Apollo VP200 User manual

MODEL : VP200
Two -Tone Voice PagerTwo -Tone Voice Pager
Two -Tone Voice PagerTwo -Tone Voice Pager
USER MANUALUSER MANUAL

WARNING .................................................................................................. 1
INSPECTION / BATTERY TYPES .......................................................... 2
BATTERY INSTALLATION ....................................................................... 3
STANDARD FEATURES AND CONTROLS (All Models) ..................... 5
STORED VOICE MODEL FEATURES AND CONTROLS .................... 10
FIELD INSTALLED OPTIONS ................................................................. 11
OPERATION .............................................................................................. 13
SCAN OPERATION .................................................................................. 14
STORED VOICE OPERATION ................................................................ 17
BATTERY LIFE / ACCESSORIES ........................................................... 20
VP200 CHARGER USER MANUAL .................................................. 21
WARNING .................................................................................................. 22
BATTERY CHARGER DESCRIPTION / OPERATION GENERAL ...... 23
OPERATION GENERAL .......................................................................... 24
CHARGER INDICATOR LIGHTS ............................................................ 26
SPECIFICATIONS .................................................................................... 27
CON ENTS
T

WARNING :
1. Do not operate this product in a hazardous atmosphere.
2. Do not replace or charge batteries in a hazardous atmosphere.
Contact sparking may occur while installing or removing batteries
and cause an explosion or fire.
3. Do not replace or change accessories in a hazardous atmosphere.
Contact sparking may occur while installing or removing accessories
and cause an explosion or fire.
4. Turn a radio off before removing or installing a battery or accessory.
5. Do not disassemble this unit in any way that exposed the internal
electrical circuits of the unit.
6. Do not substitute components. This could void the intrinsic safety
rating.
X
X
X
X
X
X
WARNING
IWARN NG
1

INSPECTION / BATTERY TYPES
INSPECTION
Verify the model number information located on the label on the
back of the VP200. Inspect the equipment thoroughly. If any part
of the equipment has been damaged in transit, report the extent
of the damage to the transportation company immediately.
BATTERY TYPES
The VP200 is powered by 3 rechargeable Ni-MH batteries, type
" AAA ".
X
X
2

BATTERY INSTALLATION
BATTERY INSTALLATION
NOTE: For optimum performance, the Ni-MH batteries must be fully
charged before operating your VP200.
Install your batteries as follows:
1. Release the belt clip by pressing the latch, and slide the belt
clips upwards.
2. Unlock the "lock switch" on the battery cover.
3. Follow the arrow " " on the battery cover and slide it out.
4. After put the batteries, slide in the battery cover into place, and
then slide the battery cover latch to the locked position.
X
X
3
1. Release the belt clip
by pressing the latch

BATTERY INSTALLATION
4
CAUTION: If the batteries are improperly installed, the VP200 will
not function and the batteries will not charge.
3. unlock the " lock switch "
4. Follow the arrow on
the battery cover and
slide it out
2. Slide the belt clip upwards
Battery/Programmer
Contacts
/

STAN ARD FEATURES ANDD
CONTROLS (All Models)
STANDARD FEATURES AND CONTROLS (All Models)
5
Amber
On/Off Switch
Volume Control Battery Alert Indicators
Reset
Button
External Accessory
Jack(Plugged)
Red
PLAYBACK Button

ON/OFF Switch/Volume Control
The ON/OFF SWITCH/VOLUME CONTROL is a combined single
control located on the top of the VP200 as shown on page 5.
Turning the control knob a few degrees in a clockwise direction
applies power to the receiver, and an audible beep is sounded
to indicate that the VP200 is turned on. As the control is rotated in
a clockwise direction, the volume level of any received. Message
and alert tone is increased. Rotating the control in the opposite
(counterclockwise) direction reduces the audio level, and turns
the VP200 off.
Audible/Visual Alert Indicators
When your VP200 is initially turned on, both the red and amber
LEDs on the control panel light and an alert tone is sounded until
the decoder circuit power-up is complete. Thereafter, whenever
a properly encoded message is received, the red LED flashes
and an audio alert is sounded.
X
X
6
STAN ARD FEATURES ANDD
CONTROLS (All Models)

If the battery voltage falls below the level required for reliable
operation, a low battery pulse tones sounds and the red LED
flashes. If the function switch is set to a vibrate position, just
the red LED flashes to indicate a low battery state.
Function Switch
According to the specific model ordered, the function switch will
be configured to 4 positions. Different function modes (monitor/
selective call, scan, etc.) can be configured for any position of
the switch.
Channel Monitoring
When the function switch is set to a monitor position, all voice
communications on the selected channel is heard through the
speaker. When monitoring channel 1 or 2 all ordered alert options
are functional.
X
X
X
X
7
STAN ARD FEATURES ANDD
CONTROLS (All Models)

Reset Button
After receipt of a properly coded message and after completion of
that message, the VP200 will automatically reset to the programmed
operational mode (see Field Installed Options section for reset
options). Some of these reset functions will place the pager in the
monitor more. In these cases, or when the manual reset function
is programmed into the pager, press the reset button to return
your VP200 to the standby mode.
External Speaker Jack
When the VP200 is used in high-noise environments or when
privacy is needed, an optional Gold Apollo approved lapel speaker
or earpiece can be connected to the external accessory jack located
at the bottom of the VP200. The jack is fitted with a protective plug.
NOTE: To prevent entry of dust and moisture, the plug should be
inserted whenever the external accessory jack is not being
used.
X
X
8
STAN ARD FEATURES ANDD
CONTROLS (All Models)
