Aputure Light torm LS 600c Pro User manual

Product Manual
English
LS 600c Pro

When using this unit, basic safety precautions should always be followed, including the
following:
1. Read and understand all instructions before using.
2. Close supervision is necessary when any fixture is used by or near children. Do not leave
the fixture unattended while in use.
3. Care must be taken as burns can occur from touching hot surfaces.
4. Do not operate the fixture if a cord is damaged, or if the fixture has been dropped or
damaged, until it has been examined by qualified service personnel.
5. Position any power cables such that they will not be tripped over, pulled, or put into
contact with hot surfaces.
6. If an extension cord is necessary, a cord with an amperage rating at least equal to that of
the fixture should be used. Cords rated for less amperage than the fixture may overheat.
7. Always unplug the lighting fixture from the electrical outlet before cleaning and servicing,
or when not in use. Never yank the cord to remove the plug from the outlet.
8. Let the lighting fixture cool completely before storing. Unplug the power cable from
lighting fixture before storing and store the cable at assigned space of the carrying case.
9. To reduce the risk of electric shock, do not immerse this fixture in water or any other
liquids.
10. To reduce the risk of fire or electric shock, do not disassemble this fixture. Contact
[email protected] or take the lighting fixture to qualified service personnel when service
or repair is required. Incorrect reassembly may cause electric shock when the lighting
fixture is in use.
11. The use of any accessory attachment not recommended by the manufacturer may increase
the risk of fire, electric shock, or injury to any persons operating the fixture.
12. Please power this fixture by connecting it to a grounded outlet.
13. Please remove the protective cover before use.
14. Please remove the protection cover before using the reflector.
15. Please do not block the ventilation or donot look at the LED light
source directly when it is powered on. Please do not touch the
LED light source in any condition.
-1-
Introduction
Thank you for purchasing the Aputure® "Light Storm" series RGBWW COB light - LS 600c
Pro. LS 600c Pro is a high power full color light source with Fully Tunable CCT from
2,300K to 10,000K, supporting CCT, HSI, XY, RGB, GEL, SOURCE light mode, and
professional control with Sidus Link, DMX512/RDM, Lumenradio CRMX, Ethernet. The LS
600c Pro brings you a more comprehensive and professional lighting solution with
intelligent power supply and cinematic control, granting you true creative freedom.
CAUTION
DO NOT TOUCH LED
Light Source Surface
IMPORTANT SAFETY INSTRUCTIONS

-2-
FCC Compliance Statement
SAVE THESE INSTRUCTIONS
16. Please do not place the LED lighting fixture near any flammable object.
17. Only use a dry microfiber cloth to clean the product.
18. Please do not use the light fixture in wet condition on account of electric shock may be
caused.
19. Please have the product checked by an authorized service personnel agent if the product
has a problem. Any malfunctions caused by unauthorized disassembly are not covered
by the warranty. The user may pay for maintenance.
20. We recommend only using the original Aputure cable accessories. Please note that any
malfunctions casued by using unauthorized accessories are not covered by the warranty.
The user may pay for maintenance.
21. When hanging the product overhead, always ensure an extra safety measure has been
attached - such as a safety chain- that is certified for the weight of the product.
22. This product is certified by RoHS, CE, KC, PSE, and FCC. Please operate the product
in full compliance with relevant country's standards. Any malfunctions caused by incorrect
use are not covered by warranty. The user may pay for maintenance.
23. The instructions and information in this manual are based on thorough, controlled
company testing procedures. Further notice will not be given if the design or specifications
change.
WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try
reorient or relocate the receiving antenna.

-3-
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a different circuit than the receiver is connected
to.
Consult the dealer or an experienced radio/TV technician for help.
This device has been evaluated to meet general RF exposure requirements.
RF Warning Statement:

-4-
The illustrations in the manual are only diagrams for reference. Due to the continuous
development of new versions of the product, if there are any differences between the
product and the user manual diagrams, please refer to the product itself.
LS 600c Pro
Lamp Head (1pc)
LS 600c Pro
Control Box (1 pc)
Lightning Clamp
(1 pc)
LS 600c Pro Rolling
Carrying Case (1 pc)
Paracord
Strap(1 pc)
LS 600 Series 7-Pin Weatherproof
Head Cable (7.5m)(1 pc)
Neutrik® powerCON AC
Power Cable (6m) (1 pc)
600 Series
Hyper Reflector (1 pc)
Protection
Cover (1 pc)
Components List
Please make sure all accessories listed below are found before using. If not, contact your
seller immediately.

-5-
Product Details
1. Lamp Head
Bowens Mount
600 Series
Hyper Reflector
600W RGBWW COB chipset
Ratcheting Disk
Brake Handle
Bowens Mount
Release button
7-Pin Male Weatherproof
Head Cable Connector
Junior/Baby Pin Mount
(1.125in/28mm | 5/8in./16mm)
Cable Relief Hook
T-Handle / Baby Pin Mounting Screw
2. Control Box
Paracord Strap Plate
LCD Display
Menu Button
Preset Button
Light Mode Button
Back Button
Select Wheel
Power Button
Antenna Box
Battery Plate
(*Anton Bauer or
V-mount)
USB Port
Floor Stand
Lightning Clamp
Quick-Release Plate
EtherCON RJ45

-6-
DMX IN
Port
DMX OUT
Port
Neutrik®
powerCON
AC Input
7-Pin Female Head Cable Connector
48V DC Input
(3-Pin XLR)
Setting Up the Light
1. Attaching/detaching the Protection Cover
Press the release button following the arrow and rotate the cover clockwise to detach
the cover. To reattach the cover, insert it into the Bowens mount and rotate counter-
clockwise.
2. Attaching/detaching the Bowens Mount Hyper Reflector
(LS 600 Series)
To install the reflector, press the release button, insert the reflector into the Bowens mount,
and rotate it counterclockwise as shown in the following pictures. To remove the reflector,
pull back the release button and rotate the reflector clockwise.
WARNING
Always remove the protection cover prior to turning on the light. Always re-install
the cover when packing it away.
Top Bottom

-7-
1
2
1
2
3. Setting Up the Lamp Head
If using a 5/8in / 16mm stand (Baby Pin), then mount the Lamp Head onto the stand,
and fix it in place using the T-Handle/Mounting Screw on the Baby Pin Receiver.
If using a 1.125in / 28mm stand (Junior Pin), then mount the Lamp Head into the Junior
Pin receiver, and fix it in place using the T-Handle on the stand. Loosen or tighten the
handbrake locking mechanism on the yoke to adjust the fixture's angle of tilt.
4. Lightning Clamp Operation Instructions
1) Clamp the Lightning Clamp onto a light stand.
2) To attach the control box, rotate the release lever to unlock the quick-release plate, then
mount the control box onto the Lightning Clamp (the release lever will spring back).
3) To remove the control box, grasp it firmly, then unlock the quick-release plate by turning
the release lever, and detach the control box.

-8-
1
2
AC 100V-240V
~ ~
5. Connecting the Lamp Head to the Control Box
Connect the Lamp Head to the control box using the 7-pin Weatherproof Connecting
Cable.
* Hang the cable using the rope to manage
and reduce tension on the cable.
* Disconnect the Head Cable by pulling up the collar on the connector. This will disengage its locking
mechanism. Do not pull directly.
1) Powering by AC
6. Powering Up the Control Box
*To disconnect the Neutrik® powerCon cable, pull back on the silver release tab on the cable connector,
and rotate the connector counter clockwise. Do not pull directly.

-9-
2) Powering by DC
* You can choose V-Mount or Anton Bauer Battery as required.
V-Mount Battery Anton Bauer Battery
7. Charging Batteries Using the Control Box
You can charge batteries via built-in Battery Plates, the maximum intensity that the light
can operate at while charging batteries are as follows:
Exponential(Exp) or Linear: ≤70%
Logarithmic(Log): ≤30%
S-Curve: ≤55%
DC Supply
48V-15A
3pin XLR
~ ~
3) Powering by DC Supply

-10-
L
S
i
l
e
n
t
CCT
100%
0
%
2000K
G/
M-1
G/
M+1
10000K
-0.05
G/M
：
：
CCT
6200K
：
INT
60%
1. Turning the Light On and Off
2. Manual Control
Operations
Intensity
Correlated Color
temperature
Green/Magenta
adjustment
There are three buttons on the control box for manual control of the light: MENU, LIGHT
MODE, and PRESET.
Press the MENU button to enter the System Menu interface. In the System Menu you'll
find Output Mode / DMX Mode / Custom FX /Dimming Curves / Fan Mode / Studio
Mode / Control System / Language / Frequency Selection / Product Information /
Update / Factory Reset / Battery Power Option
2.1 MENU
Default Control Screen (CCT Mode)
System Menu Control Screen
2.1.1) Output Mode
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to enter the Output Mode.
Constant Output: maintain the brightness output during the process of changing the
color temperature.
DMX Mode
MENU

* The fade-out time decreases as the percentage of brightness decreases. When the Intensity
output is 100%, the fade-out time is 60 seconds, which decreases in sequence.
* If the signal is reconnected, the DMX console will continue to maintain the signal output as s
ame as before.
-11-
Output Mode
Constant Output
Maximum Output
DMX Mode
DMX Address
DMX Loss Behavior
DMX Profile
DMX Termination
Max Output: perform at the maximum possible output throughout the CCT range.
2.1.2) DMX Mode
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to enter the DMX mode.
DMX address: LS 600c Pro will set to in DMX Address interface. Press and hold the MENU
for 2 seconds to lock the DMX Address. In the locked state, cannot enter
other interfaces, Press and hold SELECT for 2 seconds to unlock.
DMX Loss Behavior: rotate the select wheel to choose Black out /fade to Black /Hold last
setting/ Hold 2 min& fade Out.
① Hold last setting -After DMX signal is lost, remember the last control setting.
②Black out -when the DMX signal is lost, it will be Black out.
③Fade to Black -after DMX signal is lost, it will fade to Black in 60 seconds.
④Hold 2 min& Fade Out -After the DMX signal is lost, keep the last control setting for two
minutes, and then Fade to Black within 60 seconds.
DMX Profile : Rotate the Select wheel, and short press to select a desired 8-bit/16-bit DMX
Profile. DMX Termination: toggle Auto-termination on or off.
2.1.3) Custom FX
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to enter the Custom FX.

-12-
Custom FX
Picker FX
Music FX
Dimming Curve
Linear
Exp
S-curve
Log
2.1.4) Dimming Curves
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to enter the Dimming Curves. Rotate and short press the wheel to choose
between exponential (Exp) or logarithmic (Log), linear and S-Curve dimming curves.
2.1.5) Fan Mode
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to enter the Fan Mode. rotate and short press the wheel to choose between
Smart, High, Medium and Silent fan mode.
Fan Mode
Silent
High
Medium
Smart
Change the fan speed with
temperature changes.
* Silent: deactivate all fans. Limits output to 60W max.
* When overheat symbol appears on the light control interface, please follow the text underneath to adjust the
Fan Mode to Smart or High. If the internal temperature of the lamp reaches the threshold that needs to be
cooled, the lamp will automatically shut down due to overheat protection.
You can choose to enter Picker FX or Music FX.
Each type can save up to 10 custom FXs. "NO FX" refers to unsaved FX, and "Untitled"
refers to saved FX.

-13-
Bluetooth
Number：FF3BEB
Bluetooth
ON
Bluetooth Reset
Bluetooth Reset
NO
YES
2.1.6) Studio Mode
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to enter the Studio Mode. When the studio mode is turned on (ON), the lamp can
be turned on directly, when the studio mode is turned off (OFF), you need to press the
power button to turn on the lamp.
2.1.7) Control System
LS 600c Pro has three remote control methods: Bluetooth, LumenRadio CRMX and
Ethernet. Only one control mode can be used at one time.
2.1.7.2) CRMX
Rotate the select wheel and short press to enter the Lumenradio CRMX, When CRMX
Status is “ON”, it will continuously search for a pairable signal in the background to
connect. “Unpair” will disconnect the currently established connection so that other
signal transmitters can be paired.
2.1.7.1) Bluetooth
Rotate the select wheel and short press to enter the Bluetooth mode. When Bluetooth
is “ON”, the serial number is displayed below, after executing Bluetooth Reset, your
mobile phone or tablet will be able to connect to and control the light with Sidus Link
App.
Studio Mode

-14-
Ethernet
Manual Set IP
Language
简体中文
English
2.1.7.3) Ethernet
Rotate the select wheel and short press to enter the Ethernet mode. You can set
the IP manually in Manual Set IP interface or obtain IP aromatically in Automatic
Obtain IP interface.
2.1.8) Language
Press the MENU button to enter the menu interface, rotate the select wheel and
short press to enter the Language settings. rotate and short press the wheel to
choose English or Simplified Chinese.
2.1.9) Frequency Selection
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to enter the Frequency Selection. Rotate the select wheel to adjust he light
frequency by 100Hz every turn.
CRMX
CRMX Status
Unpair
ON

-15-
Update
Update Firmware
Firmware Version
Product Information
Hardware Version
UID: 6LY00X1000X
2.1.10) Product Information
Press the MENU button to enter the menu interface, rotate the select wheel and
short press to enter Product Information, you can view the Hardware Version
and UID of the product.
2.1.11) Update
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to Update. You can update the firmware in the Update Firmware interface,
and view the Firmware Version. Firmware update can also be done via Sidus Link
app using OTA (Over the Air Technology).
2.1.12) Factory Reset
Press the MENU button to enter the menu interface, rotate the select wheel and
short press to Factory Reset.
Frequency Selection
+
2000

2.2 Accessing Lighting Modes
-16-
NO
YES
Factory Reset
Battery Power Option
Wake up Batteries
Full Battery Power
Press the LIGHT MODE button on the control box to enter the mode: CCT, HSI, RGB,
XY, RGB, Source, and GEL.
2.1.13) Battery Power Option
Press the MENU button to enter the menu interface, rotate the select wheel and short
press to Battery Power Option.
Wake Up Battery: When you need to activate the lithium battery from overdischarge
protection. Select the lithium battery specification 14.4V/26V and enter the Wake
Up Batteries interface, confirm Activate to output 3A current in order to activate
the lithium battery; After activation, check whether the lithium battery has a voltage
output. If so, the activation is successful, otherwise the activation fails.
Full power output: a single lithium battery meets 360W continuous output (14.4V
lithium battery maximum output current 30A, 26V lithium battery maximum output
current 15A), two lithium batteries can meet the input power requirement of 720W,
and the lamp can achieve 100% illumination Output.
The factory settings list :
Light mode: Intensity 50%, CCT 5600K;
Language: English
Fan Mode: Smart
Dimming Curve: Linear
Studio Mode: OFF
Control System: Bluetooth
DMX: Address 001, Hold Last Settings, DMX Termination OFF

-17-
L
S
i
l
e
n
t
CCT
100%
0
%
2000K
G/
M-1
G/
M+1
10000K
-0.05
G/M
：
：
CCT
6200K
：
INT
60%
Fire
1 °
0%
2.2.2) Advanced HSI
Press the LIGHT MODE button to enter the light mode interface, rotate the select wheel
and short press to Adv. HSI . You can adjust Intensity (0-100%), Hue(1-360°)，Saturation
(0-100%), and Correlated Color Temperature (2300K - 10000K).
2.2.3) FX
Press the LIGHT MODE button to enter the light mode interface, rotate the select wheel
and short press to FX.
You can choose 16 light preset effects: Fire, Strobe, Explosion, Faulty Bulb, Pulsing,
Welding, Cop Car, Color Chase, Party Lights, Firework, Club Lights, Paparazzi,
Lightning, TV and Candle.
Each preset has multiple parameters that can be changed to customize the effects.
2.2.1} CCT
Press the LIGHT MODE button to enter the light mode interface, rotate the select wheel
and short press to CCT. You can adjust Intensity (0-100%), Correlated Color Temperature
(2300K - 10000K), and Green/ Magenta adjustment (-1.0 to +1.0).

-18-
L
S
i
l
e
n
t
RGB
：
INT
60%
100%
0%
0%
：
R
：
G
：
B
100%
0
%
L
S
i
l
e
n
t
X Y
100%
0
%
X
0.4865
：
Y
0.3895
：
：
INT
60%
L
S
i
l
e
n
t
Source
X :
0.4260
Y :
0.4005
Tungsten
Incandescent
Halogen
Antique Bulb
Bulb
INT
：
100%
100%
0
%
2.2.4) RGB
Press the LIGHT MODE button to enter the light mode interface, rotate the select wheel
and short press to RGB. You can adjust Intensity (0-100%) and Red/Green/Blue values
(0-100%).
2.2.5) XY
Press the LIGHT MODE button to enter the light mode interface, rotate the select wheel
and short press to XY. You can adjust Intensity (0-100%) and X/Y coordinates
(0.0000 – 0.8000).
2.2.6) Source
Press the LIGHT MODE button to enter the light mode interface, rotate the select wheel
and short press to Source. You can choose 46 preset light source effects.

-19-
Connecting DMX to an LS 600c Pro
Daisy chaining multiple lights
using DMX
DMX512
OUTPUT
DMX512
L
S
i
l
e
n
t
GEL
R
186
Silver Rose
187
Rouge
188
Peach
189
Peach
189
Peach
DMX2-3
DMX4-5
DMX6-7
DMX8-9
DMX10-11
Col.Corr
Cal.Filter
600 Series
Cosmetic
700 Series
DMX0-1
3200K
5600K
100%
0
%
184
Peach
INT
：
100%
L
CCT
RGB
INT
HUE
SAT
R
G
B
GEL
INT
3200 / L
184
X Y
X
Y
1
2
3
4
5
INT
CCT
G/M
66%
5300K
0.2
80%
60°
0%
255
166
43
80%
0.3127
0.3290
Adv.
HSI
2.2.7) GEL
Press the LIGHT MODE button to enter the light mode interface, rotate the select wheel
and short press to GEl. You can set 3200K or 5600K as the light color temperature , and
select the Rosco or LEE Gel Lighting Filter paper.
2.3) Light Preset
Press the PRESET button on the control box to enter the light preset mode, you can save
10 light preset effects.
Rotating and short press the select wheel to save/replace the preset effect in CCT, Adv.
HSI, RGB, XY, Source, GEL mode. You can open/delete previously saved to the preset
mode in any mode.
3. Connecting to DMX
3.1) Connecting a standard DMX controller
