Anzzi SD-AZ056-01 Series User manual

1

Right-hand door installation shown
Left-hand door installation shown
2

3
1.Wall Profile X2
2.Pivot Assembly X2
3.Rubber strip X2
4.Sweep Vinyl Seal X1
5.Hinge-Side Vinyl Seal X1
6.Magnetic Strike Vinyl X1
7.Door Glass X1
8.Decorative Washer X8
9.Pivot Bar X2
10.Vinyl Gasket (for Pivot Bar) X16
11.Truss Head Screw St5x40 X6
12.Wall Anchor X6
13.Hex Socket Bolt M8x20 X8
14.Hex Socket Bolt M8x10 X4
15.Panel Glass X2
16.Handle X1

4

5
1
Ø1/4”
3
5
2
4
20m m
1. Make sure space is enough for the shwoer door (36*36 inch)
2. Place the side wall frofile (1) 20mm away from the edge of the shower base and
use a horizontal ruler to make it perpendicular to the ground, and mark the position of
the screw hole. Use a φ1 / 4 ”drill to drill holes, drive into the plastic anchor (12), and
fix the side wall profile with screws (11). The other side wall profile is installed in the
same way.)

6
1
inside
inside
2
3. mount the fixed glass (15) into the side wall profile (1), adjust it, and install it with
the rubber strip(3). To mount the other fixed glass (15) on the other side with same
installation way.Two fixed glass are installed.
4. Install the pivot bar ( 9) as shown in the picture)

7
inside
panel
inside
panel
5. Install the pivot (2) on the pivot bar with screws (14). Pay attention to the rotation
direction of the pivot)
6. Install swing glass (7) on the pivot as shown
1
door
2
2
14
2
14
7
7

8
inside
7. Install the handle (16) on the swing glass (7) as shown
8. As shown in the picture, install the Hinge Side Vinyl Seal (5) on the glass of the
side near the pivot , and install the magnetic strip (6) on the other side of the glass.
Install the bottom seal strip (4) on the bottom of the swing glass. If the upper and
lower part of the magnetic strip cannot be aligned at the same time, adjust two
pivots as shown in the picture to align the magnetic strip at the same time.
4
outside
inside
door
panel
inside
outside
1
door
panel
outside
inside
2
3
door
inside

9
After the installation, adhesive sealant on the outside of the product as shown, and it
can only be used after 24 hours adhesive .
