Product Manual
LIGHT BOX 30120
English
Foreword
Thank you for purchasing Aputure Light Box 30120.
Light box 30120 is designed for LS 120d II,LS 300d II,LS 300X,
LS 600d Pro,Amaran 60,Amaran 100 and Amaran 200 series and
compatible with other Bowens Mount LED video light.
Check list
When you unbox the product, please make sure all the items listed
below are included. Otherwise, please contact the seller immediately.
According to the diagonal installation method, insert the four
support rods, then lock the chuck, and fit the velcro on the softbox,
then install the softbox on the lamp.
Use Velcro to install the Fabric Light Control Grid on the diffuser.
Trademarks
Bowens is a trademark registered by Bowens in China and other
countries.
Disassembly: Pull out four steel rods diagonally and in the opposite
direction
Speed Ring Adapter (1pc)
Installations
When using this unit, basic safety precautions should always be
followed, including the following:
4. Care must be taken when touching, installing or disassembling
the elastic support rod.
5. Let the fixture cool completely before storing.
6. To reduce the risk of injury, please install or disassemble the fixture
properly.
7. The use of an accessory attachment not recommended by the
manufacturer may increase the risk of fire, electric shock, or injury
to any persons operating the fixture.
8. Please do not place the fixture near any liquids or other
flammable objects.
9. Only use a dry microfiber cloth to clean the product.
10. This product is certified by RoHS. Please operate the product
in full compliance with the operation standards.
Please note that this warranty does not apply to repairs arising
from malfunctions, although you may request such repairs on a
chargeable basis.
IMPORTANT SAFETY INSTRUCTIONS
1. Read and understand all instructions before using.
2. Close supervision is necessary when any fixture is used by or
near children. Do not leave the fixture unattended while in use.
3. Care must be taken as burns can occur from touching hot surfaces.
11. The instructions and information in this manual are based on
thorough, controlled company testing procedures. Further notice
will not be given if the design or specifications change.
SAVE THESE INSTRUCTIONS
30*120 Square softbox (1pc)
Inside Fabric Diffusion
(1pc) (1pc 1.5 Stop Diffusion,
1pc 2.5 Stop Diffusion)
Front Fabric Diffusion
Fabric Light Control Grid
（1pc）
Light Box 30120 Carrying Bag
(1pc)
Detailed product manual can be found on www.aputure.com.
Specifications
Item Dimension Net Weight
1086g
120*30*40cm/47.24*11.81*15.75in
67.8*10*3cm/26.69*3.94*1.18in
120*30cm/47.24*11.81in
120*30cm/47.24*11.81in
120*30cm/47.24*11.81in
Standard Bowens Mount
softbox(built)
softbox(Collapsed)
Front Fabric Diffuser 1(1.5 stop)
Front Fabric Diffuser 2(2.5 stop)
65.5*20cm/25.8*7.9in
Inside Fabric Diffusion
Fabric Light Control Grid
Speed Ring Adapter
Aputure Imaging Industries Co., Ltd.
Add: F/3, Building 21, Longjun industrial estate,
HePing West Road, Shenzhen, Guangdong
Sales Contact: (86)0755-83285569-613
Aputure Imaging Industries Co., Ltd. warrants the original consumer purchaser
from defects in material and workmanship for a period of one (1) year after the
date of purchase. For more details of warranty visit www.aputure.com
Serial No.
Item Name
Purchase Date
Buyer Name
Buyer Phone
Buyer Add
Franchiser Seal
Add: F/3, Building 21, Longjun Industrial Estate, Heping West Road, Shenzhen, Guangdong
Aputure Imaging Industries Co.,Ltd.
Inspection: Qualified
