Aqua Ultraviolet A00001 User manual

Dynamic Room Air Sterilizer
Ultraviolet Sterilization and Purification Lamp
Register your UV by using the attached warranty card
or
go online to aquauv.com
Find us on Facebook
www.facebook.com/AquaUltraviolet
Follow us on Instagram
www.instagram.com/aquauv
See us on YouTube
www.youtube.com/AquaUltraviolet
PO Box 2189
Temecula, CA 92593
MAIN OFFICE
42371 Avenida Alvarado
Temecula, CA 92590
Toll Free: [phone]
Tel: [phone]
www.aquauv.com
MAILING ADDRESS
EPA Est 68177-CA-001

PRODUCT FEATURES AND SPECIFICATIONS
AQUA ULTRAVIOLET | 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 | TEL: [phone] or [phone]
The Dynamic Room Air Sterilizer is a new generation of UVC products, which can
be directly connected to the main power supply. This 254nm high-efficiency UVC
lamp with 360
°
ring-shaped illumination. The direct irradiation part of the UV lamp
tube is made of aluminum alloy material, which avoids the problems of anti-aging
and yellowing of the material. Microwave+ PIR sensors ensure the detection of
any movement. It can be set to 30min / 60min / 90min / 120min timing increments
by wireless remote control.
-/+180
-C0/180,330.8
-C30n10,330.5
-(60/240,332.3
-(90/270,332.1
AVERAGE BEAM ANGLE (50%): 331.4 DEG
Model
Influenza
(µW.S/cm')
Disi nfec tio n
ti me f or 9.42 ft'
( 3.28ft dist ance
to lam p )
6000
A00001 1.276min 3.245min
Disi nfec tio n
ti me f or 20.41 ft'
( 4.92ft dist ance
to lam p )
7.238min
Disi nfec tio n
ti me f or 35.60ft'
( 6.56ft dist ance
to lam p )
13.299min
Disi nfec tio n
ti me f or 54.99ft'
( 8.20ft dist ance
to lam p )
27.346min
Disi nfec tio n
ti me f or 78.58ft'
( 9.84ft dist ance
to lam p )
105.215min
Disi nfec tio n
ti me f or 138.35ft'
( 13.12ft dist ance
to lam p )
INSTRUCTIONS
Remote Control Instructions (choose the mode before using)
Two modes: Standard mode and automatic mode, switch button under back battery.
1
Standard Mode Automatic Mode
When movement is detected,
lamp will turn off.

AQUA ULTRAVIOLET | 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 | TEL: [phone] or [phone]
INSTRUCTIONS CONTINUE
Remote Control Instructions(select mode before using)
1. Two modes: standard mode and automatic mode, switch button is located under back battery.
2. Standard mode
3. Automatic mode
4. Press the "lock" button to start. Choose any button, it will take around 12 seconds to turn on after it stops beeping.
5. The beeping warns you to move away from the disinfection area, ASAP.
6. Five different disinfection time settings (ON/30MIN/60MIN/90MIN/120MIN); "ON" means not time limited.
7. If you want to cancel the time setting, press OFF. Each time the lamp sounds around 12 seconds then on without detection.
8. The remote controller is paired to the lamp.
Note: Other buttons are out of function, if the "lock button" is not pressed
Remote Control Battery Installation Instructions
Insert 2 AAA alkaline batteries, please pay attention to the polarity of the battery, and it is strictly prohibited to mix new and old batteries.
1. Press the "LOCK" button before operating other function buttons.
2. After the UVC lamp is working normally, the lamp is turned off by the artificial trigger sensor module. If there is no abnormal detection within 2
minutes, the lamp will automatically turn on and work normally. The suspended time will not count in the timer.
3. The signal of the remote control is a non-linear wave signal, and may detect movement through some walls.
CAUTION
TECHNICAL SPECIFICATIONS
Operating Temperature :14 -+ 95°F
Operating Environment Humidity: <80%
Storage Temperature: -4 -+ 140°F
Sensor Detection Range: 360 degrees
Sensor Detection Distance: 0-16 feet
Sensor Type: 1 Microwave+ 3 PIR sensors
Remote Control Distance: 33 feet
Principles and Sterilization Factors
Sterilization Factor: Ultraviolet 253. 7nm
The Principle of Sterilization: Use the C-band ultraviolet light emitted by the ultraviolet
lamp to destroy the bacteria and DNA of bacteria for sterilization.
Sensor detection distance: 16ft
2

3
AQUA ULTRAVIOLET | 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 | TEL: [phone] or [phone]
PRECAUTIONS FOR USE
1. If the ambient temperature is too high (above 95°F), the PIR sensing distance will be shortened(It is normal). It is possible for the lamp to turn off
because of where it is setup, avoid setting up the lamp in direct air flow locations (such as: cold / hot water outlet, exhaust fan, near the electric
furnace, etc.). The sensor head cannot be blocked or covered otherwise there will be a risk of PIR sensor failure.
2. There should be no metal shielding in front of the microwave sensor.
3. Vibration can turn off the sensors.
4. Weather - Heavy Thunderstorms, lightening can affect use.
5. Multiple lights need to be separated by more than 3 feet installation distance, otherwise the microwave sensor may fail to detect.
6. The wireless remote control may be controlled through the wall and multiple lights may be controlled by one remote separately or the same time.
WARNING
1. UVC is harmful to humans and animals, please do not expose directly to the skin and eyes,
please leave immediately once beeping starts.
2. In severe cases, headache, dizziness, increased body temperature, eye irritation, or decreased
vision, Skin irritation, itching, swelling, etc. please consult your doctor immediately.
TROUBLESHOOTING
No.
1
2
3
4
5
6
Failure Analysis Solution
No beep (the indicator light is off)
No beep (the indicator light is on)
Prompt beep (the indicator light not on)
Remote does not work
"UVC lamp" can not turn on
The light appears to trigger the light off
1. Confirm whether it is connected to the main power.
2. Confirm whether the remote control has a battery and whether the
batteries are installed correctly.
Call for Assistance
Call for Assistance
Confirm whether the lamp is powered on. If the lamp is powered on, press the re
mote control "LOCK" first, and then press other function buttons; Whether the
voltage of the remote control battery is too low, the battery needs to be replaced
Confirm whether the lamp is powered on. If the lamp is powered on,
confirm the remote control is operating correctly. "Call for assistance"
Check the "Precautions" in this manual. lf you have avoided the high-level
issues and still have no improvement, please call for assistance; Confirm
whether the ambient temperature exceeds the operating temperature of the
whole lamp.

4
AQUA ULTRAVIOLET | 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 | TEL: [phone] or [phone]
1. The product cannot be used for lighting purposes.
2. The product can only be used for the sterilization of area surfaces and surrounding stable air, this can not be used for the sterilization of the any
part of the human body. The lamp should be kept dust free, if needed, when the lamp is cold, you can wipe with a damp cloth and let dry. Never
rinse the lamp or any part of the unit with water.
3. When you use the product for indoor air sterilization, please close the doors and windows to keep the room clean and dry, and reduce dust and
moisture. NOT RECOMMENDED FOR USE - If the room temperature is lower than -10 degrees or higher than 35 degrees.. Please open the doors
and windows for 10 minutes after sterilization.
4. When using this product to sterilize the surface of objects, a distance of not more than 4 feet from the irradiation surface. The closer to the lamp,
the better the sterilization effect. The best sterilization location is near the lamp tube. If there are paintings, plants, utensils, and other ultraviolet
sensitive items in the room, they should be covered.
5. Extended UV exposure can cause irreversible damage to an object that is not resistant to ultraviolet rays, and the object can become altered. If
the surface of a white object is exposed, the illumination will change the objects color and may begin to look Pale Blue. Plastic items that are not UV
resistant will become brittle.
6. After sterilization, the Unit Should be Unplugged and Stored in a Dust Free Area with the remote control to avoid damage and to avoid accidental
injury.
7. If the UV sterilization lamp is accidentally broken, it should be ventilated in time and wear gloves for clean up.
IMPORTANT INFORMATION
INSTALLATION DIAGRAM
LAMP SHOULD ALWAYS BE INSTALLED AND OPERATED FACING DOWNWARD
Safety Precautions:
The following basic safety measures must be observed at all stages of operation, maintenance and repair of this equipment. Failure to
observe these measures may affect the basic protection provided by the equipment and will void warranty.
1. Please use under the conditions described by this manual.
2. Unauthorized use of this product is strictly prohibited.
3. Electrical components can not be opened or repaired.
4. Connect to singular power source preferrably with GFI.
5. This product is not waterproof, please do not use this product in areas where it could get wet.
6. Do not use this product near fire, and do not hit or shake this product.
7. Strong ultraviolet rays are harmful to the human body, please pay attention to ultraviolet radiation. When using, it is strictly prohibited to
directly irradiate the human body with ultraviolet rays.
8. Wear protective glasses and clothing as necessary to avoid direct exposure to human skin, mucous membranes and eyes.
9. It is strictly prohibited to use in places where flammable and explosive substances are stored.
10. The power plug should be unplugged during maintenance or stand by.
11. The storage environment should be :Relative humidity S:80%

WARRANTY
AQUA ULTRAVIOLET | 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 | TEL: [phone] or [phone]
WARRANTY INFORMATION - DYNAMIC UV AIR STERILIZER
LIMITED LIABILITY 12 MONTHS FROM DATE OF PURCHASE - MUST HAVE COMPLETED WARRANTY CARD AND PROVIDED ORIGINAL
INVOICE
Aqua Ultraviolet systems are warranted against failure due to defects in materials and/or workmanship during the warranty period.
This warranty covers defects that may occur under normal use and applies to the original retail purchaser and may not be transferred.
The warranty and remedies set forth herein are conditional upon proper storage, installation, use, maintenance and conformance with the
applicable use.
It will be based upon Aqua Ultraviolet’s discretion as to whether the defects are of manufacturing origin.
This warranty does not apply to appearance or accessory items.
This warranty does not include damage due to shipping and handling, transportation, unpacking, set up, installation, improper maintenance,
incorrect line voltage, modification, abuse, misuse, neglect, accident, fire, flood, acts of God or repair or replacement of parts supplied by anyone
other than Aqua Ultraviolet.
Any oral statements about this product made by the seller, the manufacturer, their representatives or any other party does not constitute warranties
and shall not be relied upon by the user and are not part of this contract.
Neither the seller nor the manufacturer shall be liable for any injury, loss or damages, direct, incidental or consequential including but not limited to
lost profits, lost sales, injury, inability to use the product and the user agrees that no other remedy is available. Before installing, the user shall
determine the suitability of the product for their intended use and the user shall assume all risk liability whatsoever in connection therewith.
To validate this warranty, mail the enclosed warranty card within 10 days of purchase or register online at www.aquauv.com/support/
productregistration.
To have warranty work done the original receipt must be provided.
Warranty Period:
Dynamic UV Air Sterilizer - Complete Unit: One year from the date of purchase.
Limitations:
Warranty does not cover any malfunction from improper installation - System is easily set up, but instructions must be followed, every unit has
been pretested to ensure all parts fit and operate.
Warranty only applies to the original end user and is not transferable.
Warranty does not cover repairs done by anyone other than Aqua Ultraviolet.
Warranty is void not utilized on individual power source with GFI connector.
Warranty may not be modified by verbal statements by Aqua Ultraviolet, distributors, retailers, their agents or any other party.
Warranty covers the repair or prorated replacement of the Aqua Ultraviolet products.
Aqua Ultraviolet denies all liability for any other loss including but not limited to loss of equipment, income, livestock, pets, aquatic life or personal
injuries.
There are no warranties on broken Lamps.
The user is responsible for Shipping Charges on any Items returned to the Manufacturer on Warranty Assessments.
Warranty is voided by the following:
Product labels defaced or removed.
Product has been painted or altered.
Product is improperly installed or maintained by user or agent.
Product abused, misused or damaged by user or their agent.
Product damage caused by electrical surges, electrical spikes, electrical brown outs or improper voltage.
Electrical cord has been cut.
Use of anything other than genuine Aqua Ultraviolet Parts.
Any implied warranty granted under state law including warranties of merchantability or fitness for a particular purpose are limited to one year from
the date of purchase or as otherwise stated in the above warranty. Aqua Ultraviolet is not responsible for direct, indirect, incidental or
consequential damages. Some states do not allow limitations on how long an implied warranty lasts and/or does not allow the exclusions or
limitations of incidental damages so the above limitation and exclusion may not apply to you. This warranty gives you special legal rights and you
may also have other rights that vary from state to state.
Warranty Returns or Repair Returns: Please call Aqua Ultraviolet at [phone] for a “Return Merchandise Authorization” (RMA) number, or
email [email protected]. You must have a valid RMA from an Aqua Ultraviolet customer service representative before sending any product in for
warranty or repair. Please have your serial number, date of purchase, original Invoice and product type available when calling for an RMA number.
All warranty returns or repair returns must come freight prepaid with an RMA number clearly marked on the outside of the box. All other returns will
be refused. Aqua Ultraviolet will not be liable for any shipping cost to return warranty or repair items. Include a note in the box with your RMA
number, name, address, daytime phone number and brief description of the reason for return or repair.
5

TRIPOD INSTALLATION
6
AQUA ULTRAVIOLET | 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 | TEL: [phone] or [phone]
WARRANTY CONTINUE
Be sure to return product in the same packing or similar packing and insure the package (we recommend sending it UPS). If you do not have or
can not locate proper packaging, please call our customer service department and we will send you packaging for a minimal charge.
Aqua Ultraviolet shall not be responsible for damage or loss done by the shipper. Nor shall Aqua Ultraviolet be responsible for merchandise
that arrives damaged due to improper packaging. All claims for loss and damage must be filed by the customer with the shipper.
If the unit is found to be out of warranty we will contact you with the cost of repair. Your authorization is required prior to making any repairs &
return shipping is at the cost of the customer
If the unit is found to be in good order and operational, it will be returned back to the customer, shipping to be paid by the customer.
EYEBOLT BASE INSTALLATION

08282020
EPA Est 68177-CA-001
MAILING ADDRESS
PO Box 2189
Temecula, CA 92593
MAIN OFFICE
42371 Avenida Alvarado
Temecula, CA 92590
Toll Free: [phone]
Tel: [phone]
www.aquauv.com
