ANTAIRA STE-6104C-T-V2 User manual

Antaira Technologies
STE-6104C-T-V2
4-Port Industrial Serial RS232/422/485 to Ethernet Device
Server, with Dual LAN; EOT: -40°C to 85°C; Version 2 Hardware
Quick Installation Guide
Version 1.0
(March 2021)
Tel: [phone]
Fax: [phone]
www.antaira.com
1. PACKAGING
The package contains the following items:
STE-6104C-T-V2
Quick Installation Guide
7-pin Terminal Block
2 HARDWARE DESCRIPTION
Front Panel Layout
Top Panel View
Product Overview
System Interface/Performance
15KV ESD Protection for serial signals
Ethernet connectivity 2*10/100Tx RJ45 ports
Store-and-forward switching architecture
4-Port RS232/422/485, Baud Rate up to 921 Kbps
Power port EFT protection: 2,000VDC; Single port ESD
Protection: 2,000VDC
Power Input & Connection
DC 12 to 48V redundant power, with a 7-pin removal
terminal block
It is recommended to use a UL listed industrial power
supply
Operating Temperature
Extended operating temperature model: -40°C to 85°C
Case/Installation
IP30 protection / DIN-Rail mount design
LED Indicators:
Name
Color
Status
Description
P1 / P2
Green
Off
Power is not connected
On
Power is connected
LAN
Green
Off
Ethernet Disconnected
Blinking
Data is transmitting on
Ethernet for 100Mbps
Orange
Blinking
Data is transmitting on
Ethernet for 10Mbps
COM
Green
Off
No data is transmitting on
COM port
Blinking
Data is transmitting on
COM port
RUN
Green
Off
System is not ready or
halt
Blinking
AP firmware is running
normally
ALM
Red
On
Alarm is triggered by user
defined events
Off
Alarm is not triggered by
user defined events
Installation Procedures:
Step 1: Connect the STE-6104C-T-V2 to a power source.
Step 2: Connect the STE-6104C-T-V2 to the Ethernet network.
Use a standard straight-through or cross-over Ethernet
cable. Always make sure the PC is on the same network
subnet as the STE-6104C-T-V2.
Step 3: Connect the STE-6104C-T-V2s serial port to a serial
device.
Step 4: Mount the STE-6104C-T-V2 to a DIN-Rail.

3 SOFTWARE SETUP
Default Network Setting:
Default User Name/Password:
LAN1 IP: 10.0.50.100
User Name: admin
Password: default
Gateway: 10.0.0.254
Subnet: 255.255.0.0
LAN2 IP：192.168.1.1
Gateway: 192.168.1.254
Subnet: 255.255.255.0
Auto IP (Dynamic IP):
A DHCP server can automatically assigns the IP address and all
the network settings. The STE-6104C-T-V2 supports the DHCP
client function. By default, the DHCP client function on the
STE-6104C-T-V2 is disabled; you may activate the DHCP client
functions by executing SerialManager Utility (Figure 3.1)
Figure 3.1.
SerialManager utility Dialog Window
Assign a Static IP Address By:
1. Configuration by Telnet
i. Telnet to the STE-6104C-T-V2 using DOS command
Telnet IP_address 23. Example: telnet 10.0.50.100
23.
ii. STE-6104C-T-V2s netork, link mode and COM
ports settings can be configured in the telnet window.
2. Configuration by SerialManager Utility
i. Use SerialManager Utility on Product CD or our
website to configure the STE-6104C-T-V2. First click
the Config option then assign a static IP.
3. Configuration by Web Browser
i. Open a web browser, then Enter in the IP address as
the STE-6104C-T-V2. The default user name is
admin and default password is default.
ii. The STE-6104C-T-V2s netork, link mode and COM
ports settings can be configured on different web
pages.
iii. Click Save Configuration to save your settings.
DIN-Rail Mounting
The DIN-Rail bracket is pre-installed on
the industrial Ethernet switch from the
factory. Please refer to Figure 3 for a
DIN-Rail bracket installation reference.
Follow the steps below for installing the
industrial switch on the DIN-Rail track:
1. Insert the top of the DIN-Rail on to
the track as shown below in Figure
4.
2. Lightly pull down the bracket on to
the rail as shown below in Figure 5.
3. Check if the bracket is mounted
tightly on the rail.
4. To remove the industrial
Ethernet
switch
from the rail, do the opposite from the steps above.
Figure 4
Field Maintenance and Service
If the device requires servicing of any kind, the user is
required to disconnect and remove it from its mounting. The
initial installation should be done in a way that makes this
as convenient as possible.
Voltage/power lines should be properly insulated as well as
other cables. Be careful when handling them so as to not
trip over.
Do not under any circumstance insert foreign objects of any
kind into the heat dissipation holes located in the different
faces of the device. This may not only harm the internal
layout, but might cause harm to user as well.
Do not under any circumstance open the device for any
reason. Please contact your dealer for any repair needed or
follow the instructions within the manual.
Warranty Policy
Warranty Conditions
Products supplied by Antaira Technologies are covered in this
warranty for sub-standard performance or defective
workmanship. The warranty is not, however, extended to
goods damaged in the following circumstances:
(a) Excessive forces or impacts
(b) War or an Act of God: wind storm, fire, flood, electric
shock, earthquake
(c) Use of unqualified power supply, connectors, or
unauthorized parts/kits
(d) Replacement with unauthorized parts
RMA and Shipping Costs Reimbursement
Customers shall always obtain an authorized "RMA" number
from Antaira before shipping the goods for repair or
replacement.
Within the warranty period (based on the invoice date), all
parts and labor are free of charge to the customers.
Customers are responsible for the cost of parts and labor, if
the products are out of warranty.
For RMA service, customers are responsible for the
shipping expense for shipping the RMA unit(s) to Antaira.
Antaira is responsible for the shipping expense via a ground
service for the return repair/replace unit(s) back to
customers.
Limited Liability
Antaira would not be held responsible for any consequential
losses from using Antairas product.
Warranty Period
5-Year Warranty
Antaira’s Customer Service and Support
Antairas Technical Service & Support Centers:
+ 844-268-2472 (Antaira US Headquarter)
+ 48-22-862-88-81 (Antaira Europe Office)
+ 886-2-2218-9733 (Antaira Asia Office)
Antairas Web Sites & Repair/Support Emails:
www.antaira.com / [email protected]
www.antaira.eu / [email protected]
www.antaira.com.tw / [email protected]
*Any changes will be announced on the Antaira website.
Figure 3
Figure 5
