Anzzi SP-AZ077 User manual

INSTALL GUIDE
Model#
SP-AZ077
SP-AZ8106
PERFECTION IS OUR TRADITION™
v2.0516

Parts List Pg. 1
Before You Start Pg. 2
Spec Drawing Pg. 3
Installation Pg. 4
Care & Maintenance Pg. 12
Warranty Pg. 13
Registration Final Page
TABLE OF CONTENTS
YOUR REVIEWS MATTER!
For more information please call 1-844-44-ANZZI
or email us at [email protected]
The ANZZI™ Family thanks you for your purchase and hopes you enjoy your very own ANZZI
product for years to come! In the meantime let us know about your experience? We would love
to hear your thoughts from the packaging to the quality and function of the product.
Leave a review on www.ANZZI.com/reviews and let everyone know how satisfied you are with
ANZZI!
Also, we humbly request submitting as many pictures as possible along with your review.
Millions of shoppers will want to know about your experience with our products. Don’t just tell
but show, too!

PARTS LIST
PERFECTION IS OUR TRADITION™
pg. 1
1
2
3
4
1. Shower Head
2. Diverter
3. Body Jets
4. Hand Shower
10
1
9
3
4
5
678
2
11
12
13
19
16
17
18
14
15
22
21
20
23
24
25
Component no.
Component
Material
1
head shower
s/s
2
flange
brass
3
body
s/s
4
washer
EPDM
5
nut
brass
6
connector
brass
7
clip
s/s
8
pvc hose
pvc
9
body jets
brass
10
knob plate cover
s/s
11
knob
zinc
12
one way joint
ABS
13
two ways joint
ABS
14
function cartridge
ABS
15
faucet
brass
16
hand shower
ABS
17
hand shower holder
ABS
18
flexible hose
s/s
19
braided hose
s/s
20
screw
s/s
21
bracket
s/s
22
plug
ABS
23
cap
ABS
24
long- short connector
ABS
25
base
ABS

PERFECTION IS OUR TRADITION™
pg. 2
For any questions or concerns contact
our dedicated technical support team
at 1-844-44-ANZZI.
BEFORE YOU START
Screwdriver Channel Locks
Adjustable Wrench Allen key
Goggles
Teflon tape
Recommended Items
ATTENTION: Please read all instructions thoroughly
including all warnings, attentions and notes before
beginning installation.

PERFECTION IS OUR TRADITION™
pg. 3
SPEC
DRAWING
SP-AZ077
Perfection is our Tradition™
Material: Stainless Steel
Finish: Brushed
Handles: 1
Jets: 3
Shower: 6.89”x6.89”
Sprayer: 60” reach
Weight: 10.80 lbs
Height: 39.37”
Supply: 1/2” connections
Flow: 2.5 gpm
Features
Heavy Rain™ Showerhead
Acu-Stream™ high pressure body jets
Euro-Grip™ hand held sprayer
Rhino Alloy™ certified materials
17.72"
4.72"
39.37"

Figure A
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 4
Before drilling any holes for the shower panel brackets, ensure there are no hidden cables or
pipelines aligned with the desired drilling position.
Drill the two holes for the top bracket 1” apart at the desired height.
Drill the two holes for the bottom bracket 1” apart at approximately 45” below the top bracket.
IMPORTANT
Step A
Step A.2
Ø 6mm Drill
1 INCH

Figure B
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 5
Insert the wall anchors into the pre-drilled holes as shown in Figure B.
Place the shower panel brackets aligned with the drilled holes and using a Philips screw-
driver tighten the screws to secure the brackets.
Step B
Step C
Figure C

Figure 1
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 6
Insert the shower wand holder through the pre-drilled hole on the shower panel.
Install the water supply hose for the shower wand onto the holder, as shown.
Make sure all O-rings are inserted to prevent leakage.
Once the shower panel is fully installed and hung on the bracket, you can install the shower
wand hose to the holder connection.
Step 1A
Step 1B
Step 1C
Step 1D

Figure 2
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 7
Finally, install the shower wand to the hose, as shown.Step 2A
1 Setting
Hand
Shower
3 Setting
Hand
Shower
or

Figure 3
INSTALLATION (SHOWER HEAD)
PERFECTION IS OUR TRADITION™
pg. 8
Install the shower head to the upper threader connectin on the shower panel as shown.Step 3A

INSTALLATION
PERFECTION IS OUR TRADITION™
Figure 4
pg. 9
Hold the plastic base against the wall, connect the 1/2" brass extender joint to the
existing outlet. Use waterproof plumbing tape to secure the connection and prevent leaks
Step 4B
Remove the old existing shower head and shower head arm assembly
Step 4A
A long
B short

Figure 5
INSTALLATION (WALL MOUNTING)
PERFECTION IS OUR TRADITION™
pg. 10
Carefully hang the shower panel on the secured mounting brackets .

INSTALLATION
PERFECTION IS OUR TRADITION™
Figure 6
pg. 11
Connect shower panel water supply hose to the existing plumbing
Step 6

pg. 12
CARE AND MAINTENANCE
ANZZI™ products are crafted with superior quality standards and workmanship and are engineered to
stand the test of time. However, that does not mean the product can be neglected and will need some
care and cleaning.
It is recommended to use regular soap and hot water along with a non-abrasive cloth or sponge to
regularly clean the product. This avoids any nasty build up or deposits which would be tougher to
remove.
If you feel the use of stronger cleaning solutions or chemicals is necessary always test the cleaning
solution or chemical on an inconspicuous area before applying to the entire surface.
Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
DO NOT ALLOW THE CLEANER TO SOAK.
Following these simple principles will ensure your ANZZI™ product will remain as lustrous and
stun-ning as the day it was first received. ENJOY!
Sincerely,
La Familia ANZZI™
For more information visit us at www.ANZZI.com
Perfection is our Tradition™
For more information visit us at www.ANZZI.com
Perfection is our Tradition™

pg. 13
LIMITED LIFETIME WARRANTY
ANZZI™ products are manufactured with superior quality standards and workmanship and are
backed by our limited lifetime warranty. ANZZI™ products are warranted to the original consumer
purchaser to be free of defects in materials or workmanship. We will replace FREE OF CHARGE* any
product or parts that proves defective. Simply call 1-844-44-ANZZI (1-844-442-6994) to submit a
warranty claim and request an RMA. Proof of purchase (original sales receipt) from the original con-
sumer purchaser must be made available for all ANZZI™ warranty claims.
