Aponorm BASIS PLUS BLUETOOTH User manual

Instructions for use
Upper arm BASIS PLUS BLUETOOTH®
Data evaluation via app
using your smartphone
Also suitable for:
Display Arrhythmia
detection
Data e
v
us
i
ng your
Clinically
tested
year
WARRANTY
children
Pregnant
women
Diabetics Kidney
disease

aponorm®Basis Plus Bluetooth®
aponorm®Basis Plus Bluetooth®– Brief instructions
Unlock
START
STOP
Insert the batteries supplied
along with the monitor.
The cuff must come to sit
approx. 3 cm above your arm
bend. Extend your arm so that
the cuff is at the same height
as your heart.
Switch the monitor off. The
measurements are stored
automatically.
Connect the cuff.
Start the measurement by
pressing the Start/Stop
button.
You can lock the monitor by
pushing the switch upwards.
Unlock the monitor by pushing
the key lock on the side down.
Do not talk, move, eat drink or
smoke during the measure-
ment.
Relax for a few minutes
before each measurement.
The blood pressure values
measured appear on the
display.
1
5
9
2
6
10
3
7
4
8
Lock
+–

aponorm®by
aponorm®Basis Plus Bluetooth®
1
12
3
4
5
6 7
8
9
10
11
12
13
14
15
16
17
18
19
20
22
21
23

aponorm®by2
aponorm®Basis Plus Bluetooth®
BF part
Important! This information must be adhered to in order to prevent damage to the device
and error messages being displayed.
Protect from moisture.
Read the instructions carefully
before using this monitor.
Switches, housing and accessories
1Start/Stop button
2Display
3Cuff connector
4Mains adapter connector
5Battery compartment
6Cuff
7Cuff connector
8Time button
9Memory button (M button)
10 “Back” button
11 “Forward” button
12 Lock switch
Display
13 Date/time
14 Systolic value
15 Diastolic value
16 Pulse rate
17 Battery indicator
18 Blood pressure traffic light
19 Stored value
20 Pulse rate measurement active
21 Cuff check indicator
22 Heart arrythmia warning symbol (PAD)
23 Motion alarm

aponorm®Basis Plus Bluetooth®3
Dear Customer,
Your new aponorm®by microlife blood pressure
monitor is a reliable medical device for taking
blood pressure measurements on the upper arm. It
is simple to use, accurate and comes highly recom-
mended for blood pressure monitoring in your
home. This device was developed in collaboration
with physicians and clinical tests were carried out
prove its measurement accuracy to be of a very
high standard.*
Please read through these instructions carefully
so that you understand all functions and safety
information. We want you to be happy with your
aponorm®by microlife product. If you have any
questions, problems or want to order spare parts
please contact the aponorm®by microlife
Customer Service. Your dealer or pharmacy will
be able to give you the address of the aponorm®
by microlife dealer in your country. For more
detailed information on our products please refer
to www.aponorm.de.
Stay healthy – aponorm®by microlife!
* This device uses the same measuring technology as the
award winning “BP 3BTO-A” model tested according to the
British Hypertension Society (BHS) protocol.
aponorm®Basis Plus Bluetooth®

aponorm®by
4
Table of Contents
1. Important Facts on Blood Pressure
and Self-Measurement 5
· How do I evaluate my blood pressure? 6
2. Using the Device for the First Time
· Inserting the batteries 6
· Setting the date and time 6
· Selecting the correct cuff 7
3. Taking a Blood Pressure Measurement
using this Monitor 7
· Not storing a reading 8
4. Heart Arrhythmia Indicator for
Early Detection 8
5. “Traffic Light” Indicator in the Display 9
6. Data Memory 9
· Viewing the stored readings 9
· Memory full 9
· Clearing all readings 10
7. Battery Indicator and Battery Change 10
· Low battery 10
· Flat batteries - replacement 10
· Which batteries and which procedure? 10
· Using rechargeable batteries 10
8. Data Transmission via Bluetooth®/
App Utilisation 11
9. Using a Mains Adapter 11
10. Error Messages 12
11. Safety, Care, Accuracy Test and Disposal 13
· Safety and protection 13
· Device care 13
· Cleaning the cuff 13
· Accuracy test 14
· Disposal 14
12. Warranty 14
13. Technical Data 15
Warranty Card (see back cover)

aponorm®Basis Plus Bluetooth®5
as the day progresses. You should therefore
take your measurements in the same quiet
conditions and when you feel relaxed!
Take at least two measurements per day (one
in the morning and one in the evening).
• It is quite normal for two measurements taken
in quick succession to produce significantly
different results. Therefore we recommend to
use the MAM technology.
• Deviations between measurements taken by
your doctor or in the pharmacy and those taken
at home are quite normal, as these situations
are completely different.
• Several measurements provide much more
reliable information about your blood pressure
than just one single measurement.
• Leave a small break of at least 15 seconds
between two measurements.
• If you suffer from an irregular heartbeat
(arrhythmia, see “Chapter 4.”), measurements
taken with this device should be evaluated with
your doctor.
• The pulse display is not suitable for
checking the frequency of heart pace-
makers!
• If you are pregnant, you should monitor your
blood pressure very closely as it can change
drastically during this time!
1. Important Facts about Blood Pres-
sure and Self-Measurement
• Blood pressure is the pressure of the blood
flowing in the arteries generated by the pump-
ing of the heart. Two values, the systolic
(upper) value and the diastolic (lower) value,
are always measured.
• The monitor also indicates the pulse rate (the
number of times the heart beats in a minute).
• Permanently high blood pressure values
can damage your health and must be
treated by your doctor!
• Always discuss your values with your doctor
and tell him/her if you have noticed anything
unusual or feel unsure. Never rely on the
blood pressure readings alone.
• There are several causes of excessively high
blood pressure values. Your doctor will explain
them in more detail and offer treatment where
appropriate. Besides medication, weight loss
and exercise can also lower your blood pres-
sure.
• Under no circumstances should you alter
the dosages of any drugs prescribed by
your doctor!
• Depending on physical exertion and condition,
blood pressure is subject to wide fluctuations

aponorm®by
6
)This blood pressure monitor is specially test-
ed for use in pregnancy and for preeclampsia.
When you detect unusual high readings in
pregnancy, you should measure again after 4
hours. If the reading is still too high, consult
your doctor or gynaecologist.
How do I evaluate my blood pressure?
Table for classifying home blood pressure values
in adults in accordance with the international
guidelines (ESH, AHA, JSH). Data in mm Hg.
Range Systolic Dias-
tolic
Recommenda-
tion
Blood
pressure
too low
z100 z60 Consult
your doctor!
1. Blood
pressure
optimum
100 - 130 60 - 80 Self-check
2. Blood
pressure
elevated
130 - 135 80 - 85 Self-check
3. Blood
pressure
too high
135 - 160 85 - 100 Seek
medical advice
4. Blood
pressure
far too
high
160 y100 y
Urgently seek
medical advice!
The higher value is the one that determines the
evaluation. Example: a blood pressure value of
140/80 mmHg or a value of 130/90 mm Hg says
“blood pressure too high”.
2. Using the Device for the First Time
Inserting the batteries
First switch the Lock Switch 12 to the “Unlock”
position. Then insert the batteries. The battery
compartment 5is at the bottom of the device.
Insert the batteries (4 x size AAA 1.5 V), observing
the indicated polarity (+/-).
Setting of time and date
1. After the new batteries are fitted, the year
flashes in the display. Set the year by either
pressing “+” 11 or “-” 10 . Press the time button
(NR) for confirmation and for changing to the
month setting mode.
2. Set the month by either pressing “+” 11 or
“-” 10 . Press the time button 8in order to
confirm and then set the date.
3. Follow the instructions above to set the date,
hour and minutes.
4. Once you have set the minutes and pressed the
time button 8, the date and time are set, and
the time is displayed.

aponorm®Basis Plus Bluetooth®7
If you want to change the date and time again,
press and hold the time button down for approx.
3 seconds until the year starts to flash. Now you
can enter the new values as described above.
Selecting the correct cuff
aponorm®by microlife offers different cuff sizes.
Select the cuff size to match the circumference
of your upper arm (measured close fitting in the
centre of the upper arm).
Cuff size for circumference of
upper arm
S 17 - 22 cm
M 22 - 32 cm
M – L 22 - 42 cm
L 32 - 42 cm
L – XL 32 - 52 cm
)Use only aponorm®by microlife cuffs!
`Connect the stuff to the monitor by inserting
the cuff to the device by inserting the cuff
connector 7into the cuff socket 3as far as it
will go.
3. Taking a Blood Pressure Measure-
ment using this Monitor
Check list for taking a reliable measurement
1. Avoid activity, eating or smoking immediately
before the measurement.
2. Sit down for at least 5 minutes before the
measurement and relax.
3. Always measure on the same arm (normally
left) and when seated. It is recommended that
doctors perform double arm measurements on
a patient’s first visit in order to determine which
arm to measure in the future. It is the arm with
the higher blood pressure which should always
be measured.
4. Remove close-fitting garments from the upper
arm. To avoid constriction, shirt sleeves should
not be rolled up. Sleeves do not interfere with
the cuff if they are laid flat.
5. Always ensure that the correct cuff size is used
(marking on the cuff).
· Fit the cuff closely, but not too tight.
· Make sure that the cuff is positioned 2 cm
above the arm bend.
· The artery mark located on the cuff (approx.
3 cm long bar) must lie over the artery which
runs down the inner side of the arm.

aponorm®by
8
Not storing a reading
Press the Start/Stop button 1while the measur-
ing result is displayed. Keep the button pressed
until the M button 19 starts flashing. The release
the button for a short time and confirm by again
shortly pressing the M button. 9
)
You can stop the measurement at any time
by pressing the Start/Stop button 1(e.g. if
you feel uneasy or an unpleasant pressure
sensation).
4. Heart Arrhythmia Indicator for Early
Detection
The appearance of the heart arrhythmia
symbol 22 indicates that certain pulse irregu-
larities were detected during the measurement.
The result may deviate from your normal blood
pressure – repeat the measurement. In most
cases, this is no cause for concern. However, if the
symbol appears on a regular basis (e.g. several
times a week with measurements taken daily) we
advise you to tell your doctor. Please show your
doctor the following explanation:
· Support your arm so it is relaxed.
· Ensure that the cuff is at the same height as
your heart.
6. Switch the Lock Switch 12 to the “Unlock”
position. Press the Start/Stop button 1to start
measuring.
7. The cuff will now pump up automatically.
Relax, do not move and do not tense your
arm muscles until the measurement result is
displayed. Breathe normally and do not talk.
8. When the correct pressure is reached, the
pumping stops and the pressure falls gradually.
If the required pressure was not reached, the
instrument will automatically pump some more
air to the cuff.
9. During the measurement, the heart icon for
pulse measurement 20 is flashing.
10. The result, comprising the systolic 14 and the
diastolic 15 blood pressure and the pulse
rate 16 is displayed. Note also the explana-
tions on further displays in this booklet.
11. When the device has finished measuring,
remove the cuff.
12. Switch off the monitor (the display will switch
off automatically after approx. 1 minute).

aponorm®Basis Plus Bluetooth®9
Information for the doctor on frequent ap-
pearance of the arrhythmia indicator
This device is an oscillometric blood pressure
monitor that also analyses pulse frequency during
measurement. The monitor was subjected to a
clinical study.
The arrhythmia symbol is displayed after the
measurement, if pulse irregularities occur during
measurement. If the symbol appears more fre-
quently (e.g. several times per week on measure-
ments performed daily) we recommend the patient
to seek medical advice, to be on the safe side. This
device does not replace a cardiac examination,
but serves to detect pulse irregularities at an early
stage.
5. “Traffic Light” Indicator in the
Display
The bars on the left-hand edge of the traffic light
display 18 show you the range within which your
blood pressure value lies. Depending on the height
of the bar, the readout value is either within the
optimum (green), elevated (yellow), too high (or-
ange) or dangerously high (red) range. The classi-
fication corresponds to the classification ranges in
the table as defined by the international guidelines
(ESH, AHA, JSH), as described in “Chapter 1”.
6. Data Memory
This device automatically stores up to 99 measure-
ment values.
Viewing the stored values
Press the M-button 9briefly, when the device
is switched on. The display shows “M” 19 and
an average value of all values stored, which is
indicated by “A” in the top right corner of the
display. Clicking on the “-” 10 will take you to the
last stored measured value.
Pressing the “+” 11 or the “-” 10 button repeat-
edly enables you to move from one stored value
to another. Press the M-button again to exit the
memory mode.
Memory full
Please note that the maximum memory
capacity is 99 values. When the 99 value
memory is full, the oldest value is au-
tomatically overwritten with the 100th
value. Values should be evaluated by a doc-
tor before the memory capacity is reached
– otherwise data will be lost.

aponorm®by
10
Clearing all values
If you are sure that you want to permanently
remove all stored values, hold down the
M button 9until “CL” appears and then release
the button. To permanently clear the memory,
again press the M button while “CL” is flashing.
)Stopping the deletion of values: Press the
Start/Stop button 1while “CL” is flashing.
)
It is not possible to clear individual readings.
7. Battery Indicator and Battery
Change
Low battery
When the batteries are approximately ¾ empty the
battery indicator 17 will flash as soon as the de-
vice is switched on (partly filled battery displayed).
Although the monitor will continue to measure
reliably, you should obtain replacement batteries
within short.
Flat batteries – battery replacement
When the batteries are flat, the battery
indicator 17 (flat battery) will flash as soon as
the monitor is switched on. You cannot take
any further measurements and must replace the
batteries.
1. Open the battery compartment 5at the bottom
of the monitor.
2. Replace the batteries – ensure correct polarity
as shown by the symbols in the compartment.
3. To again set date and time, follow the proce-
dure described in “Chapter 2”.
)
The memory retains all values although date
and time must be reset.
Which batteries and which procedure?
)Use 4 new, long-life alkaline, 1.5V, size AAA
batteries.
)Do not use batteries beyond their date of
expiry.
)Remove batteries if the device is not going to
be used for a prolonged period.
Using rechargeable batteries
You can also operate this device using recharge-
able batteries.
)Only use “NiMH” type reusable batteries.
)Batteries must be removed and recharged
when the flat battery symbol appears.
They must not remain inside the instrument,
as they may become damaged (total dis-
charge as a result of low use of the instru-
ment, even when switched off).

aponorm®Basis Plus Bluetooth®11
)Always remove the rechargeable batteries if
you do not intend to use the device for a week
or more.
)Batteries CANNOT be charged IN the blood
pressure monitor.
)Recharge batteries in an external charger and
observe the information regarding charging,
care and durability.
8. Data Transmission via Bluetooth®/
App Application
You can transfer the measured data stored on this
device to a mobile device (Android or iPhone) so
that you have them accessible at any time or e.g.
have them handy for a visit to the doctor’s.
The prerequisite to this is the installation of an
app to your smartphone.
Please load the most current and detailed app and
for data synchronisation with this blood pressure
monitor down from the download area of
www.aponorm.de.
9. Using a Mains Adapter
You can operate this device using the aponorm®
by microlife mains adapter (DC 6V, 600mA).
)Use only the aponorm®by microlife mains
adapter available as an original accessory
appropriate for your supply voltage.
)Ensure that neither the mains adapter nor the
cable are damaged.
1. Plug the adapter cable into the mains connec-
tor 4in the blood pressure monitor.
2. Plug the adapter plug into the wall socket.
When the mains adapter is connected, no battery
current is consumed.

aponorm®by
12
10. Error Messages
If an error occurs during the measurement, the
measurement is interrupted and an error message,
e.g. “ERR 3” is displayed.
Error Desig-
nation
Potential cause
and remedy
“ERR 1” Signal
too weak
The pulse signals on the
cuff are too weak. Re-
position the cuff and
repeat the measurement.*
“ERR 2”
13
Error
signal
During the measurement,
error signals were de-
tected by the cuff, caused
for instance by movement
or muscle tension. Repeat
the measurement, not
moving your arm.
“ERR 3”
10
No pres-
sure
in the cuff
An adequate pressure
cannot be generated in
the cuff. A leak may have
occurred. Check that the
cuff is correctly connect-
ed an is not too loose.
Replace the batteries if
necessary. Repeat the
measurement.
Error Designa-
tion
Potential cause
and remedy
“ERR 5" Abnormal
result
The measuring signals
are inaccurate and no
result can therefore be
displayed. Read through
the check list for perform-
ing reliable measurements
and then repeat the
measurement.*
“HI”
Pulse or
cuff pres-
sure too
high
The pressure in the cuff
is too high (over 300
mmHg) OR the pulse is too
high (over 200 beats per
minute). Relax for
5 minutes and repeat the
measurement.*
“LO” Pulse too
low
The pulse rate is too
low (less than 40 beats
per minute). Repeat the
measurement.*
* Please consult your doctor, if this or any other
problem occurs repeatedly.
)If you think the results are unusual, please
read through the information in “Chapter 1”
carefully.

aponorm®Basis Plus Bluetooth®13
11. Safety, Care, Accuracy Test and
Disposal
Safety and protection
• This monitor may not be used for purposes
other than those described in these instruc-
tions. The manufacturer cannot be held liable
for damage caused by incorrect application.
• This blood pressure monitor contains sensitive
components and must be handled carefully.
Observe the storage and operating conditions
described in the “Technical Data” chapter!
• Protect the monitor from:
`water and moisture
`extreme temperatures
`impact and falls
`dirt and dust
`direct sunlight
`heat and cold
• The cuff is rather delicate and must be handled
carefully.
• Do not use any other type of cuff or cuff connec-
tor for measuring with this device.
• Inflate the cuff only when fitted to your arm.
• The function of this monitor can be impaired
by strong electromagnetic fields as emitted by
mobile telephones or radio installations. We
recommend
observing a minimum distance of
3.3 metres. If you cannot maintain the minimum
distance please check the proper function of
the device before use.
• Do not use the monitor if you think it is dam-
aged or notice anything unusual.
• Never open the monitor.
• If the device is not going to be used for a pro-
longed period the batteries should be removed.
• Please observe the additional safety informa-
tion in the different chapters of these instruc-
tions.
Do not let unsupervised children use the
monitor. Some of the components are so
small that children can swallow them or
choke on them. Beware of the risk of stran-
gulations in case this monitor is fitted with
cables or tubes.
Device care
Only clean the monitor with a soft and dry cloth.
Cleaning the cuff
Carefully remove spots on the cuff with a damp
cloth and soapsuds.
WARNING: Do not wash the cuff in a wash-
ing machine or dishwasher!

aponorm®by
14
Accuracy test
We recommend this device is tested for accuracy
every 2 years or after mechanical impact (e.g.
being dropped). Please contact the aponorm®by
microlife service (see foreword).
Disposal
Batteries and electronic devices must be
disposed of in accordance with the locally
applicable regulations, not with domestic
waste.
12. Warranty
We are convinced of the high quality of our
aponorm®blood pressure monitors. Therefore we,
WEPA Apothekenbedarf GmbH & Co. KG, grant
end customers who are consumers, a voluntary
5 year warranty for all aponorm®blood pressure
monitors purchased in Germany, subject to the
proviso below:
1. Subject matter and scope of the warranty
The warranty applies to any aponorm®blood
pressure monitor which the customer purchased in
Germany as a consumer. WEPA Apothekenbedarf
GmbH & Co. KG warrants the customer that the
product is free of material and manufacturing
defects. If despite proper handling of the product
a defect occurs within the 5 year warranty period,
WEPA Apothekenbedarf GmbH & Co. KG will re-
pair the product free of charge (with the exception
of the transport cost for returning the monitor) or
will replace it at WEPA’s discretion.
2. Exclusion of warranty
No claims under this warranty can be raised in the
event of damage caused by customer’s own fault
or third-party fault, e.g. fall, accident or improper
handling. The same applies to defects resulting
from leaking batteries or failure to observe the
instructions. Warranty by WEPA Apothekenbedarf
GmbH & Co. KG is also excluded if a defect/dam-
age is due to improper repair or other interference
by a third party.
The warranty does not cover wear parts, accesso-
ries (e.g. pouches, cables, etc.), batteries and the
cuff coming with the monitor.
We grant a function warranty (air tightness of the
bladder) of 2 years.
3. Warranty period
The warranty applies for a period of five years
from the date of purchase (warranty period). The
decisive date is the date of the sales receipt or of
the warranty card filled in by the dealer indicating
the date of purchase.

aponorm®Basis Plus Bluetooth®15
The warranty period is not extended due to
services provided under this warranty, in particu-
lar not in the event of repair or exchange of the
product. In these cases, the warranty does not
start anew, either.
4. Assertion of claims
The customer can assert the rights under this war-
ranty by presenting the defective product and the
sales receipt or the warranty card filled in by the
dealer within the warranty period directly to WEPA
Apothekenbedarf GmbH & Co. KG or to the dealer
where they purchased the product.
In the event of a warranty case, WEPA Apotheken-
bedarf GmbH & Co. KG will repair the product
free of charge (with the exception of the transport
cost for returning the monitor) or fully replace it at
WEPA’s discretion.
If the check yields that the damage does not come
under the warranty, the product can be repaired by
WEPA Apothekenbedarf GmbH & Co. KG at cus-
tomer’s expense. In this case WEPA Apotheken-
bedarf GmbH & Co. KG informs the customer of
the estimated cost in a quotation before even
starting the repair. In this case the customer is free
to order the repair of the product at customer’s
expense or request the return of the damaged/
unrepaired product.
5. Further rights of customer
WEPA Apothekenbedarf GmbH & Co. KG grants
the warranty subject to the conditions stipulated.
The customer may, in addition, have further legal
rights. This warranty does not affect the custo-
mer’s contractual and legal rights, in particular
the legal warranty rights vis-à-vis the seller of the
product.
The law of the Federal Republic of Germany ap-
plies to this warranty. Date: 07/2016
13. Technical Data
Operating 10 - 40 °C / 50 - 104 °F
conditions: 15 to 95% relative maxi-
mum air humidity
Storage
conditions: -20 to +55 °C /
-4 to +131 °F 15 to 95%
relative maximum air
humidity
Weight: 354 g (including batteries)
Dimensions: 160 x 82 x 32 mm
Measuring
method: oscillometric, validated
by the Korotkoff method:
phase I systolic, phase V
diastolic

aponorm®by
16
Measuring range: 20 - 280 mmHg – blood
pressure 40 - 200 beats per
minute – pulse
Display range
cuff pressure: 0 - 299 mmHg
Measuring
resolution: 1 mmHg
Static
accuracy: pressure within ± 3 mmHg
Pulse accuracy: ± 5 % of the readout value
Voltage source: • 4 x 1.5 V alkaline
batteries, size AAA
• Mains adapter 6V DC,
600 mA (optional)
Battery approx. 400 measurements
life: (with new batteries)
IP class: IP 20
Reference to
Standards: EN 1060-1 /-3 /-4;
IEC 60601-1-2; (EMC);
IEC 60601-1-11
Average Monitor: 5 years or
life: 10,000 measurements
Accessories: 2 years
This device complies with the requirements of the
Medical Device Directive 93/42/EEC.
Technical alterations reserved.
The Bluetooth name mark description are reg-
istered trademarks in the property of Bluetooth
SIG, Inc. and any use of these marks owned by
Microlife Corp. and subject to a licence. Any other
trademarks and trade names are the property of
their owners.

aponorm®Basis Plus Bluetooth®
aponorm®Basis Plus Bluetooth®– Warranty Card
Customer name
Serial number
of monitor (SN)
Date of purchase
Pharmacy stamp and signature

Warranty pass
To be on the safe side: our aponorm®by microlife warranty.
Your new blood pressure monitor is a top-class precision medical device.
We are convinced of its high quality and therefore, from the date of purchase, we grant a
Please refer to page 14 of the instructions for the terms of warranty in detail.
5
year
WARRANTY
Tip:
In case you lost the instructions for use with the
terms of warranty during your period of use of
the device, you can at any time download them
at www.aponorm.de.
