Victoria Bench with Back Rest
Before you commence the assembly process, we recommend that you read these
instructions thoroughly beforehand to familiarise yourself with the assembly process and to
also check that you have the correct components. If for any reason you need assistance,
you can find our contact details on the top of page of these instructions.
We highly recommend that any assembly is carried out on a flat, level surface if possible
and that you use another person to assist you if necessary.
You can check our YouTube channel for assemble video.
Please click here
Package contents Tools required
1x Bench top 10mm socket or spanner
2x Bench frames
2x Cross braces
M8 coach screws
Cover caps

01945 410950 [e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 1
Step 2
Step 3
Step 4
Lay one of the bench seats face down on the flat
surface as you did with the tabletop. Make sure that
you are using benchtop with extended braces.
Place one of the bench A-frames centrally against the fixing
batten ensuring that the gap at the bench edge is the same
on both sides. Now, using 2 of the supplied coach screws
and the predrilled holes, secure the bench A-frame to the
fixing batten on the seat and repeat same move on the
other side.
For a 3ft or 4ft set, take one of the bench braces
(rectangular) and align it between the two A-frames.
Secure into place using 2 coach screws at either end as
shown.

01945 410950 [e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 5
Step 6
Step 7
Step 8
For a 5ft to 8ft set, place a shorter brace aligned
centrally on the seat as shown and affix to the bench
with a coach screw.
Ensure that the brace is lined up centrally on the bench
and attach it to the A-frame with a coach screw.
Add the remaining braces to both seat assemblies
Lay bench on the side facing extended bench braces.
Align brace with the edge of the middle A-frame brace
and secure via pilot holes.

01945 410950 [e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 9
Step 10
Place bench back on its feet and slide in backrest panel
into place. For this step, you will require assistance if
possible. Secure back panel via two pilot holes, on both
sides.
Your finished bench should look like this.
Your Victoria Bench with Back Rest are now completed!
We hope that you found your product quick and easy to assemble but if not and you require
further assistance or have any questions you can contact us via details above.
Also, you can check our YouTube channel for assemble videos, click on the link below:
https://www.youtube.com/watch?v=2Nb7GCCKK7s&t=2s
Or
Type in YouTube search box Arbor Garden Solutions
