrument only)
ND81163 Front Panel LED PCB Assembly
ND80986 Fan Assembly, Right
ND80987 Fan Assembly, Left
ND80989 Fan Assembly, Rear
3-40-191 Power Supply Assembly
ND80990 19V CPU Main Board Cable Assembly
ND80991 5V Power Supply Cable Assembly
ND80992 12V and 3.3V Power Supply Cable Assembly
ND81711 VNA Module 12V Power Cable
3-513-122 N female Test Port Adapter
(For Instruments with Options 4 or 10)
3-75651 K male Test Port Adapter
(For Revision 1 Instruments with Options 14, 20, 30 or 40)
3-71353 K male Test Port Adapter
(For Revision 2 Instruments with Options 14, 20, 30 or 40)
3-806-279 RF Cable, SMA(m) to SMA(m), N female Test Port Adapter to VNA Module Assembly
(For instruments with Options 4 or 10)

1-7 Replaceable Parts and Assemblies General Information
1-8 PN: 10410-00342 Rev. J MS46322A/B MM
3-806-283 RF Cable, BNC(f) to MCX(m), 10 MHz Ref In or Trigger TTL
3-806-288 Interface Cable, USB Mini B to 4 pin header, VNA Module Assembly to CPU Module
3-806-315 RF Cable, K(f) to K(m), K male Test Port Adapter to VNA Module Assembly
(For Revision 1 Instruments with Options 14. 20, 30 or 40)
3-806-362 RF Cable, K(m) to K(m), K male Test Port Adapter to VNA Module Assembly
(For Revision 2 Instruments with Options 14, 20, 30 or 40)
Table 1-4. MS46322B Replaceable Parts and Assemblies (1 of 2)
Part Number Description
3-ND83420-RFB VNA Module Assembly for MS46322B instruments with Option 10 with serial number
< 1822002, except for 1819001
3-ND83985-RFB VNA Module Assembly for MS46322B instruments with Option 10 with serial number
>= 1822002, including for 1819001
3-ND83421-RFB VNA Module Assembly for MS46322B instruments with Option 20 with serial number
< 1822002, except for 1819001
3-ND83986-RFB VNA Module Assembly for MS46322B instruments with Option 20 with serial number
>= 1822002, including for 1819001
3-ND83422-RFB VNA Module Assembly for MS46322B instruments with Option 40 with serial number
< 1822002, except for 1819001
3-ND83987-RFB VNA Module Assembly for MS46322B instruments with Option 40 with serial number
>= 1822002, including for 1819001
3-ND84774-RFB VNA Module Assembly for MS46322B instruments with Option 43
3-ND83587-RFB CPU Assembly for Rev 1 and 2 instruments with serial number < 2234001
3-ND87247-RFB CPU Assembly for Rev 3 instruments with serial number >= 2234001
3-ND87278 CPU Assembly Conversion Kit for Rev 1 and 2 Instruments to Rev 3 Instrument
3-ND83423 Solid State Drive with Operating System Software (Win 7)
3-ND85711 Solid State Drive with Operating System Software (Win 10)
3-ND80994 Back Plane PCB Assembly for Rev 1 and 2 instruments with serial number < 2234001
3-ND87249-RFB Back Plane PCB Assembly for Rev 3 instruments with serial number >= 2234001
3-ND80995-RFB IO Handler PCB Assembly
3-ND81163 Front Panel LED PCB Assembly
3-ND80986 Fan Assembly, Right
3-ND80987 Fan Assembly, Left
3-ND83585 Fan Assembly, Rear
3-40-191 Power Supply Assembly
3-ND83586 19V CPU Main Board Cable Assembly
Table 1-3. MS46322A Replaceable Parts and Assemblies (2 of 2)
Part Number Description

General Information 1-7 Replaceable Parts and Assemblies
MS46322A/B MM PN: 10410-00342 Rev. J 1-9
3-ND80991 5V Power Supply Cable Assembly
3-ND80992 12V and 3.3V Power Supply Cable Assembly
3-ND81711 VNA Module 12V Power Cable
3-513-122 N female Test Port Adapter (For Instruments with Option 10)
3-71353 K male Test Port Adapter (For Instruments with Options 20 or 40)
3-84738 K male Test Port Adapter (For Instruments with Option 43)
3-806-279 RF Cable, SMA(m) to SMA(m), N female Test Port Adapter to VNA Module Assembly
(For instruments with Option 10)
3-806-362 RF Cable, K(m) to K(m), K male Test Port Adapter to VNA Module Assembly
(For Instruments with Options 20, 40, or 43)
3-806-283 RF Cable, BNC(f) to MCX(m), 10 MHz Ref In or Trigger TTL
3-806-288 Interface Cable, USB Mini B to 4 pin header, VNA Module Assembly to CPU Module
Table 1-4. MS46322B Replaceable Parts and Assemblies (2 of 2)
Part Number Description

1-7 Replaceable Parts and Assemblies General Information
1-10 PN: 10410-00342 Rev. J MS46322A/B MM

MS46322A/B MM PN: 10410-00342 Rev. J 2-1
Chapter 2 — MS46322A Performance
Verification
2-1 Introduction to Performance Verification
This chapter provides procedures to be used to verify the performance of ShockLine MS46322A.
There are many levels to the concept of VNA “verification”.
On the explicit VNA hardware level are operational checkout items such as port power and noise levels.
On the calibrated instrument level (which includes the VNA and the calibration kit or AutoCal™ Automatic
Calibrator) are the system residual specifications (corrected directivity, source match, load match, and
tracking) which are measured using airlines (traceable impedance standards).
An intermediate level which can look at overall system behavior (VNA, calibration kit, cables, environment) in
a traceable fashion is through the use of a verification kit. While not intended for day-to-day use, the
verification kit can provide a periodic check on system behavior without going through the rigor needed for full
residual analysis (which can usually be done less often).
While there are many ways of verifying VNA performance, sometimes simpler procedures are desired. The use
of verification kit, available from Anritsu, is a simpler method of verifying the measurement capabilities of the
instrument by analyzing the measurement of artifacts that are traceable to International System of Units (SI)
via national metrology institutes.
2-2 VNA Traceability and Uncertainty
Vector network analyzers (VNAs) are precision instruments for making high frequency and broadband
measurements in devices, components, and instrumentations. The accuracy of these measurements is affirmed
by demonstrated and adequate traceability of measurement standards. Metrological traceability, per
International Vocabulary of Metrology, JCGM 200:2012, is property of a measurement result whereby the
result can be related to a reference through a documented unbroken chain of calibrations, each contributing to
the measurement uncertainty. For the accuracy of VNAs and quality assurance by users, two standard
approaches were created to ensure sound metrology traceability. One is to construct tight uncertainty budget
and specifications in three tiers from the ground up, and the other is to develop a calibration hierarchy for
systematic verification. The three-tier process is depicted in the sections below.
First Tier of Uncertainty  The VNA Calibration
A traceable VNA itself requires proper calibration for several key quantities, e.g., frequency, power level, and
high level noise, via traceable standards to the SI units. Each contributing uncertainty was evaluated at the
time of instrument calibration.
The inception of a precision VNA is accuracy-enhanced 50 ohm impedance, which is characterized in lieu of
coaxial transmission lines all with proper propagation properties throughout the whole measurement systems
including the device-under-test. A transmission line for VNAs is best represented by a coaxial airline, which
was precisely selected and machined based on the electromagnetic properties such as conductivity, skin depth,
and etc. Therefore, the dimensional measurement accuracy of the airline gives out the first tier of
measurement uncertainty of impedance quantity.

2-2 VNA Traceability and Uncertainty MS46322A Performance Verification
2-2 PN: 10410-00342 Rev. J MS46322A/B MM
Second Tier of Uncertainty  Systematic Measurement Errors
The second tier of uncertainty, corrected or residual uncertainty, is the result of the accuracy enhancement of
VNA calibration to remove systematic errors. Systematic measurement errors are components of measurement
error that in replicate measurements remains constant or values in a predictable manner. This accuracy
enhancement is usually the function of calibration kits. The choice of calibration kits used will dictate the level
of uncertainties for the intended measurements or applications.
Third Tier of Uncertainty  Random Measurement Error
The third tier of uncertainty is random measurement error that in replicate measurements varies in an
unpredictable manner. The examples are connector repeatability, cable stability, and etc. Random
measurement error equals measurement error minus systematic measurement error.
Standards and Verification
Most often instrument end users demand system verifications in order to provide quality check or assurance.
This is accomplished by utilizing a set of known or characterized devices, e.g., verification kit, for comparison.
It can also be done by using devices that are different from the calibration kit. The calibration hierarchy of
verification uncertainty is built through unbroken chain comparisons with the national standards, as
illustrated in Figure 2-1.
•Physical standards airline dimensionality impedance standard residuals and port parameters
•Basic power standards power sensors power accuracy specifications
•Basic time standards frequency reference source frequency accuracy
f
Figure 2-1. VNA Traceability
Verification Kit
Working Standards
Verification Kit
Reference Standards
Verification Kit
Traveling Standards
Users Anritsu National Standards
Calibration Kit
Working Standards
Calibrated VNA1
Reference Standards
Calibrated VNA1
Reference Standards
Calibration Kit
Working Standards
Assurance Airline
(i.e. Partially Supported
Airline)
Calibrated VNA1
Reference Standards
Calibration Kit
Working Standards
NIST Airline
(i.e. Beadless Airline)
Working Standards
System Verification2
Calibrated VNA1- Without error-correction (accuracy enhancement) by calibration kit
System Verification2- S-parameter measurements with error-correction

MS46322A Performance Verification 2-3 Electrostatic Discharge Prevention
MS46322A/B MM PN: 10410-00342 Rev. J 2-3
2-3 Electrostatic Discharge Prevention
A VNA is a precision electronic instrument consisting of components and/or circuitries that are sensitive to
electrostatic discharge (ESD). In order to prevent intrusion of electrostatic charge and mitigate risk of costly
ESD damage, it is important to take preventive measures to protect against ESD before and during usage. For
example, prior to connecting a test port cable to the VNA test port, take steps to eliminate the static charges
built up on the test port cable. This can be done by terminating the open end of the cable with the short from
the calibration kit and then grounding the outer conductor of the connector on the cable.
2-4 Calibration and Measurement Conditions
The surrounding environmental conditions and the condition and stability of the test port connectors, thru
cable, and calibration kit determine system measurement integrity to a large extent.
These are all user controlled conditions, and as such, should be evaluated periodically for impact on system
performance.
The standard conditions specified below must be observed when performing any of the operations in this
chapter – both during calibration and during measurement.
•Warm-up Time:
•30 minutes
•Environmental Conditions
•Temperature
•23 °C ± 3 °C, with < 1 °C variation from calibration temperature
•Relative Humidity
•20-50% recommended
Using best measurement practices and maintaining environmental conditions within specified limits during
calibration and measurements are critical requirements for performing system verification that involves
reliable high-quality measurements with associated measurement uncertainties. Note that both of these key
factors affect the measurement uncertainty.

2-5 System Verification MS46322A Performance Verification
2-4 PN: 10410-00342 Rev. J MS46322A/B MM
2-5 System Verification
The system verification procedures verify the measurement capabilities of the VNA, calibration kit, test port
cables, and any required adapters as a system by analyzing the measurement of artifacts that are traceable to
national standards laboratories. The procedures are automated by using the automated System Verification
Software (PVS), in conjunction with the appropriate Anritsu Calibration and Verification Kits listed in the
table below.
Table 2-1. Equipment Required for MS46322A System Verification
Equipment Critical Specification Recommended Manufacturer/Model
Calibration Kit
(For Opt. 4 or 10)
Frequency: DC to 8 GHz
Connector: N (m)
Anritsu Model OSLN50A-8 or
TOSLN50A-8
Calibration Kit
(For Opt. 4 or 10)
Frequency: DC to 8 GHz
Connector: N (f)
Anritsu Model OSLN50A-8 or
TOSLN50A-8
Verification Kit
(For Opt. 4 or 10) Connector: N Type Anritsu Model 3663-2 (Includes System Verification Software)
Adapter
(For Opt. 4 or 10)
Frequency: DC to 18 GHz
Connector: N(m) to K(m) Anritsu Model 34NK50
Adapter
(For Opt. 4 or 10)
Frequency: DC to 18 GHz
Connector: N(m) to K(f) Anritsu Model 34NKF50
Torque Wrench
(For Opt. 4 or 10)
3/4 in Open End Wrench
12 lb· in (1.35 N·m) Anritsu Model 01-200
Calibration Tee
(For Opt. 14, 20, 30 or 40)
Frequency: DC to 40 GHz
Connector: K(m) Anritsu Model TOSLK50A-40
Calibration Tee
(For Opt. 14, 20, 30 or 40)
Frequency: DC to 40 GHz
Connector: K(f) Anritsu Model TOSLKF50A-40
Verification Kit
(For Opt. 14, 20, 30 or 40) Connector: K Type Anritsu Model 3668-2 (Includes System Verification Software)
Torque Wrench
(For Opt. 14, 20, 30 or 40)
5/16 in Open End Wrench
8 lb·in (0.90 N·m) Anritsu Model 01-201
Torque Wrench
(For Opt. 14, 20, 30 or 40)
13/16 in Open End Wrench
8 lb·in (0.90 N·m) Anritsu Model 01-203
Adapter
(For Opt. 14, 20, 30 or 40) Connector: K(m) to K(f) Anritsu Model 33KKF50B
Adapter
(For Opt. 14, 20, 30 or 40) Connector: K(f) to K(f) Anritsu Model 33KFKF50B
RF Coaxial Cable
Frequency: DC to 40 GHz
Impedance: 50 ohm Connector:
K(f) to K(m)
Anritsu Model 3670K50-2
Interface Cable Ethernet: RJ45, cross-over, Cat.5E
Ethernet: RJ45, Cat.5E
Anritsu Part Number 3-806-152
Anritsu Part Number 2000-1371-R
Personal Computer
Operating System: Windows 7 or
higher
Interface: Ethernet, RJ45
Software: National Instruments
VISA version 4.4.1 or later
Any
Caution: The use of non-Anritsu calibration kits or verification kits is not supported.
