Anzzi TRYNN SP-AZ025 User manual

INSTALL GUIDE
Model#
SP-AZ025
TRYNN
PERFECTION IS OUR TRADITION™
v2.0516

Parts List Pg. 1
Before You Start Pg. 2
Spec Drawing Pg. 3
Installation Pg. 4
Care & Maintenance Pg. 11
Warranty Pg. 12
Registration Final Page
TABLE OF CONTENTS
YOUR REVIEWS MATTER!
The ANZZI™ Family thanks you for your purchase and hopes you enjoy your very own ANZZI
product for years to come! In the meantime let us know about your experience? We would love
to hear your thoughts from the packaging to the quality and function of the product.
Leave a review on www.ANZZI.com/reviews and let everyone know how satisfied you are with
ANZZI!
Also, we humbly request submitting as many pictures as possible along with your review.
Millions of shoppers will want to know about your experience with our products. Don’t just tell
but show, too!

PARTS LIST
PERFECTION IS OUR TRADITION™
pg. 1
ASME A112.18.1/CSA B125.1
1. Shower Head
2. Body Jets
3. Diverter
4. Mixer
5. Hand Shower
15
1
16
18
19
20
21
17
29
28
27
2
9
11
14
10
13
22 23
12
3
46
5
7
8
24
25
26
Component no.
Component
Material
1
head shower
s/s
2
arm bar
bras s
3
flange
bras s
4
body
5
wash 1
rubber
6
nut 1
bras s
7
one way joint
ABS
8
clip
s/s
9
shelf
Acrylic
10
glass clamp
bras s
11
screw
s/s
12
screw 2
s/s
13
nut 2
s/s
14
body jets
bras s
15
knob
zinc
16
knob plate cover
bras s
17
cartridge
bras s
18
handle
zinc
19
handle plate cover
bras s
20
cap
ABS
21
thermostatic cartridge
ABS
22
body jets cover
ABS
23
nut 3
bras s
24
thermostatic faucet
bras s
25
hand shower
ABS
26
hand shower holder
ABS
27
pvc hose
PVC
28
braided hose
s/s
29
flexible hose
s/s
1
2
3
2
4
5

PERFECTION IS OUR TRADITION™
pg. 2
For any questions or concerns contact
our dedicated technical support team
at 1-844-44-ANZZI.
BEFORE YOU START
Screwdriver Channel Locks
Adjustable Wrench Allen key
Goggles
Teflon tape
Recommended Items
ATTENTION: Please read all instructions thoroughly
including all warnings, attentions and notes before
beginning installation.

PERFECTION IS OUR TRADITION™
pg. 3
SPEC
DRAWING
TRYNN
SP-AZ025
Material:
Finish: White
Handles: 2
Jets: 2
Shower: 6.89”x6.89”
Sprayer: 60” reach
Weight: 13.23 lbs
Height: 51.18”
Supply: 1/2” connections
Flow: 1.8 gpm
Features
Heavy Rain™ Fixed Showerhead
Acu-Stream™ high pressure body jets
Euro-Grip™ hand held sprayer
Rhino Alloy™ certified materials
51.18
"
8.66"
20.37"

Figure A
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 4
Before drilling any holes for the shower panel brackets, ensure there are no hidden cables or
pipelines aligned with the desired drilling position.
Drill the two holes for the top bracket 1” apart at the desired height.
Drill the two holes for the bottom bracket 1” apart at approximately 45” below the top bracket.
IMPORTANT
Step A
Step A.2
Ø 6mm Drill
1 INCH

Figure B
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 5
Insert the wall anchors into the pre-drilled holes as shown in Figure B.
Place the shower panel brackets aligned with the drilled holes and using a Philips screw-
driver ighten the screws to secure the brackets.
Step B
Step C
Figure C

Figure 1
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 6
Insert the shower wand holder through the pre-drilled hole on the shower panel.
Install the water supply hose for the shower wand onto the holder, as shown.
Make sure all O-rings are inserted to prevent leakage.
Once the shower panel is fully installed and hung on the bracket, you can install the shower
wand hose to the holder connection.
Step 1A
Step 1B
Step 1C
Step 1D
21

Figure 2
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 7
Finally, install the shower wand to the hose, as shown.Step 2A
1 Setting
Hand
Shower
3 Setting
Hand
Shower
or

Figure 3
INSTALLATION(SHELF)
PERFECTION IS OUR TRADITION™
pg. 8
Place clamp onto the panel side, use the screw to tighten them, insert the shelf to the clamp,
tighten the screw to fix it
Step 3

Figure 4
INSTALLATION (SHOWER HEAD)
PERFECTION IS OUR TRADITION™
pg. 9
Install the shower arm to the shower panel, using the rubber washer and nut on the opposite
side to tighten.
Makes sure the shower arm is sitting correctly before installed the shower head.
Screw the shower head onto the shower arm.
Step 4A
Step 4B
Step 4C

Figure 5
INSTALLATION (WALL MOUNTING)
PERFECTION IS OUR TRADITION™
pg. 10
Screw the cold and hot water from the shower panel to the supply lines in the wall.
Carefully hang the shower panel on the secured mounting brackets as shown in Figure 4.
Step 5A
Step 5B
Hot
Cold

pg. 11
CARE AND MAINTENANCE
ANZZI™ products are crafted with superior quality standards and workmanship and are engineered to
stand the test of time. However, that does not mean the product can be neglected and will need some
care and cleaning.
It is recommended to use regular soap and hot water along with a non-abrasive cloth or sponge to
regularly clean the product. This avoids any nasty build up or deposits which would be tougher to
remove.
If you feel the use of stronger cleaning solutions or chemicals is necessary always test the cleaning
solution or chemical on an inconspicuous area before applying to the entire surface.
Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
DO NOT ALLOW THE CLEANER TO SOAK.
Following these simple principles will ™ product will remain as lustrous and
stun-ning as the day it was first received. ENJOY!
Sincerely,
La Familia ANZZI™
Perfection is our Tradition™Perfection is our Tradition™
