Anritsu MP1220A User manual

Document No.: M-W1304AE-13.0
ANRITSU CORPORATION
MP1220A
ATM Quality Analyzer
Operation Manual
Read this manual before using the equipment.
Keep this manual with the equipment.
13th Edition

ii
Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the following
safety symbols to indicate safety-related information. Insure that you clearly understand the meanings of the sym-
bols BEFORE using the equipment. Some or all of the following five symbols may not be used on all Anritsu
equipment. In addition, there may be other labels attached to products which are not shown in the diagrams in this
manual.
Symbols used in manual
This indicates a very dangerous procedure that could result in serious injury or
death if not performed properly.
This indicates a hazardous procedure that could result in serious injury or death if
not performed properly.
This indicates a hazardous procedure or danger that could result in light-to-severe
injury, or loss related to equipment malfunction, if proper precautions are not taken.
Safety Symbols Used on Equipment and in Manual
The following safety symbols are used inside or on the equipment near operation locations to provide information
about safety items and operation precautions. Insure that you clearly understand the meanings of the symbols
and take the necessary precautions BEFORE using the equipment.
This indicates a prohibited operation. The prohibited operation is indicated sym-
bolically in or near the barred circle.
This indicates an obligatory safety precaution. The obligatory operation is indicat-
ed symbolically in or near the circle.
This indicates warning or caution. The contents are indicated symbolically in or
near the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.
MP1220A
ATM Quality Analyzer
Operation Manual
15 May 1997 (First Edition)
12 July 2005 (13th Edition)
Copyright © 1997-2005, ANRITSU CORPORATION.
All rights reserved. No part of this manual may be reproduced without the prior written permission of the
publisher.
The contents of this manual may be changed without prior notice.
Printed in Japan
DANGER
WARNING
CAUTION

For Safety
iii
WARNING
1. ALWAYS refer to the operation manual when working near locations
at which the alert mark shown on the left is attached. If the opera-
tion, etc., is performed without heeding the advice in the operation
manual, there is a risk of personal injury. In addition, the equipment
performance may be reduced.
Moreover, this alert mark is sometimes used with other marks and
descriptions indicating other dangers.
2. Measurement Categories
This instrument is designed for Measurement category I (CAT I).
Don’t use this instrument at the locations of measurement categories
from CAT II to CAT IV.
In order to secure the safety of the user making measurements, IEC
61010 clarifies the range of use of instruments by classifying the lo-
cation of measurement into measurement categories from I to IV.
The category outline is as follows:
Measurement category I (CAT I):
Secondary circuits of a device connected to an outlet via a power
transformer etc.
Measurement category II (CAT II):
Primary circuits of a device with a power cord (portable tools, home
appliance etc.) connected to an outlet.
Measurement category III (CAT III):
Primary circuits of a device (fixed equipment) to which power is di-
rectly supplied from the power distribution panel, and circuits from the
distribution panel to outlets.
Measurement category IV (CAT IV):
All building service-line entrance circuits through the integrating
wattmeter and primary circuit breaker (power distribution panel).
3. When supplying power to this equipment, connect the accessory 3-
pin power cord to a grounded outlet. If a grounded outlet is not
available, before supplying power to the equipment, use a conversion
adapter and ground the green wire, or connect the frame ground on
the rear panel of the equipment to ground. If power is supplied
without grounding the equipment, there is a risk of receiving a severe
or fatal electric shock.
or

For Safety
iv
WARNING
4. This equipment cannot be repaired by the operator. DO NOT attempt
to remove the equipment covers or unit covers or to disassemble inter-
nal components. Only qualified service technicians with a knowledge
of electrical fire and shock hazards should service this equipment.
There are high-voltage parts in this equipment presenting a risk of
severe injury or fatal electric shock to untrained personnel. In addition,
there is a risk of damage to precision components.
5. This equipment should be used in the correct position. If the cabinet
is turned on its side, etc., it will be unstable and may be damaged if it
falls over as a result of receiving a slight mechanical shock.
And also DO NOT use this equipment in the position where the power
switch operation is difficult.
6. This instrument uses a Liquid Crystal Display (LCD); DO NOT subject
the instrument to excessive force or drop it. If the LCD is subjected
to strong mechanical shock, it may break and liquid may leak.
This liquid is very caustic and poisonous.
DO NOT touch it, ingest it, or get in your eyes. If it is ingested acci-
dentally, spit it out immediately, rinse your mouth with water and seek
medical help. If it enters your eyes accidentally, do not rub your
eyes, irrigate them with clean running water and seek medical help.
If the liquid gets on your skin or clothes, wash it off carefully and thor-
oughly.
Repair
Falling Over
LCD

For Safety
v
CAUTION
1. Before Replacing the fuses, ALWAYS remove the power cord from
the poweroutlet and replace the blown fuses. ALWAYS use new
fuses of the type and rating specified on the fuse marking on the rear
panel of the cabinet.
T3.15 A indicates a time-lag fuse.
There is risk of receiving a fatal electric shock if the fuses are re-
placed with the power cord connected.
2. Keep the power supply and cooling fan free of dust.
•Clean the power inlet regularly. If dust accumulates around the
power pins, there is a risk of fire.
•Keep the cooling fan clean so that the ventilation holes are not ob-
structed. If the ventilation is obstructed, the cabinet may over-
heat and catch fire.
Replacing Fuse
Cleaning

For Safety
vi
CAUTION
This equipment uses a lithium battery to back-up the memory. This
battery must be replaced by a service engineer when it has reached the
end of its useful life; contact the Anritsu sales section or your nearest
representative.
This equipment uses HDD and FDD as external media for storing data
and programs.
If this media is mishandled, important data may be lost. To prevent this
chance occurrence, all important data and programs should be backed-
up.
Anritsu will not be held responsible for lost data.
Pay careful attention to the following points.
•Never turn off the power, while the HDD is being accessed.
•Never remove the FD from the FDD, while it is being accessed.
Replacing Memory
Back-up Battery
Storage Media

vii
Equipment Certificate
Anritsu Corporation certifies that this equipment was tested before
shipment using calibrated measuring instruments with direct traceability
to public testing organizations recognized by national research laborato-
ries including the National Institute of Advanced Industrial Science and
Technology, and the National Institute of Information and Communica-
tions Technology, and was found to meet the published specifications.
Anritsu Warranty
Anritsu Corporation will repair this equipment free-of-charge if a mal-
function occurs within 1 year after shipment due to a manufacturing fault,
provided that this warranty is rendered void under any or all of the fol-
lowing conditions.
•The fault is outside the scope of the warranty conditions described in
the operation manual.
•The fault is due to mishandling, misuse, or unauthorized modification
or repair of the equipment by the customer.
•The fault is due to severe usage clearly exceeding normal usage.
•The fault is due to improper or insufficient maintenance by the cus-
tomer.
•The fault is due to natural disaster including fire, flooding, earthquake,
etc.
•The fault is due to use of non-specified peripheral equipment,
peripheral parts, consumables, etc.
•The fault is due to use of a non-specified power supply or in a non-
specified installation location.
In addition, this warranty is valid only for the original equipment pur-
chaser. It is not transferable if the equipment is resold.
Anritsu Corporation will not accept liability for equipment faults due to
unforeseen and unusual circumstances, nor for faults due to mishandling
by the customer.
Anritsu Corporation Contact
In the event that this equipment malfunctions, contact an Anritsu Service
and Sales office. Contact information can be found on the last page of
the printed version of this manual, and is available in a separate file on
the CD version.

viii
Notes On Export Management
This product and its manuals may require an Export License/Approval by
the Government of the product's country of origin for re-export from you
r
country.
Before re-exporting the product or manuals, please contact us to confirm
whether they are export-controlled items or not.
When you dispose of export-controlled items, the products/manuals are
needed to be broken/shredded so as not to be unlawfully used for military
purpose.
Trademark and Registered Trademark
Microsoft, MS-DOS, and Windows are a registered trademark of Microsof
t
Corporation in the United States and/or other countries.
Disposing of Product
This product that you have purchased contains a rechargeable battery.
The battery is recyclable. At the end of its useful life, under various
state and local laws, it may be illegal to dispose of this battery into the
municipal waste stream. Check with your local solid waste officials fo
r
details in your area for recycling options or proper disposal.

ix
Crossed-out Wheeled Bin Symbol
Equipment marked with the Crossed-out Wheeled Bin Symbol complies
with council directive 2002/96/EC (the “WEEE Directive”) in European
Union.
For Products placed on the EU market after August 13, 2005, please con-
tact your local Anritsu representative at the end of the product's useful
life to arrange disposal in accordance with your initial contract and the
local law.

x
Software License Agreement
Please read this Software License Agreement before using the accom-
panying software program (hereafter this software).
You are authorized to use this software only if you agree to all the terms
of this License.
By opening the sealed package containing this software, you are agreeing
to be bound by the terms of this License.
If you do not agree to these terms, return the unopened software package
to Anritsu Corporation (hereafter Anritsu).
1. License
(1) This License gives you the right to use this software on one
MP1220A (hereafter computer system).
(2) To use this software on one computer system, this License allows
you to make one copy of this software on the storage device of your
computer system.
(3) You must obtain a site license to use this software on more than one
computer system even if such computer systems are not operating
simultaneously.
2. Copyright
(1) Although you are licensed to use this software, Anritsu retains the
copyright.
(2) Although you have purchased this software, rights other than those
specified in this License are not transferred to you.
(3) You may not print, copy, modify, create derivative works, incorpo-
rate in other software programs, decompile or disassemble this
software in whole or in part, without obtaining prior written per-
mission from Anritsu.
3. Copying
Notwithstanding item (3) of section 2 above, you may make one copy of
this software for backup purposes only. In this case, you may only use
either the original or the backup copy of this software.
4. Termination
(1) Anritsu will deem this License to be automatically terminated if you
fail to comply with any provision of this License. Upon termination,
you will lose all rights to this software.
(2) Either party (Anritsu or yourself) to this Software License Agree-
ment may terminate this Agreement by giving 1 months notice in
writing to the other party.
(3) Upon termination of this License for any reason, you must either
immediately destroy this software and related documentation, or re-
turn it to Anritsu.
