APW Wyott CSC-3 User manual

Phone: +1
Fax: [phone]
Toll Free: [phone]
Website: www.apwwyott.com
E-mail: [email protected]
[phone]
INSTALLATION AND OPERATING INSTRUCTIONS
INTENDED FOR OTHER THAN HOUSEHOLD USE
P/N 88803/88804/88946/88947/88952 9/05
1
APW WYOTT
P.O. Box 1829
Cheyenne, WY 82003
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment.
!!
R
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
ModelNumber SerialNumber DatePurchased
REFRIGERATED & ICE COOLED
CONDIMENT DISPENSERS
Counter Top Models:
CSDR-3
CSDR-4
CSDC-3
CSDC-4
CSC-3
CSC-4
Standing Models:
FCSR-4
FCSR-8
FCSC-4
FCSC-8

1
2
3
4
5
REFRIGERATED
DROP-IN
CONDIMENT DISPENSER
ICE COOLED
COUNTER TOP
CONDIMENT DISPENSER
PARTS LIST W/EXPLODED VIEW
1 Top Plate 2332 2344
2 Container 24081 24981
3 Thermostat with Knob 14873 14873
ITEM DESCRIPTION FCSR-4
CSDR-3
P/N
FCSC-4
CSDR-4
P/N
4 Cord Set 2845 2845
5 Condensing Unit 18034 18034
(Compressor Assy.)
31
2
1. Preassemble part 1 and 2 as shown above.
2. Assemble petcock drain assembly into unit through 3/4" hole as shown above. (For best
results, pipe thread compound shouldbe usedon all threads.)
3. Thread 4 adjustable feet (part 3) into unit bottom. Adjust feet by turning hex foot to attain
desiredheight.
ASSEMBLY INSTRUCTIONS
MODELS: CSC-3 & CSC-4
ICE COOLED COUNTER TOP CONDIMENT DISPENSER

3
