Arcan Blackline XL2TB User manual

1 REV: 11/27/19
Model XL2TB
2 Ton Extra Long and Low Clearance Service Jack
For Technical Questions, Call: 1-800-879-7316
WARNING INFORMATION
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING
BEFORE USING THIS DEVICE, READ THIS MANUAL COMPLETELY AND THOROUGHLY, UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS.
It is the responsibility of the owner to make sure all personnel read this manual prior to using the device. It is also the responsiblity of the
device owner to keep this manual intact and in a convenient location for all to see and read. Contact Arcan Customer Service for a replace-
ment label if your stand's label is not readable. If the operator is not fluent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator's native language by the purchaser/owner or his designee, making sure that the operator
comprehends its contents.
THE NATURE OF HAZARDOUS SITUATIONS
The use of Portable Automotive Lifting Devices are subject to certain hazards that cannot be prevented by mechanical means, but only
by the exercise of intelligence, care, and common sense. It is essential to have personnel involved in the use and operation of the device
who are careful, competent, trained, and qualified in the safe operation of the device and its proper use when servicing motor vehicles
and their components. Examples of hazards are dropping, tipping or slipping of loads caused primarily by improperly securing loads,
overloading, off-centered loads, use on other than hard level surfaces, and using equipment for a purpose for which it was not intended.
METHODS TO AVOID HAZARDOUS SITUATIONS
• Read, study, understand and follow all instructions before operating this device.
• Inspect the jack before each use. Do not use jack if damaged, altered, modified, in poor condition, leaking hydraulic fluid, or
unstable due to loose or missing components. Make corrections before using.
• Lift only on areas of the vehicle as specified by the vehicle manufacturer.
• User and bystander must wear eye protection that meets ANSI Z87.1 and OSHA standards.
• Do not use jack beyond its rated capacity. Do not shock load.
• THIS IS A LIFTING DEVICE. Immediately after lifting, support the vehicle with jack stands capable of sustaining the load before
working on the vehicle.
• Use only on a hard level surface free from obstructions so the jack is free to reposition itself during lifting and lowering
operations.
• Center load on saddle. Be sure setup is stable before working on vehicle.
• Do not move or dolly the vehicle while on the jack.
• Do not use any materials that may serve as risers, spacers or extenders between the stock lifting saddle and the load.
• Do not use any adaptors that replace the stock lifting saddle unless approved or supplied by the jack manufacturer.
• Do not use (or modify) this product for any other purpose than that for which it was designed without consulting the
manufacturer's authorized representative.
• Always lower the jack slowly and carefully.
• Failure to heed these warnings may result in fatal personal injury and/or property damage.
CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS
Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS,
MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS
could cause accidents resulting in serious or fatal personal injury and/or property damage.
WARNING: Indicates a hazardous situation
which, if not avoided, could result in death
or serious injury.
WARNING
WARNING
WARNING
WARNING
WARNING: This product can expose you to chemicals including nickel, which is known to the State of California to
cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

XL2TB User Manual 2 REV: 11/27/19
INSPECTION
Visual inspection should be made before each use of the jack, checking for leaking hydraulic uid and damaged, loose or missing parts. Any
jack which appears to be damaged in any way, is found to be badly worn, or operates abnormally MUST BE REMOVED FROM SERVICE
until necessary repairs are made.
SETUP
1. Depress the upper handle lock in the upper handle while simultaneously inserting the end of the upper handle in the lower handle.
Rotate the upper handle back and forth until the handle lock seats in the hole in the lower handle lock hole.
2. Unscrew the handle bolt so that it will not interfere with the insertion of the handle in the handle socket. Insert the handle in the handle
socket and rotate the handle assembly back and forth until the release valve ts in the receiver in the bottom of the handle. Secure the
handle in the handle socket by tightening the handle bolt.
3. Sometime air gets trapped in the hydraulic system during shipping and handling. If the pump feels spongy, or there is not a full
incremental pump stroke, or the jack will not raise to maximum height, follow these instructions in order to purge air from the system:
a. With the lift arm in its completely retracted position and the pump handle rotated all the way in a clockwise direction until it stops,
rotate the pump handle in a counterclockwise direction two full revolutions.
b. Proceed to pump the jack 15 full incremental pump strokes.
c. Rotate the pump handle clockwise until it stops and proceed to pump the handle until the lift arm reaches maximum height.
d. Repeat steps "A" through "C" until all air is purged from the system.
Handle Socket
Bolt
Handle
Socket
Front
Wheels
Upper
Handle
Lower
Handle
Lower
Handle
Bumper
Upper
Handle
Lock
Rear
Casters
Handle
Socket
Saddle
Lift
Arm

XL2TB User Manual 3 REV: 11/27/19
OPERATING INSTRUCTIONS
This is the safety alert symbol used for the OPERATING INSTRUCTIONS section of this manual to alert you to potential personal
injury hazards. Obey all instructions to avoid possible injury or death. IMPORTANT: Before attempting to raise any vehicle, check
vehicle service manual for recommended lifting surfaces.
OPERATION
1. Put vehicle transmission in park or in gear and then apply the emergency brake.
To raise load: Turn the handle in a clockwise direction until tight. Position the jack under the load. Proceed to pump the handle
in order to raise the lift arm to the load. As the saddle at the end of the lift arm gets closer to the load, reposition the jack so the
saddle will contact the load rmly and the load is centered on the saddle. Make sure the saddle is correctly positioned. Raise the
load to the desired work height. Place jack stands of appropriate capacity at the vehicle manufacturers's recommended support
areas that provide stable support for the raised vehicle. DO NOT CRAWL UNDER VEHICLE WHILE LIFTING VEHICLE OR PLACING
OR REMOVING THE JACK STANDS! Once jack stands are positioned, turn the jack handle VERY SLOWLY in a counterclockwise
direction to lower the load to rest on the jack stands. Inspect the relationship between the jack stands and load to make sure the setup
is stable and safe. If the setup is not stable or safe, follow the preceding steps until corrected.
2. To lower load: Follow the procedures mentioned in "To raise load" section of the OPERATING INSTRUCTIONS in order to raise
the load off the jack stands. Once the load has cleared the jack stands, remove the jack stands from under the load and away from the
work area. DO NOT CRAWL UNDER VEHICLE WHILE LIFTING VEHICLE OR PLACING OR REMOVING THE JACK STANDS! Turn
handle very slowly in a counterclockwise direction until the load is completely lowered to the ground. Once the jack's lifting saddle has
cleared the load, remove the jack from under the load. CAUTION: Keep hands and feet away from the hinge mechanism of the jack.
PREVENTATIVE MAINTENANCE
This is the safety alert symbol used for the PREVENTATIVE MAINTENANCE section of this manual to alert you to potential
personal injury hazards. Obey all instructions to avoid possible injury or death.
1. Always store the jack in a well protected area where it will not be exposed to inclement weather, corrosive vapors, abrasive dust,
or any other harmful elements. The jack must be cleaned of water, snow, sand, grit, oil, grease, or other foreign matter before using.
2. The jack must be lubricated periodically in order to prevent premature wearing of parts. A general purpose grease must be applied to
caster wheels, front axle, elevator arm, handle base pivot bolts, release mechanism and all other bearing surfaces. Worn parts resulting
from inadequate or no lubrication are not eligible for warranty consideration. See page 4 for lubrication instructions.
IMPORTANT: In order to prevent seal damage and jack failure, never use alcohol, hydraulic brake uid, or transmission oil in the
jack. Use hydraulic jack oil, a light turbine oil, Chevron AW ISO 32 or Unocal Unax AW 150.
3. Every jack owner is responsible for keeping the jack labels clean and readable. Use a mild soap solution to wash external
surfaces of the jack but not any moving hydraulic components.
4. Inspect the jack before each use. Do not use the jack if any component is cracked, broken, bent, shows sign of damage or leaks
hydraulic uid. Do not use the jack if it has loose or missing hardware or components, or is modied in any way. Take corrective action
before using the jack again.
PROPER STORAGE
It is recommended that the jack be stored in a dry location with all wheels touching the ground on a relatively level surface.
TROUBLESHOOTING
Important: Service jacks are self-contained devices used for lifting, but not sustaining, a partial vehicular load. In accordance with ASME-
PASE Load Sustaining Test: “A load not less than the rated capacity…shall not lower more than 1/8" (3.18mm) in the rst minute, nor a total
of .1875" (4.76mm) in 10 minutes.” Lowering within this range is considered normal operation and is NOT a warrantable defect.
PROBLEM ACTION
1. Unit will not lift rated load. Purge air from hydraulic system by following procedure under SETUP.
2. Unit will not sustain rated load or feels “spongy” under rated load. Purge air from hydraulic system as above.
3. Unit will not lift to full height. Purge air from hydraulic system as above.
4. Handle tends to raise up while the unit is under rated load. Pump the handle rapidly several times to push oil past ball valves in
power unit.

XL2TB User Manual 4 REV: 11/27/19
#2
#4
#4
#4
#3
#3
#1
#2
#2
#2
HYDRAULIC MAINTENANCE GUIDE
IMPORTANT: Service jacks are designed for lifting purposes only; always support raised load with jack stands.
REGULAR MAINTENANCE
MONTHLY or as necessary (depending on usage)
1. Using a grease gun, add grease to grease tting in the lift arm pivot shaft.
(Use a multi-purpose NLGI type grease only.)
2. Lubricate all linkages and pivot points.
(Use white lithium spray grease only.)
3. Remove handle; lubricate handle receptacle and handle end.
(Use white lithium spray grease only.)
4. Lubricate both rear casters bearings and both front wheels.
(Use white lithium spray grease only.)
Tighten all accessible hardware.

XL2TB User Manual 5 REV: 11/27/19
8
11
9
10
14
15
1
2
3
4
6
7
36
39
40
31 30
28
29 27
33
5
32
16
17
37
38
34
35
12
20
18
21
22
19
41
24
26
25
13
PARTS LIST AND DIAGRAM
Item No. Part No. Description QTY Item No. Part No. Description QTY
1 RS660205 Star Retaining Clip 2 22 Roller Shaft 1
2 RS35T02 Washer(20) 2 24 Handle lever “A ” 1
3 RS6602LP03 Front Wheel 2 25 Handle lever “B ” 1
4 Frame 1 26 RS660209 Handle Spring button 1
5 Retaining Ring(25) 2 27 RS6602LP27 Hydraulic Unit 1
6 RS6602LP06 Nut(M16) 4 28 RS6602LP28 Spring 2
7 Washer(16) 4 29 RS6602LP29 Hydraulic Unit Adaptor 1
8 Screw(M5X12) 4 30 Retaining Ring(22) 2
9 RS660206 Rear Caster 2 31 Pin(A4X55) 1
10 Screw(M10X25) 4 32 Lift Arm Shaft 1
11 Washer(10) 4 33 RS6602LP33 Zerk 1
12 RS6602LP41 Universal rotating
device
1 34 Lift Arm 1
13 RS660207 Saddle pad 1 35 Bolt 2
14 RS660208 Bolt 2 36 Cover Plate 1
15 Washer(20) 2 37 RS6602LP37 Retaining Ring(14) 2
16 Nut(M8X20) 4 38 Radius Linkage 2
17 Washer(8) 5 39 RS6602LP39 Saddle 1
18 Set Screw Handle 1 40 RS6602LP40 Saddle Screw 1
19 RS6602LP19 Handle Socket 1 41 RS660210 Handle Bumper 1
20 Retaining Ring(12) 1 RSXL2TBPLK Product Label Kit 1
21 Roller 1

XL2TB User Manual 6 REV: 11/27/19
SPECIFICATIONS
Capacity 2 Tons
Minimum Lift Height in. 2.76"
Maximum Lift Height in. 24.02"
Rear Caster Size in. 2.56 x 1.2"
Front Wheel Size in. 2.36 x 2"
Saddle Diameter in. 3.86"
Handle Length in. 45.28"
Product Length in. 34.45"
Product Width in. 14.17"
Product Height in. 6.30"
Product Weight lbs. 92.59 lbs.
Shipping Weight lbs. 97.00 lbs.
LIMITED WARRANTY
ARCAN® PROFESSIONAL TOOLS WARRANTS TO ITS CUSTOMERS THAT THE COMPANY’S ARCAN® PROFESSIONAL
TOOLS BRANDED PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS.
Arcan® Professional Tools will repair or replace its Arcan® Professional Tools branded products which fail to give satisfactory service
due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed
to that specific product. This product carries a ONE-YEAR warranty. During this warranty period, Arcan® Professional Tools will repair
or replace at our option any part or unit which proves to be defective in material or workmanship.
Other important warranty information:
This warranty does not cover damage to equipment or tools arising from alteration, abuse, misuse, damage and does not cover any
repairs or replacement made by anyone other than Arcan® Professional Tools. The foregoing obligation is Arcan® Professional Tools’
sole liability under this or any implied warranty and under no circumstances shall we be liable for any incidental or consequential
damages.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. If you have any questions about warranty service, please contact Arcan® Professional Tools.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
1-800-879-7316
Monday - Friday 9am to 5pm EST
P.O. Box 1203
Travelers Rest, South Carolina 29690
