Aputure Light Box 45x45 User manual

LIGHT BOX 4545
Softbox
Product Manual
English

󾙓
Foreword
Thank you for purchasing Aputure product.
When using this unit, basic safety precautions should always be
followed, including the following:
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
1. Read and understand all instructions before using.
2. Close supervision is necessary when any xture is used by or
near children. Do not leave the xture unattended while in use.
3. Care must be taken as burns can occur from touching hot surfaces.
4. Care must be taken when touching, installing or disassembling
the elastic support rod.
5. Let the lighting xture cool down completely before storing.
6. To reduce the risk of injury, please install or disassemble the
product in methods not specied in this manual.
7. The use of an accessory attachment not recommended by the
manufacturer may increase the risk of re, electric shock, or injury
to any persons operating the xture.
8. Please do not place the xture near any liquids or other ammable
objects.
9. Only use a dry microber cloth to clean the product.
10. This product is certied by RoHS. Please operate the product
in full compliance with the operation standards. Please note that
this warranty does not apply to repairs arising from malfunctions,
although you may request such repairs on a chargeable basis.
11. The instructions and information in this manual are based on
thorough, controlled company testing procedures. Further notice
will not be given if the design or specications change.
Aputure Light Box 45x45 is a new square softbox from Aputure.
It is designed for compact LED lights with full size Bowens Mount
such as amaran COB 60/100/200 series lights, to create a soft,
natural lighting on the go.

Softbox (1 pc) Speed Ring Adapter (1 pc)
󾙖󾙗Fabric Light
Control Grid（1 pc）
Carrying Bag（1 pc）
Front Fabric Diusion
（1.5 stop 1 pc, 2.5 stop 1 pc）
󾙔
Components List
When you unbox the product, please make sure all the items listed
below are included. Otherwise, please contact the seller immediately.
*The illustrations in the manual are only diagrams for reference. Due to the
continuous development of new versions of the product, if there are any
dierences between the product and the user manual diagrams, please refer
to the product itself.

󾙕
Installation
1. Insert the four rods of the softbox into the speed ring adapter,
making sure to align the position of each rod with one of the
red markers. For easier setup, insert the rods in alternating order.
2. Make sure the locking screw is tightened. Attach either of the
front diusions to the softbox using the hook and loop fabric,
depending on the required softness.
3. Close the gaps towards the rear of the softbox using hook and
loop fabric aps.
4. To mount the Light Box, insert the Speed Ring Adapter into the
Bowens Mount of the lighting xture and rotate counterclockwise
to lock it into position.
Optional: attach the included light control grid using hook and loop
fabric onto the softbox to control the spread of the light.

* These are average data measured in the laboratory, there will be slight
dierences in the brightness, color temperature and other parameters
of dierent lights.
󾙖
Specications
Trademarks
Bowens is a trademark registered by Bowens in China and other
countries.
* amaran COB 60 shown as reference. Also compatible with: amaran COB 100
/ 200 series lights, Aputure LS 60 series lights (with included Bowens Mount
Adapter), and Aputure LS 300 series lights.
Dimensions
Light
Control Grid
Speed Ring Adapter Standard Bowens Mount
Net Weight 680g
Softbox (Built) 450 x 450 x 300mm /
17.7 x 17.7 x 11.8in
480 x 260 x 50mm /
18.9 x 10.2 x 2in
420 x 420mm /
16.5 x 16.5in
420 x 420mm /
16.5 x 16.5in
45°
420 x 420mm /
16.5 x 16.5in
Softbox (Collapsed)
Front Diusion (1.5
Stops)
Front Diusion (2.5
Stops)
Beam Angle
Dimension
