1. General Description
The "SensoDirect" is a small, handy measurement
device, which can be used anywhere where conduc-
tivity has to be measured quickly and accurately. The
unit is very easy to use and is fitted with a digital dis-
play, reading to 2 decimal points. The measurement
range is 0 - 10.00 mS/cm. Because conductivity meas-
urement is dependent on temperature, the unit has a
manual temperature compensation facility, from
0 - 100 °C.
2. Products supplied
• SensoDirect Basic unit, including electrode
• carrying case
• operating instructions
3. Setting to work
The unit is supplied as standard with a battery and is
therefore ready for immediate use, once the cinch
connector plug to the pH electrode is inserted into its
socket. The unit is switched on and off with the red
push-button to the side of the electrode connection.
4. Calibration
To ensure optimum accuracy of measurement, the unit
should be calibrated regularly. Determine the
temperature of the calibration solution and turn the
right-hand knob (the temperature compensation
control) to set the temperature which has been
determined : 1 line-mark is roughly equivalent to 10°C.
Rinse the electrode in fully demineralized water, dry it

5
carefully and immerse it in the calibration solution,
moving it gently to and fro so that any trapped air
bubbles can escape through the side openings. Wait
for some 15 to 20 seconds (until the display stabilizes)
and then turn the left-hand knob (Adjust mS/cm) to
set the appropriate figure.
To achieve optimum measurement accuracy from the
system, adjustments should be made until the
adjustment figure and the expected measurement
figure are in the same range. This may cause accuracy
over the total measurement range to reduce slightly
under certain circumstances.
To maintain the instrument specification, adjustments
in the factory are made using a 0.05 molecular KCl
solution at a temperature of 25°C (6.7 mS/cm).
5. Carrying out measurements
First of all, determine the temperature of the medium
to be measured and set the appropriate temperature
by turning the right-hand knob. Then rinse the electrode
thoroughly in fully demineralized water and dry it
carefully. Immerse the electrode in the medium to be
measured and move it gently to and fro. Wait for some
15 to 20 seconds (until the display stabilizes) and then
read the figure in the display. Always wash the electrode
in fully demineralized water when measurements have
been completed.
NOTE :
The display reads in mS/cm.
1 mS/cm = 1000 µS/cm / 0.1 mS/cm = 100 µS/cm
Overrange is indicated by three decimal points in the
Display, e.g. 1.4.1.4 .

6
6. Overhaul & Maintenance
Conductivity electrodes do not generally deteriorate
with age. However, their life and performance can be
reduced by deposits, contamination or mechanical
damage. It is therefore recommended that the
electrode be cleaned from time to time in warm water,
using a small brush with great care.
The electrode must NEVER come into contact with
any water-repellent substances (oils; greases;
silicones).
7. Changing the Battery
If "BAT" appears in the bottom left corner of the display,
the battery is flat and must be replaced. Remove the
back of the unit by loosening the 6 screws and replace
the battery.
Due to the electronic design the „BAT“ indication
disappears if the battery is nearly empty. Readings
under these conditions are faulty.
8. Spare Parts / Accessories
Article No. Description
42 12 15 Conductivity calibration solution
1413 µS/cm (250 ml)
42 12 16 Conductivity calibration solution
6,7 mS/cm (250 ml)

7
9. Technical Data
Measurement range: 0 - 10,00 mS/cm
Resolution: 0,01 mS
Accuracy: +/- 2,5 % of range +/- 1 digit (Inst.)
Electrode: PETP shaft; Electrode material: graphite
Ambient conditions: 0 - 45 º C
0 - 80 % relative humidity
(non-condensing)
Power supply: 9 V pack; ca. 100 operating hours
Housing: ABS plastic housing
Dimensions: 165 x 95 x 42 mm (LxBxH)
Weight: ca. 280 g (without electrode)
Certified: CE
Cat. No.: 418 819
Temperature
Compensation: 0 - 100°C, manual

8
9. Short Instructions
Temperatur
CAL.
Sensor
Dry
Dry
General
3
ON
OFF
ON/OFF
1
2
Instrument
CAL
0
46
10
28
°C
0
40 60
100
20 80
Range: 0.00 - 10.00 mS/cm
Resolut on: 0.01 mS/cm
Accuaracy: ± 2.5 % F.S. ± 1 D g t (Instrument)
Amb ent 0 - 45°C
Cond t ons: 0 - 80% rel. hum d ty
(no condens ng)
Sample
Cond t ons: 0° - 80° C
Battery: 9 V (IEC 6F22)
CE: 89/336/EN
(add. Tolerance < 1%)
Sensor
Clean
Deonzed
Water
Adjust
Temperature
Value
Read
SAMPLE
225°
25°
Measurement
CAL
0
46
10
28
°C
0
40 60
100
20 80
Sensor
Clean
Deonzed
Water

9
Calibration
Clean
Deionized
Water
Dry
Measurement
Maintenance
Remove
6 screws
9 V
Replace
9 V Battery
Typ IEC 6F22
Don`t
touch
LOW BAT
D splay
Remove battery f nstrument s unused for a long t me.
Clean
Deionized
Water
Dry
CAL
Adjust
mS/cm
6.70
D splay
0.05 mol/l
KCl
2
25°
1
Adjust
Temperature
25°
CAL
0
46
10
28
°C
0
40 60
100
20 80

10
