Aqua Guard 59725 Series User manual

323800-015 10/10
OWNER'S MANUALO MANUEL DUPROPRIÉTAIREO MANUAL DEL USUARIO
© 2010
59725-XXXX, 59726-XXXX and 59727-XXXX
877.278.2797 fax [phone]
D.E. FILTER FORPOOLS& SPAS
FILTRES T.D. POUR PISCINES ET SPAS
FILTRO DED.E. PARA PISCINAS Y
TINAS DEHIDROMASAJE
Certified to
NSF/ANSI Standard 50
®
AQUAGUARDPOOLSYSTEMS.COM

AQUAGUARDPOOLSYSTEMS.COM
2
Operating Instructions and Parts List
Table of Contents
Description ......................2
Unpacking .......................2
General Safety Information ......2 - 3
Pool / Spa Chemistry ...............3
Specifications..................4 - 5
Installation Procedures .............6
Equipment Inspection ...........6
Equipment Location .............6
Plumbing ......................6
Electrical ......................6
Assembly ......................6
New Pool / Spa Installations .......6
Initial Start-Up....................7
Filter Disassembly .................8
Cartridge Cleaning ................8
Filter Assembly ...................9
System Inspection . . . . . . . . . . . . . . . . .9
Winterizing ......................9
Troubleshooting Guide............10
Replacement Parts ...............11
Warranty .......................12
Description
This pool filter is designed to
use diatomaceous earth (D.E.) to
remove debris and particulates from
permanently installed swimming pools
and spas. D.E. is a form of sedimentary
rock that contains fossilized remains of
one-celled algae called diatoms. When
ground into a powder and applied to a
filter element, D.E. makes an excellent
filter media by trapping debris in the
microscopic holes in the fossils. After
it becomes clogged with debris, the
spent D.E. can easily be washed away
so a new, fresh coat can be applied.
This filter is equipped with a cartridge-
style filter element that can be easily
removed for cleaning or replacement.
Unpacking
Inspect this unit before it is used.
Occasionally, products are damaged
during shipment. If the filter or
components are damaged, return
the unit to the place of purchase for
replacement. Failure to do so could
result in serious injury or death.
READ & FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DO NOT DISCARD
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
Danger indicates an
imminently
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Warning indicates a
potentially
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
Caution indicates a
potentially
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
Notice indicates
important
information, that if not followed, may
cause damage to equipment.
NOTE:Information that requires special
attention.
General Safety
Information
CALIFORNIA PROPOSITION 65
This product
may contain
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
GENERAL SAFETY
Read all manuals included
with this product carefully.
Be thoroughly familiar with
the controls and the proper
use of the equipment.
This filter
operates
under high pressure.
Incorrectly installed or
serviced equipment could
explode, causing severe injury, death,
and/or property damage.
t )BWFBUSBJOFEQPPMQSPGFTTJPOBM
perform all pressure tests.
t %POPUDPOOFDUUIFGJMUFSUP
compressed air under any
circumstances.
t 6TFGJMUFSPOMZJOBQPPMPSTQB
installation.
t %POPUDPOOFDUGJMUFSUPDJUZXBUFS
or any other external source of
pressurized water.
t %POPUDPOOFDUGJMUFSUPQVNQT
capable of exceeding 50 psi (345 kPa)
pressure.
t %POPUTVCKFDUGJMUFSUPQSFTTVSFJO
excess of 50 psi (345 kPa), even when
conducting hydrostatic pressure
tests. Pressures exceeding 50 psi
can cause the tank to rupture and
could result in severe injury, death or
property damage.
t "JSUSBQQFEJOUIFTZTUFNDBODBVTF
an explosion. Open the air relief
valve to vent all air from the system
before operating or testing the
system.
Do not use solvents
to clean the filter
assembly as they may damage the
plastic components.
Wear
rubber
gloves, protective clothing
and eyewear when using
acids and cleaners. Avoid
contact with skin and eyes.
If ingested, call local poison
control center. Observe all
warnings and precautions
supplied with acids and
cleaners.
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
MANUAL
© 2010
323800-015

AQUAGUARDPOOLSYSTEMS.COM
3
59725-XXXX, 59726-XXXX and 59727-XXXX
General Safety
Information (Continued)
Risk of
electrical
shock or electrocution.
t 1PTJUJPOUIFGJMUFSESBJO
and air relief valve to
safely direct drainage and purged
air or water away from the pump
and other electrical components.
Water discharged from an
improperly positioned assembly can
create an electrical hazard that can
cause serious injury, death, and/or
property damage.
t &OTVSFGJMUFSHSPVOEJOHBOECPOEJOH
meets local codes and National
Electrical Code (NEC) standards. All
wiring, grounding, and bonding
of associated equipment must be
performed by a qualified electrician.
Installations must be in accordance
with local and national codes.
Risk of falling
and drowning.
t 1MBDFFRVJQNFOUBUMFBTUGFFU
meters) from pool (or spa) so that
children cannot climb over it into
pool.
t %POPUTUBOEPSQMBZPOQPPM
equipment.
t /FWFSMFBWFGJMUFSPQFOBOE
unattended. Secure area where filter
is installed.
t ,FFQDIJMESFOBXBZGSPNQPPM
equipment, especially when
servicing.
This filter is
designed to remove
debris and particulates from pool and
spa water. Proper water chemistry MUST
be maintained to keep water clean and
avoid spreading diseases. Consult a local
pool professional for more information.
This filter is not
designed for
backwashing. If unit is plumbed
backwards or backwashed, it will
damage the filter cartridge and will
void the warranty.
Attention Installer:
This manual contains important
information about the installation,
operation and safe use of this filter. This
information should be furnished to the
end user of this equipment.
Attention User:
SAVE THESE INSTRUCTIONS.
Pool / Spa Chemistry
Maintaining water chemistry
at the correct levels is critical
for health of pool / spa users
and will help prolong the
life of pool / spa equipment.
This chart contains the
recommended levels for a
typical pool / spa. If you have
questions about maintaining
your pool / spa and its
chemistry, consult your local
APSP / NSPI pool professional
or call 877-278-2797 to talk
to a representative.
INDUSTRY
STANDARD POOL / SPA MINIMUM
IDEAL WATER
CHEMISTRY MAXIMUM
Free Chlorine,
ppm
Pool 1.0 2.0 - 4.0 5.0
Spa 2.0 3.0 - 5.0 10.0
Total Bromine,
ppm Pool / Spa 2.0 4.0 - 6.0 10.0
pH Pool / Spa 7.2 7.4 - 7.6 7.8
Total Alkalinity,
ppm Pool / Spa 60 80 - 100*
100 - 120** 180
Calcium
Hardness, ppm
as CaCO
3
Pool 150 200 - 400 1000
Spa 100 150 - 250 800
Cyanuric Acid,
ppm Pool / Spa 0 30 - 50 ***
* For Calcium Hypochlorite, Lithium Hypochlorite, or Sodium Hypochlorite
** For Sodium Dichlor, Trichlor, Chlorite gas, BCDMH (Bromine Tablets).
*** Dictated by state or local codes. Typically 100 ppm.
NOTE: PPM = parts per million
TABLE 1

AQUAGUARDPOOLSYSTEMS.COM
4
Operating Instructions and Parts List
www.aquaprosystems.com
Table 2: Model Specific Specifications
Model Number 59725-XXXX 59726-XXXX 59727-XXXX
Filter Area Sq. Ft. (m
2
) 36 (3.3) 48 (4.5) 60 (5.6)
Maximum Flow Rate* GPM (LPM)
[Gal Turnover 6hr/8hr]
72 (273)
[26,000/35,000]
96 (363)
[35,000/46,000]
120 (454)
[43,000/58,000]
Weight of D.E. Precoat Lbs. (kg) 3.5 (1.6) 4.5 (2.0) 5.5 (2.5)
Minimum Service Clearance** “A” inches (mm) 38-1/4 (972) 45-1/2 (1156) 45-1/2 (1156)
Filter Height “B” inches (mm) 26-5/8 (676) 34 (864) 34 (864)
* Note: Maximum Flow rate = 2.0 GPM /Sq Ft. of filter area. Actual system flow will depend on plumbing size, length, operating
pressure, bends, and other system components.
** Note: Min. Service Clearance is the height required to remove the filter cartridge from the tank base for service. The height required
to just remove the top assembly is less than this height.
Specifications
COMMON SPECIFICATIONS
Maximum Operating
Pressure: ...........50 psi (345 kPa)
Maximum Continuous Water
Temperature: .........104° F (40° C)
Relief valve
Pressure gauge
Locking ring
Safety latch
Outlet: 2 inch NPT
Inlet: 2 inch NPT
Drain: 2 inch NPT
3-1/8 inch
12-1/4 inch DIA.
6-7/32 inch
8-5/16 inch
A
B
16 -7/8 inch
Figure 1 - Filter Dimensions

AQUAGUARDPOOLSYSTEMS.COM
5
www.aquaprosystems.com
Specifications
(Continued)
Figure 2 - Piping Connections
Union Coupling
Filter
Pump
Union
Coupling
To Pool
From Pool
Outlet
Inlet
Union Coupling
Figure 3 - Filter Pressure Loss Curve
59725-XXXX, 59726-XXXX and 59727-XXXX

AQUAGUARDPOOLSYSTEMS.COM
6
Operating Instructions and Parts List
www.aquaprosystems.com
Installation Procedures
This filter should only be installed
by qualified personnel.
EQUIPMENT INSPECTION
Carefully inspect equipment before
installing. Occasionally, products are
damaged in transit. Any damaged
filter components can cause failure and
should be replaced immediately.
EQUIPMENT LOCATION
t .PVOUUIFGJMUFSPOBMFWFMDPODSFUF
slab. The base of this filter has
four mounting holes to provide
for secure anchoring to the slab,
(mounting screws are not included).
t 1SPWJEFBNJOJNVNPGJODIFTPG
clearance around the filter from
walls or structure to permit visual
inspection of the unit.
t 1SPWJEFTVGGJDJFOUDMFBSBODFBCPWF
the filter to remove the filter top
assembly for servicing and cleaning.
The amount of clearance varies by
model. Refer to Table 2 on page 4
for the required clearance.
t *OTUBMMFMFDUSJDBMDPOUSPMTBUMFBTU
feet from the filter.
t -PDBUFFRVJQNFOUPVUPGEJSFDU
sunlight to prolong the life of the
equipment.
t 1PTJUJPOUIFGJMUFSTPUIBUQJQJOH
connections, control valves, drain
and safety latch are accessible
for servicing and winterizing. If
necessary, the safety latch can be
moved to the opposite side of filter
tank to provide easier access (See
Figure 4).
Do not operate the
filter without the
safety latch in place. Doing so could
result in the locking ring loosening from
the filter tank, causing system failure.
PLUMBING
Ensure filter and all
piping can be
drained for winterizing.
Over-tightening
fittings can crack
filter ports.
Do not use pipe
thread compounds
to seal connections. They will damage
the housing material, causing the
connection to crack and leak. Only use
thread sealant tape, (or equivalent
sealant that is designed for plastics) on
threaded connections to filter ports.
t 1JQJOHNVTUDPOGPSNUPMPDBMTUBUF
plumbing and building codes.
t 4VQQPSUQJQFJOEFQFOEFOUMZUP
prevent strains on the filter.
t 'PSFBTFPGNBJOUFOBODFJOTUBMM
union couplings near inlet and
outlet ports.
t 7BMWFTJOTUBMMFEOFBSCPUIJOMFUBOE
outlet of filter will isolate the filter
and ease servicing.
t *OTUBMMIFBUFSEPXOTUSFBNPGGJMUFS
Install check valve between filter
and heater to prevent hot water
from backing up into filter if heater
does not incorporate one. Damage
to filter modules caused by excessive
heat will void the warranty.
t "DIFDLWBMWFJOTUBMMFECFGPSFUIF
filter inlet will prevent contaminants
from draining back into the pool.
t "WBMWFBOEQJQJOHJOTUBMMFEPOUIF
drain port will help divert water
away from the equipment area
when servicing the filter.
t *GTZTUFNJTFRVJQQFEXJUIBOJOMJOF
chlorinator or chlorine generating
system, install the filter upstream
of these items. Install a check
valve between the filter and the
chlorinator to prevent highly
chlorinated water from entering the
filter.
ELECTRICAL
Ensure filter grounding and bonding
meets local and national codes.
ASSEMBLY
This filter is pre-assembled at the
factory. The only assembly required at
installation is the installation of the
pressure gauge and placement of the
safety latch.
Pressure Gauge
Use thread sealant tape to seal the
threads of the gauge. Install the
pressure gauge in the 1/4 inch NPT
port in the top of the filter (marked
"Pressure Gauge").
The pressure gauge
is the primary
indicator of filter performance. Maintain
the pressure gauge in good working
order. If the gauge is damaged, replace
it immediately.
Safety Latch
If necessary, the safety latch can be
moved to the opposite side of the filter
tank to provide easier access (See
Figure 4).
Air Bleed Tube
When installing the cartridge in the
filter base, ensure the tube is inserted
in the center portion of the cartridge
support, if equipped (See Figure 5). This
will help to ensure the tube is correctly
positioned inside the top support ring of
the filter housing.
NEW POOL/SPA INSTALLATIONS
t 5IPSPVHIMZDMFBOBOFXQPPMCFGPSF
filling pool and operating filter.
t "UZQJDBMQPPMJOTUBMMBUJPOSFRVJSFT
approximately one week of
operation to obtain final clarity.
t "GUFSJOJUJBMDMFBOVQGPMMPXUIF
instructions in the "Cartridge
Cleaning" section of this owner's
manual (Page 8).
Figure 4 - Safety Latch installation

AQUAGUARDPOOLSYSTEMS.COM
7
www.aquaprosystems.com
Initial Start-Up
Do not operate
filter at more than
50 psi (345 kPa).
To prevent damage
to the cartridge
fabric, do not run the filter more than
2-3 minutes without a D.E. pre-coat. Use
D.E. that is sold and labeled specifically
for pools and spas. Do not use more
than the recommended amount of D.E.
as it will clog the filter. Do not use less
than the recommended amount as it
will not fully coat the fabric and will
shorten the life of the cartridge.
1. Ensure pump is OFF. Turn off any
automatic controls and lock out / tag
out switches and / or circuit breakers
to ensure the system cannot
inadvertently turn on.
Verify power is
removed from the
system. Disconnect, tag and lock out
power source before attempting to
install, service, relocate or perform any
maintenance.
2. Install the filter cartridge in the
base of the tank, being careful to
avoid the flow diverter in the inlet.
Ensure the air bleed tube is correctly
installed (Figure 5). Push down
firmly to seal the cartridge.
3. Clean the o-ring seating area on the
inside of the base (Figure 6). Lightly
lubricate with silicone based grease.
Only use silicone
based grease to
lubricate the o-ring. Other lubricants
may damage the o-ring and plastic
filter components. Do not lubricate the
threads on the tank base or the locking
ring, as they may collect debris and
hinder removal.
4. Inspect o-ring. Ensure the o-ring is
clean and properly seated in the
o-ring groove (Figure 7). The o-ring
should not be twisted.
Do not remove the
o-ring unless it is to
be replaced.
5. Open the air relief valve by turning
it counter-clockwise two full turns.
6. Place the top assembly on the filter
base, centering it on the cartridge
and the base.
7. Turn the locking ring counter-
clockwise until the top assembly falls
into place (1/4 turn or less.)
8. Holding the locking ring stationary,
rotate the top to point the air relief
valve in a safe direction (away from
the pump and any other electrical
components.)
9. Secure the locking ring by turning it
clockwise until the safety latch clicks
into place (approximately 1/2 turn).
The latch should fall between the
two tabs on the ring (Figure 8). The
ring may be slightly loose, but it will
tighten when the pump turns on.
If the locking ring will not fully engage
the latch, turn it counter-clockwise to
remove the top assembly and return
to step 2, ensuring the cartridge is
properly seated and the o-ring is
lubricated and properly seated.
10. If installed, open the valves
separating the filter from the rest of
the system.
11. Mix a slurry using 1-2 lbs. of D.E. in
approximately 4 gallons of water.
12. Stand clear of the filter tank.
Following the pump manufacturer's
instructions, start the pump to purge
the air from the system.
13. Once a steady stream of water flows
from the air relief valve, close the
valve by pushing it down while
turning it clockwise. It should fully
tighten in approximately 2 turns.
Do not over-tighten
the valve. If the
valve fails to seal, turn the pump off,
remove the top assembly and inspect
the valve o-ring. Re-seat or replace if
necessary.
14. Pre-coat the filter by slowly adding
the D.E. slurry through the skimmer
basket in the pool. Continue to mix
the slurry and slowly add to the
skimmer basket until the proper
amount of D.E. pre-coat is added
(refer to Table 2 on page 4).
15. Record the filter pressure gauge
reading in the "Cartridge Cleaning"
section of this owner's manual.
Figure 6 - O-ring seating area
Clean and lube
o-ring seating
area (shaded)
Figure 7 - O-ring groove
O-ring must be
seated in this
groove
Do NOT seat
o-ring in this
groove
Figure 8 - Safety latch: locked position
Safety latch must fall
between the two tabs in
the locking ring
Figure 5 - Air bleed tube alignment
Air bleed
tube must
go through
center of
cartridge
support (if
equipped)
Air bleed
tube must
be inside
top support
ring
59725-XXXX, 59726-XXXX and 59727-XXXX

AQUAGUARDPOOLSYSTEMS.COM
8
Operating Instructions and Parts List
www.aquaprosystems.com
Filter Disassembly
1. Ensure pump is OFF. Turn off any
automatic controls and lock out / tag
out switches and / or circuit breakers
to ensure the system cannot
inadvertently turn on.
Verify power is
removed from the
system. Disconnect, tag and lock out
power source before attempting to
install, service, relocate or perform any
maintenance.
2. Close filter isolation valves, if
installed.
3. Open the air relief valve by turning
it counter-clockwise two full turns.
This will relieve pressure in the tank.
4. Remove the drain plug (or open the
drain valve) and drain all water from
the tank.
5. Press the safety latch toward the
tank to release it from the locking
ring.
6. While holding the safety latch in the
release position, turn the locking
ring counter-clockwise to remove it
(approximately 1/2 turn). If the ring
is difficult to turn, tap it gently with
a rubber mallet to overcome the
initial resistance.
Cartridge Cleaning
When to clean the filter: The filter
cartridge should normally be removed
and cleaned when the pressure gauge
reads 10 psi to 12 psi (69 kPa - 83 kPa)
above the start-up pressure noted
below:
Installation date: __________________
Start-up pressure: __________________
Cleaning pressure: __________________
In some pools and spas, accessories
such as fountains, waterfalls, and pool
cleaners may be noticeably affected by
the normal decrease in flow as the filter
becomes dirty. If so, these systems may
require more frequent cleaning (that is,
at a pressure increase of less than 10 psi)
to operate properly.
The cleaning interval is based on
pressure rise, not on operation time.
Different water conditions will lead to
different cleaning intervals.
NOTE:To limit the down time of the
filter, keep a second cartridge on hand.
This will allow time to properly clean
the cartridge and also will allow for
immediate replacement should one
filter cartridge fail.
When using PHMB
(polyhexamethylene
biguanide) based sanitizers, such as
Baquacil
®
, special care must be taken
when cleaning the cartridge. Cartridges
in systems using these sanitizers
must be cleaned more frequently and
thoroughly than chlorine systems.
PHMB based sanitizers also require the
use of special PHMB cleaners. Carefully
follow the PHMB sanitizer/cleaner
manufacturer's instructions when
cleaning the filter. Use of any other
type of cleansers with PHMB sanitizers
will permanently clog the filter and will
void the filter warranty
1. Follow all steps in the "Filter
Disassembly" section of this manual.
2. With drain plug removed, hose
down the cartridge to try and
remove as much of the spent D.E. as
possible. Flush any foreign material
from the inside of the tank before
removing the filter cartridge.
3. Allow the tank to drain.
4. Carefully pull the cartridge straight
up from the filter base, avoiding
contact with the flow diverter.
5. Using a garden hose with a nozzle,
clean the cartridge thoroughly.
Work from the top down, holding
the nozzle at a 45° angle. Spray all
the pleats, with emphasis between
the pleats, until all dirt, debris and
D.E. is gone. Allow the cartridge to
drain.
6. For cartridges used where
perspiration, suntan lotions, and
other oils are present, soak the
element for at least one hour
(overnight is recommended) in one
of the following:
a. Commercial filter cleaner
(follow the manufacturer’s
directions)
b. Solution of one cup (8 fl oz)
trisodium phosphate (TSP) and
five gallons water.
c. Solution of one cup (8 fl oz)
dishwasher detergent and five
gallons of water.
7. Thoroughly rinse the cartridge again
to remove cleaning solution and oils.
8. Inspect the cartridge for cleanliness
and damage. If necessary, repeat the
washing process. If the cartridge is
damaged, replace it.
Failure to remove
all oils and cleaning
solution before soaking cartridge in
acid will permanently damage the filter
cartridge.
9. If the filter has a coating of algae,
calcium carbonate (residue from
calcium hypochlorite), iron or other
minerals, soak the cartridge in a
solution of one part muriatic acid
to twenty parts water (6 fl oz per
gallon of water) until all bubbling
stops.
Wear
rubber
gloves, protective clothing
and safety goggles when
using acid. Do not add water
to acid, as splashing of full
strength acid could result.
10. Thoroughly rinse the cartridge to
remove all acid solution.
When this
procedure no longer
adequately cleans the cartridge, discard
the cartridge and replace it with a new
one.
11. Carefully follow the steps in the
“Filter Assembly” section of this
manual.

AQUAGUARDPOOLSYSTEMS.COM
9
www.aquaprosystems.com
Filter Assembly
1. Inspect and clean the tank, threads,
and o-ring. Replace damaged parts
as necessary.
2. Install the drain plug in the drain
port (or close the drain valve).
3. Follow steps 1-14 in the “Initial
Start-up” section of this manual.
System Inspection
The pool circulation system should be
frequently inspected for debris and
signs of leaks.
Any time the system
is opened, air must
be bled from the filter using the air
relief valve. Air trapped in the system
can cause an explosion.
1. Ensure pump is OFF. Turn off any
automatic controls and lock out / tag
out switches and / or circuit breakers
to ensure the system cannot
inadvertently turn on.
Verify power is
removed from the
system. Disconnect, tag and lock out
power source before attempting to
install, service, relocate or perform any
maintenance.
2. Close system isolation valves, if
installed.
3. Remove debris from the pool
skimmer basket.
4. Open the air relief valve to release
any pressure in the system.
5. Check system for signs of leaks. If
found, consult the owner’s manual
of the leaking equipment.
6. Remove pump trap cover and
basket; remove debris. Refer to the
pump owner’s manual for more
specific information.
7. Replace the pump basket and
trap cover according to the pump
owner’s manual.
8. Open system isolation valves, if
installed.
9. With the air relief valve open, stand
clear of the filter and start the
pump.
10. Once a steady stream of water flows
from the air relief valve, close the
valve.
Do not over tighten
valve. If the valve
fails to seal, turn the pump off, remove
the top assembly and inspect the valve
o-ring. Reseat or replace if necessary.
11. When the system has returned to
normal operation, check the filter
operating pressure. If the filter
pressure is 10 psi to 12 psi (69 kPa -
83 kPa) above the start-up pressure,
the filter needs to be cleaned. Refer
to the “Cartridge Cleaning” section
of this owner's manual (Page 8).
Winterizing
Protect the filter from freezing. If
possible, take the system indoors for
storage.
1. Ensure pump is OFF. Turn off any
automatic controls and lock out / tag
out switches and / or circuit breakers
to ensure the system cannot
inadvertently turn on.
Verify power is
removed from the
system. Disconnect, tag and lock out
power source before attempting to
install, service, relocate or perform any
maintenance.
2. Clean the filter. Refer to the
“Cartridge Cleaning” section of this
owner's manual (Page 8).
3. Remove the filter cartridge and store
in a warm, dry area. Protect the
cartridge from sunlight.
4. Cover the filter with plastic or a tarp
to prevent water from entering the
assembly and freezing.
Failure to follow
the above steps
could cause the filter assembly to
expand and crack. This will void the
warranty.
Troubleshooting Guide
Short Cycle Time
Cycle time will vary between
installations and different areas of the
country. The following remedies are for
cycle times shorter than normal:
t New pool / spa installation: Until the
water in a new pool is completely
filtered, cycle time will be short due
to plaster dust and construction
debris. Thoroughly clean the
cartridge. Refer to the "Cartridge
Cleaning" section of this owner's
manual (Page 8).
t Improper D.E. Coat: Check cartridge
for incomplete or excess D.E. precoat
coverage. Refer to "Initial Startup"
section of this owner's manual (Page 7).
t Low chlorine residual: Maintain
proper chlorine residual (consult
local pool professional for
recommendation.)
t Dirty or plugged filter cartridge:
Thoroughly clean the filter. Follow
the instructions in the "Cartridge
Cleaning" section of this owner's
manual (Page 8).
t Excessive air in filter: Vent all air
from the filter tank and check
system for suction pipe leaks or low
59725-XXXX, 59726-XXXX and 59727-XXXX

AQUAGUARDPOOLSYSTEMS.COM
10
Operating Instructions and Parts List
www.aquaprosystems.com
water level. Also, check and clean air
bleed tube (See Figure 5).
t Chemical imbalance in water: Check
pool chemistry (refer to Table 1
on page 3). Consult local pool
professional.
t Algae in system: Apply heavy dose of
chlorine or algicide as recommended
by the pool manufacturer and/or
local professional.
t Cartridge is at the end of its life:
When cleaning procedure no longer
adequately cleans the cartridge,
replace the cartridge.
t Filter is undersized / pump is
oversized: Use a filter with higher
square footage or use a smaller HP
pump. Consult a customer service
representative for sizing information
at 1-877-278-2797.
Low Flow / High Pressure
Resistance in or after the filter will
reduce the flow and increase the
pressure inside the filter. Check the
following to remedy this problem:
t Dirty or plugged filter cartridge:
Thoroughly clean the filter. Follow
the instructions in the "Cartridge
Cleaning" section of this owner's
manual (Page 8).
t Piping is blocked downstream from
the filter: Remove the obstruction.
t Return valve is not fully open: Fully
open return valve
t Piping is too small: Use larger pipe.
Consult pool manufacturer.
t Filter is undersized / pump is
oversized: Use a filter with higher
square footage or use a smaller HP
pump. Consult a customer service
representative for sizing information
at 1-877-278-2797.
Low Flow / Low Pressure
Resistance before the filter will reduce
the flow and pressure inside the filter.
Check the following to remedy this
problem:
t Skimmer basket(s) clogged:
Thoroughly clean the skimmer
basket(s).
t Pump plugged: Thoroughly clean
the suction trap in the pump.
t Drain and skimmer valves are not
fully open: Fully open the drain and
skimmer valves
t Piping is blocked upstream from the
filter: Remove the obstruction.
Plugged Cartridge
Over time, the filter media will become
clogged and will not perform properly.
If the cartridge cannot be cleaned,
replace it. If the cartridge needs
replacement often, check the following:
t Improper D.E. precoat: Check cartridge
for incomplete or excess D.E. precoat
coverage. Refer to "Initial Start-Up"
section of this owner's manual (Page 7).
t Insufficient cleaning: Closely follow
the instructions in the "Cartridge
Cleaning" section of this owner's
manual (Page 8).
t Excessive air in filter: Vent all air
from the filter tank and check
system for suction pipe leaks. Also,
check and clean air bleed tube (See
Figure 5).
t Low chlorine residual: Maintain
proper residual (consult local pool
professional.)
t Chemical imbalance in water: Check
pool chemistry (refer to Table 1
on page 3). Consult local pool
professional.
t Algae in system: Apply heavy dose of
chlorine or algicide as recommended
by the pool manufacturer and/or
local professional.
t High iron content in water: Consult
local pool professional.
t Improper use of powdered chlorine
tablets containing binders: Consult
local pool professional.
t Cleaning with incorrect chemicals
when using PHMB sanitizers:
Replace the filter cartridge. Only use
cleaners specifically made for PHMB
sanitizers.
Water Not Clear
A number of factors can affect water
clarity. The following causes should be
checked:
t Improper D.E. precoat: Check cartridge
for incomplete or excess D.E. precoat
coverage. Refer to "Initial Start-Up"
section of this owner's manual (Page 7).
t Chemical imbalance in water: Check
pool chemistry (refer to Table 1
on page 3). Consult local pool
professional.
t Low chlorine residual: Maintain
proper chlorine residual (consult
local pool professional for
recommendation).
t Damaged filter cartridge: If cartridge
is torn or punctured, replace it.
t High iron content in water: Consult
local pool professional.
t Improper use of powdered chlorine
tablets containing binders: Consult
local pool professional.
t Algae in system: Apply heavy dose of
chlorine or algicide as recommended
by the pool manufacturer and/or
local professional.
Automatic Pool Cleaner Stops
Working
Pool cleaners may be noticeably affected
by the normal decrease in flow as the
filter becomes clogged. If the filter stops
working, thoroughly clean the cartridge.
Refer to the "Cartridge Cleaning" section
of this owner's manual (Page 8). If the
pool cleaner performs better after the
filter is cleaned, clean the filter more
often than recommended [Note: pressure
increase from start-up may be less than
10 psi to 12 psi (69 kPa - 83 kPa)].

AQUAGUARDPOOLSYSTEMS.COM
11
www.aquaprosystems.com
Part Number by Model
Item Description 59725-XXXX 59726-XXXX 59727-XXXX
1 Filter Cartridge 62559-AQP1 62560-AQP1 62561-AQP1
2 Breather Tube 68028-AQP1 68029-AQP1 68029-AQP1
3 Flow Diverter 28584-AQP1 28584-AQP1 28584-AQP1
4 Locking Ring 28576-AQP1 28576-AQP1 28576-AQP1
5 Pressure Gauge 06913-AQP1 06913-AQP1 06913-AQP1
6 Air Relief Valve Assembly (Includes O-rings) 28585-AQP1 28585-AQP1 28585-AQP1
7 Filter Top 28580-AQP2 28581-AQP2 28581-AQP2
8 O-Ring Kit (Includes Lubricant) 19079-AQP1 19079-AQP1 19079-AQP1
9 Filter Base 28574-AQP1 28574-AQP1 28574-AQP1
10 Safety Latch Assembly (Includes Screw) 05736-AQP1 05736-AQP1 05736-AQP1
11 Drain Plug Assembly, 2 inch (Includes O-ring) 28583-AQP1 28583-AQP1 28583-AQP1
9
4
8
7
2
1
5
3
6
10
11
8
8
For Replacement Parts or Technical Assistance,
Call 1-877-278-2797
Please provide following information:
- Model number
- Serial number
- Part description and number as
shown in parts list
59725-XXXX, 59726-XXXX and 59727-XXXX

AQUAGUARDPOOLSYSTEMS.COM
12
Operating Instructions and Parts List
www.aquaprosystems.com
Limited Warranty
For one (1) year from the date of purchase, the manufacturer will repair or replace, at its option, for the original owner
any parts of its filters (“Product”) which are found upon examination by the manufacturer to be defective in materials or
workmanship. This Limited Warranty covers labor for a period of one (1) year.
Please call the manufacturer at 1-877-278-2797 for instructions. Be prepared to provide a receipt, the model number and
serial number when exercising this limited warranty.
Purchaser must pay all transportation charges on Products or parts submitted for repair or replacement.
All non-warranty service charges are the responsibility of the original owner. Failure to pay for non-warranty service charges
will void this Limited Warranty.
This Limited Warranty does not cover Products that have been damaged as a result of accident, freezing, abuse, misuse,
neglect, improper installation, improper maintenance or failure to operate in accordance with the manufacturers’ written
instructions. All maintenance and service must be performed by service agents approved by the manufacturer. Any
unauthorized alteration or repairs will void this Limited Warranty.
THERE IS NO OTHER EXPRESS WARRANTY. IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE (1) YEAR FROM THE DATE OF PURCHASE. THIS IS
THE EXCLUSIVE REMEDY AND ANY LIABILITY FOR ANY AND ALL INDIRECT OR CONSEQUENTIAL DAMAGES OR
EXPENSES WHATSOEVER IS EXCLUDED.
Some states do not allow limitations on how long an implied warranty lasts, or do not allow the exclusions or limitations of
incidental or consequential damages, so the above limitations might not apply to you. This limited warranty gives you specific
legal rights, and you may also have other legal rights which vary from state to state.
In no event, whether as a result of breach of contract warranty, tort (including negligence) or otherwise, shall the
manufacturer or its suppliers be liable for any special, consequential, incidental or penal damages including, but not limited
to loss of profit or revenues, loss of use of the products or any associated equipment, damage to associated equipment, cost
of capital, cost of substitute products, facilities, services or replacement power, downtime costs, or claims of buyer’s customers
for such damages.
This Limited Warranty does not include freight charges for equipment or component parts, to and from the factory, services
such as maintenance or inspection, repair or damage due to negligence such as freezing conditions, incorrect installation,
nor acts of God. The liability of the manufacturer shall not exceed the repair or replacement of defective parts under this
Limited Warranty. This Limited Warranty also does not include unnecessary service calls due to erroneous operational reports,
external valve positions, or electrical service. If a non-warranty service call is made, and the homeowner is unwilling to pay
for the service call, this Limited Warranty will be voided. This Limited Warranty is voided if the product is repaired or altered
by any persons or agencies other than those authorized by the manufacturer. This Limited warranty applies only within the
continental USA. For warranty outside the continental USA, contact the manufacturer.
You MUST retain your purchase receipt along with this form. In the event you need to exercise a warranty claim, you MUST
present a copy of the purchase receipt at the time of service. Please call 1-877-278-2797 for service or return authorization
and instructions.
DO NOT MAIL THIS FORM TO the manufacturer. Use this form only to maintain your records.
MODEL NO. _____________________ SERIAL NO. _____________________ INSTALLATION DATE __________________________

AQUAGUARDPOOLSYSTEMS.COM
-
1
-
QUICK START QUIDE
OWNER’S MANUAL
INSTALLATION, OPERATION & PARTS
POOL PUMPS
SINGLE SPEED & 2-SPEED
This equipment must be installed and serviced by a qualified technician in accordance with all applicable codes
and ordinances. Improper installation can create hazards which could result in property damage, serious injury
or death. Improper installation will void the warranty.
The NOTICE label indicates special instructions that are important but not related to hazards.
Notice to Installer
This manual contains important information about the installation, operation and
safe use of this product. Once installation is complete, this manual must be
given to the owner/ operator of this equipment.
WARNING
！

AQUAGUARDPOOLSYSTEMS.COM
-
2-
Description
The self-priming pool pump is designed for high efficiency and easy installation and maintenance. It is constructed
for years of trouble-free service. This swimming pool pump is designed for use with permanently installed swimming
pools only.
Unpacking
After unpacking the unit, carefully inspect for any damage that may have occurred during transit. Check for loose,
missing or damaged parts
INSTALLATION
Only qualified, licensed personnel should install pump and wiring.
The pump mount must be located away from corrosive or flammable chemicals.
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions with this equipment, including:
To reduce the risk of injury, do not allow children to use product unless supervised at all times.
This pump is for use with permanently installed pools. Do not use with portable pools. A permanently installed pool is
constructed in or on the ground or in a building and is not intended to be disassembled or moved.
Provide sufficient ventilation to maintain air temperature below the maximum ambient temperature rating shown on
the motor nameplate. Any enclosure or pump house must allow adequate ventilation to assure the ambient
temperature remains below the motor rating when the pump is operating.
Locate pump on a non-combustible surface as close to the pool/spa as possible. The surface should be hard, level,
dry, and well ventilated. The surrounding area should provide protection from the elements and allow sufficient space
for maintenance and service. Ensure the drainage will flow away from the pump. To reduce vibration and pipe stress,
use anchor bolts to secure the pump base to the surface.
Design the piping system to allow the pump suction inlet height to be as close to the water level as possible. Mount
the pump below water level for easy priming. If the pump must be located above the filled water level, keep the
vertical distance to a minimum. Use short, direct piping to the suction to minimize friction loss.
Fire and burn hazard. Motors run at high temperatures. Do not allow leaves, debris, or foreign matter to collect
around the pump motor. Allow the motor to cool before handling.
Use rigid or flexible PVC pipe. Ensure pipe ends are clean and free of any flash caused by cutting. Use proper glue
for the type of pipe selected.
NOTE: Use a supplier recommended primer to ensure glued joints are secure. Many local codes require primer with
a purple tracer to verify primer use.
Consider climatic conditions when applying adhesives. Atmospheric conditions with high humidity will make the
adhesive action of certain glues less effective. Follow the manufacturer's instructions.

AQUAGUARDPOOLSYSTEMS.COM
-
3-
THREADED CONNECTIONS
Use only Teflon® tape or equivalent on threaded plumbing connections. Other pipe compounds may damage
threads. Do not use silicone or petroleum based compounds. Do not over tighten. Hand tightening plus 1/2 turn is
sufficient.
PUMP PLUMBING
Suction pipe should be as large as or larger than discharge pipe. Avoid using a suction pipe smaller than the pump
connection. The pump is designed to accept 1-1/2” suction piping.
1. Keep the piping as straight and short as possible, and of suitable size.
2. Avoid connecting an elbow directly into the pump inlet. A length of straight pipe will allow proper entry of the water
to the pump.
3. Slope horizontally, and run upward to the pump to prevent trapping air.
4. Use independent piping supports to reduce strain on the pump.
5. Keep as much of the suction line as possible below the water level to reduce priming time.
6. Install valves and unions in the pump suction and return the lines to facilitate servicing. Valves are also essential
for pump maintenance,if the system is installed below deck level.
NOTICE: Use Teflon®tape or Plasto-Joint Stik for making threaded connections to the pump. Do not use pipe dope.
Teflon® Taping Instructions:
Use only new or clean PVC pipe fittings. Wrap male pipe threads with one to two layers of Teflon®tape. Cover entire
threaded portion. Do not over tighten. If leaks occur, remove pipe, clean off old tape, rewrap with one to two
additional layers of tape and remake the connection.
Fittings:
Fittings restrict flow; for best efficiency use the fewest number of possible fittings. Avoid fittings which could cause an
air trap. Pool fittings must conform to International Association of Plumbing and Mechanical Officials (IAPMO)
standards. Use only non-entrapping suction fitting or double suction.
POOL PUMP SUCTION REQUIREMENTS
Pump suction is hazardous and can trap, drown,or disembowel bathers. Do not use or operate swimming
pools, spas, or hot tubs if a suction outlet cover is missing, broken, or loose. Follow the guidelines below for a
pump installation which minimizes risk to all users of pools, spas, and hot tubs.
Entrapment Protection
The pump suction must be designed to eliminate the possibility of suction entrapment or hair
entrapment/entanglement.
Suction Outlet Covers
All suction inlet covers must be maintained and replaced if cracked, broken, or missing.
See Figure * for outlet cover certification requirements.
Testing and Certification
All suction inlet covers must comply with ASME/ANSI specifications for suction fittings for use in swimming pools,
spas, hot tubs, and whirlpool bathtub applications. The product must be tested for compliance with the standards,
and the certification must be included with the components.

AQUAGUARDPOOLSYSTEMS.COM
-
4-
Suction inlets must be designed so that water is drawn simultaneously. A vacuum relief device can be installed in line
leading to the pump suction.
All suction outlet covers must conform to ASME/ANSI A112.19.18M; or must be a minimum 18 x 23 grate or larger;
or must have an approved channel drain system. Skimmers are exempted. All pool and spa single or multiple outlet
circulation systems shall be equipped with an atmospheric vacuum relief system. The system must be ASME/ANSI
A112.19.17 Rated.
Any pool or spa shall immediately be closed if the cover or grate is damaged or missing.
Suction outlet covers/grates shall be tested and listed by a nationally recognized testing laboratory as conforming to
ASME/ANSI A112.19.8
ELECTRICAL
Ground the motor before connecting to electrical power supply. Failure to ground the motor may cause
severe or fatal electrical shock hazard. Never ground to a gas supply line.
To avoid dangerous or fatal electrical shock, turn OFF power to motor before working on electrical
connections.
Ground Fault Circuit Interrupter (GFCI) tripping indicates an electrical problem. If GFCI trips and will not
reset, have a qualified electrician inspect and repair electrical system.
Verify that supply voltage matches the nameplate voltage. Incorrect voltage can cause fire or seriously
damage motor and voids warranty.
Voltage
Voltage at motor must be within 10% of the motor nameplate rated voltage or motor may overheat, causing overload
tripping and reduced component life. If voltage does not fall within the specified range during operation consult the
power company.
Grounding/Bonding
Install, ground, bond and wire motor according to local or National Electrical Code requirements. Permanently
ground the motor. Use the ground terminal provided in the terminal box on the back of the motor. Use size and type
wire required by local codes. Connect motor ground terminal to electrical service ground.
Bond motor to pool structure. Use a solid copper conductor, size No. 8 AWG or larger. Run wire from external
bonding lug to reinforcing rod or mesh.
Connect a No. 8 AWG solid copper bonding wire to the pressure wire connector provided on the motor housing and
to all metal parts of the swimming pool, spa, or hot tub and to all electrical equipment, metal piping or conduit within 5
feet of the inside walls of swimming pool, spa, or hot tub.
Wiring
Follow all national and local wiring codes. If unsure of the code requirements,consult a professional electrician.
Pump must be permanently connected to circuit. See Figures ** for wiring connection diagrams. Match wire and
circuit breaker sizes to correct fusing and wiring data chart. If other lights or appliances are also on the same circuit,
be sure to add their amp loads to pump amp load. If unsure,consult a licensed electrician.

AQUAGUARDPOOLSYSTEMS.COM
-
5-
A Ground Fault Circuit Interrupter (GFCI) is required in the circuit. For size of GFCI required and test procedures for
GFCI, please see manufacturer’s instructions.
OPERATION
Avoid running the pump dry. Fill the pump with water before starting motor. Before removing the trap
cover:
1. STOP PUMP before proceeding.
2. CLOSE GATE VALVES in suction and discharge pipes.
3. RELEASE ALL PRESSURE from pump and piping system.
4. NEVER tighten or loosen clamp while pump is operating!
If pump is being pressure tested, be sure pressure has been released before removing trap cover. Do not
block pump suction. To do so with body may cause severe or fatal injury. Small children using pool must
ALWAYS have close adult supervision.
Fire and burn hazard. Motor runs at high temperatures, to reduce the risk of fire, do not allow debris, or foreign
matter to collect around the pump motor. Allow the motor to cool prior to handling or performing maintenance.
The motor is equipped with an internal thermal protection circuit to guard against overheating. The maximum
ambient temperature for the motor operation must not exceed rating on motor model plate.
Priming Pump
Release all pressure from filter, pump, and piping system; see the filter owner’s manual. In a flooded suction system
(water source higher than pump), pump will prime automatically during suction and discharge valves are opened. If
the pump is located above the normal pool water level, remove ring and cover assembly, and fill basket and pump
with water. Clean and inspect o-ring; then reinstall on trap. Replace ring and cover assembly, then rotate clockwise
to tighten cover.
NOTICE: Tighten ring and cover assembly by hand - do not use tools. Pump priming time will depend on the vertical
distance and length of the suction line. The pump is designed to prime at 10 ft or less. Ifthe pump does not prime,
make sure that all valves are open, and that the suction pipe is submerged. Verify there are no leaks in the suction
lines.
Routine Maintenance
The only routine maintenance needed is the inspection and cleaning of the trap basket. Debris or trash that collects
in the basket will choke off water flow through the pump.
Before attempting to clean the basket:
A. Stop pump, close valves in suction and discharge, and release pressure from system.
Hazardous suction can trap hair or body parts, causing severe injury or death. Do not block suction.
B. Remove the ring and cover assembly by turning counterclockwise. If necessary, tap handles gently with a rubber
mallet.
C. Remove the basket and clean. Inspect holes in basket for blockage. Clean the basket with water and replace in
trap. Verify that the basket is oriented correctly in pump housing.
D. Clean and inspect lid o-ring; then reinstall the ring and cover assembly.

AQUAGUARDPOOLSYSTEMS.COM
-
6-
E. Prime the pump (see priming instructions).
Draining the Pump
A. Pump down water level below all inlets to the pool.
To avoid dangerous or fatal electrical shock hazard, turn OFF power to the motor before draining pump.
B. Remove the basket cover
C. Drain the basket housing and pump housing through the drain plugs
D. Clean the pump and basket,then replace cover assembly.
NOTICE: Tighten trap cover by hand only
E. Be sure motor is kept dry and covered.
Storage/Winterizing:
Explosion hazard. Purging the system with compressed air can cause components to explode, with risk of
severe injury or death to anyone nearby. Use only a low pressure (below 5 PSI), high volume blower for purging
the pump, filter, or piping.
NOTICE: Allowing pump to freeze will damage pump and void warranty!
NOTICE: Use only non-toxic antifreeze. Do not use automotive antifreeze. It is highly toxic and may damage plastic
components in the system.
PUMP SERVICE TROUBLESHOOTING GUIDE
Read and understand safety and operating instructions in this manual before doing any work on pump!
Only qualified personnel should electrically test the pump motor!
FAILURE TO PUMP; REDUCED CAPACITY OR DISCHARGE PRESSURE
Suction leaks/lost prime:
1. Pump must be primed. Make sure that pump body and basket body are full of water. See priming instructions.
2. Make sure there are no leaks in suction piping.
3. Make sure suction inlet is well below the water level to prevent pump from sucking air.
4. Pump is designed to prime at a vertical distance of 10 ft or less. Verify suction lift is 10 ft or less. Lower pump
closer (vertically) to water source.
Clogged Pipe/Trap/Impeller, Worn Impeller:
5. Make sure suction trap is not clogged; if it is, then clean trap and strainer.
6. Make sure the impeller is not clogged
7. Impeller and diffuser may be worn. If so, order replacement parts from Repair Parts List, Pages 14-15.
8. The pump may be trying to push too high a column of water. If so, a “higher head” pump is needed.
Electrical:
9. Pump may be running too slowly; check voltage at motor terminals and at meter while pump is running. If low, see
wiring instructions or consult power company. Check for loose connections.
10. Pump may be too hot.
A. Check line voltage; if less than 90% or more than 110% of rated voltage consult a licensed electrician.
B. Increase ventilation.
C. Reduce ambient temperature.
D. Tighten any loose connections.

AQUAGUARDPOOLSYSTEMS.COM
-
7-
MECHANICAL TROUBLES AND NOISE
1. If suction and discharge piping are not adequately supported, pump assembly will be strained. See “Installation”.
2. Do not mount the pump on a wooden platform! Securely mount on a concrete platform for quietest performance
before working on pump or motor.


AQUAGUARDPOOLSYSTEMS.COM
-
8-
Limited Warranty
For one (1) year from the date of purchase, manufacturer will repair or replace, at its option, for the original owner any
parts of its pumps (“Product”) which are found upon examination to be defective in materials or workmanship.
Please call 1-877-278-2797 for instructions. Be prepared to provide a receipt, the model number,and serial number when
exercising this limited warranty.
Purchaser must pay all transportation charges on Products or parts submitted for repair or replacement. All non-warranty
service charges are the responsibility of the original owner. Failure to pay for non-warranty service charges will void this
Limited Warranty.
This Limited Warranty does not cover Products that have been damaged as a result of accident, freezing, abuse, misuse,
neglect, improper installation, improper maintenance or failure to operate in accordance with written instructions. All
maintenance and service must be performed by approved service agents. Any unauthorized alteration or repairs will void
this Limited Warranty.
THERE IS NO OTHER EXPRESS WARRANTY. IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE (1) YEAR FROM THE DATE OF PURCHASE. THIS IS THE
EXCLUSIVE REMEDY AND ANY LIABILITY FOR ANY AND ALL INDIRECT OR CONSEQUENTIAL DAMAGES OR
EXPENSES WHATSOEVER IS EXCLUDED.
Some states do not allow limitations on how long an implied warranty lasts, or do not allow the exclusions or limitations of
incidental or consequential damages, so the above limitations might not apply to you. This limited warranty gives you
specific legal rights, and you may also have other legal rights which vary from state to state.
In no event, whether as a result of breach of contract warranty, tort (including negligence) or otherwise, shall its suppliers
be liable for any special, consequential, incidental or penal damages including, but not limited to loss of profit or revenues,
loss of use of the products or any associated equipment, damage to associated equipment, cost of capital, cost of
substitute products, facilities, services or replacement power, downtime costs, or claims of buyer’s customers for such
damages.
This Limited Warranty does not include freight charges for equipment or component parts, to and from the factory,
services such as maintenance or inspection, repair or damage due to negligence such as freezing conditions, incorrect
installation, nor acts of God. The liability shall not exceed the repair or replacement of defective parts under this Limited
Warranty. This Limited Warranty also does not include unnecessary service calls due to erroneous operational reports,or
electrical service. If a non-warranty service call is made, and the homeowner is unwilling to pay for the service call, this
Limited Warranty will be voided. This Limited Warranty is voided if the product is repaired or altered by any persons or
agencies other than those authorized. This Limited warranty applies only within the continental USA. For warranty outside
the continental USA please contact Aquapro Systems customer service.
You MUST retain your purchase receipt along with this form. In the event you need to exercise a warranty claim, you
MUST present a copy of the purchase receipt at the time of service. Please call 1-877-278-2797 for service or return
authorization and instructions.
DO NOT MAIL THIS FORM. Use this form only to maintain your records.
MODEL NO. ______________ SERIAL NO. _____________________ INSTALLATION DATE __________________________
