INSTRUCTION SHEET
PEX
Quick Pinch Clamp Tool
PEX
69PTKG1096
1. Cut PEX tubing square, leaving a clean, even
edge. Remove any burrs.
2. Slip PEX pinch clamp over tubing and insert
fitting. Place pinch clamp 1/8”below edge
of tubing.
3. Place PEX pinch clamp nub between tool
jaws and ratchet the clamp until the PEX
Pinch Clamp Tool auto-releases. This action
will assure that the PEX pinch clamp is fully
engaged.
4. Pressure test the PEX tubing and inspect
before burying or normal use. If there are
any signs of leaks, repeat the total
procedure.
For use with Apollo®, Watts®, Murray®, and Oetiker®PEX cinch clamps.
Do not use with Zurn®Qickclamp™PEX crimp rings.
Apollo® PEX Pinch Clamps
PXPC3810PK 3/8" 10 Pack
PXPC1210PK 1/2" 10 Pack
PXPC1225PK 1/2" 25 Pack
PXPC12100PK 1/2" 100 Pack
PXPC3410PK 3/4" 10 Pack
PXPC3425PK 3/4" 25 Pack
PXPC34100PK 3/4" 100 Pack
PXPC15PK 1" 5 Pack
PXPC110PK 1" 10 Pack

Conbraco Industries, Inc.
Matthews, NC 28105
1.888.229.2874
www.apolloflow.com
is-69PTKG1096_04/06/17
INSTRUCTION SHEET
PEX One Hand Pinch Clamp Fastening Tool
Calibration
PEX
Apollo PEX tools are pre-calibrated for up to 10,000 uses. After repeated use of this tool, it
may require calibration. A calibration gauge and bar is provided with the tool.
69PTKG1096
1
1. Insert the Calibration Bar into the tool as
shown. Ratchet the Pinch Tool to the closed
position (tool jaws should be biting into the
bar).
22. Use the Calibration Tool to gauge the jaw
gap. Ideally, the jaw gap should be between
0.8 mm and 1.2 mm.
If the 1.2 mm side of the gauge slides into
the gap, then the jaw space is too large. If
the 0.8 mm side of the gauge cannnot slide
into the gap, then the jaw space is too
narrow.
3. To adjust the jaw
gap, turn the Pinch
Tool on its side and
locate the locking
screw positioned
on the handle. Use
a standard
screwdriver to
loosen the locking
screw. Locate the
adjustment screw.
Turn the adjustment
screw right or left
as needed to change
the size of the jaw
gap. When adjustment
is complete, tighten the
locking screw.
Locking Screw
Adjustment Screw
3. To adjust the jaw
gap, turn the Pinch
Tool on its back
and locate the
locking screw. Use a
standard screwdriver
to loosen the locking
screw. Turn the tool
over and locate the
adjustment dial. Turn
the adjustment dial
right or left as
needed to change
the size of the jaw
gap. When
adjustment is
complete, tighten the
locking screw.
If you have a side adjustment screw If you have a front adjustment dial
Tool back
Tool front
33
