Apeks XTX FSR User manual

TECHNICAL SUPPORT
APEKS MARINE EQUIPMENT LTD, NEPTUNE WAY, BLACKBURN, LANCASHIRE. BB1 2BT
Tel: [phone] Fax: [phone] E-mail: [email protected] Web: www.apeks.co.uk
MAINTENANCE MANUAL
FOR
AUTHORISED TECHNICIANS
Document No. AP5825F
Issue 1
10/11/2013
XTX FSR & FST FIRST
STAGE REGULATOR

2
XTX FSR & FST First Stage Regulator Maintenance Manual
Change
No.
Change
Request No.
Description & Comments: Change
Date
New Issue
No.
Changed
By:
Approved
By:
AMENDMENTS RECORD:
Amendments and approval of this document can only be carried out by the relevant people listed on the Approved list of
signatures, which is listed in the Apeks Quality Manual. To instigate a change, a Task / Change request form, (Form No.
‘DESI/10002’), must be completed and passed to the relevant person(s) for approval which are listed on the Approved List of
Signatures. When approval has been granted and recoreded this table can then be completed and the document up issued.

3
XTX FSR & FST First Stage Regulator Maintenance Manual
Contents
COPYRIGHT NOTICE ............................................................................................................................................... 4
INTRODUCTION ....................................................................................................................................................... 4
WARNINGS, CAUTIONS & NOTES ......................................................................................................................... 4
SCHEDULED SERVICE ........................................................................................................................................... 4
GENERAL GUIDELINES .......................................................................................................................................... 4
GENERAL CONVENTIONS ...................................................................................................................................... 5
DISASSEMBLY PROCEDURES............................................................................................................................... 5
REASSEMBLY PROCEDURES................................................................................................................................ 7
IMMERSION TESTING ........................................................................................................................................... 11
TABLE 1 - TROUBLESHOOTING GUIDE .............................................................................................................. 12
TABLE 2 - RECOMMENDED TOOL LIST .............................................................................................................. 13
TABLE 3 - RECOMMENDED LUBRICANTS AND CLEANERS ........................................................................... 14
CLEANING AND LUBRICATION PROCEDURE .................................................................................................... 15
TABLE 4 -TORQUE SPECIFICATIONS ................................................................................................................. 16
TABLE 5 - TEST BENCH SPECIFICATIONS ......................................................................................................... 16
FSR XTX200 EXPLODED PARTS DRAWING ....................................................................................................... 17
FST XTX100 EXPLODED PARTS DRAWING ........................................................................................................ 18

4
XTX FSR & FST First Stage Regulator Maintenance Manual
COPYRIGHT NOTICE
This manual is copyrighted, all rights reserved. It may not,
in whole or in part, be copied, photocopied, reproduced,
translated, or reduced to any electronic medium or machine
readable form without prior consent in writing from Apeks
Marine Equipment Ltd. It may not be distributed through the
internet or computer bulletin board systems without prior
consent in from Apeks Marine Equipment Ltd.
©2013 Apeks Marine Equipment Ltd.
FSR & FST First Stage Maintenance Manual
(AP5825F Issue 8)
INTRODUCTION
This manual provides factory prescribed procedures for the
correct maintenance and repair of the Apeks FSR & FST rst
stage regulators. The model shown in this manual is the FSR,
although the FST differs in appearance, most components
are identical. It is not intended to be used as an instructional
manual for untrained personnel. The procedures outlined
within this manual are to be performed only by personnel
who have received factory authorised training through an
Apeks Service & Repair Seminar. If you do not completely
understand all of the procedures outlined in this manual,
contact Apeks to speak directly with a Technical Advisor
before proceeding any further.
WARNINGS, CAUTIONS & NOTES
Pay special attention to information provided in warnings,
cautions, and notes that are accompanied by one of these
symbols:
WARNINGS indicate a procedure or situation that
may result in serious injury or death if instructions
are not followed correctly.
CAUTIONS indicate any situation or technique that
will result in potential damage to the product, or
render the product unsafe if instructions are not
followed correctly.
NOTES are used to emphasise important points, tips,
and reminders.
SCHEDULED SERVICE
It is recommended that the Apeks FSR & FST rst stage
regulators should be examined annually regardless of usage.
A full serviced should be performed every two years.
However, If at all unsure about the correct functioning of
the Apeks rst stage, then it must be ofcially inspected
immediately.
All service and inspection details need to be documented
in the Regulator Service Record in the back of the Owner’s
Manual to keep the Limited Lifetime Warranty in effect.
An Ofcial Inspection consists of:
1. A pressurised immersion test of the entire unit to
check for air leakage.
2. Checking for stable medium pressure that is within
the acceptable range.
3. Checking that all parts are tightly fastened together
and that no parts are loose.
4. A visual inspection of the Environmental Diaphragm
looking for tears or holes and checking the general
condition.
5. A visual inspection of any lters for debris or dis-
colouration.
6. Pulling back hose protectors and checking that the
hoses are secure in the hose crimps.
If a regulator fails steps 1,2, or 3 the entire regulator should
be serviced. If a regulator fails 4 or 5 it will be up to the
technician’s discretion whether or not a full service is re-
quired. Failure of step 6 requires replacement of the Hose.
GENERAL GUIDELINES
1. In order to correctly perform the procedures outlined
in this manual, it is important to follow each step
exactly in the order given. Read over the entire
manual to become familiar with all procedures and
to learn which specialty tools and replacement parts
will be required before commencing disassembly.
Keep the manual open beside you for reference while
performing each procedure. Do not rely on memory.
2. All service and repair should be carried out in a work
area specically set up and equipped for the task.
Adequate lighting, cleanliness, and easy access to all
required tools are essential for an efcient repair facil-
ity.
3. During disassembly, reusable components should be
segregated and not allowed to intermix with non-
reusable parts or parts from other units. Delicate
parts, including inlet ttings and valve seats which
contain critical sealing surfaces, must be protected
and isolated from other parts to prevent damage
during the cleaning procedure.
4. Use only genuine Apeks parts provided in the 1st
stage service kit (AP0241). DO NOT attempt to
substitute an Apeks part with another manufacturer’s,
regardless of any similarity in shape or size.
5. Do not attempt to reuse mandatory replacement
parts under any circumstances, regardless of the
amount of use the product has received since it was
manufactured or last serviced.
6. When reassembling, it is important to follow every
torque specication prescribed in this manual,
using a calibrated torque wrench. Most parts are
made of either marine brass or plastic, and can be
permanently damaged by undue stress.

5
XTX FSR & FST First Stage Regulator Maintenance Manual
Pinch Method
Press upwards on
sides of ‘O’ Ring
to create a protru-
sion. Grab ‘O’ Ring
or insert ‘O’ Ring
tool at protrusion.
Removal of hose
Removal of Blanking Plugs
GENERAL CONVENTIONS
Unless otherwise instructed, the following terminology and
techniques are assumed:
1. When instructed to remove, unscrew, or loosen a
threaded part, turn the part anti-clockwise.
2. When instructed to install, screw in, or tighten a
threaded part, turn the part clockwise.
3. When instructed to remove an ‘O’ Ring, use the pinch
method (see gure below) if possible, or use a brass,
aluminium or plastic ‘O’ Ring removal tool. Avoid using
hardened steel picks, as they may damage ‘O’ Ring
sealing surfaces. All ‘O’ Rings that are removed are
discarded and replaced with brand new ‘O’ Rings.
4. The following acronyms are used throughout the
manual: MP is Medium Pressure; HP is High Pressure;
PN is Part Number.
5. Numbers in parentheses reference the key numbers
on the exploded parts schematics. For example, in the
statement, “...remove ‘O’ Ring (4) from...”, the number
4 is the key number to the Spring Carrier ‘O’ Ring.
DISASSEMBLY PROCEDURES
NOTE: Before performing any disassembly, refer
to the exploded parts drawing, which references all
mandatory replacement parts. These parts should be
replaced with new, and must not be reused under any
circumstances - regardless of the age of the regula-
tor or how much use it has received since it was last
serviced.
CAUTION: Use only a plastic, brass or aluminium
‘O’ Ring removal tool (PN AT79) when removing
‘O’ Rings to prevent damage to the sealing
surface. Even a small scratch across an ‘O’ Ring
sealing surface could result in leakage. Once an
‘O’ Ring sealing surface has been damaged, the
part must be replaced with new. DO NOT use a
dental pick, or any other steel instrument.
1. Using a 9/16 spanner, remove all of the hoses from the
rst stage. Remove the ‘O’ Ring from inside the Hose
Swivel. Exercise caution not to scratch the ‘O’ Ring
groove. Remove the ‘O’ Ring from the Hose Nut end of
the Hose.
2. Pull back the two
Hose Protectors and
inspect the Hose
Crimps. If either
Crimp is damaged or
the Hose is pulling
out of the crimp then
the Hose must be
replaced.
3. Using a 5mm Allen
key remove all of the
MP and HP blanking
plugs.
4. Remove all of the
‘O’ Rings from the
Blanking Plugs.
5. Using the First Stage
Work Handle (PN
AT48) clamp the
regulator in a vice.

6
XTX FSR & FST First Stage Regulator Maintenance Manual
Removal of Balance Plug Assembly
Removal of Dry Sealed Chamber
NOTE: If the First Stage has a DIN Connection, go
to step 13: if it has a Yoke Connection follow step 14.
Removal of Din Connection
NOTE: The thickness of the spanner must not
exceed 11mm or it will not t between the thread and
the ange. The correct spanner can be purchased
from Apeks (PN AT47)
6. Using a 6mm Allen key unscrew the Balance Plug (18)
and withdraw the Balance Plug assembly.
7. Separate the Balance
Plug assembly by
pulling on each end.
8. Remove ‘O’ Rings
(16,12,17) from the
Balance Plug (18),
taking care not to
scratch the ‘O’ Ring
grooves.
9. Using a C Spanner (PN AT30) unscrew the
Environmental End Cap (1). Remove the Load
Transmitter (3) from inside the Diaphragm Clamp (6).
10. Remove the Moulded Ring (5) and using a 34mm
open ended spanner unscrew the Diaphragm Clamp (6).
11. Remove the Spring (7) & Spring Carrier (8). Replace
three of the MP blanking plugs (no ‘O’ Rings required)
and screw them in nger tight. Put the nozzle of a
compressed air blow gun in the remaining MP port and
blow a sharp blast of air to remove the diaphragm (9).
Remove the MP blanking plugs.
12. Remove the Valve Lifter (10) from the Valve Body (11).
13. Using a 6mm Allen key, unscrew the DIN Connection
Assembly and separate into four pieces. Remove the ‘O’ Ring
(23) from the end of the Handwheel connector (30).

7
XTX FSR & FST First Stage Regulator Maintenance Manual
Removal of Yoke Connection
Removable
HP Valve Seat XTX200 HP
Seat Tool
(PN AT53)
14. Unscrew the Yoke Clamp Screw (24) and remove the
Protective Cap (22) from the Yoke Clamp (19). Using a
3/4” A/F spanner, loosen the Yoke Clamp Connector
(20). Unscrew the Yoke Connector and Yoke Clamp.
Remove the ‘O’ Ring from the Yoke Clamp Connector
(20).
15. Insert a dowel
through the open end
of the Yoke Clamp
Connector (20) and
push out the Disc
Filter (21).
Removal of Removable HP Valve Seat (FSR Only)
CAUTION: Before proceeding, make sure
you are working over a padded work
surface: otherwise, the Removable HP Valve
Seat (13) may be damaged during removal.
16. To remove the HP Valve Seat (13) from the FSR Valve
Body (11) locate the end of the HP Seat Tool (PN
AT53) inside the small hole. Gently slide the tool into
the hole, this will push the HP Valve Seat out of the
bottom of the Valve Body (11).
17. Remove the ‘O’ Ring (12) from the HP Valve Seat (13).
This Ends Disassembly
Before starting reassembly, perform parts cleaning
and lubrication according to the procedures
outlined in ‘Cleaning & Lubrication’ on page 15.
REASSEMBLY PROCEDURES
Fitting of Removable HP Valve Seat (FSR Only)
1. Install a new lubricated ‘O’ Ring (12) onto the
Removable HP Valve Seat (13). Locate the Removable
HP Valve Seat onto the end of the HP Seat Tool (PN
AT53). Ensure that the seating face of the Valve Seat
is against the Seat Tool. Firmly push the Seat Tool
into the Valve Body (11) until the Removable HP Valve
Seat is located at the bottom of the bore.
WARNING: The regulator will not operate if the
Removable HP Valve Seat is inserted into the Valve
Body incorrectly.
NOTE: A slot on the at face of the HP valve seat has
been added to identify the way of assembly

8
XTX FSR & FST First Stage Regulator Maintenance Manual
Assembling and tting of Yoke Connection
NOTE: Ensure that the ‘O’ Ring is retained in the
Connector after the Conical Filter has been tted.
CAUTION: If the Yoke Clamp Assembly is not
held vertically whilst it is screwed into the
Valve Body, the ‘O’ Ring in the end of the Yoke
Clamp Connector may not remain in the correct
position.
Assembling and tting of DIN Connection
CAUTION: If the Handwheel Connector
Assembly is not held vertically whilst it is
screwed into the Valve Body, the ‘O’ Ring in the
end of the Handwheel Connector may not remain
in the correct position.
1. Insert a new Disc Filter (21) with the smooth side out,
into the Yoke Clamp Connector (20). Install a new
lubricated ‘O’ Ring (12) into the end of the Connector.
2. Insert the Yoke Clamp Connector (20) through the
Yoke Clamp (19). With the Valve Body held so that
the inlet connection port points down, screw the Yoke
Clamp Connector into the Valve Body (11) until nger
tight.
3. Secure the Valve Body (11) back into the vice using the
First Stage Work Handle (PN AT48). Tighten the Yoke
Clamp Connector using a 3/4” A/F spanner. Install the
Protective Cap (22) with the logo facing outwards, onto
the Yoke Clamp (19). Screw the Yoke Clamp Screw
(24) back into the Yoke Clamp (19), until the Protective
Cap (22) is retained in place.
4. Install a new ‘O’ Ring (23) into the face of the
Handwheel Connector (30). Install a new lubricated
‘O’ Ring (12) into the opposite end of the Connector.
Install the Conical Filter (35) into the Connector,
through the ‘O’ Ring.
5. Insert the threaded end of the Handwheel Connector (30)
through the threaded end of the Handwheel (29). With
the Valve Body held so that the inlet connection port
points down, screw the Handwheel Connector into the
Valve Body (11) until nger tight.
6. Secure the Valve Body (11) back into the vice using
the First Stage Work Handle (PN AT48). Tighten the
Handwheel Connector (30) using a 6mm Allen key bit
in a torque wrench to 20 Nm.

9
XTX FSR & FST First Stage Regulator Maintenance Manual
This Ends Re-assembly
Fitting of the Dry Sealed Chamber
7. Drop the Valve Lifter (10) through the centre hole of
the Valve Body (11). Press a new Diaphragm (9) into
the Body. Run your nger around the edge of the
diaphragm to make sure it is properly seated.
8. Place the spring carrier (8) and Spring (7) centrally onto
the diaphragm (9).Thread the Diaphragm Clamp (6) onto the
Valve Body (11), making sure that the Spring (7) remains on
the Spring Carrier (8), until hand tight. Using a 34mm Span-
ner (PN AT47) tighten the Diaphragm Clamp (6) until there is
metal to metal contact. Ret the Moulded Ring (5).
9. Fit new Lubricated ‘O’ Rings (12 & 17) onto the H.P.
Balance Plug. Install a new lubricated ‘O’ Ring (16)
into the end of the H.P Balance Plug. Ensure that the ‘O’
Ring is ush.
10. Press the Spring (15) onto the end of the H.P. Balance
Plug. Carefully insert a new H.P. Valve (14) into the
H.P Balance plug assembly.
11. Insert the H.P. Balance Plug (18) into the Valve Body
(11) and tighten using a 6mm Allen key bit in a torque
wrench to 8 Nm.

10
XTX FSR & FST First Stage Regulator Maintenance Manual
Adjusting the First Stage
CAUTION: If the pressure gauge rapidly exceeds
11 bar, then there is a HP leak. Quickly close the
cylinder valve and purge the regulator. Refer to
the troubleshooting table for the causes of the
leak.
WARNING: Compressed air can be highly
explosive and is dangerous if misused. Ensure
cylinder valve is opened slowly. Use Eye and
Ear Personal Protective Equipment when
performing any tests involving Compressed
air.
Final Assembly
NOTE: The Pour Moulded Hydrostatic Diaphragm
(2) in the XTX does not need to be replaced with a
new one unless it is deemed damaged or worn by the
technician.
1. Attach the rst stage
(with no Blanking
Plugs tted) to a fully
charged 232 or 300
bar cylinder. Slowly
open the cylinder
valve, this will
remove any particles
or contaminants from
the rst stage.
2. Install new
lubricated ‘O’ Rings
(12,27) on all of
the Blanking Plugs
(26,28). Using a
5mm Allen key,
install all of the
Blanking Plugs into
the Valve Body.
3. Attach a MP test gauge (0 - 20 bar) to a medium
pressure hose and thread the hose into a MP port.
If your test gauge does not have an over pressure
relief valve, you must also attach a properly adjusted
second stage to the rst stage to act as the relief valve
in case of a HP leak. Make sure Blanking Plugs are
installed in any open ports.
4. Assuming there are no leaks, close the cylinder valve
and depressurise the regulator by opening the gauge
relief valve or by pressing the purge button of the
second stage regulator. Adjust the medium pressure
by turning the Spring Adjuster (4): Turning in the
Spring Adjuster increases the MP; Turning out the
Spring Adjuster decreases the MP. Turn the Spring
Adjuster in 1/8th turn increments and purge the relief
valve several times after each adjustment. When the
MP is between 9 and 10 bar , purge the relief valve
on and off 10-15 times. After cycling, watch the gauge
needle. The rst stage MP should “lock-up” between 9
and 10 bar. Make any adjustments as necessary. Allow
the rst stage to stay pressurised for several minutes
and check the MP again to make sure it remains
“locked-up” between 9 and 10 bar. If the MP creeps
upward more than 0.25 bar, then there is a leak. Refer
to the troubleshooting table for possible causes.
5. Close the cylinder valve and depressurise the
regulator by opening the gauge relief valve or by
pressing the purge button of the second stage
regulator. Close the relief valve and repressurise
the system. The MP should still read between 9 and
10 bar. If the pressure reading is different than the
original setting, repeat steps 3 and 4 until the MP is
stable.
1. With the regulator still pressurised, insert the Load
Transmitter (3) into the Diaphragm Clamp (6). Press a
new Hydrostatic Diaphragm (2) into the Environmental
End Cap (1) (If required).

11
XTX FSR & FST First Stage Regulator Maintenance Manual
IMMERSION TEST
With the Blanking Plugs and at least one properly
adjusted second stage installed, slowly open
the cylinder valve and pressurise the rst stage.
Completely Submerge the rst stage in fresh water
and check for leaks.
NOTE: Do not confuse bubbles from trapped air with
a true air leak. If there is an air leak, bubbles will come
out in a steady constant stream.
Assuming that there are no leaks, close the cylinder
valve and depressurise the regulator. Remove the rst
stage from the valve and secure the Protective Cap
(22) in place with the Yoke Clamp Screw (24). If the
regulator has a DIN connection replace the Protective
DIN Cap (34).
If a leak is detected, note the source of the leak and
refer to the troubleshooting table on page 12 for
possible causes and corrective actions.
This Ends Testing
This Ends Reassembly
4. Assuming there are no leaks, close the cylinder valve
and depressurise the regulator by opening the gauge
relief valve or by pressing the purge button of the
second stage regulator. Adjust the medium pressure
by turning the Spring Adjuster (4): Turning in the
Spring Adjuster increases the MP; Turning out the
Spring Adjuster decreases the MP. Turn the Spring
Adjuster in 1/8th turn increments and purge the relief
valve several times after each adjustment. When the
MP is between 9 and 10 bar , purge the relief valve
on and off 10-15 times. After cycling, watch the gauge
needle. The rst stage MP should “lock-up” between 9
and 10 bar. Make any adjustments as necessary. Allow
the rst stage to stay pressurised for several minutes
and check the MP again to make sure it remains
“locked-up” between 9 and 10 bar. If the MP creeps
upward more than 0.25 bar, then there is a leak. Refer
to the troubleshooting table for possible causes.
2. Thread the Environmental End Cap (1) onto the
Diaphragm Clamp (6) until hand tight. Using the C
Spanner (PN AT30), tighten the Environmental End Cap
(1) until there is metal to metal contact. Re-check the
medium pressure, making sure that it is still between 9
and 10 bar.
NOTE: Lightly press the diaphragm whilst tightening
the end cap, once the rst stage has been depressurised
the diaphragm will assume a concaved positioning for
added protection.
3. Close the cylinder valve and depressurise the
regulator. Remove the test gauge and reinstall the
Blanking Plug.

12
XTX FSR & FST First Stage Regulator Maintenance Manual
Table 1 - Troubleshooting Guide
SYMPTOM POSSIBLE CAUSE TREATMENT
High Pressure Creep
(also causes second stage leaks)
1. HP Valve (14) is worn or damaged. 1. Replace HP Valve.
2. Removable HP Valve Seat(13) is worn or
damaged. (FSR Only) 2. Replace Removable HP Valve Seat.
3. ‘O’ Ring on Removable HP Valve Seat
(12) is damaged or worn. 3. Replace ‘O’ Ring.
4. HP Balance Plug internal wall damaged. 4. Replace HP Balance Plug.
5. ‘O’ Ring (16) inside HP Balance Plug
(18) is damaged or worn. 5. Replace ‘O’ Ring.
6. ‘O’ Ring (12) on HP Balance Plug (18) is
damaged or worn. 6. Replace ‘O’ Ring.
7. HP Valve Seat in Valve Body (11) is worn
or damaged. (FST Only) 7. Replace Valve Body.
External air leakage
or
Secondary diaphragm distended
or burst
1. Blanking Plug ‘O’ Rings (12,27) are worn
or damaged. 1. Replace ‘O’ Ring.
2. Diaphragm (9) worn or damaged. 2. Replace diaphragm.
3. Diaphragm seating surface damaged. 3. Replace Valve Body.
4. Connector ‘O’ Ring (12) worn or
damaged. 4. Replace ‘O’ Ring.
5. Diaphragm Clamp (6) loose. 5. Tighten Diaphragm Clamp.
6. ‘O’ Ring on HP Balance Plug (17) worn
or damaged. 6. Replace ‘O’ Ring.
Restricted air ow or high inhalation
resistance through entire system
1. Cylinder valve not completely open. 1. Open valve, check ll pressure.
2. Cylinder valve requires servicing 2. Switch to different cylinder.
3. Conical Filter (33) or Disc Filter (21) is
clogged. 3. Replace lter.
4. Very Low Medium Pressure. 4. Adjust Medium Pressure to between
9 and 10 bar.

13
XTX FSR & FST First Stage Regulator Maintenance Manual
Table 2 - Recommended Tool List
PART NO. DESCRIPTION APPLICATION
AP0430 I.P. test gauge Intermediate pressure testing
AT79 ‘O’ Ring removal pick ‘O’ Ring removal
AT30 C spanner Removal of Diaphragm Clamp & End Cap
AT48 First Stage Work Handle Clamping Valve Body in Vice
AT53 Removable HP Valve Seat Tool Removal and installation of HP Valve Seat (FSR)
n/a Torque wrench, Nm or lbf/ft Installation of Balance Plug & DIN Connection
n/a 6mm Allen key bit for torque wrench Installation of Balance Plug & DIN Connection
AT34 11/16” spanner Hose Removal
AT37 5mm Allen key Blanking Plugs
AT38 6mm Allen key Removal of Balance Plug, DIN Connection & Spring
Adjuster
AT47 34mm open ended spanner Removal of Diaphragm Clamp
AT33 3/4” ring spanner Removal and installation of Yoke Clamp Connector
n/a 232 or 300 bar Diving cylinder Testing of regulator

14
XTX FSR & FST First Stage Regulator Maintenance Manual
Table 3 - Recommended Lubricants & Cleaners
LUBRICANT / CLEANER APPLICATION SOURCE
Christo-Lube® MCG-111
(Lubricant)
All ‘O’ Ring seals Apeks Marine Equipment Ltd
PN AP1495, or
Lubrication Technologies
310 Morton Street
Jackson, OH 45640, USA
[phone]
PerFluoroLube® 20/1 (Lubricant) All ‘O’ Ring seals Lubrication Technologies
310 Morton Street
Jackson
OH 45640, USA
[phone]
Biox
(Cleaning agent)
Biological immersion uid for reusable
stainless steel and brass parts.
Solent Divers Ltd
122-128 Lake Rd, Portsmouth,
Hants, PO1 4HH
White distilled vinegar (100 gr.)
(Cleaning agent)
Acid bath for reusable stainless
steel and brass parts.
“Household” grade
Liquid dishwashing detergent diluted
with warm water
(Cleaning agent)
Degreaser for brass and stainless
steel parts; general cleaning solution
for plastic and rubber
“Household” grade
CAUTION: Silicone rubber requires no lubrication or preservative treatment. DO NOT
apply grease or spray to silicone rubber parts (eg. Diaphragm, Exhaust Valves.) Doing
so may cause a chemical breakdown and premature deterioration of the material.
CAUTION: Do not use muriatic acid for the cleaning of any parts. Even if strongly diluted,
muriatic acid can harm chrome plating and may leave a residue that is harmful to ‘O’
Ring seals and other parts

15
XTX FSR & FST First Stage Regulator Maintenance Manual
Cleaning & Lubrication Procedure
General Cleaning of all Parts
1. Place all components in an ultrasonic cleaning bath containing an appropriate cleaning solution, such as Biox.
2. The components should be cleaned for 6 minutes, depending upon their condition. Longer cleaning times may used if
required.
3. Rinse the components in warm fresh water.
4. The components should then be blown dry or left to dry naturally
Lubrication and Dressing
All ‘O’ Rings should be lubricated with Christo-Lube® MCG-111 or PerFluoroLube® 20/1. Dress the ‘O’ Rings with a very light
lm of grease, and remove any visible excess by running the ‘O’ Ring between thumb and forenger. Avoid applying excessive
amounts of Christo-Lube grease, as this will attract particulate matter that may cause damage to the ‘O’ Ring.
Caution: Use a small amount of an appropriate lubricant (such as Christo-Lube) LIGHTLY applied to the thread of the Din Hand-
wheel periodically. This prevents seizing on the Cylinder Valve. DO NOT OVER LUBRICATE or apply to the internals of the
handwheel or cylinder valve gas-way.
Enriched Air Nitrox Use – Outside EEC (European Economic Community) Countries Your Apeks regulator has been prepared for use with
Enriched Air Nitrox (EAN) where the percentage of oxygen in the EAN does not exceed 40%. This is possible because each regulator is built to a
high standard of cleanliness using EAN compatible components and lubricants. In addition, each regulator design has passed stringent adiabatic
compression testing to ensure its safety and compatibility with increased percentages of oxygen. If it is your intention to use your new Apeks
regulator with Nitrox EAN (O2 not to exceed 40%), it is imperative that you maintain the internal cleanliness of the regulator (see section on Care
and Maintenance). If it is your intention to use the regulator interchangeably with breathing air, the breathing air should be oxygen-compatible
or “hyperltered” where the condensed hydrocarbons do not exceed 0.1 mg/m3. Your local authorised Apeks dealer can help you determine
whether the breathing air that they provide meets this criterion.
Standard compressed breathing air meeting the EN 12021 standard, often referred to as Grade E in the United States, does not necessarily
meet this criterion. Grade E or EN 12021 breathing air may contain a certain level of hydrocarbons, including traces of compressor oils that
while not considered harmful to breathe, can pose a risk in the presence of elevated oxygen content. Passing hydrocarbons through a valve
and regulator creates a cumulative effect where the hydrocarbons build up over time along the internal passageways of the equipment. When
these hydrocarbons come into contact with high-pressure oxygen enriched air, they can pose a very real hazard that can lead to combustion.
Therefore, if a regulator has had use with Grade E or EN 12021 breathing air, it should be returned to an authorised Apeks dealer for overhaul
service including oxygen cleaning, prior to being put back into nitrox service. Although second stage components are not exposed to high
pressure EAN, Apeks recommends that the same cleaning procedures be followed for the complete regulator. This prevents the possibility of
cross contamination and guarantees the cleanliness of the entire regulator.
Enriched Air Nitrox Use – Inside EEC (European Economic Community ) countries EN 1443-3 and EN13949In CEE countries, diving with
Nitrox/O2 is controlled by Standards EN 144-3 – Respiratory protective devices - Gas cylinder valves - Part 3: Outlet connections for diving gases
Nitrox and oxygen - and EN 13949 – Respiratory equipment - Open circuit self-contained diving apparatus for use with compressed Nitrox and
oxygen - requirements, testing, marking.
NOTE : Apeks offers a range of regulators designed and manufactured specially for use with oxygen-enriched mixtures, over 21% and up to
100% oxygen. This range has been certied according to the EN 144-3 and EN 13949 standards and meets the requirements of the adiabatic
compression tests. They have received CE certication for this type. For further information on this range, contact your Apeks specialist center.
WARNING : These regulators tted with special connections should be used only with complementary equipment (tank valves, tanks, pressure
gauges, etc.) designed and prepared for use with an oxygen-enriched mixture. These items are marked Nitrox/O2.
WARNING: If the regulator that you use is tted with a yoke or DIN connection, it is designed for use only with compressed breathing air (21%
oxygen and 79% nitrogen) which meets the EN 12021 standard. DO NOT USE this equipment with other mixtures or with gases containing more
than 21% oxygen. Disregarding this rule could result in serious injury or death caused by re or explosion.
Every Nitrox/O2 regulator is assembled in a clean workshop, using compatible components and special lubricants. It is important to maintain the
interior of the regulator in a clean state. Breathing air used in the production of a mixture should be oxygen compatible and double ltered with
a hydrocarbon content not greater than 0.1 mg/m3. Your Apeks technical specialist should be able to help you determine if the breathing air he
supplied meets these criteria.
WARNING: Please check the regulations regarding Nitrox in your particular country as this may
differ from Apeks standard policy.

16
XTX FSR & FST First Stage Regulator Maintenance Manual
Table 5 - Test Bench Specications
TEST CONDITION ACCEPTABLE RANGE
Leak Test Inlet pressure 150 - 232 bar No Leaks allowed
Medium Pressure Inlet pressure 150 - 232 bar 9 to 10 bar
Medium Pressure Creep Inlet pressure 150 - 232 bar 0.25 bar max for 15 seconds after
purging regulator
Table 4 - Torque Specications
PART NUMBER DESCRIPTION / KEY NUMBER TORQUE
AP1471, AP1471/PVD Handwheel Connector (33) 20 Nm / 14.7 lbf/ft
AP5309 H.P. Balance Plug (18) 8 Nm / 5.9 lbf/ft
AP1407 Yoke Clamp Connector (20) 20Nm / 14.7 lbf/ft

17
XTX FSR & FST First Stage Regulator Maintenance Manual
1 AP1484 Environmental End Cap 18 AP5309/B H.P Balance Plug
AP1484/PVDS Tungsten End Cap 19 AP1403 Yoke Clamp
2 AP1482F/1 Hydrostatic Diaphragm AP1403/PVDS Yoke Clamp PVD
AP1482/T Tungsten Hydrostatic Diaphragm 20 AP1407 Yoke clamp connector
3 AP1483 Pressure Transmitter 21* AP1406 Disc Filter
4 AP1474 Spring Adjuster 22 AP1404 Protective Cap
5 AP5725 Moulded Logo Ring 23* AP1166 ‘O’ Ring
AP6203 Moulded Logo Ring Nitrox 24 AP1402/B AP1402/B
6 AP1473-1 Diaphragm Clamp 25 AP6308/1/200 XTX 200 Decal
7 AP1475 Spring AP6239F XTX Tungsten Decal
8 AP1476 Spring Carrier 26 AP1413 7/16” UNF Blanking Plug
9* AP1478 Diaphragm 27* AP1445 ‘O’ Ring
10 AP5722 Valve Lifter 28 AP1408 3/8” UNF Blanking Plug
11 AP5101F XTX200 Valve Body FSR 29 AP6201 DIN Moulded Handwheel
AP5101F/PVDS XTX Tungsten valve Body FSR NP6201 Nitrox DIN Moulded Handwheel M26
12* AP1409 ‘O’ Ring 30 AP1471 Handwheel Connector
13 AP5721 Removable H.P Valve Seat AP1871 Nitrox Handwheel Connector M26
14* AP1419 H.P Valve 31* AP1405 ‘O’ Ring
15 AP1415 Spring 32 AP6202 DIN Protective Cap
16* AP1299 ‘O’ Ring AP1270 Moss Cap
17* AP1300 ‘O’ Ring 33* AP1472 Conical Filter
XTX FSR (XTX 200) Exploded Parts Diagram
36
35
12
37
38
39
All * items in bold italics to be replaced when servicing
1
234
5
6
78910 25 12 12 28
28
27
28
12
20
21
19
23
22
24
23
32
23
30
29
33
11
12 12 13 14
15 16 12 17 18
26
12

18
XTX FSR & FST First Stage Regulator Maintenance Manual
1 AP1484/S Environmental End Cap 19 AP1403/S Yoke Clamp
2 AP1482F/1 Hydrostatic Diaphragm 20 AP1407/S Yoke Clamp Connector
3 AP1483 Pressure Transmitter 21* AP1406 Disc Filter
4 AP1474 Spring Adjuster 22 AP1404 Protective Cap
5 AP5725 Moulded Logo Ring 23* AP1166 ‘O’ Ring
AP6203 Moulded Logo Ring Nitrox 24 AP1402 2-Shot Yoke Clamp Knob Satin
6 AP1473-1 Diaphragm Clamp 25 AP6308/100 XTX100 Decal
7 AP1475 Spring 26 AP1413 7/16” UNF Blanking Plug
8 AP1476 Spring Carrier 27* AP1445 ‘O’ Ring
9* AP1478 Diaphragm 28 AP1408 3/8” UNF Blanking Plug
10 AP1479 Valve Lifter 29 AP1470/S Handwheel
11 AP5102F XTX FST Body AP1870 Nitrox Handwheel M26
12* AP1409 ‘O’ Ring 30 AP1471/S Handwheel Connector
13 n/a AP1871 Handwheel Connector M26
14* AP1419 H.P. Valve 31* AP1405 ‘O’ Ring
15 AP1415 Spring 32 AP6202 Protective DIN Cap
16* AP1299 ‘O’ Ring AP1270 Moss Cap
17* AP1300 ‘O’ Ring 33* AP1472 Conical Filter
18 AP5309 H.P. Balance Plug
XTX FST (XTX100) Exploded Parts Diagram
28
33
12
30
31
32
All * items in bold italics to be replaced when servicing
123456
78910 25
12
20
21
23
22
24
32
23
30
29
33
12
11
14 15 12 17 18
16
12
28
28
12
26
27
23

FSR & FST FIRST STAGE REGULATOR
AUTHORISED TECHNICIANS
Apeks Marine Equipment Ltd
Neptune Way, Blackburn, Lancs, England, BB1 2BT
MAINTENANCE MANUAL
FOR
TECHNICAL SUPPORT
