APsystems QS1-EU User manual

2018/06/06 Rev1.1 Quick Installation Guide
1
QS1-EU Microinverter Quick Installation Guide
The sketch of QS1 support system.
All the PV modules are placed into two lines. Then put a QS1 in the middle of the two lines and make
sure it is easy to connect with four PV modules which are next to it, as well all the cables.
Step 1. Verify the grid voltage to match with microinverter rating
Step 2. The AC bus distribution
a. The AC bus is arranged at the proper position of the microinverter.
b. One end of the AC bus access junction box into power grid.
c. Wire the conductors of the AC bus: L - BROWN; N - BLUE.
NOTE: Wiring colour code can be different according local regulation, check all the wires of the
installation before connecting to the AC bus to be sure they match.Wrong cabling can damage
irreparably the microinverters, such an issue is not covered by the warranty.
Step 3. Attach the APsystems Microinverters to the racking
NOTE: Do not place the microinverters (including DC and AC connectors) where exposed to the
sun, rain or snow, even gap between modules. Allow a minimum of 3/4’’(1.5cm.) between the roof
and the bottom of the microinverter to allow proper air flow.The racking of install microinverter
must be reliably grounding.
d. Mark the location of the microinverter on the rack, with respect to the PV module
junction box or any other obstructions.
e. Mount one microinverter at each of these locations using hardware recommended
by your module racking vendor.when install microinverter, grounding washer
Must be facing the racking.
Step 4. Ground the system.
Step 5. Connect the APsystems Microinverter to AC bus cable
Push the microinverter AC connector to the trunk cable connector. Listen for the "Click".
Please scan the QR code to get
mobile app and more support
to help the installation.
Click
Power grid
Best Practice: Use the Bus
Cable Unlock Tool of AC
Bus to split the connectors.
grounding washer

2018/06/06 Rev1.1 Quick Installation Guide
2
NOTE: AC connector interface as follows.
Step 6. Install a Bus Cable End Cap at the end of AC bus cable.
a. Strip cable jacket. c. Insert the wires into the cable clamps.
b. Insert the cable end into the seal. d. Rotate the nut with 3.3N·m until the
latching mechanism meets the base.
Step 7. Place the PV modules and connect each QS1 to the PV modules
Step 8. Complete the APsystems installation map
a. Each APsystems Microinverter has removable serial number labels.
b. Peel labels off, affix one to the respective location on the APsystems installation map,and fill
in 1,2 in the label below,according to the layout on the roof..
c. The other one serial number label, posted on the solar module frame is easy to view the
position.
d. After the completion of installation drawings sent to APsystems website.
www.APsystems.com.
NOTE: Sequence of steps 1~8 can change for convenience of installation.
NOTE: Using APsystems' mobile app ArrayApp can make the installation and registration much
more simple.
Step 9. Start the operation
1. Turn on the AC circuit breaker on each microinverter AC branch circuit.
2. Turn on the main utility-grid AC circuit breaker. Your system will start producing.
power after a two-minute waiting time.
Product information is subject to change without notice.(Please download manuals at www.APsystems.com).
Nut
Seal
Body
NOTE: Cover any unused connectors with Bus
Cable Y-CONN Cap to protect the connectors.
NOTE: If the DC connector is not connected with the PV module,you
need to remove the dust cap,and cover the protection cap.
N
