ARC Flex 2JX User manual

FLEX 2JX
User’s Manual

Page 1
Service Information
Your New Radio System
Thank you for your purchase of ARC Flex 2JX radio remote control system. Without a doubt, our Flex
2JX system is the ultimate solution for providing precise, undeterred, and safe control of your material.
If your product ever needs modification or service, please contact our representative in your country
or at the following location:
World Headquarter:
Advanced Radiotech Corporation
288-1, Hsin Ya Road, Chien Chen District
Kaohsiung, Taiwan
Telephone:
[phone]
Fax Number:
[phone]
Website:
www.advanced-radiotech.com
e-mails:
[email protected]
[e-mail]
All rights reserved. This notice applies to all copyrighted materials included with this product, including,
but not limited to, this manual and software embodied within the product. This manual is intended for
the sole use of the person(s) to whom it was provided, and any unauthorized distribution of the
manual or dispersal of its contents is strictly forbidden. This manual may not be reproduced in whole
or in part by any means whatsoever without the expressed written permission of ARC.

Page 2
PRODUCT MANUAL SAFETY INFORMATION
Advanced Radiotech Corporation (ARC) offers a broad range of radio remote control product for
material handling applications. This manual has been prepared by ARC to provide information and
recommendations for the installation, use, operation and service of ARC’s material handling products
and systems (ARC Products). Anyone who uses, operates, maintains, services, installs or owns ARC
Products should know, understand, and follow the instructions and safety recommendations in this
manual for ARC Products.
The recommendations in this manual do not take precedence over any of the following requirements
relating to cranes, hoists lifting devices or other material handling equipment which use or include
ARC Products:
Instructions, manuals, and safety warnings of the manufacturers of the equipment where the
radio system is used.
Plant safety rules and procedures of the employers and the owners of facilities where the
ARC Products are being used.
Safety standards and practices for the industries in which ARC Products are used.
This manual does not include or address the specific instructions and safety warnings of these
manufacturers or any of the other requirements listed above. It is the responsibility of the owners,
users and operators of the ARC Products to know, understand and follow all of these requirements. It
is the responsibility of the employer to make its employees aware of all of the above listed
requirements and to make certain that all operators are properly trained. No one should use ARC
Products prior to becoming familiar with and being trained in these requirements and the
instructions and safety recommendations in this manual.
WARRANTY INFORMATION
For information on ARC’s product warranties, please contact ARC representative nearest to you or
visit www.advanced-radiotech.com.

Page 3
Table of Contents
Page
1. Introduction 5
2. Radio Controlled Safety 6
3. General System Information
3.1Transmitter 11
3.2 Receiver
3.2.1 External Illustration 12
3.2.2 Internal Illustration 13
4. Function Settings
4.1 Transmitter
4.1.1 Programming Procedure 14
4.1.2 Transmitter Channel 15
4.1.3 Transmitter Type 15
4.1.4 Transmitter Inactivity Timer 16
4.1.5 Transmitter Output Power 16
4.1.6 Transmitter Infrared Mode 17
4.1.7 Transmitter Infrared ID 17
4.1.8 Transmitter Infrared START Function 18
4.1.9 Transmitter Tilt Function 18
4.1.10 SW1 Button Function 19
4.1.11 SW2 Button Function 19
4.1.12 SW3 Button Function 20
4.1.13 SW4 Button Function 20
4.1.14 SW5 Button Function 21
4.1.15 SW6 Button Function 21
4.1.16 SW7 Button Function 22
4.1.17 Save Function 22
4.1.18 I-Chip Installation 22
4.2 Receiver Unit
4.2.1 Programming Procedure 23
4.2.2 I-Chip Programming 24
4.2.3 Receiver Channel 24
4.2.4 Receiver Channel Scanning 25
4.2.5 Receiver Type 26
4.2.6 Main Relay Function 26
4.2.7 Function Relay #1 27
4.2.8 Function Relay #2 28
4.2.9 Joystick LX Acceleration and Deceleration Delay 29
4.2.10 Joystick LY Acceleration and Deceleration Delay 29

Page 4
4.2.11 Joystick RX Acceleration and Deceleration Delay 30
4.2.12 Joystick RY Acceleration and Deceleration Delay 30
4.2.13 SW1+SW2 Output Relays Function 31
4.2.14 SW1 Output Relay Function 32
4.2.15 SW2 Output Relay Function 33
4.2.16 SW3 Output Relay Function 34
4.2.17 SW4+SW5 Output Relays Function 35
4.2.18 SW4 Output Relay Function 36
4.2.19 SW5 Output Relay Function 37
4.2.20 SW6+SW7 Output Relays Function 38
4.2.21 SW6 Output Relay Function 39
4.2.22 SW7 Output Relay Function 40
4.2.23 Save Function 41
4.2.24 Voltage Settings 41
5. System Channels Table 42
6. Receiver Installation
6.1 Output Relay Contact Diagram 43
6.2 Pre-Installation Precautions 44
6.3 Step-By-Step Installation 44
6.4 System Testing 45
7. Operating Procedure
7.1 General Operating Procedure 46
7.2 Pitch & Catch Operating Procedure 47
7.3 Automatic Channel Scanning Operating Procedure 48
7.4 Battery Changing Instruction 48
8. Status & Warnings
8.1Transmitter 49
8.2 Receiver
8.2.1 LED STATUS Indications 50
8.2.2 LED SQ Indications 50
8.2.3 LED POWER Indications 50
8.2.4 LED COM Indications 50
8.2.5 LCD Indications 51
9. Trouble Shooting Tips 52
10. System Specifications 53
11. EU Declaration of Conformity 54

Page 5
1. Introduction
The Flex 2JX radio remote control systems are designed for control of industrial equipment and
machinery such as overhead traveling cranes, jib cranes, gantry cranes, tower cranes and other
material handling equipment where wireless control is preferred.
Each Flex 2JX system consists of a transmitter belly box and receiver unit. Other standard-equipped
accessories include one rechargeable battery pack, one charging station, one each transmitter waist
and shoulder belt, one spare transmitter power key and user’s manual.
List of notable features include:
* 62 user-programmable channels – Advanced synthesized RF controls with 62 built-in
channels.
* Automatic channel scanning receiver – No more hassle of climbing up the crane to change
receiver channels. Transmitter channel can be changed directly on the transmitter via the LCD
panel.
* Transceiving RF modules – The Flex 2JX system is capable of two-way communication
between transmitter and receiver.
* LCD readout – All settings and system status information are displayed and executed via the
LCD panel on transmitter and in receiver.
* Goretex vent – The transmitter is equipped with special Goretex vent to guard against
water/vapor buildups inside transmitter enclosure.
* Transmitter tilt function – The transmitter is embedded with special tilt switch to guard against
accidental crane movements when the transmitter is dropped.
* Over one million unique serial numbers (20bit) – Each and every Flex 2JX system has its
own unique serial number; no repeats.
* Advanced controls – The Flex 2JX system utilizes dual advanced microprocessor controls
with 32bit CRC and Hamming Code, which provide ultra-fast, safe, precise, and error-free
encoding and decoding.
* Unique I-Chip design – The I-Chip functions in a way that is very similar to SIM cards used
on mobile phones, with the ability to transfer system information and settings from one
transmitter to another without the hassle of resetting the spares.
* Fully sealed enclosures – The transmitter and receiver enclosures are IP66 rated.
* Infrared start/range limiting features – The Flex 2JX transmitter is standard-equipped with
infrared sensor for infrared start and infrared range limiting operation.
* Other features – Tandem operation, multi-receiver operation, random access operation, pitch
and catch operation, and many others.
* Full compliance – All systems are fully compliant with the FCC Part-15 Rules, European
Directives (Safety, EMC, R&TTE and Machinery), and Industry Canada Specifications (IC).

Page 6
2. Radio Controlled Safety
WARNINGS and CAUTIONS
Throughout this document WARNING and CAUTION statements have been deliberately placed to highlight items
critical to the protection of personnel and equipment.
WARNING – A warning highlights an essential operating or maintenance procedure, practice, etc. which if
not strictly observed, could result in injury or death of personnel, or long term physical hazards.
Warnings are highlighted as shown below:
WARNING
CAUTION – A caution highlights an essential operating or maintenance procedure, practice, etc. which if
not strictly observed, could result in damage to, or destruction of equipment, or loss of functional
effectiveness. Cautions are highlighted as shown below:
CAUTION
WARNINGS and CAUTIONS SHOULD NEVER BE DISREGARDED.
The safety rules in this section are not intended to replace any rules or regulations of any applicable local, state,
or federal governing organizations. Always follow your local lockout and tagout procedure when maintaining any
radio equipment. The following information is intended to be used in conjunction with other rules or regulations
already in existence. It is important to read all of the safety information contained in this section before installing
or operating the Radio Control System.

Page 7
2.1 CRITICAL INSTALLATION CONSIDERATIONS
WARNING
PRIOR TO INSTALLATION AND OPERATION OF THIS EQUIPMENT, READ AND DEVELOP AN
UNDERSTANDING OF THE CONTENTS OF THIS MANUAL AND THE OPERATION MANUAL OF THE
EQUIPMENT OR DEVICE TO WHICH THIS EQUIPMENT WILL BE INTERFACED. FAILURE TO FOLLOW
THIS WARNING COULD RESULT IN SERIOUS INJURY OR DEATH AND DAMAGE TO EQUIPMENT.
ALL EQUIPMENT MUST HAVE A MAINLINE CONTACTOR INSTALLED AND ALL TRACKED CRANES,
HOISTS, LIFTING DEVICES AND SIMILAR EQUIPMENT MUST HAVE A BRAKE INSTALLED. FAILURE TO
FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY OR DEATH AND DAMAGE TO EQUIPMENT.
AN AUDIBLE AND/OR VISUAL WARNING MEANS MUST BE PROVIDED ON ALL REMOTE CONTROLLED
EQUIPMENT AS REQUIRED BY CODE, REGULATION, OR INDUSTRY STANDARD. THESE AUDIBLE
AND/OR VISUAL WARNING DEVICES MUST MEET ALL GOVERNMENTAL REQUIREMENTS. FAILURE TO
FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY OR DEATH AND DAMAGE TO EQUIPMENT.
FOLLOW YOUR LOCAL LOCKOUT TAGOUT PROCEDURE BEFORE MAINTAINING ANY REMOTE
CONTROLLED EQUIPMENT. ALWAYS REMOVE ALL ELECTRICAL POWER FROM THE CRANE, HOIST,
LIFTING DEVICE OR SIMILAR EQUIPMENT BEFORE ATTEMPTING ANY INSTALLATION PROCEDURES.
DE-ENERGIZE AND TAGOUT ALL SOURCES OF ELECTRICAL POWER BEFORE TOUCH-TESTING ANY
EQUIPMENT. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY OR DEATH AND
DAMAGE TO EQUIPMENT.
THE DIRECT OUTPUTS OF THIS PRODUCT ARE NOT DESIGNED TO INTERFACE DIRECTLY TO TWO
STATE SAFETY CRITICAL MAINTAINED FUNCTIONS, I.E., MAGNETS, VACUUM LIFTS, PUMPS,
EMERGENCY EQUIPMENT, ETC. A MECHANICALLY LOCKING INTERMEDIATE RELAY SYSTEM WITH
SEPARATE POWER CONSIDERATIONS MUST BE PROVIDED. FAILURE TO FOLLOW THIS WARNING
COULD RESULT IN SERIOUS INJURY OR DEATH OR DAMAGE TO EQUIPMENT.
2.2 GENERAL
Radio controlled material handling equipment operates in several directions. Cranes, hoists, lifting devices and
other material handling equipment can be large, and operate at high speeds. Quite frequently, the equipment is
operated in areas where people are working in close proximity to the material handling equipment. The operator
must exercise extreme caution at all times. Workers must constantly be alert to avoid accidents. The following
recommendations have been included to indicate how careful and thoughtful actions may prevent injuries,
damage to equipment, or even save a life.
2.3 PERSONS AUTHORIZED TO OPERATE RADIO
CONTROLLED CRANES
Only properly trained persons designated by management should be permitted to operate radio controlled
equipment.
Radio controlled cranes, hoists, lifting devices and other material handling equipment should not be operated by
any person who cannot read or understand signs, notices and operating instructions that pertain to the equipment.
Radio controlled equipment should not be operated by any person with insufficient eyesight or hearing or by any
person who may be suffering from a disorder or illness, is taking any medication that may cause loss of
equipment control, or is under the influence of alcohol or drugs.

Page 8
2.4 SAFETY INFORMATION AND RECOMMENDED TRAINING
FOR RADIO CONTROLLED EQUIPMENT OPERATORS
Anyone being trained to operate radio controlled equipment should possess as a minimum the following
knowledge and skills before using the radio controlled equipment.
The operator should:
have knowledge of hazards pertaining to equipment operation
have knowledge of safety rules for radio controlled equipment
have the ability to judge distance of moving objects
know how to properly test prior to operation
be trained in the safe operation of the radio transmitter as it pertains to the crane, hoist, lifting device or
other material handling equipment being operated
have knowledge of the use of equipment warning lights and alarms
have knowledge of the proper storage space for a radio control transmitter when not in use
be trained in transferring a radio control transmitter to another person
be trained how and when to report unsafe or unusual operating conditions
test the transmitter emergency stop and all warning devices prior to operation; testing should be done on
each shift, without a load
be thoroughly trained and knowledgeable in proper and safe operation of the crane, hoist, lifting device, or
other material handling equipment that utilizes the radio control
know how to keep the operator and other people clear of lifted loads and to avoid “pinch” points
continuously watch and monitor status of lifted loads
know and follow cable and hook inspection procedures
know and follow the local lockout and tagout procedures when servicing radio controlled equipment
know and follow all applicable operating and maintenance manuals, safety procedures, regulatory
requirements, and industry standards and codes
WARNING
Keep away interference source to make sure performance integrate.
The operator shall not:
lift or move more than the rated load
operate the material handling equipment if the direction of travel or function engaged does not agree
with what is indicated on the controller
use the crane, hoist or lifting device to lift, support or transport people
lift or carry any loads over people

Page 9
operate the crane, hoist or lifting device unless all persons, including the operator, are and remain clear
of the supported load and any potential pinch points
operate a crane, hoist or lifting device when the device is not centered over the load
operate a crane, hoist or lifting device if the chain or wire rope is not seated properly in the sprockets,
drum or sheave
operate any damaged or malfunctioning crane, hoist, lifting device or other material handling equipment
change any settings or controls without authorization and proper training
remove or obscure any warning or safety labels or tags
leave any load unattended while lifted
leave power on the radio controlled equipment when the equipment is not in operation
operate any material handling equipment using a damaged controller because the unit may be unsafe
operate manual motions with other than manual power
operate radio controlled equipment when low battery indicator is on
WARNING
THE OPERATOR SHOULD NOT ATTEMPT TO REPAIR ANY RADIO CONTROLLER. IF ANY PRODUCT
PERFORMANCE OR SAFETY CONCERNS ARE OBSERVED, THE EQUIPMENT SHOULD IMMEDIATELY BE
TAKEN OUT OF SERVICE AND BE REPORTED TO THE SUPERVISOR. DAMAGED AND INOPERABLE
RADIO CONTROLLER EQUIPMENT SHOULD BE RETURNED TO MAGNETEK FOR EVALUATION AND
REPAIR. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY OR DEATH AND
DAMAGE TO EQUIPMENT.
2.5 TRANSMITTER UNIT
Transmitter switches should never be mechanically blocked ON or OFF. When not in use, the operator should
turn the transmitter OFF. A secure storage space should be provided for the transmitter unit, and the transmitter
unit should always be placed there when not in use. This precaution will help prevent unauthorized people from
operating the material handling equipment.
Spare transmitters should be stored in a secure storage space and only removed from the storage space after the
current transmitter in use has been turned OFF, taken out of the service area and secured.
2.6 PRE-OPERATION TEST
At the start of each work shift, or when a new operator takes control of the crane, operators should do, as
a minimum, the following steps before making lifts with any crane or hoist:
Test all warning devices.
Test all direction and speed controls.
Test the transmitter emergency stop.

Page 10
2.7 BATTERIES
WARNING
KNOW AND FOLLOW PROPER BATTERY HANDLING, CHARGING AND DISPOSAL PROCEDURES.
IMPROPER BATTERY PROCEDURES CAN CAUSE BATTERIES TO EXPLODE OR DO OTHER SERIOUS
DAMAGE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY OR DEATH AND
DAMAGE TO EQUIPMENT.
2.8 BATTERY HANDLING
Use only battery packs provided by ARC for the specific product.
Do not dispose of a battery pack in fire; it may explode.
Do not attempt to open the battery pack.
Do not short circuit the battery.
Keep the battery pack environment cool during charging operation and storage (i.e., not in direct sunlight or close
to a heating source).
2.9 BATTERY CHARGING
For those transmitters equipped with battery chargers, please familiarize all users with the instructions of the
charger before attempting to use.
Do not attempt to charge non-rechargeable battery packs.
Avoid charging partially discharged rechargeable batteries to help prolong battery cycle life.
Avoid charging the battery pack for more than 24 hours at a time.
Do not charge batteries in a hazardous environment.
Do not short the charger unit.
Do not attempt to charge a damaged battery.
Use only ARC charger unit for the appropriate battery pack.
Do not attempt to use a battery pack that is leaking, swollen or corroded.
Charger units are not intended for outdoor use.
2.10 BATTERY DISPOSAL
Before disposing of battery packs consult local and governmental regulatory requirements for proper disposal
procedure.
2.11 SPECIFIC SYSTEM WARNINGS
Below are some specific operating safety tips that should be strictly followed when operating a Flex 2JX system:
1. Check the Status LCD on the transmitter for any signs of low battery power.
2. Check the Status LCD on the transmitter for any signs of irregularities.
3. Make sure the system is not set to the same channel as any other Flex systems in use within a
distance of 300 meters (900 feet).
4. Never operate equipment with two transmitters at the same time unless they are programmed to
do so.

Page 11
23 4 5
1
611 7109
8
12
15
14 16
17
18
13
3. General System Information
3.1 Transmitter
1. SW1 button or switch 7. SW7 button 13. E-Stop button
2. SW2 button or switch 8. LCD screen 14. Goretex vent
3. SW3 button or switch 9. Left (L) joystick 15. System information
4. SW4 button or switch 10. Right (R) joystick 16. I-Chip port
5. SW5 button or switch 11. Infrared sensor 17. START button
6. SW6 button 12. Shoulder strap clip 18. Power key

Page 12
1
2
6
7
8
5
4
3
3.2 Receiver
3.2.1 External Illustration
1. External antenna jack (optional) 5. Status LED display
2. Shock mount 6. Power LED display
3. COM LED display 7. System information
4. SQ LED display 8. Cord grip

Page 13
2
3
1
6
7
8
4
5
3.2.2 Internal Illustration
1. Power transformer 5. Receiving module
2. LCD display 6. AC line filter board
3. PS1 & PS2 programming buttons 7. Top relay board
4. Decoder module 8. Bottom relay board

Page 14
>S/N:
0000001
SW6 SW7
LCD
>S/N:
0000001 ABCDEF
>TYPE:
01
>CHANNEL
433.000
>FREQ:
NORMAL
>SW1FUNC>SW2FUNC
NORMAL
NORMAL
>SW3FUNC
NORMAL
>SW4FUNC
NORMAL
>SW5FUNC >SW6FUNC
NORMAL
>SW7FUNC
NORMAL YES NO
>SAVE?
GH
00M00S
>TIMER
+START
0.1mW
>RFpower
>IR MODE
OFF000
>IR_ID
OFF
>TILT >IRSfunc
IRS off
TimeOut
SETTING
MODE
4. Function Settings
4.1 Transmitter
4.1.1 Programming Procedure
How to enter transmitter programming mode:
1) Turn on the transmitter power switch.
2) Do not press the green START button.
3) Press both SW6 and SW7 buttons below the LCD screen at
the same time for up to 1 second to enter the Programming
Mode. Setting Mode screen will show up for a brief second
followed by the Serial Number screen (see below).
4) Serial number and frequency range can not be reprogrammed directly on the
transmitter so press SW7 button repeatedly until you see the Channel Setting
screen and so on.
5) Button functions:
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Press and hold SW7 and then SW6 to go back to the previous main menu.

Page 15
>62
>CHANNEL
11>02
CHANNEL
>BACK
^
01
>CHANNEL
^
CHANNEL
^
^
CHANNEL
02
01 01
CHANNEL
CHANNEL
>01
CHANNEL
>01
CHANNEL
CHANNEL
01
CHANNEL
01
>TYPE:
ABCDEF
GH
+START
AC
F
F
>TYPE:
>TIMER
GH
TYPE:
^
00M00SABCDEF
E
C
>TYPE:
E
C
D A
^
D
>BACK
BF
TYPE:
D
E
TYPE:
^
TYPE:
B
BA ABCDEF
GH
H
TYPE:
^
GG
B to F
GHG
TYPE:
H
TYPE:
^
^
H
^
TYPE:TYPE:
GH
4.1.2 Transmitter Channel
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
When transmitter channel is changed make sure the receiver channel is also set to the newly
selected channel. Please refer to section 7.3 automatic channel scanning operating procedure
if the receiver is set to “scan all channels” (see section 4.2.4).
4.1.3 Transmitter Type
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Transmitter Type is associated with functions such as tandem operation, random access
operation, multi-receiver operation, etc... Please do not alter the factory settings unless
authorized to do so.

Page 16
TIMER
>00M00S 0
TIMER
^
TIMER
^^
0M00S
000MS0000MS0
^
TIMER
0S000M
>+START
TIMER
0S000M
TIMER
1
^
0M00S 0
TIMER
0
^
S10M
>BACK
TIMER
ON>ON
TIMER
TIMER
00M00S
0.1mW
>RFpower
00M00S
>TIMER
+START
+START
+START
>ON
TIMER
+START
ON
TIMER
>+START
TIMER
ON
>+ANY +START
>TIMER
ON
~
>+ANY
0S
>BACK
TIMER
00M
00M00S
>TIMER
0
+START
TIMER
>00M00S
+START
0.1mW
>RFpower >IR MODE
OFF
RFpower
>0.1mW
RFpower
>0.4mW
RFpower
0.1mW
>BACK
>0.1mW
RFpower
0.1mW
>RFpower
>02mW
>04mW
>08mW
>06mW
>10mW
RFpower
>01mW
4.1.4 Transmitter Inactivity Timer
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Transmitter inactivity timer is for setting transmission cutoff time when the transmitter is not in
operation for a certain period of time. When set to 5 minutes (05M00S), the transmitter will
seize transmission at 5.0 minutes after last transmitter operation.
Select “ON” means the transmission is constantly on (inactivity timer disabled) until the e-stop
button is pressed or when the transmitter power is switched off.
Select “+START” means after 5 minutes of transmitter inactivity you must press the green
START button to continue operation. Select “+ANY” means after 5 minutes of transmitter
inactivity operate the joysticks, buttons or switches to continue operation.
4.1.5 Transmitter Output Power
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.

Page 17
OFF
>IR MODE
>BACK
>IR_ID
000
>OFF
IR MODE
IR MODE
>IRS
IR MODE
>IRL
IR MODE
OFF
IR MODE
>OFF
OFF
>IR MODE
000
>IR_ID
>000
IR_ID
IR_ID IR_ID IR_ID
IR_ID
IR_ID
>001
>255
000
^
100
^
000
^
IR_ID
010
^
IR_ID
000
^
^
001
IR_ID
000
>BACK
IR_ID
>IR_ID
000
>000
IR_ID
>IRSfunc
TimeOut
IRS off
4.1.6 Transmitter Infrared Mode
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Select “OFF” to disable infrared function.
Select “IRS” to enable infrared START function.
Select “IRL” to enable infrared range limiting function.
4.1.7 Transmitter Infrared ID
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Make sure the infrared module on crane is set to same ID code as the transmitter.
Select “000” disables the ID code function hence any types of infrared modules can be used.

Page 18
>TILT
OFF
>SW1FUNC
NORMAL
>OFF
TILT
TILT
>0.5S
>1.0S
TILT
OFF
TILT
>BACK
OFF
>TILT
>OFF
TILT
>IRSfunc
TimeOut OFF
>TILT
IRS off
IRSfunc
TimeOut
>IRS off
TimeOut
IRSfunc
>IRS on
IRSfunc
TimeOut
>BACK
>IRSfunc
TimeOut
IRS off
IRSfunc
TimeOut
>IRS off
4.1.8 Transmitter Infrared START Function
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Select “IRS ON” if infrared START is required after every transmitter timeout (see section 4.1.4).
Select “IRS OFF” if infrared START is not required after every transmitter timeout.
4.1.9 Transmitter Tilt Function
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
When TILT function is set to 0.5s (more sensitive) or 1.0s (less sensitive), the receiver mains
are disconnected (opened) when the transmitter is tilted for more than 35~40 degrees. Select
OFF disables the TILT function.

Page 19
>SW1FUNC
NORMAL
>SW2FUNC
NORMAL
>NORMAL
SW1FUNC
SW1FUNC
>TOGGLE
SW1FUNC
>BACK
NORMAL
NORMAL
>SW1FUNC
SW1FUNC
>NORMAL
SW1FUNC
>A->B
>0->A->B
>A->B->AB
>0->A->B->AB
>SW2FUNC
NORMAL
>SW3FUNC
NORMAL
>NORMAL
SW2FUNC
SW2FUNC
>TOGGLE
SW2FUNC
>BACK
NORMAL
NORMAL
>SW2FUNC
SW2FUNC
>NORMAL
SW2FUNC
>A->B
>0->A->B
>A->B->AB
>0->A->B->AB
4.1.10 SW1 Button Function
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Select “NORMAL” the output relay becomes momentary contact.
Select “TOGGLE” the output relay becomes toggled contact.
Important note: If SW1 is equipped with a rocker switch then this SW1 button function and
SW1 output relay function in receiver (see section 4.2.14) must both set to “NORMAL”.
4.1.11 SW2 Button Function
SW6 button is the “Enter” or “Change” command.
SW7 button is the “Next” command.
Select “NORMAL” the output relay becomes momentary contact.
Select “TOGGLE” the output relay becomes toggled contact.
Important note: If SW2 is equipped with a rocker switch then this SW2 button function and
SW2 output relay function in receiver (see section 4.2.15) must both set to “NORMAL”.
