Arbor Technology ARTS-4770 User manual

1
ARTS-4770
Fanless In-Vehicle Surveillance with Intel®Core i7-3517UE
User’s Manual
Version 1.0
2014.05
P/N: 4012477000100P

2
Revision History
Version Release Time Description
1.0 May 2014 Initial release

- i -
Contents
Preface........................................................................................... iii
Copyright Notice .......................................................................................iii
Declaration of Conformity .........................................................................iii
CE......................................................................................................iii
FCC Class A.......................................................................................iii
RoHS .................................................................................................iv
SVHC / REACH .................................................................................iv
Important Safety Instructions.................................................................... v
Warning .................................................................................................... v
Replacing Lithium Battery.........................................................................vi
Technical Support .....................................................................................vi
Warranty ..................................................................................................vii
Chapter 1 - Introduction................................................................ 1
1.1. Product Highlights ............................................................................. 2
1.2. About this Manual .............................................................................. 2
1.3. Specications .................................................................................... 3
1.5. Ordering Information.......................................................................... 5
1.5.1. Optional Accessories ............................................................... 5
1.5.2. Congure-to-Order Service...................................................... 5
Chapter 2 - Getting Started........................................................... 7
2.1. Dimensions........................................................................................ 8
2.2. Take A Tour ........................................................................................ 9
2.3. Driver Installation Notes .................................................................. 11
Chapter 3 - System Conguration ............................................. 13
3.1. Board Layout ................................................................................... 14
3.1.1. CPU Boards........................................................................... 14
3.1.2. Carrier Board ......................................................................... 16
3.2. Jumpers and Connectors ................................................................ 18
3.2.1. Jumpers ................................................................................. 18
3.2.2. Connectors............................................................................. 21
Chapter 4 - Installation and Maintenance.................................. 43
4.1. Install Hardware............................................................................... 44
4.1.1. Open the Computer ............................................................... 44
4.1.2. Install/uninstall SIM Card ....................................................... 45
4.1.3. Install SATA HDD/SSD .......................................................... 47
4.1.4. Disassemble SSD bracket .................................................... 49
4.1.5. Install Memory Module on CPU Module ................................ 50
4.2. Mount the Computer........................................................................ 51
4.3. Wire DC-in Power Source................................................................ 53
4.31 Vehicle Application .................................................................. 53
4.3.2 Automation Application............................................................ 54

- ii -
Contents
Chapter 5 - BIOS.......................................................................... 55
5.1. ARTS-4770 BIOS............................................................................. 58
5.1.1. Main ....................................................................................... 58
5.1.2. Advanced ............................................................................... 59
5.1.3. Chipset................................................................................... 69
5.1.4. Boot........................................................................................ 74
5.1.5. Security.................................................................................. 76
5.1.6. Save & Exit ............................................................................ 77
Appendices .................................................................................. 79
Appendix A: HSPA-SI1400 Hardware Installation................................... 80
C.1. Install HSPA-SI1400................................................................. 80
Appendix B: WIFI-AT2350 Hardware Installation ................................... 85
D.1. Install WIFI-AT2350.................................................................. 85
Appendix C: GPS Module Hardware Installation.................................... 90

- iii -
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in order to
improve the reliability, design and function. It does not represent a commitment on the
part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect, special,
incidental, or consequential damages arising from the use or inability to use the product
or documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this document may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
Declaration of Conformity
CE
The CE symbol on the computer indicates that it is in compliance with the directives of
the Union European (EU). A Certicate of Compliance is available by contacting Technical
Support.
This product has passed the CE test for environmental specications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from ARBOR. Please contact your local supplier for ordering
information.
Warning
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Preface

- iv -
Preface
NOTE:
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
RoHS
ARBOR Technology Corp. certies that all components in its products are in compliance
and conform to the European Union’s Restriction of Use of Hazardous Substances in
Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose of
the directive is to prohibit the use of lead, mercury, cadmium, hexavalent chromium,
polybrominated biphenyls (PBB), and polybrominated diphenyl ethers (PBDE) in electrical
and electronic products. Member states of the EU are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a
maximum concentration value of 0.1% by weight or for cadmium exceed 0.01% by
weight, per homogenous material. Homogenous material is dened as a substance or
mixture of substances with uniform composition (such as solders, resins, plating, etc.).
Lead-free solder is used for all terminations (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth we live,
Arbor hereby conrms all products comply with the restriction of SVHC (Substances of
Very High Concern) in (EC) 1907/2006 (REACH --Registration, Evaluation, Authorization,
and Restriction of Chemicals) regulated by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)

- v -
Preface
Important Safety Instructions
Read these safety instructions carefully
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall
may cause damage
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment and should
be easily accessible.
5. Keep this equipment away from humidity.
6. The openings on the enclosure are for air convection and protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
7. Position the power cord so that people cannot step on it. Do not place anything over
the power cord.
8. Never pour any liquid into opening. This may cause re or electrical shock.
9. Never open the equipment. For safety reasons, the equipment should be opened
only by qualied service personnel.
10. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
11. Keep this User’s Manual for later reference.
Product Heat
The computer generates heat during operation. Contact the computer's
chassis with your body could cause discomfort or even a skin burn.
Warning

- vi -
Preface
The Box PC and its components contain very delicately Integrated Circuits (IC). To protect
the Box PC and its components against damage caused by static electricity, you should
always follow the precautions below when handling it:
1. Disconnect your Box PC from the power source when you want to work on the inside.
2. Use a grounded wrist strap when handling computer components.
3. Place components on a grounded antistatic pad or on the bag that came with the Box
PC, whenever components are separated from the system.
Replacing Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
If you have any technical difculties, please consult the user’s manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still cannot nd
out the answer.
http://www.arbor.com.tw
E-mail:[e-mail]

- vii -
Preface
Warranty
This product is warranted to be in good working order for a period of one year from the
date of purchase. Should this product fail to be in good working order at any time during
this period, we will, at our option, replace or repair it at no additional charge except as set
forth in the following terms. This warranty does not apply to products damaged by misuse,
modications, accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any other
incidental or consequential damage resulting from the use, misuse of, or inability to use
this product. Vendor will not be liable for any claim made by any other related party.
Vendors disclaim all other warranties, either expressed or implied, including but not limited
to implied warranties of merchantability and tness for a particular purpose, with respect
to the hardware, the accompanying product’s manual(s) and written materials, and any
accompanying hardware. This limited warranty gives you specic legal rights.
Return authorization must be obtained from the vendor before returned merchandise will
be accepted. Authorization can be obtained by calling or faxing the vendor and requesting
a Return Merchandise Authorization (RMA) number. Returned goods should always be
accompanied by a clear problem description.

- viii -
This page is intentionally left blank.

- 1 -
1Chapter 1
Introduction
Chapter 1 - Introduction

- 2 -
Introduction
1.1. Product Highlights
• Fanless and rugged design
• Build-in Intel® Core™ i7-3517UE 1.7G Hz Processor
• Wide Range DC Power Input (9~36V)
• Support Smart Ignition for vehicle
• Power on/off delay and low voltage
protection
• 4-channel POE
• Mini PCIe expansion slots with 2*SIM
holders for LTE and HSUPA
• Two Removable 2.5” SSD trays
• 12VDC output
1.2. About this Manual
This manual is meant for the experienced users and integrators with hardware knowledge
of personal computers. If you are not sure about the description herein, consult your
vendor before further handling.
We recommend that you keep one copy of this manual for the quick reference for any
necessary maintenance in the future. Thank you for choosing ARBOR products.

- 3 -
Introduction
1.3. Specications
System
CPU Soldered onboard Intel®Core™ i7-3517UE 1.7GHz
BIOS AMI BIOS
Chipset Intel®QM77
Graphic Integrated Intel®HD Graphics 4000
Memory 1 x 204-pin SO-DIMM sockets, supporting DDR3
1333/1600 MHz, up to 8GB SDRAM
Storage • One internal mSATA.
• Two external SATA SSD.
Ethernet • One Intel®82579LM GbE controller
• Five Intel®i210IT Gigabit Ethernet controller
Watchdog Timer 1 ~ 255 levels reset
I/O Ports
Serial Port •1 x RS-232 and 1 x RS-232/422/485 with DB-9
male connector, isolation protection
USB Port •4 x USB 3.0 ports with type A connector
(2 ports: front, 2 ports: rear)
LAN Port
•2 x RJ-45 ports for Gigabit Ethernet, front side
•4 x RJ-45 ports for Gigabyte Ethernet and support
IEEE802.3af PoE (Max. 60W), rear side
Video Port 1 x DB-15 female connector for Analog RGB
1 x DVI-D female connector for Digital Video output
Audio Mic-in/ Line-out
Expansion Bus
•1 x Mini-PCIe slot for optional Wi-Fi/Bluetooth
module
•1 x Mini-PCIe slot interconnected with SIM card socket for optional
LTE module
•1 x Mini-PCIe slot interconnected with SIM card socket for optional
HSUPA module
•2 x SIM sockets (outside accessible)
Storage
Type •Two 2.5” drive bays for SATA SSD
•One mSATA socket for mSATA Disk.

- 4 -
Introduction
Qualification
Certication CE, FCC Class A, E13 Mark
Environment
Operating Temp. -20~55°C (-4~131°F), ambient w/ air ow
Storage Temp. -40~80°C (-40 ~ 185°F)
Relative Humidity 5 ~ 95% @ 55°C (non-condensing)
Vibration 3Grms/5~500Hz/random operation, with SSD
Shock Operating 40G (11ms), Non-operating 60G with SSD
Mechanical
Construction Aluminum alloy
Mounting Support wall-mount
Weight 4.65 Kg (10.25 lb)
Dimensions
(W x D x H) 260 x 180 x 80 mm (10.6” x 7.08 x 3.14”)
Power Requirement
Power Input DC 9~36V input, w/ 3-pin terminal block
Power
Consumption Max. 90W
1.4. Inside the Package
Upon opening the package, carefully inspect the contents. If any of the items is missing
or appears damaged, contact your local dealer or distributor. The package should contain
the following items:
ARTS-4770
Fanless In-Vehicle Surveillance PC
One Driver CD
One User’s Manual

- 5 -
Introduction
1.5. Ordering Information
ARTS-4770 Vehicle Barebone System w/ Intel® Core™ i7-3517UE, w/o
memory and storage
ARTS-4700-16S4G Vehicle BOX System w/ Intel® Core™ i7-3517UE, w/ 16GB
mSATA and 4GB memory
1.5.1. Optional Accessories
The following items are normally optional, but some vendors may include them as a
standard package, or some vendors may not carry all the items.
PAC-B120W-FSP 19V/6.32A 120W AC/DC adapter kit
1.5.2. Congure-to-Order Service
Make the computer more tailored to your needs by selecting one or more components
from the list below to be fabricated to the computer.
SSD-25032 Memoright 2.5" 32GB SATAII SSD kit
SSD-25016 Memoright 2.5" 16GB SATAII SSD kit
GPS-UART Kit U-BLOX GPS Kit
WIFI-AT2350 Atheros AR9462 WiFi module w/ 20cm &
30cm internal wiring
ANT-D11 1 x WiFi Dual-band 2.4G/5G antenna
HSPA-SI1400 HSUPA 3.75G module kit & internal wiring
MM-3I-4G
Industrial-grade DDR3-1333 4GB SDRAM
MK-3I-8G
Industrial-grade DDR3-1600 8GB SDRAM

- 6 -
This page is intentionally left blank.

- 7 -
2Chapter 2
Getting Started
Chapter 2 - Getting Started

- 8 -
Getting Started
2.1. Dimensions
The following illustration shows the dimensions of the computer, with the measurements
in width, depth, and height called out.
180.00
50.0050.00
80.0080.00
92.5092.50
282.20 86.00
80.00
86.00
260.00

- 9 -
Getting Started
2.2. Take A Tour
The computer has some I/O ports, status LED light and controls on the front and rear
panel. The following illustrations show all the components called out .
Front View
⑥
⑤
②
①
⑦
③
④
➊ ➋ ➌ ➍
➎ ➏ ➐ ➑
Status LED Lamps
Antenna holes
stopped up by
plugs
⑧
• I/O
No. Description No. Description
①SSD tray 1 ⑤Antenna holes stopped up by
plugs
②SSD tray 2 ⑥Reset button
(accessible with a pin)
③SIM1/2 card slots ⑦Power button
④USB 3.0 port ⑧LED Indicator
• Status LED Lamps:
No. LED
Color Description
➊Red This LED lights red when WiFi is on.
➋Yellow This LED lights yellow when LAN2 port is streaming data.
➌Yellow This LED lights yellow when LAN1 port is streaming data.
➍Red This LED lights red when SSD is being accessed.

- 10 -
Getting Started
➎Green This LED lights green when 3G is on.
➏
Green This LED lights green when LAN2 port is connected to 100M
bit/s network equipment.
Orange This LED lights orange when LAN2 port is connected to
1000M bit/s network equipment.
➐
Green This LED lights green when LAN1 port is connected to 100M
bit/s network equipment.
Orange This LED lights orange when LAN1 port is connected to
1000M bit/s network equipment.
➑Green This LED lights when power is on.
Rear View
Power
jack
DIO
port
DVI-D
port RS232/422/485
serial port
Power over
Ethernet
ports
USB
ports
LAN1/LAN2
ports
VGA
KB/MS
Fuse Audio
port
12V
DC-OUT
