Aquasana Deluxe Drinking Filtration System AQ-4501
Model Replacement Operating pressure range Rated capacity Operating temp range Rates flow
AQ-4501 AQ-4035 20-80 psi 500 gallons 40-90° F 0.4 gpm
Manufactured by: Aquasana, Inc. - 6310 Midway Road - Haltom City, Texas 76117 - 888.516.9752
Installation Instructions
AQ-4501 Premium Under Counter Water Filter
This filter system is designed and tested for use with genuine Aquasana parts including
replacement filters and all hardware. Use of parts from other manufacturers may result in loss
of contaminant reduction performance, system damage or failure. Use of parts from other
manufacturers will also void your warranty.

AB
Brass
Insert Plastic Sleeve Supply Line Brass Nut
Brass
“T”
1. Unpack and unwrap contents.
• Open Relief Faucet
• Mounting Bracket
• Screws and Anchors
• 3/8” x ¼” Brass “T”
2. Mount the faucet. (Figure A)
3. Mount the filter. (Figure B)
Note: make sure that the location of the
lter unit allows the tubing from the faucet
to connect to the base of the lter without
kinking or side pressure; if the hose is not
able to plug straight into the inlet without
side pressure, it may drip.
4. Connect water supply. (Figure A)
Turn o your cold water supply valve and at-
tach the “T” tting to the cold water supply.
5. Once the lter and faucet are mounted and
the “T” tting is attached to the cold water
supply line, proceed with the following steps:
• Connect the hoses. (Figure A)
• Turn the cold water supply line on; this
will open the supply to the faucet.
• Check for leaks. If leaks are present, turn
o the supply valve and check all con-
nections.
• Turn handle clockwise and allow the
water to run until all cloudiness and air
bubbles are gone.
Figure A
Figure B
Precautions and important information:
Stop. Did you pick a location for the faucet mount?
• Determine the appropriate location for the faucet to be mounted
• The faucet may be mounted using an existing hole for a sprayer nozzle, or by
drilling a 7/8” hole in the sink or countertop
• Note: we do not recommend drilling granite or porcelain sinks unless done by
a professional. Be sure the location of the faucet allows the spout to extend
slightly past the edge of the sink as all faucets have a 4” overhang
“Pure Satisfaction”
All aquasana products oer a 90-day 100% money back guarantee. If for any
reason you are not satised with your purchase, simply call us, or the dealer
you purchased from, for a return merchandise authorization number and a full
refund will be promptly issued upon return. Thank you for choosing aquasana!
PLEASE NOTE:
For the rst 72 hours this faucet will drip intermittently, until the lters
become fully saturated. Once they are saturated you should anticipate a
residual ow of water each time you use the lter, as the system is vented
and designed to clear the line.
IMPORTANT:
The aquasana AQ-4501 can only be used with a faucet supplied by Aquasana.
Any other faucet may cause damage to the lter system and/or leakage.
This unit can NOT be used in constant pressure applications,
such as ice-makers or fountains.
PRECAUTIONS:
• Read all instructions carefully
• No constant hydrostatic pressure line to lter allowed
• For technical assistance support call: 888.516.9752
