Aquasana EQ-400 User manual

Owner’s Manual
CITY WATER
EQ-400
Whole House
Water Filter
Rhino®

TABLE OF CONTENTS
Box Contents ................................................................................................................ 1
System Conguration.................................................................................................. 2
Use & Care .................................................................................................................... 3
Installation Steps......................................................................................................4–6
Performance Data Sheet............................................................................................. 7
Warranty ....................................................................................................................... 8
Water for Life® Program.............................................................................................. 9
Meet clean, healthy water. Your new Aquasana®whole house Rhino®
system was expertly engineered to reduce contaminants, including
chloramines, from the water throughout your entire home.
Enjoy the peace of mind that comes from knowing our award-winning
water lter technology is working for you.
Whole House Water Filter
Rhino®
EQ-400

BOX CONTENTS 1
10" Pre-Filter
10" Post-Filter
Shut-O Valve
(Not included with Pro-Kit)
3" Nipples (6)
Slip Unions (3)
Garden Hose
Adapter
WrenchSupport Bracket (2)
• Drill
• Wrench
• Channel locks
• PVC pipe cutter
Tools recommended for installation:
Parts and pieces included with your system will vary depending on your specic order.
Please call Customer Service with any questions or concerns 866-662-6885.
OPTIONAL UPGRADE
Professional Grade Install Kit
20" Pre-Filter
Pex Support
Brackets (2)
Brass
Valves (3)
Brass "T"
Fittings (2)
Brass
Adapters (2)
• NSF approved PVC primer and glue
• NSF certied plumber's tape
• Copper wire & grounding clamps
(if copper pipes are present)
Not NSF Certied
Rhino® Tank

2SYSTEM CONFIGURATION
2
If you have added components to your Rhino® Water Filter System,
note the correct sequencing below.
(Installation shown below includes Professional Grade Install Kit)
Salt-Free Water
Conditioner
(Optional)
Rhino® Water
Filter System
10" Post-Filter
10" Pre-Filter
20" Pre-Filter
(Pro-Kit only)
UV Filter
(Optional)
Before installing
• Lay out system in appropriate conguration. Improper sequence
of equipment will aect performance, and could possibly damage
your system.
• For all installations: Anticipate the need for additional parts and pieces
including but not limited to pex tubing, clamps and mounting screws to
install unit properly (available at a local home improvement stores or
through your plumbing contractor). Due to the varieties of home design,
not all congurations can be addressed in this guide.
• DO NOT install this lter where the line pressure may exceed 100 psi.
The operating pressure range for this lter is between 20psi – 100psi.
• Install on cold water lines only (40° – 90°F).
• Installation of the ltration system must comply with existing state and
local plumbing codes. Aquasana and its manufacturer are not liable for
consequential or incidental damages due to improper installation.
• DO NOT install the unit on its side. It must be installed upright
to maximize contact with media bed.

2USE & CARE 3
Read all precautions and installation instructions carefully and completely
before installing.
Precautions
• Properly tighten all ttings to
ensure a leak-free assembly.
• NSF certied plumber's tape (thread
sealing tape) is the only sealer that
can be used on threaded ttings.
DO NOT use pipe dope or PVC
primer/glue on threaded ttings.
Exposure to these compounds will
damage nipples causing leaks.
• Pick an appropriate installation
location. Dimensions of systems
vary—always allow an estimated
minimum of 60” clearance for
height of tank, and a minimum
of 45” for oor space.
• Unit must be installed in an area
where the main water line enters
your home, before connecting to
the water heater. DO NOT install
after a water heater or on the
hot water line.
• It is recommended your system
be installed indoors and out of
direct sunlight. Prolonged
exposure to light can weaken
plastic components, resulting in
lter housing failure. If this is not
possible and the system is outdoors
or in a sunny area, the unit must be
protected from both direct sunlight
and freezing temperatures.
• If installing on metallic plumbing,
two grounding clamps and #4
copper wire are essential for safety.
• Some local codes may require
the use of a licensed plumber or
certied installer when disrupting
a potable water line.
• In areas with high pressure, a
pressure relief valve and a water
hammer arrestor may be necessary.
Cleaning
The exterior of your ltration
system can be cleaned with warm,
soapy water. Rinse well with fresh,
clean water.
A Pre-Filter is included with your
system. Sediment levels vary from one
location to another. It is recommended
to replace your Pre-Filter every 2
months. If the ow rate has noticeably
decreased, replace your lter cartridge
sooner.
Specications
This lter system is designed and
tested for use with genuine Aquasana
parts including replacement lters and
all hardware. Use of parts from other
manufacturers may result in loss of
contaminant reduction performance,
system damage or failure. Use of parts
from other manufacturers will also
void your warranty. Please visit
aquasana.com for replacement parts.
Model: EQ-400
Replacement tank: EQ-400R
Additional Replacements:
20" Pre-Filter: EQ-304-20
10" Pre-Filter: EQ-304
10" Post-Filter: EQ-PFC.35
UV Lamp: AQ-UV-L330C
Salt-Free Conditioner: EQ-AST-WH-R-C
NOTE: Never use chemical
cleaning products on the system’s
exterior surface as they may
damage the housing.

44
Pre-Condition Rhino Tank
Select Location
1. Pick an appropriate installation location. Unit must be installed in an
area where the main water line enters your home, before connecting
to the water heater.
2. Turn o the main water source prior to installation. Drain water from
lines to relieve pressure by turning on a faucet inside your home.
NOTE: DO NOT install after the water heater or on the hot water line.
Components and installation will vary.
NOTE: It’s imperative that this system is ushed properly prior to nal installation.
The granular carbon used in the bottom tank contains 1-2% by volume of carbon
nes that must be ushed out prior to use. Surge ushing is the best method for
purging these carbon nes from the media bed.
1
2
1. Once out of the box, keep the tank upright
at all times as to not apply pressure to divider.
Remove shipping caps from inlet and outlet
ports. Using supplied adapter, connect a
garden hose to the inlet port so the water will
ow into the system and out of the outlet port.
2. Slowly turn faucet on and allow discolored
water to ow from outlet into a suitable
drainage area. The rst few gallons will
appear black and cloudy due to
carbon nes.
TIP: You may need to slightly shake
the tank to help remove carbon nes.
3. After an initial 15-minute ushing, begin
a period of “surge ushing” by turning water
supply on for 30 seconds and then o for 30
seconds, repeating cycle for 15 minutes or
until initial surge of water is completely clear
and free from discoloration and cloudiness.
4. Disconnect the system from the garden hose,
be sure the white washers are properly set
inside the inlet and outlet ports, and position
the system for installation.
INSTALLATION STEPS

55
INSTALLATION STEPS
Prepare Rhino Tank
Wrap your pipe nipples with NSF certied
plumber's tape. Connect the nipples to the
system's inlet and outlet.
NOTE: DO NOT use pipe
solvent (dope), as solvents
in some types of pipe dope
may cause damage to plastic
ttings. Do not over-tighten to
prevent damage to lter head.
3
When installing on metallic plumbing,
ensure you take the following
precautions. Securely install two (2)
grounding clamps and a #4 copper
wire (not included) across the
location where the system will be
installed. Tightly clamp at both
ends, as shown in the illustration.
Ground
Clamp
Ground
Clamp
Ground
Wire
WARNING
ELECTRICAL SHOCK HAZARD
Prior to installation on metallic plumbing, securely install two grounding clamps and a #4 copper wire
per installation instructions. Failure to follow these instructions can result in death or electric shock.
4COPPER PIPES ONLY (proceed to Step 5 for PVC Pipes)
Install Shut-o Valve and Ensure Spacing (Cont. on next page)
1. Using a pipe cutter, cut into the main water supply line to install the
shut-o valve.
2. Loosely t shut-o valve to calculate proper spacing of components.
3. Measure distance for Pre-Filter, Rhino tank, and optional add-ons
(Salt-Free Conditioner and UV) and mark pipe accordingly.
If you're installing additional add-ons make sure to read through
those separate installation manuals prior to fully installing your
complete system.
5

6
Congure System
Fit Rhino tank and additional optional
add-ons into the system at this time.
Screw Pre-Filter and Post-Filter support
brackets onto the wall and attach lters.
Properly connect system together
accordingly (slip ttings, barbed ttings,
NSF certied PVC glue, etc.). Ensure all
parts are owing through the "IN" port
in the correct direction of water ow.
Final System Check
Once installation is complete, allow proper time for glue to dry according
to manufacturer instructions. Then, slowly turn water on and inspect
for leaks.
After inspecting for leaks, turn on the faucet closest to the installed unit
and allow water to run for 5-10 minutes for the nal ushing period.
7
8
INSTALLATION STEPS
Incoming
water supply
Outgoing
water supply
Install Shut-o Valve and Ensure Spacing (Cont. from previous page)
5
Ensure proper spacing to t Pre-Filter, Rhino tank,
and any optional add-ons
NOTE: DO NOT cut more pipe than necessary. You can cut more pipe later if
needed. If you're also installing a Pro-Install Kit or bypass loop, do so at this time.
Cut Pipes
Cut pipe along the marked sections from step
5 and clean ends of pipe. Ensure there are no
burrs, sharp edges or deep scratches.
6
NOTE: Cut tubing as straight as possible
with a utility knife, or an appropriate
pipe cutter for copper tubing or PVC.
CORRECT
INCORRECT

Performance Data Sheet for the EQ-400 Aquasana Whole House Rhino®Water Filter System
Models Replacement Max Operating pressure Rated capacity Operating temp. range Rated ow
EQ-400 EQ-400R
100 psi 400,000 gallons 40-90º F 7.0 gpm
Manufactured by: Aquasana, Inc. 6310 Midway Road · Haltom City, Texas 76117 · 866-662-6885
For use with municipally treated water only. Do not use with water that is microbiologically unsafe or of
unknown water quality without adequate disinfection before or after the system.
Filter is only to be used with cold water.
Filter usage must comply with all state and local laws.
Testing was performed under standard laboratory conditions, actual performance may vary.
Systems certied for cyst reduction may be used on disinfected waters that may contain lterable cysts.
See owner’s manual for general installation conditions and needs plus manufacturer’s limited warranty.
• All contaminants reduced by this lter are listed.
• Not all contaminants listed may be present in your water.
• Does not remove all contaminants that may be present in tap water.
This system has been independently tested for reduction of chloramines on standard chloraminated tap water.
Data Summary Table
Sample
Point
Accumulated
Volume (gal) Dynamic Pressure (psi) Chloramine, Free Available (mg/L) Flow Rate (gpm) % Reduction
Euent 1 Inuent Inuent Euent 1 Euent 1 Euent 1
Startup 10 60 3.21 <0.01 7.10 79.9%
10% 50,000 60 2.84 0.13 6.99 95.4%
20% 100,000 60 3.10 0.39 6.98 87.4%
30% 150,000 60 3.08 0.87 6.84 71.8%
40% 200,000 60 3.00 0.76 7.05 74.7%
50% 250,000 60 2.99 1.07 6.94 65.2%
60% 300,000 60 3.08 1.31 6.99 57.5%
70% 350,000 60 3.23 1.75 7.15 45.8%
80% 400,000 60 3.19 0.75 7.10 76.5%

RHINO®WATER FILTER
LIMITED WARRANTY
Who is covered
AQUASANA AND ITS SUPPLIERS, (herein collectively referred to as “Manufacturer”) warrants to the
owner of the home where the water lter is initially installed (hereinafter “Owner”). The warranty is
restricted to the water lter used in a single-family residence in the United States of America and is
void if moved from the original installation location.
What is covered
This Warranty covers defects in materials or workmanship during the limited warranty period of
your Aquasana Rhino Whole House Filtration System including sub-components purchased with
original system (may or may not include pre-lter, post-lter, and ttings), except as provided below.
The water lter is warranted only when it is installed, operated and maintained in accordance with
the instructions accompanying the water lter found on Aquasana.com. A water lter should be
installed in such a manner that, if the tank or any connection thereto should leak, the resulting ow
of water will not cause damage to the area in which it is installed. For detailed instructions read the
manual accompanying the water lter and review drawings in the manual.
For how long
This warranty runs for months specied in chart below from the date of purchase by a consumer
(herinafter "Warranty Period"). No warranty coverage will be provided if the claimant is unable to
provide proof of purchase. Water conditions and use rates may limit the functional lifespan of your
lter. This Limited Warranty does not extend to the full estimated life span of the lter.
What Aquasana will do
1. If necessary, the Manufacturer will provide a replacement that fullls the remaining estimated
lifespan/capacity (see chart) of your original purchase and send it to you with installation
instructions. If industry standards, product improvements or product obsolescence prohibit
Manufacturer from furnishing an identical model replacement water lter under this warranty,
the Owner will be furnished with a new water lter of comparable remaining capacity and
functionality; however, the Owner will be charged for the additional value of the item(s) which
Manufacturer has incorporated in the replacement water lter.
RHINO SYSTEM WARRANTY COVERAGE
Model Lifespan/Capacity
EQ-400 4 Years / 400,000 Gallons
Installation Kit
(includes pre-lter, post-lter, and ttings purchased with original system) 1 Year
2. Component Part – If any component part proves to Manufacturer’s satisfaction to be defective
in material or workmanship within the warranty period listed on the data plate label, the
Manufacturer will furnish the Owner with a replacement for the defective part(s).
3. Return of Defective Water Filter and Component Parts – Manufacturer reserves the right to
examine the alleged defect in the water lter or component part(s), and it will be the Owner’s
obligation to return the water lter and/or component part(s) to the Manufacturer at the
Manufacturers request.
a. When returning a water lter, it must include all component parts.
b. When returning component part(s), they must be individually tagged and identied with the
water lter’s model number, date of purchase, and date of installation.
This warranty does not include the UV FIlter. See full warranty information for the UV Filter in the original UV manual.

What is not covered
1. This warranty does not cover lter cartridges and any systems that were not installed in
compliance with the instructions or that have been abused or operated incorrectly.
2. The Limited Warranty stated herein is in lieu of any and all warranties, express or implied
(whether written or oral), including, but not limited to, the implied warranties of merchantability
and tness for a particular purpose.
3. Manufacturer shall not be liable for any incidental, consequential, special, or contingent damages
or expenses, arising, directly or indirectly, from any defect in the water lter or the use of the
water lter.
4. Manufacturer shall not be liable for any water damage arising, directly or indirectly, from any
defect in the water lter or component part(s) or from its use.
5. Manufacturer shall not be liable for any damage or product failures caused by any of the
following:
• The water lter or any of its component parts have been subject to misuse, alteration, neglect
or accident.
• The water lter has not been installed in accordance with the applicable local plumbing and/or
building code(s) and/or regulations or in their absence.
• The water lter is not installed, operated and maintained in accordance with the printed
Manufacturer’s instructions, including if the water lter has any additional aftermarket
equipment introduced into the sealed system not approved by the manufacturer.
• The water lter is exposed to highly corrosive conditions.
• The water lter is not continuously supplied with potable water.
• The water lter is not operated within the factory calibrated temperature limits.
• The water lter is removed from its original installation location.
• The water lter is installed in direct sunlight or exposed to freezing temperatures.
• The water lter or any of its component parts fail due to iron or sediment build-up.
• Clogging due to purchaser’s failure to replace the Pre-Filter cartridge.
• Damage caused by re, ood or acts of God.
• Damage caused by over-pressurization in the water line.
6. This warranty does not cover damage caused by the use of parts that are not genuine Aquasana
parts. This includes, but is not limited to replacement lters, faucets, and/or diverter valves.
7. Except when specically prohibited by the applicable state law, the Owner, and not the
Manufacturer, shall be liable for and shall pay for all charges for labor or other expenses incurred
in the removal, repair or replacement of the water lter or any component part(s) claimed to
be defective or any expense incurred to remedy any defect in the product. Such charges may
include, but are not necessarily limited to:
a. All freight, shipping, handling and delivery costs of forwarding a new water lter or
replacement part(s) to the owner.
b. All costs necessary or incidental in removing the water lter or component part(s)
and installing a new water lter or component part(s).
c. Any material required to complete, and/or permits required for, installation of a new water
lter or replacement part(s), and
d. All costs necessary or incidental in returning the water lter or component part(s) to a location
designated by the manufacturer.
How to get service
To receive service under this Warranty, you must contact Aquasana (A. O. Smith Water Treatment
(North America), Inc.) at 1-866-662-6885 or [email protected] within the Warranty Period to
describe the problem to a customer service representative who will verify that the product is under
warranty and determine whether a part or the system will be replaced and whether you must send
back the unit. You will be required to provide proof of purchase and proof of proper installation.

EQ-400_OM_011921
Aquasana, Inc.
6310 Midway Road
Haltom City, Texas 76117
866.662.6885 USA
877.332.7873 Canada
www.aquasana.com
LOVE IT?
Please let us know with
a review on Aquasana or
your retailer’s website.
NEED HELP?
Give us a call at
866-662-6885 and
tell us what's going on.
Replace your lters on time, without worry —
auto-delivered to you, for less.
Free
Shipping
Discount
Replacements
Extended
Warranty
No
Contract
[email protected]
CONTACT US TO LEARN MORE
