ANTAIRA ARY-7235-AC-PD User manual


ARY-7235-AC-PD
Industrial Outdoor IP67 Plastic Housing IEEE 802.11a/b/g/n/ac Wireless
Access Point/Client/Bridge/Repeater/Router with PoE PD
Hardware Manual

Version 1.0
(November 2020)
 

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
© Copyright 2020 Antaira Technologies, LLC
All rights reserved
This document contains information, which is protected by copyright. Reproduction, adaptation, or
translation without prior permission is prohibited, except as allowed under the copyright laws.

Trademark Information
Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows and the Windows logo
are the trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA
are the registered trademarks of Wi-Fi Alliance. All other brand and product names are trademarks or
registered trademarks of their respective owners.

Notice: Copyrights © 2020 by Antaira Technologies, LLC. All rights reserved. Reproduction, adaptation, or
translation without prior permission of Antaira Technologies, LLC is prohibited, except as allowed under
the copyright laws.

Disclaimer
Antaira Technologies, LLC provides this manual without warranty of any kind, expressed or implied,
including but not limited to the implied warranties of merchantability and fitness for a particular purpose.
Antaira Technologies, LLC may make improvements and/or changes to the product and/or specifications
of the product described in this manual, without prior notice. Antaira Technologies, LLC will not be liable
for any technical inaccuracies or typographical errors found in this guide. Changes are periodically made
to the information contained herein and will be incorporated into later versions of the manual. The
information contained is subject to change without prior notice.

FCC Warning
This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy. It may cause harmful interference to radio communications if the equipment is not installed and
used in accordance with the instructions. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modifications not expressly approved by the grantee of this device could void
the user’s authority to operate the equipment.

Avertissement FCC
Cet équipement a été testé et déclaré conforme aux limites d'un appareil numérique de classe A,
conformément à la partie 15 des règles de la FCC. Ces limites sont conçues pour fournir une protection
raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère,
utilise et peut émettre de l'énergie radiofréquence. Cela peut provoquer des interférences nuisibles aux
communications radio si l'équipement n'est pas installé et utilisé conformément aux instructions.
Cependant, il n'y a aucune garantie qu'aucune interférence ne se produira dans une installation
particulière. Si cet équipement provoque des interférences nuisibles à la réception radio ou télévision, ce
qui peut être déterminé en éteignant puis en rallumant l'équipement, l'utilisateur est encouragé à essayer
de corriger les interférences par une ou plusieurs des mesures suivantes:
●Réorientez ou déplacez l'antenne de réception.
●Augmentez la distance entre l'équipement et le récepteur.
●Connectez l'équipement à une prise sur un circuit différent de celui auquel le récepteur est
connecté.
●Consultez le revendeur ou un technicien radio / TV expérimenté pour obtenir de l'aide.

CE Mark Warning
This is a Class-A product. In a domestic environment, this product may cause radio interference in which
case the user may be required to take adequate measures.
Avertissement de marque CE
Ceci est un produit de classe A. Dans un environnement domestique, ce produit peut provoquer des
interférences radio, auquel cas l'utilisateur peut être amené à prendre des mesures adéquates.

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
Industrial Wireless Access Points
Industrial Grade Wireless Access Point

Hardware Manual
Version 1.0 (November 2020)

The manual supports the following models:
●ARY-7235-AC-PD

This document is the current official release hardware manual. Please check our website
(www.antaira.com) for any updated manual or contact us by e-mail ([email protected]). 

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
Table of Contents
1 Overview 1
1.1 Product Hardware Features 1
1.2 Product Software Features 1
1.3 Package Contents 2
1.4 Safety Precaution 2
2 Hardware Description 4
2.1 Physical Dimensions 4
2.2 Front View Panel 5
2.3 Top View Panel 5
2.4 LED Indicators 6
2.5 Reset Button 7
2.6 Ethernet Ports 7
2.7 Cabling 8
2.8 Wiring the Power Inputs 8
2.9 Wiring the Fault Alarm Contact 9
2.10 Grounding Note 10
3 Mounting Installation 12
3.1 DIN-Rail Mounting 12
3.2 Wall Mounting 13
4 Hardware Installation 15
4.1 Installation Steps 15
4.2 Maintenance and Service 15
4.3 Troubleshooting 16
5 Technical Specifications 17


Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
1 Overview
Antaira Technologies’ ARY-7235-AC-PD is designed for industrial and enterprise outdoor wireless access
applications. Embedded with the Qualcomm IPQ4029 SoC chipset, it boasts network robustness, stability
and a wider network coverage. Based on IEEE 802.11a/b/g/n/ac, the access point supports high-speed
data transmission of up to 867Mbps.
The ARY-7235-AC-PD is capable of operating in different modes, which makes it suitable for a wide
variety of wireless applications including long-distance deployments. With the standard operating
temperature range of -40°C to 50°C and the plastic housing IP67 rated, this wireless access point is built
for applications where extreme dust and other harsh environmental conditions exist.
1.1 Product Hardware Features
System Interface and Performance
- Qualcomm IPQ4029 Quad-Core Wi-Fi SoC
- WAN 1*10/100/1000Tx
- LAN 1*10/100/1000Tx (with PoE PD)
- WLAN supports concurrent 2.4G/5GHz Wi-Fi
Product Input
- PoE PD: 48~56VDC
- The power input specification complies with the requirements of SELV (Safety Extra Low Voltage)
and the power supply should comply with UL 61010-1 & UL 61010-2-201
Operating Temperature
- Standard operating temperature model: -40°C to 50°C
Case / Installation
- IP67 protection plastic housing
- Pole mount and wall-mount design
1.2 Package Contents
- ARY-7235-AC-PD
- Quick Installation Guide
- Pole mounting bracket set with screws
1

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
- Set of antennas
1.3 Safety Precaution
Attention: If the DC voltage is supplied by an external circuit, please use a protection device on the power
supply input. The industrial wireless access point’s hardware specs, ports, cabling information, and wiring
installation will be described within this hardware manual.

Attention: Si la tension CC est fournie par un circuit externe, veuillez utiliser un dispositif de protection sur
l'entrée d'alimentation. Les spécifications matérielles, les ports, les informations de câblage et
l'installation du câblage du point d'accès sans fil industriel seront décrits dans ce manuel du matériel.

Warning Labels
The caution label means that you should check certain information on the user manual when working
with the device. (Shown in Figure 1.1)

Étiquettes d'avertissement
L'étiquette d'avertissement signifie que vous devez vérifier certaines informations du manuel d'utilisation
lorsque vous travaillez avec l'appareil. (Illustré à la figure 1.1)
Figure 1.1 - Caution Label
Figure 1.1 - Étiquette de mise en garde
Figure 1.2 - Hot Surface Warning Label
Figure 1.2 - Étiquette d'avertissement de surface chaude
 
2

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
2 Hardware Description
2.1 Physical Dimensions
Figure 2.1, below, shows the physical dimensions of this product:

(W x D x H) is 230mm x 230mm x 58mm
Figure 2.1 - Physical Dimensions
 
3

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
2.2 Front View Panel
Figure 2.2, below, shows the front panel of the product:
Figure 2.2 - Front View Panel
2.3 Ethernet Ports
●RJ45 Ports
RJ45 Ports (Auto MDI/MDI-X): The RJ45 ports are auto-sensing for 10Base-T, 100Base-TX, or
1000Base-T connections. Auto MDI means that the switch can connect to another switch or workstation
without changing the straight-through or crossover cabling. See the figures below for straight-through and
crossover cabling schematics.
 
4

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
●RJ45 Pin Assignments
Table 2.2 - 10/100Base-T(X) RJ45 Pin Assignments

Table 2.3 - 1000Base-T RJ45 Pin Assignments
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
2.4 Cabling
Twisted-pair segments can be connected with an Unshielded Twisted Pair (UTP) or Shielded Twisted Pair
(STP) cable. The cable between the switch and the link partner (wireless AP, switch, hub, workstation,
etc.) must be less than 100 meters (328 ft.) in length.
5
Crossover Cable
Straight-Through Cable
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
1 / RX+
3 / TX+
1 / RX+
1 / TX+
2 / RX-
6 / TX-
2 / RX-
2 / TX-
3 / TX+
1 / RX+
3 / TX+
3 / RX+
6 / TX-
2 / RX-
6 / TX-
6 / RX-
Crossover Cable
Straight-Through Cable
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
Pin Number / Signal
1 / TP0+
3 / TP1+
1 / TP0+
1 / TP1+
2 / TP0-
6 / TP1-
2 / TP0-
2 / TP1-
3 / TP1+
1 / TP0+
3 / TP1+
3 / TP0+
4 / TP2+
7 / TP3+
4 / TP2+
4 / TP3+
5 / TP2-
8 / TP3-
5 / TP2-
5 / TP3-
6 / TP1-
2 / TP0-
6 / TP1-
6 / TP0-
7 / TP3+
4 / TP2+
7 / TP3+
7 / TP2+
8 / TP3-
5 / TP2-
8 / TP3-
8 / TP2-

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
2.5 Wireless Antenna
The 2.4GHz/5GHz antennas are connected with N-Type connectors. Other external antennas can be used.
 
6

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
3 Mounting Installation
3.1 Pole Mounting
The unit has a pole mounting kit on the rear panel. Please see Figure 3.1 for diagram on how to pole
mount the wireless AP.
Figure 3.1 - Pole Mounting Bracket Installation Diagram
7

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
4 Hardware Installation
4.1 Installation Steps
This section will explain how to install the industrial wireless access point:
Installation Steps
1. Unpack the industrial wireless access point from the original packing box.
2. To hang the industrial wireless access point on a pole, please refer to the Mounting Installation
section.
3. To power the industrial wireless access point, you will need an accessory that can provide PoE
via an RJ45 cable.
4. Prepare the twisted-pair, straight-through category 5 cable for Ethernet connection/power.
5. Insert one side of the RJ45 cable into the wireless access point’s Ethernet port (LAN) and on the
other side into the networking device’s Ethernet port (e.g.; switch, PC, or server).
6. When all connections are set, the installation is complete.
4.2 Maintenance and Service
●If the device requires servicing of any kind, the user is required to disconnect and remove it from
its mounting. The initial installation should be done in a way that makes this as convenient as
possible.
●Voltage / Power lines should be properly insulated as well as other cables. Be careful when
handling them so as to not trip over.
●Do not under any circumstance insert foreign objects of any kind into the heat dissipation
holes located in the different faces of the device. This may not only harm the internal layout,
but might cause harm to users as well.
●Do not under any circumstance open the device for any reason. Please contact your dealer
for any repair needed or follow the instructions within the manual.
●Clean the device with dry soft cloth.
8

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
4.3 Troubleshooting
●Always verify the right power cord or adapter is being used. Never use a power supply or adapter
with a non-compliant DC output voltage or it will burn the equipment.
●Select the proper UTP or STP cable in order to construct the network. Use an unshielded
twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ45 connections: 100Ω Category 5e for
10/100Mbps. Also be sure that the length of any twisted-pair connection does not exceed 100
meters (328 feet). 
9

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
5 Technical Specifications
Table 5.1 has the technical specifications for this product series.
10
Technology
Standards
IEEE 802.11a/b/g/n/ac Wireless LAN
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3af/at Power over Ethernet
Protocols
IP, TCP, UDP, ARP, BOOTP, ICMP, HTTP, HTTPS, DNS Proxy,
NAPT, SNTP, Dynamic DNS, SMTP, SNMP
WLAN Operation Modes
AP/Client/Bridge/Repeater/Router
Encryption Security
WPA, WPA2, WPA3, WEP, TKIP, AES, RADIUS, 802.1x/EAP
Interface
Ethernet Ports
WAN: 10/100/1000Tx
LAN (PoE PD): 10/100/1000Tx
WLANs
Dual Band 2.4GHz/5GHz concurrent
Antennas
2*External N-Type Antennas:
5dBi for 2.4GHz, 5dBi for 5GHz
(MIMO support, Dual 2Tx/2Rx)
Frequency Range
IEEE 802.11a/b/g/n/ac (2.4GHz)
2.402G - 2.482GHz, 25dBm
IEEE 802.11a/b/g/n/ac (5GHz)
4.92G - 5.92GHz, 24dBm
Mechanical Characteristics
Housing
Plastic, IP67 rated
Dimensions
230 x 58 x 230 mm (W x H x D)
Weight
Unit: 2.689 lbs.
Shipping: 4.047 lbs.
Mounting
Pole mounting
Power Requirement
Input Voltage
802.3at PoE (48~56VDC)

Antaira Technologies - Industrial Wireless Access Points
ARY-7235-AC-PD - Hardware Manual - v1.0
Table 5.1 - Technical Specifications

Antaira Customer Service and Support
(Antaira US Headquarter) + 844-268-2472
(Antaira Europe Office) [phone]
(Antaira Asia Office) [phone]
Please report any problems to Antaira:
www.antaira.com / [email protected]
www.antaira.eu / [email protected]
www.antaira.com.tw / [email protected]
Any changes to this material will be announced on the Antaira website.
11
System Power Consumption
4.2 Watts
Environmental Limits
Operating Temperature
-40°C to 50°C
Storage Temperature
-40°C ~ 80°C
Ambient Relative Humidity
5 to 95%, (non-condensing)
Regulatory Approvals
EMI
FCC Part 15 Subpart B
CE EN55032
EMS
CE EN55024
IEC61000-4-2,3,4,5,6,8,11
Green
RoHS Compliant
Certifications
FCC, CE
Warranty
5 Years
