Aqara Water Leak Sensor User manual

Water Leak Sensor

English
Water Leak Sensor
Quick Start Guide
Aqara Water Leak Sensor detects water leak and ooding and
monitors the status of water leak. When the water leak or
ooding occurs, it sends an instant alert notication via app. It
also works with other smart
*
*
A hub is required.
Aqara Hub is required to enable Aqara Water Leak Sensor to work with
HomeKit technology. See www.aqara.com for more details.
* This product is for indoor use only.
Inductive ProbeIndicator Light
Reset Button
Long Press for 5s: Reset/Connect to Network
Single Press: Eective Range Test
accessories to automate your home.
Product Introduction

English
1. Before activating the accessory, please make sure you have
the Aqara Home app downloaded and Aqara hub installed.
2. Please open the app, tap“Home”and then tap“+” in the top
right corner to enter“Add Device (Accessory)” page. Select
“Water Leak Sensor”, and add it according to
* If the connection fails, please move the accessory closer to the Hub
* Avoid metal surface to maximize signal strength.
Quick Setup
Installation
Option 1: Place it directly on the surface where you need
instructions.
and try again.
to monitor water leak.
Eective Range Test: Single press the reset button on the
accessory at your desired position. If the Hub makes voice
prompts, it indicates that the accessory can communicate
eectively with the Hub.

English
Battery Replacement
Option 2: Use a hex screwdriver to loosen the probes, and
* The antenna is right above the water drop icon.
connect to cables for more smart scenes.
* In order to ensure the dustproof and waterproof performance of the
product, the back cover of the battery must be tightened before use, and
the groove is at the same level as the probe.
1. Insert a coin into the groove of the battery cover and turn
it counterclockwise to open the battery cover;
2. Put a new CR2032 button battery into the battery
compartment, and pay attention to making the side with
the"+" sign face out;
3. Close and tighten the battery cover, and ensure that the
groove of the battery cover is aligned with the metal
probes on both sides in a straight line;

English
Model: SJCGQ11LM
Dimensions: 50 × 50 × 15 mm (1.97 × 1.97 × 0.59 in.)
Wireless Protocol: Zigbee
Battery: CR2032
Operating Temperature: -10° – +55°C (14° – 131°F)
Operating Humidity: 0 – 100% RH
Maximum Transmit Power (Zigbee): 9.99dBm
Working Frequency: 2400 MHz – 2483.5 MHz
Specications
Online Customer Service: www.aqara.com/support
Email: [email protected]
Manufacturer: Lumi United Technology Co., Ltd.
Address: 8th Floor, JinQi Wisdom Valley, No.1 Tangling Road,
Liuxian Ave,Taoyuan Residential District, Nanshan
District, Shenzhen, China.
Tightened in place Not yet tightened in place

English
FCC ID: 2AKIT-SJCGQ11LM
Federal Communications Commission (FCC) compliance
statement:
1. This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
This product is NOT a toy. Please keep children away from
this product.
This product is designed for indoor use only. Do NOT use in
outdoors.
Do NOT place this product near a heat source. Do NOT
place it in an enclosure unless there is normal ventilation.
Do NOT attempt to repair this product by yourself. All
repairs should be performed by an authorized professional.
This product is only suitable for improving the
entertainment, convenience of your home life and
reminding you about the device status. If a user violates
the product use instructions, the manufacturer will NOT be
liable for any risks and property losses.
1.
2.
3.
4.
5.
Warnings

English
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
(2) this device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:

English
-Consult the dealer or an experienced radio/TV technician for help.
RF Exposure statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance of 20 cm between
the radiator and your body. This transmitter must not be co-located
or operating in conjunction with any other antenna or transmitter.
IC: 22635-SJCGQ11LM
IC NOTICE TO CANADIAN USERS
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES‐003.
This device complies with RSS‐247 of Industry Canada. Operation
is subject to the condition that this device does not cause harmful
interference.

English
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be
installed and operated with minimum distance of 20 cm between
the radiator and your body. This transmitter must not be co-located
or operating in conjunction with any other antenna or transmitter.
L'émetteur/récepteur exempt de licence contenu dans le présent
appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes :
(1) L'appareil ne doit pas produire de brouillage;
(2) L'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Cet appareil numérique de la Classe B conforme à la norme
NMB‐003 du Canada.
Cet appareil est conforme à la norme RSS ‐247 d'Industrie Canada.
Le fonctionnement est soumis à la condition que cet appareil ne
provoque pas d'interférences nuisibles.
Cet équipement est conforme aux limites d’exposition aux
rayonnements de la IC établies pour unenvironnement non contrôé.
Cet équipement doit être installé et fonctionner à au

English
moins 20cm de distance d’un radiateur ou de votre corps.Cet
émetteur ne doit pas être co-localisé ou fonctionner en
conjonction avec une autre antenne ou un autre émetteur.
CAUTION
Risk of explosion if the battery is replaced by an incorrect
type.
Dispose of used batteries according to the instructions.
Do not ingest battery, Chemical Burn Hazard.
This product contains a coin / button cell battery. If the coin / button
cell battery is swallowed, it can cause severe internal burns in just 2
hours and can lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the
product and keep it away from children.
If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
1. The equipment is only suitable for mounting at heights ≤ 2 m
2. Disposal of a battery into re or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion
Leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of
ammable liquid or gas
A battery subjected to extremely low air pressure that may result in an
explosion or the leakage of ammable liquid or gas

English
Hereby, [Lumi United Technology Co., Ltd.] declares that
the radio equipment type [Water Leak Sensor,
SJCGQ11LM] is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address:
http://www.aqara.com/DoC/
All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU)
which should not be mixed with unsorted household
waste. Instead, you should protect human health and the
environment by handing over your waste equipment to a
designated collection point for the recycling of waste electrical and
electronic equipment, appointed by the government or local
authorities. Correct disposal and recycling will help prevent
potential negative consequences to the environment and human
health. Please contact the installer or local authorities for more
information about the location as well as terms and conditions of
such collection points.
Symbol on the product or on its packaging indicates
that this product may not be treated as household
waste. Instead it shall be handed over to the
applicable collection point for the recycling of
electrical and electronic equipment.

Aqara水浸感测器是一款可檢測漏水和浸水的設備，能夠監
測無水到有水、有水到退水兩種狀態。當發生漏水或浸水
時，可透過app即時推送報警訊息，並能夠透過閘道器設備
聯動控制其他智慧硬體產品。
水浸感測器快速入門指南
產品介紹
* 本產品需要配合具備閘道器功能的設備使用;
* 欲使本產品相容於HomeKit，需要配備Aqara閘道器，如需更多詳情，
請登入：www.aqara.com;
* 本產品僅限室內使用。
感測探頭指示燈
面殼重設鍵
長按5s：重設/入網
繁體中文
：通訊有效距離驗證按一下

繁體中文
2、開啟app，點選首頁右上角的「+」，進入「加入設備
（配件）」頁面，選擇水浸感測器，並依照提示進行操作。
有效距離驗證：在預選的安裝位置，按一下設備重設鍵，閘
道器發出提示音，表明設備與閘道器之間可以有效通訊。
快速設定
1、
* 如加入失敗，請將設備移近閘道器後重試。
安裝方法
* 為了確保無線通訊穩定，須避免安裝在金屬表面。
方式一：直接放置在所需監測的平面上。
方式二：用內六角螺絲刀將感測探頭擰松，接上導線後，
可應用於更多場景。
連接設備前，請確保已下載Aqara Home app並添加了閘
道器。

繁體中文
* 感測器天線的位置在「水滴」圖示的上方。
1.使用硬幣插入電池蓋凹槽，逆時針方向旋轉打開電池蓋。
2.將一枚新的CR2032類型鈕扣電池放入電池倉，注意電、
池“+”標誌一面朝外。
3.蓋上並擰緊電池蓋，確保電池蓋凹槽與兩側金屬探針對、
齊成一條直線。
更換電池
*為保證產品的防塵防水性能，使用前需保證電池蓋擰緊，凹槽與探頭
處於同一水平線。
擰緊到位 尚未擰緊到位

網站支援：www.aqara.com/support
售後電子信箱：[email protected]
製造商：深圳綠米聯創科技有限公司
地址：廣東省深圳市南山區留仙大道塘嶺路1號金騏智
谷大廈8樓
產品型號：SJCGQ11LM
產品尺寸：50×50×15公釐（1.97×1.97×0.59英吋）
無線連接：Zigbee
電池型號：CR2032
工作溫度：-10℃~+55℃ (14℉~131℉)
工作濕度：0~100% RH
發射功率（Zigbee）：9.9dBm
工作頻率：2400MHz～2483.5MHz
基本參數
繁體中文

繁體中文
本產品非玩具，請讓兒童遠離本產品。
本產品僅限室內使用，請勿在室外使用。
請勿將本產品置放於靠近熱源的地方。除非有正常的通
風，否則不可放在密閉位置中。
請不要嘗試自行維修本產品，應由授權的專業人士進行
此項工作。
本產品僅適用於提升家居生活娛樂性、便捷度，以及用
於設備狀態提醒，如有用戶違反產品使用說明及本注意
事項，製造商對因此造成的任何風險和財產損失不承擔
責任。
1、
2、
3、
4、
5、
使用注意事項

繁體中文
Deutsch
Wasserlecksensor –
Schnellstartanleitung
Produktübersicht
Der Aqara-Wasserlecksensor entdeckt Wasseraustritt und
Überschwemmungen und überwacht den Zustand des
Wasseraustritts.Wenn ein Wasseraustritt oder eine
Überschwemmung auftritt, sendet er sofort eine
Alarmmeldung per App. Er kann auch mit anderem
* Ein hub ist erforderlich.
* Damit dieses Gerät mit der HomeKit-Technologie zusammenarbeiten
Induktive Sonde
Anzeigelampe
Rücksetztaste
Langer Tastendruck 5 Sek: Netzwerk zurücksetzen/Verbinden
Einmal drücken: Test der wirksamen Reichweite
intelligenten Zubehör zusammenarbeiten, um Ihr Haus zu
automatisieren.
kann, ist ein Aqara-Hub erforderlich. Weitere Einzelheiten siehe
www.aqara.com.
* Dieses Gerät ist nur für Verwendung in Innenräumen bestimmt.

2. Bitte önen Sie die App, tippen Sie auf„Home“ (Haus) und
dann auf„+“ in der oberen rechten Ecke, um die Seite„Add
Device (Accessory)“ (Gerät hinzufügen (Zubehör))
aufzurufen. Tippen Sie auf„Water Leak Sensor“
(Wasserlecksensor) und fügen Sie ihn gemäß
an den Hub und versuchen Sie es erneut.
Schnelleinrichtung
Test der wirksamen Reichweite: Drücken Sie einmal die
Rücksetztaste des Zubehörgeräts an dessen gewünschtem
Standort. Wenn der Hub Töne von sich gibt, bedeutet dies,
dass das Zubehör mit dem Hub
* Vermeiden Sie die Nähe von Metalloberächen, um die Signalstärke
Montage
Deutsch
der Anleitung hinzu.
1. Bevor Sie das Zubehör aktivieren, stellen Sie bitte sicher,
dass Sie die Aqara Home App heruntergeladen und den
Aqara hub installiert haben.
* Wenn die Verbindung fehlschlägt, geben Sie bitte das Zubehör näher
korrekt kommunizieren kann.
zu maximieren.

Deutsch
Option 2: Um bei der Erstellung Ihrer Szenarien noch exibler
zu sein, lösen Sie die Fühler mit einem
Sechskant-Schraubendreher und schließen Sie sie
per Kabel an.
* Die Antenne bendet sich gleich über dem Wassertropfen-Symbol.
Option 1: Legen Sie ihn direkt auf die Oberäche, die Sie
auf Wasseraustritt überwachen möchten.
* Um die staub- und wasserdichte Leistung des Produkts zu gewährleisten,
muss die hintere Abdeckung der Batterie vor dem Gebrauch festgezogen
werden, und sich die Rille auf der gleichen Höhe wie die Sonde benden.
