APPA A17 Technical manual

Leakage Current Card
A17 Instruction
Warning
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . .
Safety
. . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . .
. . . . . . . . .
 Read First
-Avoid working alone so assistance can
be rendered.
- Do not use test leads or the Tester if
they look damaged.
- Do not use the Tester if the Tester is
not operating properly or if it is wet.
- Use the Tester only as specified in the
Instruction card or the protection by
the Tester might be impaired.
- Use extreme caution when working
around bare conductors or bus bar.
Contact with the conductor could result
in electric shock.
Symbols as marked on the Tester
and Instruction card
 Safety Information
To ensure safe operation and service of
the Tester, follow these instructions.
Failure to observe warnings can result in
severe injury or death.
Risk of electric shock
See instruction card
DC measurement
Equipment protected by double or
reinforced insulation
Low battery
Earth
AC measurement
Conforms to EU directives
FApplication around and removal
from hazardous live conductors is
permitted
Do not discard this product or
throw away
Power On / Off
•The Meter displays Battery Capacity
when powering up. Please replace the
battery when 0% is shown.
Auto Power Off Enable /
Disable
Auto Backlight
 Caution
If the meter is used in the vicinity of equip-
ment which generates electromagnetic
interference, the display may become
unstable or the measurements show may
be subject to large errors.
ACA
Leakage Current Measurement
Clamp Meter
Auto Hold Enable / Disable
 Caution
Take sufficient care to not to apply shock,
vibration or excessive force to the jaw tips.

Data Hold
Data Hold Beep Guard
The internal sounder will beep continuously
with the LCD display flashing in the Data
Hold mode when the measured signal is
larger 50 counts than the LCD reading.
Peak Hold
(forcing into the manual range mode)
Low Pass Filter
(forcing into the manual range mode)
•The Cut-Off frequency of the low pass
filter is about 100Hz with attenuation
characteristic of approx. –24dB/octave.
Auto Range / Manual Range
Comparator
•The Meter offers 3 limit values (0.25mA,
0.5mA and 3.5mA) in accordance with
safety standards. (EN 60950-1)
•The internal sounder will beep continu-
ously with the LCD display flashing
when measured value exceeds the
confirmed limit value.
Auto Power Off

Battery Replacement
Auto Hold
1-3 Electrical Specifications
Accuracy is ±(% reading + number
of digits) at 23°C ±5°C < 80%RH.
The specifications of 50 ~ 100A is not
Specified.
Current
ⅠThe circuits not connected to mains.
ⅡThe circuits directly connected to
Low-voltage installation.
ⅢThe building installation.
ⅣThe source of the Low-voltage
installation.
Range Resolution Accuracy
6mA * 0.001mA
60mA 0.01mA
600mA 0.1mA
6A 0.001A
60A 0.01A
100A 0.1A
0 ~ 50A
1% + 3D (50 ~ 60Hz)
50 ~ 60A
5% + 6D (50 ~ 60Hz)
60 ~ 100A
8% + 6D (50 ~ 60Hz)
* There is a little rolling within ±3 digits.
Frequency Response (61~400Hz) :
2%+6D(0~30A), 30%+6D(30~100A)
Influence of external magnetic field of
adjacent wires : 0.04% typical value.
Low Pass Filter
Range Resolution Accuracy
6mA * 0.001mA
60mA 0.01mA
600mA 0.1mA
6A 0.001A
60A 0.01A
100A 0.1A
0 ~ 50A
2% + 6D (50 ~ 60Hz)
50 ~ 60A
6% + 8D (50 ~ 60Hz)
60 ~ 100A
9% + 8D (50 ~ 60Hz)
* There is a little rolling within ±3 digits.
Attenuation characteristic:
approx. –24dB/oct
Cut-off frequency : 100Hz
Maintenance
Do not attempt to repair this Tester.
It contains no user-serviceable parts.
Repair or serving should only be
performed by qualified personnel.
Cleaning
Periodically wipe the case with a dry
cloth and detergent do not use
abrasives or solvents.
Specifications
1-1 General Specifications
LCD display digits :
6000 digit large scale LCD readout.
Measuring rate : 5 times / sec.
Overrange display :
Shows the real value for “100A” and
shows “OL” for other ranges.
Automatic power off time :
Approximately 20 minutes after power on
without operations.
Low battery indicator : is displayed.
CAT Application field Limited Warranty
This Meter is warranted to the original
purchaser against defects in material
and workmanship for 2 years from the
date of purchase. During this warranty
period, manufacturer will, at its option,
replace or repair the defective unit,
subject to verification of the defect or
malfunction. This warranty does not
cover disposable batteries, or damage
from abuse, neglect, accident, unauthor-
ized repair, alteration, contamination, or
abnormal conditions of operation or
handling.
Any implied warranties arising out of
the sale of this product, including but
not limited to implied warranties of
merchantability and fitness for a
particular purpose, are limited to the
above. The manufacturer shall not be
liable for loss of use of the instrument
or other incidental or consequential
damages, expenses, or economic loss,
or for any claim or claims for such
damage, expense or economic loss.
Some states or countries laws vary, so
the above limitations or exclusions may
not apply to you.
APPA TECHNOLOGY CORP.
9F, 119-1 Pao-Zong Rd.,
Shin-Tien, Taipei, 23115, Taiwan.
P.O.Box. 12-24 Shin-Tien, Taiwan.
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
http: //www.appatech.com
Replace the battery when the indicator
appears in the display.
Power requirement : 1.5Vx2 batteries.
Battery type and life :
ALKALINE 60 hours.
1-2 Environmental Conditions
Indoor Use.
Pollution degree : 2
Calibration : One year calibration cycle.
Operating temperature :
0°C ~ 30°C (≦80% RH)
30°C ~ 40°C (≦75% RH)
40°C ~ 50°C (≦45%RH)
Storage temperature : -20 to +60°C,
0 to 80% RH (batteries not fitted).
Operating altitude : 2000m (6562 ft)
Conductor Size : 40mm diameter.
Shock vibration :
No shock, No vibration to the jaw tips.
Temperature coefficient :
0.2 x (Specified accuracy) / °C, < 18°C,
> 28°C .
EMC : EN 61326-1
Overvoltage category :
IEC 61010-1 300V CAT.Ⅲ
