Apera Instruments LabSen763 User manual

LabSen763 Blade Spear pH Electrode
User Manual
LabSen electrochemical sensors are premium pH electrode with manufacturing technology and key
components imported from Switzerland. LabSen763 places the tapered glass membrane in a
stainless steel shaft with blade. This probe is suitable for pH measuring of fish, meat and meat
products.
This Electrode has following features:
⚫ Adopts food grade stainless steel blade and sheath, offers strong protection, comply with food
hygiene requirements, suitable for food pH testing.
⚫ Blue gel inner solution, does not flow and will not cause bubble.
⚫ Maintenance-free polymer electrolyte, non-diaphragm structure.
⚫ Long life reference system, has better stability and service life.
1 Technical Data
Measuring Range
(0 ~ 14) pH
Electrolyte
Polymer
Temperature Range
(0 ~ 80) °C
Soaking Solution
3M KCl
Shaft Material
Food-Grade Titanium
Temp. Probe
NTC 30kΩ
Membrane Type
S
Membrane Resistance
<250MΩ
Reference
Long Life
Electrode Dimension
(Ø12×115) mm
Junction
Ceramic+Single Pore
Connector
BNC/RCA
Cable
Ø5×1m
2 Usage and Maintenance
2.1 When measuring, please unscrew the bottle cap, pull out the electrode and rinse it with
deionized water. After using, please put the electrode back into the bottle and screw tight the
cap.
Before pulling out or putting back the electrode,
make sure to fully loosen the blue cap on the
storage sleeve so that the electrode can move
in and out smoothly.

2.2 The electrode’s measuring tip should be soaked in the soaking bottle containing certain amount
of Protelyte soaking solution to keep the membrane hydrated and junction unblocked. Clean the
bottle and replace the storage solution if the storage solution gets turbid and mildewed. The
electrode should never be sinked in pure water or buffer solution for long.
2.3 Please forcibly even when piercing into meat (especially frozen meat); do not bend it to prevent
damage of the tapered membrane. Wash the electrode and the stainless steel sheath with soapy
water after measurement, the stainless blade can be screwed off and cleaned if necessary.
2.4 The electrode must be soaked in Protelyte solution for storage. Because after long time
exposure in air, Polymer electrolyte will cause shrinkage.
2.5 The connector of the electrode should keep clean and dry. If being contaminated, please clean
it with medical cotton and absolute alcohol and blow dry to prevent the short circuit of the
electrode and slow reaction of electrode.
2.6 The stainless steel sheath and blade have a specially treated coating, it is absolutely forbidden
to damage the coating with sandpaper or blade, otherwise the stainless steel sheath and blade
will get rust in Protelyte solution.
2.7 After 1-year of use, we recommend replacing the electrode to ensure the best accuracy.
3 Warranty
We warrant this electrode free from defects in material and workmanship and agrees to repair or
replace free of charge, at option of APERA INSTRUMENTS any malfunctioned or damaged product
attributable to responsibility of APERA INSTRUMENTS for a period of six months. Warranty period
is the time limit to provide free service for the products purchased by customers, not the service life
of the tester or electrodes.
This limited warranty does not cover any damages due to:
transportation; storage; improper use; failure to follow the product instructions or to perform any
preventive maintenance; modifications; combination or use with any products, materials, processes,
systems or other matter not provided or authorized in writing by us; unauthorized repair; normal wear
and tear; or external causes such as accidents, abuse, or other actions or events beyond our
reasonable control.
APERA INSTRUMENTS (Europe) GmbH
Address: Wilhelm-Muthmann-Str.18,
42329 Wuppertal, Germany
Phone: [phone]
Website: www.aperainst.de
Email: [e-mail]
