Aqua Ultraviolet STATUARY 8 Watt 1/L User manual

42371 Avenida Alvarado
Temecula, CA 92590
TOLL FREE [phone]
TEL [phone]
FAX [phone]
www.aquauv.com
Aqua Ultraviolet
UV Sterilizer Instruction Manual for Statuary UV’s

Returning the product is expensive and time consuming for you, your retailer and for us, the
manufacturer. Should you encounter any problems with your product, please call our toll free
“HELP” line for assistance. PLEASE DO NOT return your product to the store! Your dealer
or distributor cannot offer any warranty work or exchanges on your product.
TABLE of CONTENTS
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Ultraviolet Works. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sizing Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Pond Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Frequently Asked Questions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trouble Shooting Leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winterizing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clean Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning or Changing the Quartz Sleeve. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Incorrect Installations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
1
2
2
3
3
4
5
6
7
8
11
12
12
13
17
20
IMPORTANT INFORMATION
THANK YOU FOR PURCHASING
THE BEST STATUARY UV
IF YOU HAVE ANY QUESTIONS
WE WILL BE HAPPY TO HELP
In the US please call
TOLL FREE 1 - 800 - 454 - 2725
[phone] Outside the U.S.
THANK YOU!

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
1
WARRANTY INFORMATION
Aqua Ultraviolet systems are warranted against failure due to defects in materials and/or workmanship during the war-
ranty period. This warranty covers defects occurring under normal use and applies to the original retail purchaser and
may not be transferred. The warranty and remedies set forth herein are conditional upon proper storage, installation, use,
maintenance and conformance with the applicable use. It will be based upon Aqua Ultraviolet’s discretion as to whether
the defects are of manufacturing origin. Any damages due to shipping and handling, packing, or installation are not cov-
ered by this warranty.
This warranty does not apply to appearance or accessory items. This warranty does not include damage due to handling,
transportation, unpacking, set up, installation, improper maintenance, incorrect line voltage, modification, abuse, misuse,
neglect, accident, fire, flood, acts of God or repair or replacement of parts supplied by any other than Aqua Ultraviolet.
Any oral statements about product made by the seller, the manufacturer, their representatives or any other parties do not
constitute warranties and shall not be relied upon by the user and are not part of this contract.
Neither the seller nor the manufacturer shall be liable for any injury, loss or damages, direct, incidental or consequential
including but not limited to lost profits, lost sales, injury, inability to use the product and the user agrees that no other rem-
edy is available.
Before installing, the user shall determine the suitability of the product for their intended use and the user shall assume
all risk liability whatsoever in connection therewith.
To validate this warranty, mail the enclosed warranty card within 10 days of purchase along with proof of purchase (copy
of sales receipt).
Warranty Period:
Housing: Limited lifetime warranty on housing against Ultraviolet degradation.
Complete Unit: One year from the date of purchase or 18 months from manufacturing date.
Limitations:
Warranty does not cover any malfunction from improper installation (we recommend that a licensed
electrician install your system to the specifications outlined in this owners guide).
Warranty only applies to the original end user and is not transferable.
Warranty does not cover repairs done by anyone other than Aqua Ultraviolet.
Warranty is void if system is not plugged into a G.F.C.I. (Ground Fault Current Interrupter).
Warranty may not be modified by verbal statements by Aqua Ultraviolet, distributors, retailers, their
agents or any other party.
Warranty covers the repair or prorated replacement of the Aqua Ultraviolet products. Aqua Ultraviolet
denies all liability for any other loss including but not limited to loss of equipment, income, livestock
or personal injury.
There is no warranty on the Quartz Sleeve.
There is no warranty on broken lamps. Lamps are prorated by usage.
Warranty is voided by the following:
Product labels defaced or removed.
Housing has been painted.
Product is improperly installed or maintained by user or agent.
Product abused, misused or damaged by user or their agent.
Product damage caused by electrical surges, electrical spikes, electrical brown outs or
improper voltage.
Electrical cord has been cut.
Unit was run without water.
Any implied warranty granted under state law including warranties of merchantability or fitness for a particular purpose
are limited to one year from the date of purchase or 18 months from the date of manufacture or as otherwise stated in
the above warranty. Aqua Ultraviolet is not responsible for direct, indirect, incidental or consequential damages. Some
states do not allow limitations on how long an implied warranty lasts and/or does not allow the exclusions or limitations
of incidental damages so the above limitation and exclusion may not apply to you. This warranty gives you special legal
rights and you may also have other rights that vary from state to state.

INTRODUCTION
AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
We at Aqua Ultraviolet would like to take the time to thank you for purchasing the finest Ultraviolet
System on the market.
For over thirty years, Aqua Ultraviolet has manufactured Ultraviolet Systems used in various industries,
including aquaculture, public and commercial aquariums, educational institutions, government agencies and
research organizations throughout the world.
Aqua Ultraviolet Sterilizers are used as a control to destroy single celled organisms, water borne bacteria,
viruses, algae, fungi and protozoa. Aqua Ultraviolet sterilizers are recommended for both fresh and salt water
systems as well as ponds. There are no residual effects when using an Aqua Ultraviolet Sterilizer. Ultraviolet
will not affect Bio-filters or lower fish immune systems!
HOW ULTRAVIOLET WORKS
The Ultraviolet Lamp emits a germicidal ray which alters or disrupts the DNA or RNA of single celled organ-
isms such as algae, bacteria and protozoa. By properly implementing an Aqua Ultraviolet System in-line,
these organisms can be eradicated effectively without any harmful residuals.
Your Aqua Ultraviolet System was made to work as a control for green water and single celled organisms.
This unit will not, nor will any other Unit, completely Sterilize your pond as the pond itself is not a Sterile
Environment. As a control, this unit will effectively lower your water's bacterial count allowing your fish to stay
healthier with less risk of disease.
The Aqua Ultraviolet Sterilizer works better on filtered water. Any debris in the water can inhibit UV
Tansmission.
CAUTION: READ ALL INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION OR
OPERATION.
The manual should answer most of the questions that you may have about the installation, operation and use
of your new Aqua Ultraviolet Sterilizer. View our installation videos at www.aquauv.com. If you need technical
support, we offer this service for free by telephone [phone], or by fax [phone] M-F
8:00 am - 4:30 pm Pacific Standard time except selected holidays. You may reach us through the web at
www.aquauv.com.

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
3
RECOMMENDED EQUIPMENT PLACEMENT LAYOUTS
For optimum pond quality it is recommended that the pond water be turned
over at least once an hour or a minimum of every 1-1/2 hours.
Sizing
STATUARY UV 120 Volt
Amp Draw
Size Fresh Water Pond
Clarifier In Gallons
GALLONS GPH / GPM
Size Fresh
Water
Sterilizer
In Gallons
30,000
mw/cm2
(EOL)
GPH
8 Watt 1/L 0.48 1,500 1,000 / 16.7 5-200 642 / 10.7
15 Watt 1/L 0.48 2,000 1,800 / 30 200-500 700 / 11.7
25 Watt 1/L 0.48 4,000 2,000 / 33.3 500-1,200 1,200 / 20
Use the sterilizer column for crystal clear water and bacterial control, in pond
environments.
Sterilizer numbers are based on turning the water over a minimum of 1 to 1-1/2
times per hour for optimal results.
Use the clarifier column when the pond is partially in shade and has 50% plant
coverage. This will improve water clarity resulting in a natural looking water
garden environment.
Clarifier numbers are based on turning the water over every 2 to 3 hours.
UV dosage is calculated at the end of lamp life (14 months).

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
Where do I install my UV?
The best place to install your Aqua Ultraviolet Sterilizer is after the filter. If an after the filter installa-
tion is not feasible, your sterilizer can be installed before the filter, but it will take a little longer to work.
If installed before the filter, be aware that a small rock passing from the pump can break the quartz
sleeve. It is recommended that if you install your unit before your filter, you check the UV periodi-
cally for any water leakage due to a broken quartz sleeve. Be sure to have adequate pre-filtration to
prevent breakage of the quartz sleeve (A broken quartz sleeve and any damage caused by a broken
quartz sleeve is not covered under warranty.)
Do I have to turn my UV off when I clean my filter?
Yes, but only if the chamber is drained or if the water will remain at a stand still for more than 30
minutes. Note: Running longer than the recommended time without water flow can cause extensive
damage to the unit.
What should I expect after my UV is installed?
If your Aqua Ultraviolet system is installed after the filter and is properly sized the water should be
clear in 3-5 days. If your Aqua Ultraviolet system is installed before the filter the water should be clear
in 7-10 days. The green algae on the sides and bottom of the pond will not disappear, this is normal
and beneficial in a pond. The UV will only control free floating algae.
What’s the difference between a sterilizer and a clarifier?
As a sterilizer, your Aqua UV system will keep your pond water crystal clear. You will have the added
benefit of bacterial control which will help keep your fish healthy by reducing the risk of spreading-
disease.
To use your UV as a clarifier and get crystal clear water you will need 50-75% plant coverage or full
shade. Without plants and shade the clarifier will give a natural green tint to your pond.
What should my flow rate be on my pond?
The optimum flow rate on your pond is to turn over the volume of water a minimum of 1 to 1-1/2
times per hour.
Is this unit submersible?
No, not this specific series.
Does the UV light have any residual effect to the fish?
No, UV only affects what passes through the chamber. There is no residual effect from UV light.
Does the UV kill good bacteria?
Ultraviolet light does not discriminate about what it destroys. If good bacteria passes by the light
it will be destroyed. Beneficial bacteria are colonized in your filter, along the sides and bottom of
your pond. The only time these will be affected is if they become free floating and pass thru the UV.
Frequently Asked Questions

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
5
Parts List
STATUARY TRANSFORMERS
Transformer
Davis Connector Lamp End
Connector
Transformer Cap
TM
Transfomer Parts List
PART # DESCRIPTION PART # DESCRIPTION
A30019 Frog / Fish 8 Watt Transformer A40109 Davis Connector
A30020 Frog / Fish 15 Watt Transformer A40113 Transformer Cap Black
A30021 Frog / Fish 25 Watt Transformer A40002 Lamp End Connector
Parts List
PART # DESCRIPTION PART # DESCRIPTION
A40000 Quartz Cap, Black A40072 3/4” Threaded Plug
A40004 Rubber Seal, Purple A40074 2” Clean Out Plug
A40108 Threaded Connector A40054 3/4” Male Barb
UV

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
1. Choose a location at the edge of the pond and make sure that the Statuary UV is
set on a stepping stone or rm ground. It is important to make sure that the edge of
the pond will not become water logged. This unit is not submersible and should be
situated so that it cannot sit in or fall into the water.
2. Insert the Male Barb in either the front or the
back of the Statuary Unit. Insert the 3/4
Threaded Plug into the unused port.
3. The Barb can be either ½” or ¾”
5. Before you install the UV Lamp, Transformer and plug in the electrical cord a Leak
Test must be conducted.
4. Connect to your existing pump with a exible hose and secure with hose clamps
(hose clamps are not included, purchase separately along with your hose).
6. LEAK TEST: Do not install Lamp or electrical components yet. After all the hose
connections have been made, turn the pump on and run it for five minutes to
check for leaks.
a. If you have a leak, return to Trouble Shooting Leaks on page 7. Carefully examine the
unit after installation. This unit should not be plugged in if there are any leaks on any
part of the unit.
b. If there are no leaks, continue with electrical installation.
Statuary Installation Instructions

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
7
Trouble Shooting Leaks
1. Place Teon tape on the threads and re-tighten.
LEAKS FROM THE MALE BARB OR
3/4” THREADED PLUG
LEAKS FROM THE CLEAN OUT PLUG
2. Place Teon tape on the threads and re-tighten.
LEAKS FROM THREADED CONNECTOR
3. Place Teon tape on the threads and re-tighten.
LEAKS FROM THE QUARTZ CAP / RUBBER SEAL
4. Undo Quartz Cap and push Rubber Seal into the
body of the Statuary Unit evenly. Half the Rubber
Seal will still be in view. Screw on the Quartz Cap
and hand tighten. Do not use a pipe wrench, pliers
or any other tool. Hand-tighten only.
LEAKS FROM THE CENTER OF THE QUARTZ SLEEVE
5. The Quartz Sleeve is broken and needs to be
replaced. Neither the broken Quartz Sleeve nor any
damage caused as a result of a broken Quartz Sleeve
is covered under warranty. Contact your dealer for a
replacement. (See Changing the Quartz Sleeve on
page 17).

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
Electrical Installation
1. Unscrew the Davis Connector located just above the Transformer Cap. This will
allow the Transformer Cap to turn without kinking the electrical cord.
NOTE: The Lamps and Quartz Sleeves should be handled with care. Lamps and
Quartz Sleeves are not warranted against breakage and damage.
2. Prevent nger marks on the lamp. If you touch the Lamp use denatured alcohol and
a soft cloth to clean the lamp.
4. To install the Lamp place the Statuary Unit on a sturdy work area with the mouth
facing down.
3. Plug the Lamp into the Transformer; make sure the Lamp is plugged in all the way
and ush with the Lamp End Connector.
WARNING: Be careful when installing the Lamp. If the Lamp is not plugged in all the way this
may cause damage to the Unit and is not covered under warranty, nor is any other damage
caused by improper installation.
Davis Connector
Transformer Cap
Wire
Lamp End Connection
Lamp End Connector

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
9
5. Slide the Lamp straight into the Statuary Body. An angle, even a slight angle may
cause a “U” shaped crack at the end of the Quartz Sleeve, or possible breakage of
the Lamp. If this should happen, do not proceed with the installation. Purchase a
new Quartz Sleeve or Lamp from your dealer. Do not force the Lamp into the Quartz
Sleeve; any force would be an indication of an improper installation
6. Twist on the Transformer Cap. Do not over tighten. This is a connection only
and is not in contact with water. Do not use a pipe wrench, pliers or any other
tool, hand tighten only.
Electrical Installation
CAUTION: Do not look at or handle UV Lamps when lit outside of the housing. Considerable Ultraviolet Energy
is emitted which may produce severe sunburn and/or conjunctivitis. As long as the UV Light is in its housing it is
100% safe for humans and sh.
NOTE: The average life expectancy of Aqua Ultraviolet Lamps is 14 months of continuous operation. After 14
months the Lamp may still light, but the germicidal rays are diminished. Be sure to change your Lamp after 14
months of use.
NOTE: We recommend that the Statuary UV be used in Continuous Operation 24 Hours a Day, 7 days a
week. Frequent Starts and Stops may shorten the life of your Lamp.
WARNING: If you are medicating your sh, we recommend shutting down the Sterilizer as the UV Radiation
may affect the treatment.
CAUTION: Do not use the Aqua Ultraviolet Sterilizer for anything other than its intended use.
7. Tighten the Davis Connector located just above the Transformer Cap.

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
a. If you have a leak, return to Trouble Shooting Leaks on page 7.
Carefully examine the Unit after installation. This Unit should not
be plugged in if there are any leaks on any part of the Unit.
b. If there are no leaks, turn on power.
9. FINAL LEAK CHECK: Do not plug the Sterilizer into power yet, turn on pump and
check for leaks again.
Electrical Installation
CAUTION: G.F.C.I. Information: The warranty is null and void if the Statuary Unit is not
plugged into a G.F.C.I. (Ground Fault Circuit Interrupter). A Surge Suppressor should be
added for extra protection, it is not required, but recommended.
CAUTION: Improper connection of the equipment to a grounding conductor can result
in the risk of electrocution. Check with a qualied electrician or service person if there
is any doubt the outlet is being properly grounded. Do not modify the plug provided
with the Unit; if the plug does not t the outlet have a proper outlet installed by an elec-
trician
8. Turn Statuary Unit upright and place into position at ponds edge
CAUTION: Do not lay the Transformer on the ground. Prevent the Transformer from lying in standing
water.
CAUTION: Do not operate the Unit if it has a damaged cord or plug, if it is malfunctioning, or if it
has been dropped or damaged in any manner.
CAUTION: If the Unit falls into the water, DO NOT reach for it. First unplug the Unit and then retrieve it. If
the electrical components of the Unit get wet unplug the unit immediately.
.
CAUTION: If an extension cord is necessary a cord with a proper rating should be used, a cord rated for
fewer amperes or watts than the Unit rating may overheat. Care should be taken to arrange the cord so
that it will not be tripped over or pulled.

AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
11
Filter Installation
Filters can be incorporated with the Statuary UV. Follow the lter manufacturers
installation instructions on how to connect the lter to the pump.
1. On the return line from the lter or pump attach a 1/2” or 3/4” hose to the Barb.
3. Cut and size hose, connect to the Statuary UV and the pump with hose clamps do
not over tighten. Keep this run as short as possible to avoid kinks or bends. The
pump should be as far away from the Statuary UV as possible for optimal water
circulation. Keep in mind the length and run of the needed hose when purchasing,
measuring and cutting.
2. Install either to the back or front of the Statuary UV. Insert the 3/4” Threaded Plug
into the unused port.

Winterizing
CAUTION: Always turn off the pump and disconnect electricity from the Unit prior to any
maintenance.
1. Protect the Statuary UV from frost or freezing. In cold weather the Statuary UV
should be unplugged, drained of water and the lamp removed and stored in a dry
area. Do not allow unit to be exposed to freezing temperatures, severe damage
and or breakage to the Unit, Lamp and or Quartz Sleeve may result and is not
covered under warranty
Clean Out Plug
1. Unplug the Unit from power
2. Remove the Lamp and Transformer
Refer to page 13
4. Place the Statuary Unit on a sturdy work area with
the mouth facing down. Unscrew Clean Out Plug to
get out any debris when necessary.
AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
3. Drain the water out.
Clean Out Plug

Changing the Lamp
2. Place the Statuary Unit on a sturdy work area with the mouth facing down.
1. Unplug the Statuary Unit from power source and drain the water out.
3. Unscrew the Davis Connector located just above the Transformer Cap. This
will allow the Transformer Cap to turn without kinking the electrical cord.
CAUTION: Always turn off the pump and disconnect the electricity from the unit prior to any
maintenance.
WARNING: Use only genuine AQUA ULTRAVIOLET replacement parts when changing your
lamp. This is a specialized lamp, while others may look similar they are not the same. Other
lamps will not produce the same result and can damage your Statuary UV.
13 AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
4. Twist off the Transformer Cap.

5. Slide the Lamp out of the Statuary Body. An angle, even a slight angle may cause
a “U” shaped crack at the end of the Quartz Sleeve, or possible breakage of the
Lamp. If this should happen, do not proceed with the installation. Purchase a new
Quartz Sleeve or Lamp from your dealer. Do not force the Lamp out of the Quartz
Sleeve; any force would be an indication of an improper removal.
Changing the Lamp
6. Unplug Lamp from Transformer and discard the Lamp.
NOTE: The Lamp and Quartz Sleeve should be handled with care. Lamps and
Quartz Sleeves are not warranted against breakage and damage.
7. Prevent finger marks on the new Lamp. If you touch the Lamp use denatured
alcohol and a soft cloth to clean it.
8. Plug the new Lamp into the transformer; make sure the Lamp is plugged in all the
way and ush with the Lamp End Connector.
WARNING: Be careful when installing the Lamp. If the Lamp is not plugged in all the way
this may cause damage to the Unit and is not covered under warranty, nor is any other
damage caused by improper installation.
14
AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]

9. Slide the Lamp straight into the Statuary Body. An angle, even a slight angle may
cause a “U” shaped crack at the end of the Quartz Sleeve, or possible breakage
of the Lamp. If this should happen, do not proceed with the installation. Purchase a
new Quartz Sleeve or Lamp from your dealer. Do not force the Lamp into the
Quartz Sleeve; any force would be an indication of an improper installation
10. Twist on the Transformer Cap. Do not over tighten. This is a connection only
and is not in contact with water. Do not use a pipe wrench, pliers or any other
tool, hand tighten only.
CAUTION: Do not look at or handle UV Lamps when lit outside of the housing. Considerable Ultraviolet Energy
is emitted which may produce severe sunburn and/or conjunctivitis. As long as the UV Light is in its housing it is
100% safe for humans and sh.
NOTE: The average life expectancy of Aqua Ultraviolet Lamps is 14 months of continuous operation. After 14
months the Lamp may still light, but the germicidal rays are diminished.Be sure to change your Lamp after 14
months of use.
NOTE: We recommend that the Statuary UV be used in Continuous Operation 24 Hours a Day, 7 Days a week.
Frequent Starts and Stops my shorten the life of your Lamp.
WARNING: If you are medicating your sh, we recommend shutting down the Sterilizer as the UV Radiation may
affect the treatment.
CAUTION: Do not use the Aqua Ultraviolet Sterilizer for anything other than its intended use.
Changing the lamp
15 AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
11. Tighten the Davis Connector located just above the Transformer Cap.

a. If you have a leak, return to Trouble Shooting Leaks on page 7.
Carefully examine the Unit after installation. The Unit should not be
plugged in if there are any leaks on any part of the Unit.
b. If there are no leaks, turn on power.
13. FINAL LEAK CHECK: Do not plug the Sterilizer into power yet, turn on pump and
check for leaks again.
CAUTION: G.F.C.I. Information: The warranty is null and void if the Statuary Unit is not
plugged into a G.F.C.I. (Ground Fault Circuit Interrupter). A Surge Suppressor should be
added for extra protection, it is not required, but recommended.
CAUTION: Improper connection of the equipment to a grounding conductor can result
in the risk of electrocution. Check with a qualied electrician or service person if there
is any doubt the outlet is being properly grounded. Do not modify the plug provided
with the Unit; if the plug does not t the outlet have a proper outlet installed by an elec-
trician
CAUTION: Do not lay the Transformer on the ground. Prevent the Transformer from lying
in standing water.
12. Turn Statuary Unit upright and place into position at ponds edge
CAUTION: Do not operate Unit if it has a damaged cord or plug, if it is malfunction-
ing, or if it has been dropped or damaged in any manner.
CAUTION: If the Unit falls into the water, DO NOT reach for it. First unplug the Unit
and then retrieve it. If the electrical components of the Unit get wet unplug the Unit
immediately.
CAUTION: If an extension cord is necessary a cord with a proper rating should be
used, cord rated for fewer amperes or watts than the Unit rating may overheat. Care
should be taken to arrange the cord so that it will not be tripped over or pulled.
Changing the Lamp
16
AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]

Cleaning or Changing the Quartz
17
2. Place the Statuary Unit on a sturdy work area with the mouth facing down.
1. Unplug the Unit from power and drain the water out.
3. Unscrew the Davis Connector located just above the Transformer Cap. This
will allow the Transformer Cap to turn without kinking the electrical cord.
CAUTION: Always turn off the pump and disconnect the electricity from the Unit prior to any
maintenance.
AQUA ULTRAVIOLET 42371 AVENIDA ALVARADO, TEMECULA, CA 92590 TEL: [phone] FAX: [phone]
4. Twist off the Transformer Cap.
