arcelik STO 812 User manual

185241252
Table top cooker
STO 812 - STO 812 E

Please read this manual first.
Dear Customer,
We would like you to obtain best performance with your product that has been
manufactured in modern facilities and passed through strict uality control
procedures.
Therefore, we advise you to read through this User Manual carefully before using
your product and keep it for future reference. If you hand over the product to
someone else, deliver the User Manual as well.
The User Manual ill help you use the product in a fast and safe ay.
•Read the User Manual before installing and operating the product.
•You must strictly observe the safety instructions.
•Keep this User Manual within easy reach for future reference.
•Also read other documents supplied with the product.
Remember that this User Manual may also be applicable for several other
models.
Differences between models are explicitly identified in the manual.
Explanation of symbols
Throughout this User Manual the following symbols are used:
Important information or useful hints about usage.
Warning for hazardous situations with regard to life and property.
Warning for electric shock.
Warning for risk of fire.
Warning for hot surfaces.

3 | EN
Table of Contents
1 General information ............... 4
Overview ............................................... 4
Technical specifications ....................... 5
Accessories supplied with the unit ....... 5
2 Safety instructions ................. 6
Explanation of safety instructions ........ 6
General safety ....................................... 6
Safety for children .............................. 7
Safety when working with gas ........... 7
Intended use ......................................... 8
Disposal ................................................ 8
Disposing of packaging material ....... 8
Disposing of the old product ............. 8
Future Transportation ........................ 9
3 Installation ............................ 10
Before installation ............................... 10
Installation and connection ................. 10
4 Preparation ........................... 13
Tips for saving energy ......................... 13
Initial operation ................................... 13
First cleaning of the appliance ........ 13
5 Ho to use the hob .............. 14
General information about cooking .... 14
Using the hobs .................................... 14
6 Maintenance and care ......... 16
General information ............................ 16
Cleaning the hob ................................. 16
7 Troubleshooting ................... 17

4 | EN
1 General information
Overvie
1
Pan support
2
Spark plug
3
Normal burner
4
Rapid burner
5
Frame
6
Burners' plate
7
Gas burner's knob
8
Auxiliary burner
1
Auxiliary burner Front right
2
Rapid burner Front left
3
Normal burner Rear left
4
Normal burner Rear right

5 | EN
Technical specifications
External dimensions (height / width / depth)
87
mm/580
mm/510
mm
Voltage / fre uency
220
-
240 V ~ 50
Hz
Cable type / section
H05RR
-
FG
3 x 0,75
mm
2
Cable length
max. 2 m
Category of gas product
II
2H 3B/P
Gas type / pressure
LPG G
30/30
mbar
Total gas consumption
7.9 kW
Converting the gas type / pressure
§
NG G
20/20
mbar
–
optional
Burners
Front right
Auxiliary burner
Power
1000
W
Front left
Rapid burner
Power
2900
W
Rear left
Normal burner
Power
2000
W
Rear right
Normal burner
Power
2000
W
Technical specifications may be
changed without prior notice to
improve the uality of the
product.
Figures in this manual are
schematic and may not exactly
match your product.
Values stated on the product
labels or in the documentation
accompanying it are obtained in
laboratory conditions in
accordance with relevant
standards. Depending on
operational and environmental
conditions of the product, these
values may vary.
Accessories supplied ith the
unit
Accessories supplied can vary
depending on the product model.
All the accessories described in
the user manual may not exist on
your product.
Coffee pot adaptor
Can be used for a coffee pot.
